United Colors of Benetton Bambini Pallino User manual

pallino
BAMBINI COLLECTION

Thank you for purchasing a product from the United Colors of Benetton Bambini
collection. The UCB Bambini collection is innovative, the design a mix of colour and detail.
This collection is for the fashion conscious parent. Parents who enjoy the spirit of colour
and the United Colors of Benetton style. The Bambini Collection will show the world how
colourful life is with kids!
Produced and distributed under license for Bencom s.r.l. by Born with Style www.bornwithstyle.com.au
BAMBINI COLLECTION

IMPORTANT SAFETY INFORMATION
2
• Never leave your child unattended while in stroller.
• To prevent choking hazard, remove and discard all
packing material before using this product.
• Always use restraint system to keep child from
standing up or falling out of the stroller. Use the
harness at all times.
• Always balance the weight of the stroller evenly.
• Always lock the stroller open before allowing your
child in or near the stroller.
• Only use this stroller with a child weighing less
than 20 kg.
• Put on all brakes whenever you park the stroller.
• Never use this stroller on stairways or escalators.
• Do not allow children to stand on seat or sit on
footrest.
• This is not an exercise stroller. Do not
use product while running, jogging or
participating in other athletic activities.
• Do not put child in basket.
• Do not carry extra children or use
accessories other than those approved
by the manufacturer.
• The stroller should not be used near an
open fire or exposed flame.
• Make sure children are clear of any moving
parts if you adjust the stroller, otherwise
they may be injured.
• Do not put more than 4 kg in the basket.
Please take a moment to read through these instructions
before you use your United Colors of Benetton Stroller.

STROLLER PARTS
Rear Wheels (2)
3
Footmuff RaincoverHeadhugger
Stroller Frame Bumper bar Padded Shoulder Straps
Canopy
Bassinet skirt Canopy skirt
Wrist Strap

OPENING THE STROLLER
1
2
Remove any cardboard inserts or plastic ties
used to protect the product during shipment.
3
Pull up simultaneously on the
two triggers located on the
stroller handles as shown.
Pull up on the handles to
begin opening the stroller.
4
4Push down on the foot lever
ensuring that the frame clicks
into place.

ASSEMBLING THE REAR WHEELS
2 3
1Remove and discard protective plastic
sleeve from ends of rear axle assembly.
Position rear wheel on leg of
stroller, and push until spring
loaded buttons click into place
as shown.
Repeat for second side.
NOTE: If rear wheel
assemblies do not click
and hold in place. The
spring button is stuck and
not protruding through
the hole in the tube. Use
a screwdriver or pliers to
move the button so that
it protrudes out of the
hole in the tube.
TO REMOVE REAR
BRAKE ASSEMBLY:
Push in spring buttons on
either side of the brake
assembly and pull off.
5

ATTACH BUMPER BAR:
Slot the two clips on both ends
of the bumper bar into the holes
in the frame.
ATTACHING/REMOVING THE BUMPER BAR
1 2 REMOVE BUMPER BAR: Press button in
(located underneath the frame) and pull
the bumper bar off. Repeat for second
side.
6

ATTACHING/REMOVING THE CANOPY
1 2
Align canopy hook with the
stroller frame as shown.
Push down until the hook clicks
into place. Repeat for second
side.
7

Place the footmuff over the
seat of the stroller with the
bottom of the footmuff sitting
underneath the leg rest.
ATTACHING THE FOOT MUFF
1 2 Pull the top panel over the
bumper bar and attach toggles
to the elastic. Clip the press
studs together at the sides of
the stroller.
8

ADJUSTING THE LEG REST
1 2
Push down release buttons
located on both sides of the leg
rest simultaneously.
Pull up the leg rest until it clicks into
place. TO LOWER LEG REST: Push
down on the release buttons and pull
the leg rest down.
9

USING THE SAFETY HARNESS
To lock harness push the two ends
of the straps into the buckle. Be
sure both ends are fully inserted.
To unlock harness press the tabs
together and then slide them from
the buckle.
1
2 3 4
Lock foot brake.
Place child in stroller.
Hook shoulder straps
to waist belt.
For proper fit, adjust
shoulder straps and
waist band as shown.
10

ADJUSTING THE SHOULDER STRAPS
Hook the shoulder straps
to waist belt. Repeat for
second strap.
1 2 3
NOTE: For a secure fit, straps should be at or
above the child’s shoulder. Adjust straps to
higher position as your child grows.
Un-hook shoulder strap
from waist belt as shown.
Pull shoulder strap
through the webbing as
shown.
11

1RAISE SEAT: Push backrest
in an upward direction
until it clicks into place.
3
ADJUSTING THE BACKREST
12
RECLINE SEAT: Pull leaver
up and pull the seat back.
Adjust seat to desired
position.
2
WARNING: To avoid finger entrapment or
pinching, take care adjusting the seat back while
child is in the stroller. To avoid head entrapment,
always fasten the canopy to the seat back at all
times.

RAISE SEAT: Push backrest
in an upward direction
until it clicks into place.
12
OPERATING THE BRAKES
13
TO UNLOCK BRAKE:
Lift up on the brake pedal
until it is released.
TO LOCK BRAKE: Push down on the
brake pedal until it clicks into place.

OPERATING FRONT SWIVEL WHEEL LOCK
14
1 2
NOTE: On rough surfaces,lock the wheel
to keep straight. On smooth surfaces,
unlock to allow the wheel to swivel.
TO LOCK FRONT SWIVEL: Adjust
front wheel so that the wheel sits
underneath the stroller. Push down
on the lock until it clicks into place.
Repeat for the second front wheel.
TO UNLOCK FRONT SWIVEL:
Push lock up, this will allow the
wheel to swivel. Repeat for the
second front wheel.

Stroller will automatically
lock folded, ensure stroller
is locked on both sides as
shown.
23 4
FOLDING THE STROLLER
15
To fold the stroller remember to
lock the brakes, raise the seat, close
the canopy and lower the leg rest.
Pull up simultaneously on
the two triggers located
on the stroller handles as
shown and push down on
handles.
Pull up on the handle
located on the back
of the stroller as shown
until stroller is folded.
1

16
CONVERTING THE STROLLER TO A BASSINET
Unbuckle harness, remove padded
shoulder straps and head hugger.
1
Lift the footrest up to its
furtherest point.
23 4
Release the velcro on the
canopy and then unzip
the skirt off the canopy.
Tilt the canopy over
so that it sits on the
bumper bar and unclip
hidden section of canopy.

17
Lift the footrest up to its
furtherest point.
Adjust canopy to desired position.
Pull the harness webbing through
to the back of the stroller.
There are hidden pockets in the
sides and crutch section. The
shoulder harness should be pulled
through the back of the stroller
and placed in basket until the
stroller is used in a forward
facing fashion.
Slip footmuff over the exposed
edge of seat for added protection.
56
7
Zip bassinet skirt (different
piece) onto the canopy and
pull the elastic edges over
the stroller footrest adjustors.
Recline the seat making
sure that it reclines to
the furtherest point.
8

There are many ways to look after and
protect your United Colors of Benetton
stroller. The most important is to clean up
any spills or food, before it dries on the
fabric.
As the covers are not designed to be easily
taken off for washing, (for safety reasons)
the easiest method to clean is, sponge the
surfaces with a mild solution of warm water
liquid laundry detergent. Rinse well with
clean sponge and leave to dry out of direct
sun.
Sand and salt water should be rinsed with
a hose and wiped dry to prolong the life of
the wheels, axles and other moving parts.
Never use petroleum based lubricants on
your stroller, the most suitable lubricants
are silicone based products.
CARE AND MAINTENANCE
18
