Urban Cultivator UC-R User manual

Urban Cultivator | 1-877-352-0490 | www.urbancultivator.net
Enclosure specication
90° 90°
(882.65mm)
34
1
2
”
24
(616 mm)
1
4
”
24
(616 mm)
1
4
”
4” (102mm)
diam. hole.
(position back
corner of cabinet)
Cabinet Cut-Out Dimensions
Height 34 Width 24 Depth 24
Product Dimensions Without Counter Top Or Wheels
Height 34 Width 24” Depth 24 ”
1
2
”
1
4
”
1
4
”
1
4
”
Allow an extra 1.5” (38mm) of clearance space if you are installing your Cultivator into a corner enclosure.
The additional space is clearance for the Cultivator’s door handle. The door must be able to open a mini-
mum of 90 degrees to the cabinet so that the grow drawers may slide in and out.
minimum 90°
25
(655 mm)
3
4
”
minimum 1.5” (38.1mm)
UC-R Installation Guide
®

11Urban Cultivator | 1-877-352-0490 | www.urbancultivator.net
Connecting the Power, Water, and Electricity
Numbered Items
1. City Water In Connection (Min 30psi required)
Use braided City Hose to connect to your city water connection. The hose
comes with a standard
⅜” compression fitting.
2. City Drain Out Connection
Connect the City Drain Hose (1/2” to 3/4“ hose connection) to your city drain
which should be no further than 6’ from the Cultivator and 2’ up from the floor.
3. Power Connection
Connect the Cultivator to a standard 110/240V power outlet. The electricity plug
should be no further than 2’ away from the unit and should run out on the same
side as the water and drain hose. The wall receptacle is non-replaceable.
4. Hole Size For All Connections
Use a 4” hole saw and remove part of the bottom shelf of the cabinet adjacent
to the Cultivator where all the connections run from.
5. Adjustable Feet
Twist the Cultivators feet to adjust its overall height from 34¼” to 34 ½” Ensure
product is level.
Leave 1½”
clearance gap for the door swing and handle when installing
the Urban Cultivator Residential adjacent to a wall.
Water In, City Drain Out & Electricity connections run out from one side
only, the left. Please contact Urban Cultivator using
[email protected] or call us toll-free:
[phone] available Monday–Friday. 8:00–16:00 PST.
1
3
2
4
5
2’0” (610mm)
maximum from
floor to City
Drain.
6’0” (1829mm) maximum from
the Cultivator to the City Drain
connection.
Connect the supplied drain hose to the
drain pipe of the kitchen sink either:
- above the P trap
- to the dishwasher connector of the
garbage disposal.
DISCLAIMER: Please make sure that the length of the drain line does not exceed 6ft. In the event that a pump is used, make sure it has capacity exceeding 80GPH. Urban Cultivator will not be
responsible for any losses arising from usage or failure of any additional devices connected to the unit for facilitation of plumbing or drainage.Please refer to applicable local codes for electrical
and plumbing installation.
Max. water pressure: 60psi.
Check home pressure gauge
before installation.

Urban Cultivator | 1-877-352-0490 | www.urbancultivator.net
External dimensions
24"
25"
34 1/2"
38"
36 1/2"
46"
24"
3 1/2" - 4"
