INSTRUCTION SHEET
758-690 Zephyr Bar Cabinet
Thank you for purchasing this quality pro uct. Be sure to check all packing material carefully for small
parts that may have come loose insi e the carton uring shipment.
Caution: (1) These parts are cumbersome an heavy. This pro uct can best be assemble with the
assistance of one or more persons in or er to prevent personal injury an to insure parts are not amage
uring the assembly process. If irty, clean finishe parts with mil ishwashing liqui an water solution
applie on amp cloth. Cloth shoul not be excessively wet. Polish finish with soft cloth an an in ustry
recognize furniture polish.
(2) To prevent amage to your floor or carpet, please check the bottom of each piece of furniture for
stain resi ue an rough surfaces an also check for staples or nails left after removing the packaging material.
The manufacturer will not be hel responsible if preventative steps are not taken prior to installation.
(3) Unpack an ispose of all packing material but be careful not to throw away any assembly parts or
har ware. Rea the instruction sheet an parts list carefully. Remove all staples an screws use for
packaging carefully using pliers an or screw rivers to prevent injury an scratching or amaging flooring.
(4) During normal use every ay, screws, bolts, nuts an woo en plugs may loosen up. They shoul be
perio ically inspecte an re-tightene to prevent amage to the furniture an (or) personal property or cause
injury. Always check to be sure all har ware on this list an the above mentione components is attache to
the furniture properly an kept tightene at all times.
PARTS LIST:
#
Description
Qty.
#
D
escription
Qty.
A
Cabinet Top 1pc Bottom Panel 1pc
C
Leg 4pcs
D
Shelf 1pc
E
Har ware Pack 1bag
Assembly Proce ure : (Please follow the sketches below.)
Step 1: Unpack, inspect, an rea assembly instruction carefully. Lay out the parts an har ware.
Make sure the quantity of each is correct.
Step 2: Put all the parts on a soft an smooth surface to avoi amage or being scratche . Attach
the legs (C) to the bottom panel (B) an table top (A) with phillip hea bolt (1), spring
washers (2) an flat washers (3) using wrench (4). Tighten all the bolts an turn it upright.
An put the shelf (D) in place with shelf pin (5).
Assembly is now complete.
Step 2
4
1
23
4
1
2
3
5
A
C
B
D

INSTRUCTION SHEET
758-690 Zephyr Bar Cabinet
WRENCH
FLAT WAHSER
SPRING WASHER
PHILLIP HEAD BOLT
5/16"*13*2mm
1PC
12PCS
12mm
5/16"*19*2mm
5/16"*2-1/4"
12PCS
12PCS
4
3
2
Q'TY
1
HARDWARE LIST(E)
SHELF PIN
5
4PCS
