Uplift Desk PDC005-PRV User manual
Panel brackets
(qty 2)
M5x12 machine screw
(qty 4)
Lock washer
(qty 4)
Package Contents
Power & Data Rail: Privacy Panel Brackets
SKU: PDC005-PRV
If assembling at the same time as the Power & Data Rail
Step 1
Place rail cover on top of rail assembly, and connect the Cov-
er to the Rail using two M5x6 machine screws (provided with
Power & Data Rail) in the center holes on either side. Hand
tighten for a few turns - do not fully tighten yet.
Step 2
Place one Panel bracket on each end of the rail cover oriented
as shown. Connect Panel bracket to the Cover and the Rail us-
ing two M5x12 machine screws and two Lock washers on either
side. Hand tighten for a few turns - do not fully tighten yet.
Repeat on the other side with the second Panel bracket.
Once all screws are started, tighten completely using the 3mm
Allen wrench provided with the Power & Data Rail.
Step 3
Slide Privacy panel into both Panel brackets and ensure that it
is centered on the rail.
M3 X 8MM PHILLIPS HEAD SCREW
M3 NYLOCK NUT
M8 FLANG NUT
M8 X 12MM SOCKETHEAD CAP SCREW
Acoustic Privacy Panels
To be used with...
Copyright Notice: These instructions are a component of this accessory. These instructions are part of the scope of delivery, even if the item is resold. These instructions are also available on the UPLIFT Desk website: uplift-
desk.com. Excerpts or copies may not be forwarded to third parties or used in any other published form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
CAUTION: Read all instructions before assembly. Failure to assemble or operate properly may
result in damage or personal injury. Retain manual for future reference.
CAUTIONS & WARNINGS
!
!
AI-PDC005-PRV-2.090.014.01.1106vA
If assembling after the Power & Data Rail is already fully assembled
Step 1
Remove two M5x6 machine screws (provided with Power &
Data Rail) from each end of the Rail cover with the provided
3mm Allen wrench.
Step 2
Place one Panel bracket on each end of the rail cover oriented
as shown. Connect Panel bracket to the Cover and the Rail us-
ing two M5x12 machine screws and two Lock washers on either
side. Hand tighten for a few turns - do not fully tighten yet.
Repeat on the other side with the second Panel bracket.
Once all screws are started, tighten completely using the 3mm
Allen wrench provided with the Power & Data Rail.
Step 3
Slide Privacy panel into both Panel brackets and ensure that it
is centered on the rail.
