Unox LineMicro XAF series User manual

English
LineMicro™
Contents
Explanation of pictograms 2
Contents 3
Introduction 4
INSTRUCTIONS FOR THE USER
- Safety regulations 5-7
Appliance use instructions and Guarantee 8
Manual Control 9
INSTRUCTIONS FOR THE INSTALLER
- Safety regulations 10
Installing the appliance 11
Electrical connections 12-13
Oven cavity smoke exhaust 14
Certication 15
3

English
8
Appliance instructions
Do not place heat source (e.g. grilles, fryers, etc.) near the oven.
The heating system and the fan automatically switch o when opening the oven cavity door
(only for the "Domenica" model). The built-in fan disengage mechanism is triggered. The fan
continues to spin briey.
If the appliance was left running for more than 15 minutes without selecting an operating
mode, stand-by is automatically engaged for energy savings. To exit stand-by mode simply
touch the START/STOP button for at least 3 seconds.
If the oven undergoes lengthy stand-by (e.g. during the night), leave the oven cavity door
slightly ajar.
If the oven is inactive for lengthy periods (e.g. non-business days), take the appliance power
o line.
The oven must not be disposed of as domestic waste or placed in the used appliance bins of
municipal waste collection centres when the oven has reached its end of life.
We are glad to help you properly dispose of the appliance.
Guarantee
Installation of the UNOX product must be performed by an Authorized UNOX Assistance Ser-
vice. The installation date and appliance model must be documented by the end purchaser,
by means of written conrmation or an installation invoice issued by the dealer or the Author-
ised UNOX Customer Assistance Service, otherwise this guarantee will not be valid;
The UNOX guarantee covers all malfunctions objectively linked to production defects. The
guarantee excludes damage due to transport, poor product storage or maintenance or incor-
rect product use. Also excluded is damage due to installation not conform to the technical
specications provided by Unox and linked to the environment of use, such as, for example,
unclean and aggressive water supply, low quality gas supply, or electrical supply failing to
respect nominal voltage and power ratings. The guarantee also excludes any damage due to
power surges or tampering by unauthorized or incompetent persons. The guarantee is also
invalidated for damage to the appliance by lime scale deposits. In addition, the guarantee
does not cover consumables, such as: seals, light bulbs, glass panels, decorative parts and
parts consumed during use.
Guarantee rights will also be invalidated in the event of damage arising as a result of incor-
rect installation, or installation which has not been carried out by an Authorised Customer
Assistance Service.

English
LineMicro™
9
Setting the cooking duration
The cooking duration can be set by using the dial (dial on the left): the time can be set any-
where from 0 to 60 minutes.
Turning the dial clockwise sets cooking duration; while turning it counter-clockwise (man-
ual position) sets the oven to continuous mode.
Turning the dial starts the oven and activates fan rotation and any interior lights.
The dial stops on the zero and the oven switches o when the cooking cycle is over.
The oven is o only when the timer dial rests precisely on the zero "0" mark. Wait 5 minutes
before leaving the appliance unattended to ensure proper functioning.
Setting the cooking temperature
The temperature inside the oven cavity can be set by using the temperature dial (dial to
the right):
the temperature can be set anywhere between 0 to 260 °C
(0 - 500 °F).
when on, the green temperature indicator light shows that the resistor is activated, which
switches o as soon as target temperature has been reached.
Manual Control
