UNITED IT-8565 User manual

OWNER’S MANUAL
IT-8565

MOSQUITOTRAP
IMPORTANT SAFETY INSTRUCTIONS:
Retain Instructions: The safety and operating instructions should be retained for future
Reference.
Heed Warnings: All warnings on the appliance and in the operating instructions should
be adhered to.
Water & Moisture: The appliance should not be used near water, for example over pond,
bath tubs, kitchen sinks or above a swimming pool.
Do Not Modify: Do not modify, paint or change the unit in any way.
Young Children / Infirm Persons: This appliance is not intended for use by young children
or infirm persons unless they have been adequately supervised by a responsible person
to ensure that they can use the appliance safely.
Young Children: Young children should be supervised to ensure they do not play with
the appliance.
Heat: The appliance should be situated away from heat sources such as radiators, stoves
and other appliances that produce heat.
Power Source: The appliance should be powered only as described in these instructions
or as marked on the appliance.
Cleaning: The appliance should be cleaned only as recommended in these instructions
and in accordance with the water and moisture warning stated in this manual
Liquid Entry: Do not submerge in water
Object Entry: Do not place any object through any of the openings in the Mosquito Trap
Extension Cord: If required carry out a physical safety check of extension cord before use.
Check for cuts or damage, kinks / twisting, exposed wires, damaged plugs (bent or loose
pins). Avoid improper use of extension cords and keep them away from moisture.
Damage Requiring Service: The appliance should be serviced by a qualified Service
Technician when:
i. Heavy objects have fallen on the appliance
ii. The appliance has been dropped or the body of the product has been damaged
iii. The appliance does not appear to operate normally or exhibits a marked change
in performance
iv. Supply cord is damaged
Service: The user should not attempt to service the appliance beyond that described in
these operating instructions. All other servicing should be referred to a qualified Service
Technician; failure to do so will void the warranty.
Owner’s Manual
1 6
SPECIFICATION:
MODEL IT-8565
POWER 230V / 25W
FAN SPEED 2,200 RPM
WEIGHT 2.3 kg
NET WEIGHT 2.0 kg
DIMENSIONS (mm) 250 x 250 x 350
Recycling Notice
Your product is designed and manufactured with high quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end-of-life,
should be disposed of separately from your household waste.
Please dispose of this equipment at your local community waste
collection/recycling centre. In the European Union there are separate collection
systems for used electrical and electronic products.
Please help us to conserve the environment we live in!
Declaration of CE Conformity
This product complies with the requirement of below directives:
EMC Directive: 2004 / 108 / EC
Low Voltage Directive (LVD): 2006 / 95 / EC
Restriction of Hazardous Substance (RoHS) Directive: 2002/95/EC
The above directives, declare that the electric insect killer is in compliance with
following standards:
EN55014-1:2006
EN61000-3-2:2006
EN61000-3-3:2008
EN55014-2:1997+A2:2008
EN60335-1:2006
EN60335-2-59:2006
EN50366:2003+A1:2006
EPA3050B:1996
EN1122:2001
EPA3052:1996, EPA3060A, EPA7196, EPA3540C & EPA8270C
EXCLUSIVE IMPORTER IN GREECE: Amiridis-Savidis S.A.
33, Vas. Olgas Street – P.C. 54641 – Thessaloniki, Greece
Tel: [phone], Fax: [phone]
45 Posidonos St. – P.C. 18344 – Moschato, Athens, Greece
Tel: [phone], Fax: [phone]
www.amiridis-savvidis.gr

MOSQUITOTRAP
2
Owner’s Manual
WELCOME:
Thank you for purchasing the UNITED IT-8565 Mosquito trap.
IN THE BOX
IT-8565 MOSQUITO TRAP • Escape free collector •
Hook • Owner’s Manual
OWNER’S MANUAL:
This manual will provide you with directions for the safe and efficient operation of
your IT-8565. Please read the manual carefully and keep it in a safe place for
future reference. Failure to operate the IT-8565 in accordance with the instructions
in this manual may cause damage to the unit.
HOW DOES IT WORK?
TheIT-8565 does not involve fogging, pesticides, repellents, citronella, coils or
candles. These products do involve the use of dangerous chemicals known to be
harmful to both humans and the environment.
The UNITED IT-8565 Mosquito trap uses a combination of Octenol, special
spectrum UV light and heat that all are produced by humans or animals. This unit
uses the most environmental friendly methods in the market today and is safe for
you and the environment.
Female biting insects require blood to nourish their eggs. They get that blood from
you, your family, your pets and your friends. They track down hosts by sensing the
carbon dioxide, Octenol moisture and heat from breath, body odors and color
contrasts. The UNITED IT-8565 mosquito trap, creates a combination of those cues.
This tricks the insects into thinking the trap is a host. Once the pests are attracted to
the exterminator, they are sucked into an enclosure by a powerful vacuum fan. Once
trapped, they quickly dehydrate and die.
WHAT TO EXPECT:
While the IT-8565 will begin to catch immediately if there is any mosquito activity
in the vicinity, it may take 6 to 8 weeks of use to reduce local populations to the
point that breeding cycles are interrupted. You may choose to discontinue use of the
trap at this point but subsequent re-infestations will occur after rain.
UV BLACK LIGHT LAMP:
The UV Black Light Lamp is long wave and therefore safe. The output / intensity of
the lamp reduce with use. To maintain maximum attraction of flying insects replace
every 24 months.
MAINTENANCE:
REPLACING UV LAMP (TURN OFF POWER)
Using Phillips head
screwdriver remove
the 4 screws
Disconnect the
fan/switch
connector
Disconnect the UV
lamp
TROUBLE SHOOTING:
Problem Possible Reason (s) Correction
UV Lamp does not
light Unit not plugged into live power point Check if fan is working and if not check power point, lead and plug
Lamp has burned out Call for replacement
Lamp is not seated
correctly in lamp holders Check seating refer to Lamp Service (above)
Ballast may have failed Call Service Department
Fan is not working
Unit not plugged into live power point Check if Lamp is working and if not check power point, lead and
plug
Fan has failed Call Service Department
Fan is making noise Catch container is
clogged or fan is clogged See Maintenance section of this manual
Trap is operating but
not catching
mosquitoes
Incorrect positioning Move to other locations
for 1 week in each position
Check Trap is no more than 40 to
60 cm from ground
Check Trap is located in position
with no wind, protected from
direct sunlight and rain.
Check Trap is located close to
bushes, shrubs, ponds, garden
beds
Disconnect the 4
lamp holders
(grasp and turn
gently inwards)
Snap off the
tube holders and
attach new lamp
2
5

MOSQUITOTRAP
OPERATION:
POSITIONING OF THE IT-8565 MOSQUITO TRAP
i. First determine the source of the mosquito nuisance: Mosquitoes breed in
wet areas such garden beds, ponds, tress / shrubs, wooded areas, streams,
and marshland
ii. Place the Trap between the mosquito sources and areas of human activity. As
far away from people and as close to the mosquito source as possible.
Attention: Do not place the trap close to people as it attracts, not repels
mosquitoes.
iii. Place the Trap in a location protected from rain and strong wind; if possible
upwind of the mosquitoes.
iv. Place the Trap in a predominantly shaded area. (It is very important to avoid
direct sunlight) hang it close to the ground, not higher than 40 – 60 cm. The
trap can be used indoors, but we then strongly recommend not using the
Attractant for indoors as it will attract mosquitoes from the outside.
MAINTENANCE:
WARNING:
Disconnect the power cord when handling the trap
Never submerge or expose the trap to water
Do not use if cords, transformers and electric connectors are damaged
Always position the trap away from wind, direct sunlight and rain
Keep fingers away from the fan
CLEAN CATCH CONTAINER:
Empty the catch container when needed or at least once a week. The container will
be found inside the trap.
i. Turn off the power
ii. Turn IT-8565 so underside is facing upwards
iii. Take hold of the catch container where it attaches to the Trap
iv. Turn the catch container counter clockwise to release
v. Empty the contents
vi. The mesh net must be clean to maintain properly airflow.
vii. Replace the catch container by turning clockwise
viii. Turn on the power
IF FAN BECOMES CLOGGED:
i. Turn off the power
ii. Remove catch container, see instruction above.
iii. Use a small brush and a small amount of soap water to clean the fan blades
iv. Replace catch tray, see instructions above
v. Turn on power
ATTACHING NET / CATCH CONTAINER:
Owner’s Manual
A = mosquito breeding area
B = wind direction
C = 10 m from Trap to human activity
D = position of Mosquito Trap
E = Mosquitos lure range
F = UV light range 360°
G = house / patio / occupied area
Quick lock adapter, note
position of the bayonet
fittings
Attach catch net to
quick lock adapter Push quick lock adapter
towards fan ring and turn
clockwise
3 4
