Unox MINDMaps CHEFTOP User manual

CHEFTOP MIND.Maps™OVEN
MANAGER MANUAL

2
Index
How to turn on the baking
station
p. 3
How to start abaking program p. 7
How to add/modify programs p. 18
How to add/modify MULI.Time programs p. 22
How to upload firmw are and change date and time p. 28
How to upload USB programs p. 35
How to set up and test network p. 38
How to refill DET&Rinse tank and launch the
automatic washing programs
p. 41
End of the day . actions needed in case of
sheduled automatic washing
p. 53
How to clean the external components of your oven p. 56
MANAGER MANUAL

HOW TO TURN ON THE
BAKING STATION
3

HOW TO TURN ON THE BAKING
STATION
4
Press on the power
button ON/OFF on the
right.
*Be sure that the oven has been connect to
elettrical supply and the socket is turned
on.

After you turn
on the oven,
you need to
wait 15 seconds
to load the
parameters.
HOW TO TURN ON THE BAKING
STATION
5

HOW TO TURN ON THE BAKING
STATION
6
The functions enables access to alist of
recipes selected as “favourites”.
Go back to
main
page
Go back tothe
previous
page
Decrease
values
Increase
values
The button START or
STOP a cooking
cycle

7
HOW TO START A
BAKING PROGRAM

Tap the STAR
button.
HOW TO START ABAKING
PROGRAM
8

Tap the
COOKING
PROGRAM of the
product you want
to bake.
-EMCS
-KKC SIEDES
- BLUEBERRY
BISCUITS
9
HOW TO START ABAKING
PROGRAM

Tap the
START/STOP
button.
10
HOW TO START ABAKING
PROGRAM

The oven will
start the
preheating.
You will see how
long it will take to
preheat and what
temperature you
have in the
cooking
chamber. DO
NOT SKIP THIS
STEP.
10
HOW TO START ABAKING
PROGRAM

The door led light
will flash once
preheating is
completed. The
CHEFTOP will
ring and the icon
will change on
the screen.
11
HOW TO START ABAKING
PROGRAM

Tap the symbol
“+” on
thescreen to
add recipes or
timer.
12
HOW TO START ABAKING
PROGRAM

Select the recipe
you need to
bake
(1) and confirm by
pressing the
“START/STOP”
Button (2).
Press the “V”
arrow to see
more products.
13
2
HOW TO START ABAKING
PROGRAM

Load the oven
with the
products you
want to bake and
DO NOT remove
them until the
baking process
is completed.
You can add up
to 5 different
programs at the
time.
14
HOW TO START ABAKING
PROGRAM

To delete atimer
from the list, tap
the row of the
timer you want
to delete and
hold for at least 3
seconds.
15
HOW TO START ABAKING
PROGRAM

Stop the
cooking cycle
by pressing and
holding the
“START/STOP”
button.
NOTE: stop the
cooking cycle at
the end of your
shift and before
11:45pm.
16
HOW TO START ABAKING
PROGRAM

1
8
HOW TO ADD/MODIFY
PROGRAMS

1. Tap the SET button .
HOW TO ADD
PROGRAMS
2. Set the parameters of
your recipe.
3. Tap the SAVE button.
4. Tap NAME and
PHOTO to assign
them.
5. Assign a recipe name and
confirm with “OK”.
6. Assign a photo to the recipe,
selecting one from those
available.
23

7. Save the baking cycle with
the set parameters, name
and image.
8. Choose the line you prefer.
HOW TO ADD
PROGRAMS
9. The recipe has been saved.
24
