Universal Remote Control Complete Control KP-900 User manual

COMPLETE
CONTROL
COMPLETE
500 Mamaroneck Avenue, Harrison, NY 10528 Phone:[phone] Fax: [phone]
www.universalremote.com
COMPLETE ™
CONTROL
COMPLETE
Specifications
Memory: 4 Megabits of Flash Memory
(for User Configuration)
Devices: Flexible, typically can support up to 255
Pages: Flexible,typically can support up to 255
Pages on each Device
Learning Capability: Standard frequencies
(15kHz to 460kHz)
Macro Capability: Up to 255 steps each, however
nesting is allowed,thus real macro length is
unlimited.
Backlighting: Blue for all buttons, 255 color
backlighting for the LCD
IR Range (line of sight via infrared): 30-50 feet,
depending on the environment
RF Range (radio frequency): 50 to 100 feet,
depending upon the environment
RF Frequency: 418MHz
Weight: 8 ounces (with batteries)
Size (KP-900 only): 4-3/4”H x 5-7/16”W x 5/8”D
Size (KP-900 with the wall bracket):
5-1/16”H x 6-1/8”W x 13/16”D
Batteries: 4AAA batteries
Add a Keypad Anywhere!
It’s a Remote ControlWhere andWhenYou Need It Most
The Pioneer in ControlTechnology
The Pioneer in ControlTechnology
White
Light Almond
Black
Lounging in the Solarium.
No wiring so there are no holes needed. In the bath for a relaxing soak.
Tunes in the kitchen.
KP-900 Wireless
Keypad/Remote
Wall Mounted Keypad and
Hand-Held Remote Control
Mounts Anywhere, Everywhere
No wires to pull—the IR/RF KP-900 Keypad Remote is
completely wireless. Powered by four easy-to-replace AAA
batteries, it can be easily removed from the wall bracket
for convenient handheld use.The keypad can be mounted
on any surface—brick, sheetrock or plaster—using the
included four small screws.And the built-in magnets allow
it to stick to metal surfaces—even most refrigerators. It
features backlit, laser etched buttons
and a bright backlit LCD for
easy text-based control.
Available in
Three Color
Options
KP-900 and Mounting Plate shown
above are actual size.

Three Sets of Keys Enable
Customized Installation
Each KP-900 includes 3 different sets button options.
Options for the Volume and Mute
Buttons for Systems with In-Wall
Volume Controls
The KP-900 is equipped with options for theVolume/Mute
positions. In systems with in-wall volume controls that really
have no remote controlled volume and mute,you can opt to
install one of the other choices.To install buttons:
1.Place the button over the desired spot.
2.Push the button into place.The button snaps into place.
Note:Buttons are not designed to be removed once installed.
Your Walls are Sealed Up
You don’t want the expense or inconvenience of construction
or running wires through your walls.Adding a wireless KP-900
solves this problem and provides better control everywhere you
need it.
OneTouch Multi-Colored
Backlighting
Press any button to backlight the screen and the hard buttons.
UpgradeYour System
Adding a KP-900 enables you to operate your HomeTheater
from any room in your house,even outdoors.You can: turn the
system ON/OFF;select what you listen want to (or watch);
change songs, CDs, channels;control the volume;
and much more!
Leverage What You Already Own
Second zone outputs are readily controlled with the KP-900.It’s
like adding new system in another room.
Integrated Sound Signaling
The KP-900 incorporates a small speaker for beeps.Anytime
you press a button,the KP-900 signals that it has understood
your command with a beep sound.
Windows Based PC Software
The KP-900 Editor is completely text based, a custom
configuration for the most demanding client can be set up
in a fraction of the time it takes with many other remotes.
The KP-900 Mounts Anywhere
The mounting plate encloses the keypad.The keypad is
removed from the mounting plate by lifting it out. Keypad is
magnetic and locks to metal inserts inside the bracket.The
keypad can mount to any surface,even most refrigerators and
easily removes from mount for hand-held use.
KP-900 Narrow Band RF
and MSC-400 Compatible
Any audio video system, by its very nature, includes components
with high speed microprocessors which produce wide band
localized RF interference.The combination of the KP-900 Narrow
Band RF Transmitters with the RFX-250 provides ultra reliable
RF via the extraordinarily specific narrow band reception of the
RFX-250.
The RFX-250 is included with both the MRF-350 Routing Base
Station and the MSC-400 Master System Controller.
The KP-900 is compatible with the new MSC-400 “Trigger”
protocol,which enables complex macros,stored in the MSC-400 to
be individually triggered with a single button push on the KP-900
regardless of the interference and noise in the environment.
The combination of very narrow
transmission of digitally encoded
packets sentTHREE times at digital
speeds in milliseconds, assures that
everybutton press onthe remote will
be received by the MSC-400.
The MSC-400’s sophisticated error
correction circuitry stores all three
packets and compares them. Once two packets are identified as
identical,the MSC-400 goes to work.
This new technology not only increases range, but increases
reliability by a vast margin.The KP-900 is equipped with both the
new Narrow Band Transmitters and the new RF Protocol for the
MSC-400.
Narrow Band
RF Transmission
RFX-250 Narrow Band RF
Receiver (Included with
the MRF-350 and MSC-400
System)
COMPLETE ™
CONTROL
COMPLETE
An ElegantWay to EnhanceYour System
Volume Control
MSC-400 Master System Controller
Blank
Transport
