Pro Series Linear™
USER GUIDE

Table of contents:
Warranty
Safety & Precautions
System Hardware & Accessories
Assembly & Mounting Instructions
URBARN Light Fixture
Bluetooth App
Technical Specifications
Warnings
Care & Maintenance
URBARN™ aligns with the spirit
and drive of a farmer:
Relentless focus on operational
efficiency and productivity
backed by a community of
like-minded business owners.
A BREED APART

Warranty
Every URBARN™ horticultural light
is designed, engineered, and built by
Abundant Lighting, LLC, in Grand Rapids,
Michigan, USA. We use the finest materials
from around the world to ensure you have
the most advanced technology available. All
URBARN™ lighting products are guaranteed
against manufacturing defects for five (5)
years from date of purchase. For detailed
warranty information, visit URBARN.com

Safety & Precautions
Please read this manual thoroughly before attempting
to install or operate your URBARN™ horticultural light,
and keep it in a safe place for future reference. This
fixture must be installed by a qualified electrician.
It is important that you read, fully understand, and
observe the subsequent safety precautions.
This fixture is suitable and rated for damp and dry
locations. Care should be taken that it is used in a
manner that does not exceed its rated ampacity or the
maximum ambient temperature (40°C) of its installed
environment. For longevity and peak performance,
avoid exposure to direct sunlight as it may raise
ambient temperatures past the fixture rating.
The URBARN luminaire should not be concealed
or extended through a wall, floor, ceiling, or other
parts of a building. It should not be located above a
suspended ceiling or dropped ceiling, and should not
be permanently affixed to a building structure.
Care should be taken that the luminaire mounting
components and wiring are not subject to strain and
are protected from physical damage. When suspended,
each luminaire should be visible over its entire length.
While our URBARN fixture operates at a low
temperature, it is best not to touch while in operation.
Connect your URBARN light fixture to power sources
of the correct voltage. Protect power cables from
being pinched, walked on, or otherwise damaged.
Be especially careful where the power cable enters
the housing of the unit. Only connect the light to an
electrical outlet or extension cord of appropriate type
and rating.
When connecting multiple fixtures from one building
facility connection (daisy chaining), maintain a
working distance of 1219mm (4’) between daisy-chain
connections and limit the number of interconnected
fixtures to a maximum of three (3).
DO NOT defeat the safety purpose of a grounding or
polarized plug by removing ground pins or using unsafe
adapters. A polarized plug has two blades—one wider
than the other. A grounding plug has a third ground
prong in addition to the two main conductors. The wide
blade or third grounding prong is provided for your
safety. If the provided plug does not fit your outlet,
consult an electrician to replace your obsolete outlet.
If you replace the power cord, only use one of similar
type and equal or greater current rating.
The URBARN light fixture should only be cleaned as
directed in the manual. You should seek service for
your system by qualified factory support if any of the
following occur:
• The power-supply cord or the plug has been
damaged.
• The unit has been exposed to rain.
• The unit exhibits a marked change in performance.
• The unit has been dropped, or its enclosure or chassis
is damaged.
The product must be installed in accordance with
the National Electrical Code and all applicable local
codes. Proper grounding is required for safety. The
fixture must be installed in accordance with the
applicable installation code by a person familiar with
the construction and operation of the product and any
hazards involved.

System Hardware & Accessories
System Hardware
A - URBARN™ Pro Series Linear™
Fully assembled light fixture with mounting brackets
Accessories
B – AC Cables
• Cable only, 8' or 12' (special order)
• 8 ', 12' (special order); preassembled
with 5P, 6P, or 7P plug per specification
C – Jumper Cables (if ordered), 4' or 8'
D – Mounting Hardware
D1 - Galvanized Cable System (standard)
D2 - Stainless Steel Adjustable Loop with
optional Rope Ratchet
E - Reference
• User Guide
Pro Series Linear
User Manual
A
B
C
E
D1D2
5P 6P 7P

WARNING: Carefully inspect the connections before hanging the cable system or rope ratchet.
DO NOT EXCEED LOAD LIMITS:
• CABLE KIT - 40 pounds per cable. Inspect each cable before using.
• ROPE RATCHET (special order) - 75 pounds per ratchet. Inspect each ratchet before using.
DO NOT USE IF DAMAGED. Avoid hot surfaces, sharp edges, abrasive surfaces and pinch points.
Cable System
Secure the hanger cable to an overhead supporting structure
using a minimum of two hanger points.
• Option 1: Secure the loop portion of the cable to a beam mount
or similar secure hanging point
• Option 2: Pass loop side of the cable over, around and under
structure capable of supporting 40 pounds or more. Then pass
straight end of cable through loop and pull tight.
• Repeat for both sides and ensure mounting position is equal
distance from ends to maintain balanced system.
• Raise fixture with “Y” toggle and grippers (already attached to
the fixture) to the loop cable secured to structure above. Pass
the straight end of loop cable through the toggle. The plunger
on top of the toggle catches and holds the cable securely.
• Level the fixture plumb with the building lines to the desired height
over the plant canopy (to let out cable, push the plunger down).
Adjustable Loop with Rope Ratchet
Fasten the adjustable rope clip hangers (provided) to light’s mounting
brackets. Repeat for both sides to ensure mounting position is equal
distance from ends to maintain a balanced system.
• Attach the carabiner clip on the ratchet to a secure overhead
hanging location such as a threaded hook or anchor.
• Secure the carabiner clip on the end of the looped rope to the
fixture. Make sure not to exceed 75 pounds per ratchet.
• Tighten the ratchet by pulling the loose end of the rope to raise the
fixture to the desired height.
• To loosen or lower the attached light, depress the small lever
recessed within the rope ratchet. Replace rope when worn.
Final Adjustments
Hang the fixture in the desired location and adjust the mounting
height to six inches from canopy.
• To prevent the overheating of lighting equipment or combustible
materials within the installation environment, please maintain at
least 6 inches of open air space above the unit and 12 inches from
each end to allow adequate airflow and cooling of the fixture.
• Once the fixture is in place, plug the AC cable into the wall or
ceiling outlet. Make sure no one is looking directly at LEDs when
power is connected.
• Note: This URBARN™ light fixture is suitable for dry or damp
location installation. The fixture is not for intra-canopy use.
Remove light fixture and hardware from packaging. Be sure to place on a stable and flat surface with LEDs facing downward.
Adjust the cables or rope ratchets fixture connections to their desired position and secure. Be sure that the connection points to the lighting
fixture are spaced an equal distance from the endcaps to ensure fixture stability.
Maintain a minimum of 300mm (12 inches) mounting distance between lighting fixtures, walls, solid partitions and other permanent structures.
Maintain a minimum of 152mm (6 inches) distance from ceilings. Care should be taken to never mount any electrical lighting fixture near
highly combustible materials. Check local building codes for more specific instruction if required.
Attach male connector of power cord to corresponding female connector end of fixture. Ensure connection snaps into place.
If layout of facility calls for multiple fixtures to be powered with jumper cables, attach female connector to male connector on fixture.
Repeat jumpers for up to three (3) fixtures.
Assembly & Mounting Instructions
Option 1
“Y” toggle and gripper
carabiner clip
rope clip hanger
mounting bracket
pull rope
to raise
depress lever
to lower
toggle
Option 2

Setup & Usage of the URBARN™ Light Fixture Bluetooth® App
This URBARN™ horticultural lighting fixture uses an advanced low energy Bluetooth® application to control all
facets of its operation. The URBARN app can be found and downloaded for either iOS or Android Bluetooth-
equipped phones from their respective app stores.
Initial Download Procedure
• After downloading the URBARN app, you will be greeted by a welcome screen. Click “Start” to begin the
setup process.
• You will be prompted to sign into an URBARN account.
• If you’ve created an account previously, enter your email address and password, and you will be launched
directly into the application.
• If this is your first time, click “Create an account” or log in using one of the available providers.
• You will be prompted with Terms & Conditions.
Setting up Your Mesh Security Settings
• Click “Continue” to setup up your mesh security settings.
• The app will guide you through the set up process by first scanning for available URBARN lights.
– Accept the prompt to use Bluetooth.
– On Android, location permissions are required to use Bluetooth. (Note: URBARN does not store or use your
location in any way.)
• Make sure your lights are powered on and you are in Bluetooth proximity. We recommend 10 feet or less.
• Once the scan is complete, click “Yes” if the app found all of your available fixtures. Click “No” to start over.
• Clicking “Yes” will bring you to a screen to set a mesh username and password. These security settings ensure
your lights can only be controlled by users with the correct username and password.
• Once you’ve met the requirements, click “Start” to apply the security settings to the lights. The lights will blink
blue when they have successfully received the new security configuration.
• Once the setup is complete, click “Finish” to enter the main application screen.

Operating Your URBARN™ Light
The main application screen allows you to scan for lights in your mesh. Be sure the lights are powered on and you
are in Bluetooth proximity to at least one light.
• To control any light, click on the light and adjust light-specific settings.
• Click and hold the light to view additional functions.
• If you do not see lights, click the “Scan” button to search for mesh lights.
• Click the three bars in the top left corner to open the main application menu and browse to other screens.
The beauty of URBARN?
You decide. Tweak the number of lights,
placement, cycles and run times through
the app—do what works based on the
needs of your plants. We’re here to
facilitate and offer advice, but ultimately
you’re at the wheel to drive results.

Groups
The Group screen allows you to control sets of lights called “Groups.”
Note: You must be connected to the mesh to create and control Groups.
Routines
The Routines screen allows you to schedule times when the light will be on or off. Note: You must be connected to
the mesh to create and modify Routines.
• To create a new Group, click “New Group” in the top
right corner.
• Click on the Group to control its settings.
• To add lights to the Group, click on the three dots in
the top right corner.
• Select the light(s) you would like to associate with
the Group.
• The light(s) will blink blue to indicate acceptance of
the Group assignment.
• Return to the main screen to control the Group.
• Click “New Routine” in the top right corner to create a
new Routine.
• Enter a name for the Routine.
• By providing an expiration date, you will be notified
when a Routine should expire. It does not automatically
cancel the Routine. You will need to reconnect to the
mesh to manually delete the Routine.
• Enter a time when the light or Group should turn on.
• Select how many hours the light or Group should remain on.
• Select on what days the Routine should execute.
• Select what target light(s) or Group(s) should execute
the Routine.
• Click the check mark in the top right corner to save
the Routine.
• Confirm the Routine’s settings.
• The light(s) or Group(s) will flash blue to indicate
acceptance of the new Routine.

Settings
The Settings screen allows you to perform additional functions such as recover your settings or add new lights.
You can also visit the website or contact support if you are experiencing issues with the lights or app.
• Click the “Recover MESH” button to re-download a copy of your mesh security settings.
• Click “Share MESH” to invite a user to use your mesh security settings. Invitees will receive two emails: one to
download the app and another to accept the mesh settings. Users must first download the app and create an
account to accept a mesh invite.
• Click “Add Lights” to add new lights to your mesh. Lights must be turned on and in Bluetooth proximity to be
added to the mesh.
• Click “Sign Out” to return to the main login screen.
Feedback
The Feedback screen allows you to submit inquiries and ideas to URBARN™ on how to improve the app. We
welcome your input.
• Click on the three lines in the top left corner to open the menu.
• On the bottom of the menu, click “Provide Feedback.”
• Complete the form and click the send button in the top right corner.

Family/Model
URBARN™ Pro Series Linear™
Spectrum
Grower adjusted
Input Voltage
120-277VAC
AC Power Cord
8’, 12’
AC Plug
NEMA Rated 5-20P Plug
NEMA Rated 6-20P Plug
NEMA Rated L7-20P Plug
Mounting Hardware
Finished Galvanized Cable System (standard)
Stainless Steel Adjustable Loop with
optional Rope Rachet
Packaging
Single Unit (1)
Frequency
50/60Hz
Max Ambient Temperature
104°F / 40°C
Photosynthetic Photon Flux (PPF)
904
Energy Efficiency (PPE)
1.86 umol/J
Technical Specifications
Nominal AC Input 120V 277V
AC Current (Amps) 4.07A 1.72A
AC Input Power (Watts) 487W 477W
CAUTION
To prevent eye damage, avoid looking directly at the unshielded LEDs.
LED and heatsink surfaces may be hot. Allow sufficient cooling time before handling.
To reduce the risk of overheating or fire, never place operating fixtures face down on a flush surface.
Always allow
for adequate ventilation of fixtures and power supplies.
WARNING
Risk of electrical shock. To reduce the possibility of serious injury, always take the proper precautions and
unplug the fixture before moving or cleaning.

Family/Model
URBARN™ Pro Series Linear™
Spectrum
Grower adjusted
Input Voltage
120-277VAC
AC Power Cord
8’, 12’
AC Plug
NEMA Rated 5-20P Plug
NEMA Rated 6-20P Plug
NEMA Rated L7-20P Plug
Mounting Hardware
Finished Galvanized Cable System (standard)
Stainless Steel Adjustable Loop with
optional Rope Rachet
Packaging
Single Unit (1)
Care & Maintenance
• Your URBARN™ horticultural light combines both active and passive cooling. The light is designed for indoor use
and the unique conditions found in plant grow facilities. Some basic care will keep your light operating at peak
performance.
• For your light to properly cool itself, we recommend at least 152mm (6 inches) of space between the fixture and
the ceiling of your grow facility. Failure could result in shortened lifespan.
• To optimize lifespan and performance, we recommend checking for and removing excess dust, debris, and mineral
build up from the fixture and glass.
• Cleaning should always be done with the fixture unplugged from its power source. We recommend using low-
pressure compressed air or water to rinse away dust.
PLEASE NOTE:
The light source of this luminaire is not replaceable; when the light source reaches its end of life, the whole luminaire
shall be replaced.
Horticulture lighting is not suitable for household room illumination.

616.947.4888 urbarn.com
© 5.2021
3529 3 Mile Road NW, Grand Rapids, MI 49534
