Upright SB85J User manual

SB85J
Operator Manual
Jan 08
PN 508381-000

The aerial platform is not electrically insulated. Death or serious injury will result from con-
tact with, or inadequate clearance from, an energized conductor.
Do not go closer than the minimum safe approach distance as defined by the Minimum Safe
Approach Distance section in Chapter 3–Safety.
Regardallconductorsasenergized.
Allowfor electrical wire sag and aerialplatform sway.
If the platform, booms, or any part of the aerial platform contacts a high-voltage electrical conductor,
theentire machine can become electricallycharged.
Ifthathappens,remainonthemachineanddonotcontactanyotherstructureorobject. This includes
the ground, adjacent buildings, poles, and any other objects that are not part of the aerial platform.
Such contact could make your body a conductor to the other object, creating an electrical shock
hazardresulting in death or serious injury.
Ifanaerialplatformis in contact with an energized conductor the platform operator must warn ground
personnelinthevicinitytostayaway.Theirbodiescanconductelectricitycreatinganelectricalshock
hazardresulting in death or serious injury.
Donotapproach or leave the aerial platform until theelectricityhas been turned off.
Do not attempt to operate the lower controls when the platform, booms, or any part of the aerial
platformis in contactwithahigh-voltage electrical conductororifthere is animmediatedangerof such
contact.
Personnelon or near an aerial platformmustbecontinuouslyaware of electrical hazards, recognizing
that death or serious injury can result from contact with an energized conductor.

SB85J Fixed Axle – 0112975
Table of Contents
Chapter 1 – Introduction
AerialPlatform Features.............................................1
Options ......................................................................1
Operator’sManual...................................................... 1
SafetyAlerts ..............................................................1
Operation ...................................................................1
Maintenance ..............................................................2
Ownerand User Responsibilities ................................2
AdditionalInformation .................................................2
Chapter 2 – Specifications
ComponentIdentification ............................................3
WorkingEnvelope ......................................................4
GeneralSpecifications................................................5
Engine Specifications .................................................6
Engine Oil Viscosity...................................................6
Chapter 3 – Safety
ElectrocutionHazards ................................................9
MinimumSafeApproach Distance..............................9
Prestart Inspection ................................................... 10
Work Place Inspection and Practices....................... 10
Operation ................................................................. 10
Tip-OverandFallingHazards.................................... 10
Electrical System..................................................... 11
Hydraulic System..................................................... 11
Engine andFuel HandlingPrecautions ..................... 11
PlacardsandDecals ................................................ 12
Chapter 4 – Safety Devices
EmergencyStop Controls ........................................ 13
EmergencyPowerSystem....................................... 13
EmergencyLowering Knob....................................... 13
GroundOperation Switch ......................................... 14
PlatformFootSwitch................................................ 14
Guardrails ................................................................ 14
LanyardAnchors ...................................................... 14
TiltAlarm.................................................................. 14
PlatformOverload SensingSystem .......................... 14
Engine Protection Systems...................................... 15
HighEngineTemperatureAlarm ............................ 15
LowOilPressureAlarm ........................................ 15
Horn ......................................................................... 15
DriveMotionAlarm ................................................... 16
FlashingLight .......................................................... 16
DrivingLights............................................................ 16
PlatformWork Lights ............................................... 16
Chapter 5 – Gauges and Displays
HourMeter ............................................................... 17
EngineTemperatureGauge ...................................... 17
Ammeter .................................................................. 17
EngineAir Filter Gauge ............................................ 17
Fuel ......................................................................... 17
EngineOil ................................................................ 18
HydraulicFluidFilterGauge ..................................... 18
FluidLevel andTemperature Gauge.......................... 18
Chapter 6 – Controls
Battery Disconnect Switch ....................................... 19
LowerControls ......................................................... 19
Start Switch .......................................................... 19
EmergencyStopButton........................................ 19
ControlsSelectorSwitch ...................................... 20
GroundOperation Switch ...................................... 20
RotationSwitch .................................................... 20
BoomElevationSwitch ......................................... 20
Boom Extension Switch ....................................... 20
BoomSpeed Knob ................................................ 20
JibArticulation Switch........................................... 20
PlatformLevel Switch............................................ 20
PlatformRotateSwitch ......................................... 20
Engine/EmergencyPower Switch ......................... 20
EngineSpeedSwitch ............................................ 20
Fuel Switch........................................................... 20
ManifoldAir Inlet Heater– Deutz Only................... 20
Hydraulic System Warm-up Switch ...................... 21
Circuit Breaker Reset Buttons.................................. 21
UpperControls ......................................................... 21
Start Switch .......................................................... 22
EmergencyStopButton........................................ 22
Drive/BoomSelector Switch.................................. 22
Boom Joystick...................................................... 22
DriveJoystick ....................................................... 22
DriveRangeSwitch............................................... 22
SteerModeSwitch................................................ 23
JibArticulation Switch........................................... 23
PlatformLevel Switch............................................ 23
PlatformRotateSwitch ......................................... 23
Boom Extend/Retract Joystick ............................. 23
Engine/EmergencyPower Switch ......................... 23
ThrottleSwitch...................................................... 23
HornButton .......................................................... 23
PlatformFootSwitch ............................................ 24
Machine/GeneratorSwitch.................................... 24
DualFuel ................................................................. 24
DrivingandPlatform Work Lights.............................. 24

Table of Contents
SB85J Fixed Axle – 0112975
Chapter 7 – Prestart Inspection
Operator’sManual.................................................... 25
Engine ..................................................................... 25
OilLevel................................................................ 25
Coolant ................................................................. 25
Radiator ................................................................ 25
FuelTank.............................................................. 26
FuelLine............................................................... 26
Air Filter................................................................ 26
ChargingSystem .................................................. 26
Cold Weather Start Kit .......................................... 27
Electrical System..................................................... 27
BatteryFluid Level ................................................ 27
BatteryTerminals.................................................. 27
CablesandWiringHarness...................................... 27
Hydraulic System..................................................... 27
FluidLevel ............................................................ 27
FluidFilter ............................................................ 28
Hoses, Tubes, and Fittings ................................... 28
TiresandWheels ..................................................... 28
LowerControl Station ............................................... 28
OperatingControls ................................................ 29
EmergencyStop ................................................... 29
EmergencyPower ................................................ 29
EmergencyLowering................................................ 29
LevelSensor ............................................................ 29
FlashingLight .......................................................... 30
Sandblast Protection Kit .......................................... 30
Structures ................................................................ 30
Weldments ........................................................... 30
Slide Pads............................................................ 30
WireRopes........................................................... 31
Fasteners ............................................................. 31
UpperControl Station ............................................... 31
GuardrailSystem.................................................. 31
LanyardAnchors................................................... 32
OperatingControls ................................................ 32
EmergencyStop ................................................... 32
EmergencyPower ................................................ 32
Horn ..................................................................... 32
ElectricalPower Outlet ......................................... 33
DriveMotionAlarm................................................ 33
Drivingand WorkLights ........................................ 33
PlatformControlCover .......................................... 33
PlacardsandDecals ................................................ 33
PrestartInspectionChecklist ................................... 39
Chapter 8 – Operation
ColdWeatherStart-Up ............................................. 41
Engine Cold Weather Start Kit.................................. 41
Cummins — Block Heater .................................... 41
Cummins—Ether Injection .................................. 42
Deutz— Manifold Preheater ................................. 42
GM— Radiator Hose In-Line ................................ 42
HydraulicSystemColdWeather Warm-Up............... 42
Hydraulic System Warm-up Switch ...................... 42
ManuallyWarmingTheHydraulic System ............ 42
PreparingforOperation............................................. 42
LowerControls ......................................................... 42
UpperControls ......................................................... 43
BoomOperation.................................................... 44
DrivingandSteering .............................................. 44
DriveSpeeds......................................................... 45
MotionWarningAlarm .......................................... 45
PlatformOverload Sensing System .......................... 45
ACGenerator ........................................................... 46
DualFuel ................................................................. 46
AirLine .................................................................... 47
DrivingLights............................................................ 47
PlatformWork Lights ............................................... 47
Chapter 9 – Stowing and Transporting
Stowing .................................................................... 49
TuckedStow ......................................................... 49
Transporting ............................................................. 49
Driving................................................................... 50
Winching .............................................................. 50
Hoisting ................................................................ 51
SecuringforTransport........................................... 51
Chapter 10 – Emergency Operation
EmergencyPowerSystem....................................... 53
LowerControls...................................................... 53
UpperControls...................................................... 53
EmergencyLowering................................................ 54
Chapter 11 – Troubleshooting
TroubleshootingChart .............................................. 55
Appendix A – Glossary

SB85J Fixed Axle – 0112975 1
Chapter 1 – Introduction
Aerial Platform Features
The aerial platform is a boom-supported elevating work
platformused toraisepersonnel,their tools,andmaterial
to the workstation. The booms are raised and lowered
with hydraulic cylinders. Hydraulic motors on the drive
wheelsprovide power tomovetheaerial platform.
Thestandard machine includes the following features.
• Proportionaldrive control
• Fourwheeldrive
• Threesteermodes;fourwheel,twowheel,andcrab
• Foamfilledtires
• Highengine temperature shutdown
• Lowoilpressureshutdown
• Hourmeter
• Ammeter
• Coolanttemperaturegauge
• Hydraulicoil levelandtemperaturegauges
• Batteryoperated emergency power system
• Manualloweringvalve
• Horn
• 3.5degreetilt alarm
• 360degree continuous turntable rotation
• 170degree platformrotation
• Tie-downlugs
• Liftinglugs
• Gravitygate
• Fiveyear limited warranty
The machine may be powered with one of the following
engines.
• Cummins B3.3 – Diesel
• DeutzF4L-2011F– Diesel
• General Motors 2.4 – Gasoline, LPG, or dual fuel
Theaerial platformhasbeen manufactured toconformto
European Directive 98/37/EC and European Standard
EN280.
Options
Thefollowing options may be provided on the machine.
• Drivemotionalarm
• Dualfuel
• Flashinglight
• Drivinglights
• Platformworklights–floodorhalogen
• Platformcontrol cover
• Swingingplatform gate
• 5foot aluminum 600 lb capacity platform
• 5foot aluminum 600 lb capacity platform
withsecondary guardrails
• 8foot aluminum 500 lb capacity platform
• Sandblast protection kit
• Cold weather start kit
• Hydraulicfluidwarm-upsystem
• Sparkarrestor muffler– Deutz or GM engines
• Airlinetoplatform
• ACgenerator– hydraulic powered, 220 V, 50 Hz
Operator’s Manual
Thismanualprovidesinformationfor safe and proper op-
eration of the aerial platform. Some information in this
manual refers to options that may or may not be on your
machine. Read and understand the information in this
Operator’sManual beforeoperatingtheaerial platformon
the job.
Additional copies of this manual may be ordered from
UpRight.Supply the model andmanualpartnumberfrom
the front cover to assure that the correct manual will be
supplied.
Allinformationin this manual is based on the latestprod-
uctinformationatthetimeofpublication.UpRightreserves
the right to make product changes at any time without
obligation.
SafetyAlerts
A safety alert symbol is used throughout this manual to
indicatedanger,warning,and caution instructions.Follow
theseinstructionsto reduce the likelihood of personal in-
jury and property damage. The terms danger, warning,
andcaution indicate varying degrees ofpersonalinjuryor
property damage that can result if the instruction is not
followed.
ADanger
Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
This signal word is to be used in the most extreme
situations.
AWarning
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
ACaution
Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
It may also be used to alert against unsafe practices.
Notes
Notes are used to provide special information or helpful
hintstoassistinaerial platform operation, but do not indi-
cate a hazardous situation.
Operation
The aerial platform has built-in safety features and has
been factory tested for compliance with manufacturers
specificationsandindustrystandards.However, any per-
sonnellifting aerial platform can be potentially dangerous
inthehandsof untrained or careless operators.
AWarning
The potential for an accident increases when the
aerial platform is operated by personnel who are

Chapter 1 – Introduction
2SB85J Fixed Axle – 0112975
not trained and authorized. Death or serious injury
can result from such accidents. Read and under-
standthe information in thismanual and on the plac-
ards and decals on the machine before operating
the aerial platform on the job.
Training is essential and must be performed by a quali-
fiedperson.Become proficient in knowledge and actual
operationbefore using theaerialplatformonthejob.You
mustbetrainedandauthorized to perform any functions
oftheaerialplatform.Operationoftheaerialplatformmust
be within the scope of the machine specifications.
Theoperator bearsultimateresponsibility forfollowingall
manufacturer’sinstructionsandwarnings,regulationsand
safetyrulesoftheiremployerand/oranystate or federal
law.
Maintenance
Every person who maintains, inspects, tests, or repairs
the aerial platform must be qualified to do so. Following
the daily prestart inspection in this Operator’s Manual
willhelpkeepthe aerialplatformin optimumworkingcon-
dition.Other maintenance functions must be performed
by maintenance personnel who are qualified to work on
theaerial platform.
ACaution
Welding current can be very intense. Damage to
electronic components can result. Connect the
ground clamp as close as possible to the area be-
ing welded. Disconnect battery cables and any mi-
croprocessors and engine control modules before
welding on the machine.
If it becomes necessary to weld aerial platform compo-
nents as a method of repair, take all precautions to pre-
vent damage to electronic circuitry and devices on the
machine. This includes, but may not be limited to, dis-
connectingbatterycables and electronic devices.
Do not modify this aerial platform without prior written
consentof theUpRightEngineeringDepartment. Modifi-
cation may void the warranty, adversely affect stability,
oraffect the operational characteristicsoftheaerial plat-
form.
Owner and User Responsibilities
All owners and users of the aerial platform must read,
understand, and comply with all applicable regulations.
Ultimatecompliance to national safety regulations is the
responsibilityofthe user and their employer.
Additional Information
For additional information contact your local distributor
orUpRightat:
UpRightPoweredAccessHQ
VigoCentre
BirtleyRoad
Washington
Tyne& Wear
NE389DA
Tel: [phone]
Fax: [phone]
http://www.upright.com

SB85J Fixed Axle – 0112975 3
Component Identification
Right Side
Chassis
Lower
Controls
Upper Controls
Fuel Tank
LP Fuel Tank
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid Tank
And Filter Battery Disconnect
Switch Batteries
Engine
Platform
Foot Switch
Operator’s
Manual
Emergency
Lowering Valve
Intermediate
Boom
Wiring Box
Jib
Rear Front
Front Rear
Chapter 2 – Specifications

Chapter 2 – Specifications
4SB85J Fixed Axle – 0112975
Working Envelope
Meters
(Feet)
3.0
(10)
12.2
(40) 9.1 (30) 0
21.3
(70)
0
3.0
(10)
15.2
(50)
3.0
(10)
6.1
(20)
15.2
(50)
18.3
(60)
24.4
(80)
3.0
(10)
6.1
(20)
9.1
(30)
12.2
(40)
18.3
(60)
21.3
(70)
24.4
(80)
27.4
(90)
6.10
(20)

Chapter 2 – Specifications
SB85J Fixed Axle – 0112975 5
General Specifications
Aerial Platform
Workingheight 27.7m(90′11″)
Maximumplatformheight 25.8 m (84′11″)
Horizontalreach 23.4 m(76′8″)
Mainboom
Articulation -13.5°to+70°
Extension 13.4m(44′)
Jibboom
Articulation -70°to+70°
Turntablerotation 360° continuous
Turningradius, 4 wheel steer 2.4 m (7′10″)
Tailswing 1.9 m (78.5″)
Wheelbase 3 m (10′)
Groundclearance 33 cm (13″)
Maximumwheelload 8,770kg(19,300lbs)
Maximumground pressure 6.9 kg/cm² (99 psi)
Weight, EVW
Approximate 17,100kg(37,600lbs)
Width 2.5 m (8′6″)
Stowedlength 11.2m(36′10″)
Stowed length, tucked stow 11.1 m (36′7.5″)
Stowedheight 2.9 m (9′8″)
Platform
Dimensions
StandardAluminum 76 cm x 244 cm (30″x 92″)
Optional Steel 76 cm x 152 cm (30″x 60″)
Optional Aluminum 76 cm x 152 cm (30″x 60″)
Ratedwork load
Steel 30″x 60″227kg (500lb)
Aluminum 30″x 60″272 kg(600 lb)
Aluminum 30″x 92″227 kg(500 lb)
Rotation 170degrees
Maximumnumberofoccupants 2people
OptionalAC generator 110 V
OptionalAC generator 220 V
OptionalAC generator 220 V, 3-phase, 12 kw
OptionalWelder
Function Speed
Turntablerotation
Booms retracted 168secondsminimum
Booms extended 228secondsminimum
Mainboom
Up 105seconds minimum
Down 105secondsminimum
Extend 80 to 90 seconds
Retract 60 to 70 seconds
Jib
Up 25 to 35 seconds
Down 25 to 35 seconds
Platformrotation 16 to 20 seconds
Drive
High, booms stowed 4.8 km/h (3.0 mph)
Mid, booms stowed 2.4 km/h (1.5 mph)
Low, booms raised/extended 1 km/h (0.6 mph)
Drive System
Standard Fourwheeldrive
Gradeability–theoretical 45%
Tires
Foam filled 15-625NHS, 16 ply
Electrical System
Voltage 12VDC negative chassis ground
Source
Gas engine One-12V 550 CCA battery
Diesel engine Two - 12 V550 CCAbatteries
Fluidrecommended distilled water
Hydraulic System
Maximumpressure 19,305 kPa(2,800psi)
Reservoircapacity 151 l (40 US gal)
System capacity 246 l (65 US gal)
Maximumoperating temperature 93°C(200°F)
Hydraulicfluid recommended
Above-13°C (10°F) MobilDTE-13M(ISOVG32)
Below -13°C (10°F) MobilDTE-11M (ISO VG15)
Engine
Diesel CumminsB3.3
Diesel DeutzF4L-2011F
Gasolineand/or LPG General Motors 2.4
Fuel Tank Capacity
Gasoline ordiesel 204 l (54 US gal)
LPG 19.7 kg (43.5 lbs)
Dualfuel gasoline 204 l (54 US gal)
Dualfuel LPG 19.7 kg (43.5 lbs)
Ambient Air Temperature Operating Range
Celsius -18°Cto 43°C
Fahrenheit 0°Fto110°F
Maximum Wind Speed
Gust or steady 45 km/h (28 mph)
Vibration less than 2.5 m/sec2
Sound Threshold below 97 dB(A)

Chapter 2 – Specifications
6SB85J Fixed Axle – 0112975
Engine Specifications
Cummins
B3.3
Diesel
Displacement Fuel Grade Coolant Operating
Temperature Oil
Capacity
3.26 liter
(199 cu. in.)
Oil
Grade
Engine
Diesel
ASTM No. 2D fuel with a
minimum Cetane number of
40.1For operating tempera-
tures below 0°C (32°F) use
winterized No. 2D.
50% water
50%Antifreeze2
7.5 liter (2 gal)
total
1.5 liter (1.6 qt)
Low to High
SAE
15W-403
API:
CH4/SG
60°C to 100°C
140°F to 212°F
Note 1: Refer to the engine manufacturers manual for specific fuel recommendations and specifications.
Note 2: Ethylene glycol or Propylene glycol may be used. Refer to the Cummins®Operation and Maintenance Manual B3.3 Series
Engines for specific coolant recommendations and specifications.
Note 3: Refer to the engine manufacturers manual for specific lubricating oil recommendations and specifications.
Note 4: API Starburst symbol on GF-4 oils reads “API Service SM.”
Deutz
F4L-2011F 3.11 liter
(190 cu. in.)
Diesel
• DIN51 601 (February 1986).1
• BS 2869: A1 andA2 (withA2
refer to Deutz manual about
sulfur content)1
• ASTMD975-88:1-D and 2-D
• CEN EN 590 or DIN EN 590
• NATO Code F-54 and F-75
• For operating temperatures
below 32°F (0°C) use win-
ter grade diesel.
Air 6.0 liter
(1.59 US gal) API:CD
or higher3
78°C to 95°C
172°F to 203°F
GM 2.4 2.4 liter
(150 cu. in.) 50% Water
50%Antifreeze
Engine Oil Viscosity
CumminsB3.3
80°C to 84°C
176°F to 183°F
With filter:
4.5 liter
(1.12 US gal)
Without filter:
4.25 liter
(1.18 US gal)
ILSAC
GF-44
Gasoline
• Unleaded 87 octane
LPG
• HD-5

Chapter 2 – Specifications
SB85J Fixed Axle – 0112975 7
General Motors 2.4
DeutzF4L-2011F
Note
Nostraightweightoilsand no specialized diesel oils are
to be used in GM engines.
°F °F-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86 104122
°C °C-40 -35 -30 -25 -20 -15 -10 -5 0 10 15 20 25 30 40 505
SAE 5W/30
SAE 0W/30

Chapter 2 – Specifications
8SB85J Fixed Axle – 0112975

SB85J Fixed Axle – 0112975 9
Chapter 3 – Safety
Knowledgeoftheinformationin this manual, and proper
training, provide a basis for safely operating the aerial
platform. Know the location of all controls and how they
operatetoact quickly and responsibly in an emergency.
Safetydevicesreducethelikelihoodofanaccident.Never
disable,modify, orignoreanysafety device.Safetyalerts
in this manual indicate situations where accidents may
occur.
Ifany malfunction, hazard orpotentiallyunsafecondition
relating to capacity, intended use, or safe operation is
suspected, stop aerial platform operation and seek as-
sistance.
Theoperator bearsultimateresponsibility forfollowingall
manufacturer’sinstructionsandwarnings,regulationsand
safetyrulesoftheiremployerand/oranystate or federal
law.
Electrocution Hazards
Theaerial platform is made of metalcomponents and is
not insulated. Regard all conductors as energized. Do
notoperateoutsideduringathunderstorm.
Minimum Safe Approach Distance
Minimum safe approach distances to energized power
linesandtheirassociatedpartsmustbeobservedwhile
operatingthe aerial platform.
ADanger
The aerial platform is not electrically insulated.
Death or serious injury can result from contact with,
or inadequate clearance from, an energized con-
ductor. Do not go closer than the minimum safe
approach distance as defined by ANSI.
ANSI publications define minimum distances that must
beobserved whenworkingnearbus barsandenergized
powerlines.Table 1 and Figure 3 are reprinted courtesy
ofScaffoldIndustryAssociation,ANSI/SIAA92.5.
Table 1 – Minimum Safe Approach Distance
Figure 3 – Minimum Safe Approach Distance
Minimum Safe Approach Distance
Voltage Range
(Phase to Phase)
0to 300V
Over300Vto50kV
Over50kVto 200kV
Over200kVto 350kV
Over350kVto 500kV
Over500kVto 750kV
Over750kVto 1000kV
Feet Meters
AvoidContact
10
15
25
20
35
45
3.05
4.60
6.10
7.62
10.67
13.72

Chapter 3 – Safety
10 SB85J Fixed Axle – 0112975
Prestart Inspection
Perform a prestart inspection before each shift as de-
scribed in Chapter 7. Do not use the aerial platform on
the job unless you are trained and authorized to do so.
Work Place Inspection and Practices
Do not use the aerial platform as a ground connection
when welding. The welding ground clamp must be at-
tachedto the same structure that is beingwelded. Elec-
trical current flow can be very intense, causing serious
internaldamagetosomecomponents.
Inspect the area before and during aerial platform use.
Thefollowingaresomepotentialhazardsthatmaybein
the work place.
• Debris
• Slopes
• Drop-offsor holes
• Bumpsandfloorobstructions
• Overheadobstructions
• Unauthorizedpersons
• Highvoltage conductors
• Windandweatherconditions
• Inadequate surface and support to withstand load
forces applied by the aerial platform in all operating
configurations
Beforeusing theaerialplatform inanyhazardous (classi-
fied)location, make certain it is approved andofthetype
requiredforuse in that particular location.
Knowandunderstandthejobsitetraffic-flowpatternsand
obey the flagmen, road signs, and signals.
While operating the aerial platform, a good safety prac-
ticeistohavequalifiedpersonnelintheimmediate work
areato:
• Help in case of an emergency
• Operateemergency controls as required
• Watchfor loss of control by platform operator
• Warn the operator of any obstructions or hazards
that may not be obvious to them
• Watch for soft terrain, sloping surfaces, drop-offs,
etc. where stability could be jeopardized
• Watchforbystanders and never allow anyone to be
under,or toreachthrough theboomswhileoperating
theaerial platform
ADanger
Pinch points may exist between moving compo-
nents. Death or serious injury can result from be-
coming trapped between components, buildings,
structures, or other obstacles. Make sure there is
sufficient clearance around the machine before
moving the chassis, booms, or platform. Allow suffi-
cient room and time to stop movement to avoid con-
tact with structures or other hazards.
Alwayslook inthedirection ofmovement.Drive with care
andat speedscompatiblewith theworkplace conditions.
Usecautionwhendrivingoverroughground,onslopes,
and when turning. Do not engage in any form of horse-
playor permit riders any place other thanintheplatform.
Secureallaccessories,containers,tools,and other ma-
terials in the platform to prevent them from accidentally
falling or being kicked off the platform. Remove all ob-
jects that do not belong in or on the aerial platform.
Never steady the platform by positioning it against an-
otherplatform.
AWarning
The potential for an accident increases when oper-
ating an aerial platform that is damaged or mal-
functioning. Death or serious injury can result from
such accidents. Do not operate the aerial platform
if it is damaged or malfunctioning.
Donot operate the aerial platform if it is damaged or not
functioning properly. Qualified maintenance personnel
must correct the problem before putting the aerial plat-
formbackintoservice.
Operation
Use three points of support when entering or exiting the
platform.For example,usetwo handsandonefoot when
climbingintothe platform.
Never cover the platform floor grating or otherwise ob-
struct your view below. Make sure the area below the
platformis free of personnelbeforelowering.
Keep both feet positioned firmly on the platform floor.
Operatethecontrolsslowlyanddeliberatelyto avoidjerky
anderraticoperation.Alwaysstopthecontrolsinneutral
beforegoingintheoppositedirection.
Do not dismount while the aerial platform is in motion or
jumpoffthe platform.
Properly stow the aerial platform and secure it against
unauthorizedoperationatthe end of each work day, be-
foretransporting, or if it is left unattended.
Tip-Over and Falling Hazards
Operatethe aerial platform only on afirm, flat, level sur-
face capable of withstanding all load forces imposed by
theaerial platforminall operatingconditions.Refer tothe
GeneralSpecificationschartforthemaximum wheelload
and ground pressure. Raise the booms only when the
aerialplatform is on level ground.
ADanger
The aerial platform can tip over if it becomes un-
stable. Death or serious injury can result from a tip-
over accident. Do not drive or position the aerial

Chapter 3 – Safety
SB85J Fixed Axle – 0112975 11
platform for elevated use near any drop-off, hole,
slope, soft or uneven ground, or other tip-over haz-
ard. Do not raise the boom in winds above 45 km/h
(28 mph).
All platform occupants must wear a fall restraint device
connectedtoa lanyard anchor point.
Itis bestnottotransferfrom theplatformto anotherstruc-
ture or from the structure to the platform, unless that is
thesafest way to do the job. Judge each situation sepa-
rately taking the work environment into account. If it is
necessarytotransferfromtheplatformtoanotherstruc-
turethefollowingguidelinesapply:
1. Where possible, place the platform over a roof or
walkingstructure to do the transfer.
2. Transfer your anchorage from one structure to the
otherbeforestepping across.
3. Remember that you might be transferring to a struc-
turewherepersonalfall arrestis required.
4. Use the platform entrance, do not climb over or
throughthe guardrails.
Donotoperatetheaerialplatformin windy or gusty con-
ditions. Do not add anything to the aerial platform that
will increase the wind loading such as billboards, ban-
ners, flags, etc.
Neveroperate the aerial platform without all partsof the
guardrailsystem inplaceand thegateclosed. Makesure
that all protective guards, cowlings, and doors are se-
curelyfastened.
Donot exceed the platform capacity as indicated on the
platformratingplacardonthe platform.Do notcarry loads
that extend beyond the platform guardrails without prior
writtenconsentfrom UpRight.
Do not operate the aerial platform from trucks, trailers,
railwaycars, floating vessels, scaffolds, or similar equip-
ment unless the application is approved in writing by
UpRight.
Do not use the aerial platform as a crane, hoist, jack, or
for any purpose other than to position personnel, tools,
andmaterials.
Donotclimbon the guardrails or use ladders, planks, or
other devices to extend or increase the work position
fromthe platform.
Take care to prevent rope, electrical cords, and hoses,
etc.,from becoming caught in or on theaerialplatform.If
the platform or booms becomes caught on an adjacent
structureor other obstacle and is prevented fromnormal
motion,reversethe control to free the platform. If control
reversaldoesnotfree theplatform, evacuatetheplatform
beforeattemptingtofreeit.
Electrical System
Chargethebatteriesinawell-ventilatedareafreeofflame,
sparks, or other hazards that might cause fire or explo-
sion.
Donotoperateanyof the aerial platform functions while
the battery charger is plugged in.
AWarning
Batteries give off hydrogen and oxygen that can
combine explosively. Death or serious injury can
result from a chemical explosion. Do not smoke or
permit open flames or sparks when checking the
batteries.
Battery acid can damage the skin and eyes. Seri-
ous infection or reaction can result if medical treat-
ment is not given immediately. Wear face and eye
protection when working near the batteries.
Batteriescontainsulfuricacid thatcandamageyoureyes
or skin on contact. Wear a face shield, rubber gloves,
andprotective clothing whenworkingaroundbatteries. If
acid contacts your eyes, flush immediately with clear
water and get medical attention. If acid contacts your
skin, wash off immediately with clear water.
Hydraulic System
Thehydraulic system contains hoses with hydraulic fluid
underpressure.
ADanger
Hydraulic fluid escaping under pressure can have
enough force to inject fluid into the flesh. Serious
infection or reaction can result if medical treatment
is not given immediately. In case of injury by escap-
ing hydraulic fluid, seek medical attention at once.
Donot placeyourhand oranypart ofyourbody infrontof
escapinghydraulicfluid.Useapieceofcardboardorwood
to search for hydraulic leaks.
Engine and Fuel Handling Precautions
Refertotheenginemanufacturer’sOperator’s Manualfor
completeinformationon safe engine operation, mainte-
nance,andspecifications.
ADanger
Engine exhaust contains carbon monoxide, a poi-
sonous gas that is invisible and odorless. Breathing
engine exhaust fumes can cause death or serious
illness. Do not run the engine in an enclosed area
or indoors without adequate ventilation.
Operatedual fuel machinesonLPGfuel when indoorsto
reduceexhaustfumesand carbon monoxide.

Chapter 3 – Safety
12 SB85J Fixed Axle – 0112975
Be careful not to run the diesel fuel tank empty. Bleed
the fuel system if air enters the lines between the tank
andtheinjection pump.
Allow the engine to return to idle before shutting the en-
gineoff.
Donot smokeorpermit openflameswhile fueling ornear
fuelingoperations.
Never remove the fuel cap or fill the fuel tank while the
engine is running or hot. Never allow fuel to spill on hot
machinecomponents.
Maintain control of the fuel filler nozzle when filling the
tank. Spilled fuel is a potential fire hazard.
Donotoverfillthe fuel tank.Allowroom for expansion.
Cleanupspilledfuel immediately.
Tighten the fuel tank cap securely. If the fuel cap is lost,
replace it with an approved cap from UpRight. Use of a
non-approved cap without proper venting may result in
pressurizationof the tank.
Neveruse fuel forcleaningpurposes.
For diesel engines, use the correct fuel grade for the
operatingseason.
ACaution
Engine coolant escaping under pressure can cause
serious burns. Shut the engine off and let it cool
before removing the radiator cap.
Lettheengineandradiatorcoolbeforeaddingcoolant.
Placards and Decals
Theaerial platform isequippedwithplacards and decals
that provide instruction for operation and accident pre-
vention. Do not operate the aerial platform if any plac-
ards or decals are missing or not legible.

SB85J Fixed Axle – 0112975 13
Thisaerial work platform ismanufacturedwithsafety de-
vices,placards, and decals toreducethelikelihoodof an
accident. For the safety of all personnel, do not disable,
modify, or ignore any safety device. Safety devices are
included in the daily prestart inspection.
AWarning
The potential for an accident increases when safety
devices do not function properly. Death or serious
injury can result from such accidents. Do not alter,
disable, or override any safety device.
Ifanysafetydevicesaredefective,removethe aerialplat-
formfromserviceuntil qualified maintenance personnel
canmakerepairs.
Emergency Stop Controls
Thereisanemergency stop control at the lower and up-
percontrols.
At the lower controls, the emergency stop is a two-posi-
tion push button (refer to Figure 4.1). Push the emer-
gency stop button in to disconnect power to all control
circuits. Pull the button out to restore power.
Figure 4.1 – Lower Controls
Note
Thelowercontrolsoverridetheuppercontrols.Iftheup-
percontrol emergency stop button isengaged,thelower
controls can still be used to operate the aerial platform.
Attheuppercontrols,the emergency stop is a two-posi-
tionpushbutton(refer to Figure 4.2).
Chapter 4 – Safety Devices
Figure 4.2 – Upper Controls
Pushtheemergencystop button in to disconnect power
to the upper control circuits. Pull the button out to re-
storepower.
Emergency Power System
Theemergency powersystemincludes aback-uppump,
motor, and battery. Use this system to operate the boom
and turntable functions to lower the platform if the main
powersystemfails due to engine or pump failure.
Hold the emergency power switch (refer to Figure 4.1
and4.2)downto activate the emergency power system.
Thelengthoftime thepumpcanbeoperated dependson
the capacity of the battery.
Emergency Lowering Knob
Theemergencyloweringknobmay be used to lower the
booms if the engine will not start and the emergency
powersystem will not work. The knob is on the base end
of the main boom lift cylinder (refer to Figure 4.3) under
the left side of the turntable.
Figure 4.3 – Emergency Lowering Knob
Theknob maybeturnedto open thecylinderbleed down
valveforemergencylowering.
Emergency
Lowering Knob
Emergency
Stop Button
Ground
Operation Switch
Engine/Emergency
Power Switch
Emergency
Stop Button Engine/Emergency
Power Switch

Chapter 4 – Safety Devices
14 SB85J Fixed Axle – 0112975
Lanyard Anchors
Two lanyardanchorsforfallrestraintanchorage are pro-
videdbelow theuppercontrolsat the frontofthe platform
(referto Figure 4.4).
Note
The lanyard anchors are not for lifting or tying the ma-
chinedown.
All personnel in the platform must connect their fall re-
straintdevice to a lanyard anchor before raising the plat-
form. Do not use the aerial platform for personal fall ar-
restanchorage.
TiltAlarm
Iftheaerialplatformchassisisout of level more than 3.5
degrees when the main boom is raised or extended, an
alarmwill sound.Thetilt alarm islocatedunder theupper
controlpanel.
ADanger
The aerial platform can tip over if it becomes un-
stable. Death or serious injury can result from a tip-
over accident. Do not drive or position the aerial
platform for elevated use near any drop-off, hole,
slope, soft or uneven ground, or other tip-over haz-
ard.
Completely retract and lower the main boom and then
drivetoa level surface when the tilt alarmsounds.
Thetiltalarmisforadded protection and does not justify
operatingon anythingotherthanfirm, flat,levelsurfaces.
Platform Overload Sensing System
All functions are stopped from the upper and lower con-
trols, when the platform overload limit is exceeded. The
horn will sound intermittently and the red overload light
(refer to Figure 4.6) will blink until the excess load is
removedfromtheplatform.Atthattime,themachinefunc-
tionsare again operational.
Figure 4.6 – Upper Controls
Ground Operation Switch
Thegroundoperation switch(refertoFigure4.1)prevents
boom and platform movement if a control switch on the
lowercontrolpanelisaccidentallymoved.
Holdthe switchuptooperate themachinefrom the lower
controls.
Platform Foot Switch
Steppingdownontheplatformfootswitch (refertoFigure
4.4)activatestheupper controls.
Figure 4.4 – Platform
The foot switch must be engaged and a control must be
movedto operate the boom, drive, and/or platform from
theuppercontrols.
Guardrails
The guardrail system includes a top rail, mid rail, and
toeboards around the sides of the platform (refer to Fig-
ure4.4).
Agravitygate(refer toFigure4.4) oranoptionalswinging
gate (refer to Figure 4.5) allows for access to the plat-
form.
Figure 4.5 – Platform
The gates close automatically after entering or exiting
theplatform. The gate is partoftheguardrail system and
mustbesecurelyfastenedafter entering the platform.
Toeboard
Top Rail
Mid Rail
Gravity
Gate Lanyard
Anchors
Platform Foot
Switch
Platform
Overload Light
