URC Total Control HDA-IO User manual

HDA-IO
Owner’s Manual
Total Control HDA-IO
Owner’s Manual

Total Control HDA-IO
Owner’s Manual
Overview....................................................................................................................... 1
Features & Benefits:.................................................................................................... 1
Parts & Pieces ............................................................................................................. 2
Front Panel Descriptions ........................................................................................... 3
Rear Panel Description - Using as a Strea Injector .......................................... 5
Rear Panel Description - Using as a Strea Receiver ........................................ 6
Installation Instructions............................................................................................. 7
Network Setup............................................................................................................. 9
HDA Modules ............................................................................................................. 10
Specifications ............................................................................................................ 11
SAFETY PRECAUTIONS ............................................................................................ 12
I portant Safety Instructions.................................................................................. 13
Caution ........................................................................................................................ 13
Federal Co unications Co ission.................................................................. 14
Interference State ent ............................................................................................ 14
Warning! ..................................................................................................................... 14
FCC Caution ................................................................................................................ 14
Li ited Warranty State ent.................................................................................... 15
Dolby Audio ................................................................................................................ 17
DTS 2.0......................................................................................................................... 17
End User Agree ent ................................................................................................. 17
Table of Contents
Congratulations!
The HDA-IO Single-Zone A plifier is URC’s powerful and discrete amplier!
This document highlights product features, LED status conditions, basic installation, and
general speaker wiring instructions
For questions on how this device operates contact your certified URC Integrator or
URC’s Technical Support Tea !
Technical Support
Toll Free: 800-904-0800
Main: 914-835-4484
[e-mail]
H o u r s : 9 : 0 0 a m - 6 p m E S T M - F

1
Total Control HDA-IO
Owner’s Manual
Overview
URC’s HDA-IO Strea Receiver/Injector creates or receives HDA audio strea s
over the network This device must be congured by a certied URC integrator to
function as either a Strea Injector or Strea Receiver
As a Strea Injector, this device distributes any connected audio source (digital
or analog) over the network to any available HDA controlled zone
As a Strea Receiver, the HDA-IO connects to your favorite 3rd party audio
device and provides it with access to all HDA audio strea on the network
HDA products are NOT compatible with URC’s legacy Total Control ampliers (DMS)
Features & Benefits:
• Strea Receiver or Strea Injector Capabilities: Congured via URC
software, the HDA-IO can receive or transmit HDA audio streams over the
local network
• HDA Audio Strea s: As a Stream Injector, this device distributes any
connected audio source to any available HDA controlled audio zone
• Source Sharing: Any zone controlled via an HDA amplier or I/O device has
access to the system’s HDA Audio Streams
• Flexible Zone Linking: When connected to a 3rd party audio device as a
Stream Receiver, the HDA-IO can link that 3rd party zone with any other HDA
controlled zone
• Integrated Audio Sensor: Each available input on the HDA-IO has built-in
audio sensing capabilities These sensors can be used to trigger programmed
events or activities
• Zone Input Ducking: The HDA-IO has the ability to “fade in” an audio input
over the currently selected audio input
The perfect solution to briey lower the volume on the current source to make
an audio announcement or doorbell chime
• Power Configuration Options: The HDA-IO can be powered via PoE or the
supplied 12VDC adapter

2
Total Control HDA-IO
Owner’s Manual
Parts & Pieces
Included with the HDA-IO is the following:

3
Total Control HDA-IO
Owner’s Manual
Front Panel Descriptions
There are three (3) LEDs on the front panel of the HDA-IO:
1. Power LED: Indicates one (1) of the following:
• Solid Blue: Power has been applied to the device and it has
successfully initialized
• Off: Power has been removed from the device
2. Status LED: Indicates one (1) of the following:
• Solid Blue: The device has been programmed with Total Control software
and is ready for operation
• Blinking Blue: The device is receiving a download from the Total Control
programming software
• Blinking Green: The device is receiving a rmware upgrade, this light
continues to blink until the update is fully applied
• Off: The device has not been programmed with Total Control software
1
2

4
Total Control HDA-IO
Owner’s Manual
3. Ethernet LED: Indicates one (1) of the following:
• Solid Blue: The device has received an IP address from the local network
• Blinking Blue: The device is connected to the local network; however, it
has not received an IP address
• Off: The device is not connected to the local network
4. Reset Button: There are two (2) ways to press this button:
• Single Press: Tap the Reset button to power cycle the device
• Factory Reset: Press-n-hold the Reset button for 10 seconds or more
This option cannot be reversed, once the device has been factory defaulted
it requires re-progra ing
34

5
Total Control HDA-IO
Owner’s Manual
Rear Panel Description - Using as a Strea Injector
Below are the available connections on the rear of the HDA-IO:
1. DC IN: Connect the supplied 12VDC adapter to this port to power the
HDA-IO
2. LAN: Full Duplex Gigabit LAN ONLY, for audio streaming and zone control
(Wi-Fi NOT supported, device must be hard-lined to the network)
3. 12 VDC CTRL: Mono 3 5mm connector capable of supplying 150mA of current
4. Analog/Digital Inputs: Both of the following inputs can be used
simultaneously to provide two (2) HDA “high-denition” audio streams:
• Analog - Unbalanced RCA
• Toslink (Optical)
• Digital Coax
1
2
3
4

6
Total Control HDA-IO
Owner’s Manual
Rear Panel Description - Using as a Strea Receiver
Below are the available connections on the rear of the HDA-IO:
1. DC IN: Connect the supplied 12VDC adapter to this port to power the
HDA-IO
2. LAN: Full Duplex Gigabit LAN ONLY, for audio streaming and zone control
(Wi-Fi NOT supported, device must be hard-lined to the network)
3. 12 VDC CTRL: Mono 3 5mm connector capable of supplying 150mA of current
4. Analog/Digital Outputs: Only one (1) of the three (3) available outputs can be
used The HDA-IO as a stream receiver provides 3rd party audio zones with
access to audio sources streaming via HDA
• Analog - RCA Style
• Toslink (Optical)
• Digital Coax
1
2
3
4

7
Total Control HDA-IO
Owner’s Manual
Installation Instructions
The HDA-IO a plifier is supplied with two (2) “L” shaped brackets for ounting
on the wall or secure vertical surface
1 Insert the supplied screws into the two (2) keyed slots on the L shaped bracket
(as displayed on the image at the right)
This L shaped bracket can be pre-installed and the HDA-IO amplier can be
inserted afterwards
2 Insert the supplied screws into the four (4) keyed slots for wall mounting
Keyhole Diameter: 0 48”/12 5mm
1
2

8
Total Control HDA-IO
Owner’s Manual
3 Assure that all screws have been installed securely 3

9
Total Control HDA-IO
Owner’s Manual
Network Setup
When using more than one (1) HDA devices, URC’s HDA-SW5 Network Switch is
REQUIRED on the local network
For more information of the HDA-SW5 Network Switch, please refer to the
HDA-SW5 Owner’s Manual
Although 3rd Party AVB switches may be utilized, they are not supported by
URC’s Technical Support team
Connecting the HDA-IO to the Network:
1 Connect an ethernet cable to an available LAN port on the head-end
network switch
If no switch is connected to the network then connect the ethernet cable to
an available LAN port on the local router (Luxul preferred)
2 Connect the ethernet cable from the previous step to any available LAN port
on the HDA-SW5
3 Connect another ethernet cable to an available LAN port on the
HDA-SW5 Network Switch
4 Connect the ethernet cable from the previous step to the ethernet port
found at the rear of the HDA-IO (page 5)
5 Congure the HDA-IO to a DHCP/MAC reservation within the local router
and program the device into the new or existing Total Control system
Acertified URC integrator is REQUIRED to integrate the HDA-IO into a
new or existing Total Control system
1 2
HDA-IO
Local Router HDA-SW5 Network Switch

10
Total Control HDA-IO
Owner’s Manual
HDA Modules
URC’s HDA line of products contains several two-way odules that are accessible
from any graphical user interface
These modules serve a variety of residential and commercial applications providing
end-users with advanced functionality directly from any URC interface
For specic instructions on how to use these HDA modules, please refer to the
HDA User’s Guide
The following modules are supported by the HDA-IO Multi-Zone A plifier:
• Roo Volu e Module
• Roo / Zone EQ Module
• Volu e Mixer Module
• Announce ent Module
• Input Status
• A plifier Status
• Zone Status
Room / Zone Status
Amplifier Status
Amplifier Status
Room / Zone EQ
Announcements
Not all HDA modules are displayed at
the right, for full details on how these
modules, refer to the
HDA User’s Guide

11
Total Control HDA-IO
Owner’s Manual
Specifications
General:
Audio Inputs:
• 1 Stereo Analog RCA style input
• 1 Toslink (Optical) Digital Input
• 1 Digital Coaxial Input
Audio Outputs:
• 1 Stereo Analog RCA style output
• 1 Toslink (Optical) Digital Input
• 1 Digital Coaxial Input
Height x Width x Depth:
• 1 44” x 4 94” x 5”
Weight:
• 0 65 lbs
Audio:
• 96 kHz / 24-bit streaming
• Dolby Digital® and DTS® 5 1 channel Down ixing (digital inputs only)
• Ducking input capability
• Page event support
• Store up to 10 .WAV files in each amplier (for doorbell ring and/or trigger
alert chimes)
Ther al:
• Operating Te perature: 32°F to 86°F
• Hu idity: Maximum 95%
• Storage: -40°F to 140°F
Power:
• Power Consu ption: 12V DC 0 9A (supplied adapter)

12
Total Control HDA-IO
Owner’s Manual
SAFETY PRECAUTIONS
Risk of electric shock
do not open
CAUTION
To reduce the risk of
electrical shock, do not
remove cover (or back). No
user-serviceable parts inside.
Refer service to a qualified
service professional
caution
WARNING:
The lightning flash with arrowhead sy bol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons
The excla ation point within an equilateral triangle
is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance
TO REDUCE THE RIS OF FIRE OR ELECTRIC
SHOC , DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
To prevent electrical shock,
match wide blade of plug to
wide slot, fully inset.
CAUTION
This device complies with Part 15 of the FCC Rules Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation

13
Total Control HDA-IO
Owner’s Manual
I portant Safety Instructions
• Read Instructions: All the safety and operating instructions should be read
before the apparatus is operated
• Retain Instructions: Safety and operating instructions should be retained for
future reference
• READ all warnings!
• FOLLOW all instructions
• In the event of malfunction, unplug IMMEDIATELY
• Do NOT use the apparatus near WATER
• Clean only with a dry cloth
• DO NOT BLOCK any ventilation openings
• Do NOT install the apparatus upside down
• Do NOT install inside any type of ventilation or AC duct
• Do NOT install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including ampliers) that produce heat
• Do NOT defeat the safety purpose of the polarized or grounding-type plug A
polarized plug has two blades with one wider than the other A grounding type
plug has two blades and a third grounding prong The wide blade or the third
prong are provided for your safety If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet
• ONLY use the attachments/accessories specied by the manufacturer
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus
• Use ONLY with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from
tip-over
• Unplug the apparatus during lightning storms or when unused for
long periods of time
• Refer all servicing to qualied service personnel Servicing required when the
apparatus has been damaged in any way, such as power-supply cord or plug I
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped
Caution
• The ventilation should not be impeded by covering the ventilation openings with
items such as newspapers, tablecloths, curtains, etc
• No naked ame sources, such as lighted candles, should be placed on the unit
• Minimum distances around the apparatus for sufcient ventilation:
20 centimeters
• The product is used in moderate climates
• Do not expose the unit dripping or splashing uids, do not place objects lled
with liquids, such as vases, on the unit

14
Total Control HDA-IO
Owner’s Manual
Federal Co unications Co ission
Interference State ent
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules These limits are designed to provide
reasonable protection against harmful interference in a residential installation
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications
However, there is no guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Warning!
Changes or modications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment
FCC Caution
This device complies with Part 15 of the FCC Rules Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation
Any changes or modications not expressly approved by the party responsible for
compliance could void the authority to operate equipment

15
Total Control HDA-IO
Owner’s Manual
Li ited Warranty State ent
1 Limited Warranty and Disclaimers
Universal Remote Control, Inc (“URC”) warrants that URC equipment
purchased directly from URC or from an authorized URC dealer or distributor
shall be free from defects in material and workmanship under normal usage
for a period of one (1) year from the date of purchase of the product by the
end-user, but no longer than thirty-six (36) months from the date of shipment
of the URC equipment by URC to an authorized URC dealer or distributor,
except that with respect to Total Control® whole-house products, the
warranty extends for two (2) years from the date of purchase by the end-user,
but no longer than forty-eight (48) months from the date of shipment of the
URC equipment by URC to an authorized URC dealer or distributor
This limited warranty is valid only in the United States of America
URC equipment purchased from other than an authorized URC dealer or
distributor is without warranty
URC warrants that the software will substantially conform in any material
respect to its functional specications at the time of delivery URC SHALL
NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS
AND/OR OMISSIONS MADE IN THE URC DOCUMENTATION URC DOES NOT
WARRANT THAT THE URC SOFTWARE IS BUG-FREE OR ERROR FREE OR
THAT THERE ARE NO ERRORS/BUGS IN THE URC SOFTWARE
URC warrants that at the time of purchase the URC equipment and the URC
software complied with all applicable regulations and policies of the Federal
Communications Commission (“FCC”) regarding electromagnetic interference
caused by electronic/computing devices and to the extent that the URC
equipment and/or the URC software fails to so comply, URC shall, at its own
expense, take all reasonable measures to promptly cause such to comply
THIS LIMITED WARRANTY DOES NOT COVER TECHNICAL ASSISTANCE FOR
HARDWARE OR SOFTWARE USAGE EXCEPT AS EXPRESSLY PROVIDED FOR
HEREIN
CERTAIN IMPLIED WARRANTIES, INCLUDING AN IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, MAY BE
AVAILABLE WITH RESPECT TO URC EQUIPMENT IMPLIED WARRANTIES
VARY FROM STATE TO STATE URC EXPRESSLY LIMITS THESE IMPLIED
WARRANTIES, TO THE EXTENT ALLOWABLE BY LAW, TO THE TIME PERIODS
COVERED BY THE EXPRESS WRITTEN WARRANTIES PROVIDED HEREIN
OTHERWISE AND EXCEPT AS PROVIDED FOR HEREIN, URC EXPRESSLY
DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR IMPLIED, AND
MAKES NO REPRESENTATIONS REGARDING THE USE OF, OR THE RESULTS
OF THE USE OF, THE EQUIPMENT, SOFTWARE OR DOCUMENTATION IN
TERMS OF CORRECTNESS, ACCURACY, RELIABILITY OR OTHERWISE
EXCEPT AS EXPRESSLY PROVIDED FOR HEREIN, TECHNICAL SERVICES ARE
SUPPLIED “AS IS”, WITHOUT ANY WARRANTY, EXPRESS, STATUTORY OR
IMPLIED, OF ANY KIND TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, URC EXPRESSLY DISCLAIMS ALL WARRANTIES RELATING
TO TECHNICAL SERVICES, EXPRESS, STATUTORY OR IMPLIED, INCLUDING
BUT NOT LIMITED TO THE WARRANTIES OF QUALITY OR REASONABLE
SKILL AND CARE, OR OUTCOME OR RESULTS
WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER
PROVISIONS HEREIN, THIS LIMITED WARRANTY DOES NOT COVER: (I)
DAMAGE FROM MISUSE, NEGLECT OR ACTS OF NATURE, (II)
MODIFICATIONS, (III) INTEGRATION WITH THIRD PARTY CONTENT, OR (IV)
BEYOND THE WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC
WARRANTY CLAIM PROCEDURE
The warranty limitations and warranty disclaimers may not apply to end user

16
Total Control HDA-IO
Owner’s Manual
in whole or in part, where such are restricted or excluded by applicable law,
and such shall apply to the maximum extent permitted by applicable law
In the event of any warranty claim, URC will, at its sole option, repair the
URC equipment using new or comparable rebuilt parts, or exchange the URC
equipment for new or rebuilt equipment In the event of a defect, these are
the end user’s exclusive remedies
All the URC equipment returned for service, exchange or repair require an
RGA number To obtain an RGA number, you must complete a Return Request
Form which you may obtain by calling [phone] or contacting URC
at returnrequest@urc-automation com To obtain warranty service, end user
must deliver the URC equipment, freight prepaid, in its original packaging or
packaging affording adequate protection to URC at 37 Ramland Road, Unit
104, Orangeburg, NY 10962 It is end user’s responsibility to backup any
macro programming, artwork, software or other materials that may have
been programmed into the unit It is likely that such data, software, or other
materials will be lost during service and URC will not be responsible for any
such damage or loss A dated purchase receipt, bill of sale, installation
contract or other veriable proof of purchase is required For the URC
equipment support and other important information, please visit URC’s
website available at www urc-automation com or call the Customer Service
Center at [phone]
This limited warranty only covers the URC equipment issues caused by
defects in material or workmanship during ordinary consumer use It does not
cover product issues caused by any other reason, including but not limited to
product issues due to commercial use, acts of God, third-party installation,
misuse, limitations of technology, or modication of or to any part of the URC
equipment This limited warranty does not cover the URC equipment sold as
used, as is, refurbished, so called “B stock” or consumables (such as
batteries) This limited warranty is invalid if the factory applied serial number
has been altered or removed from the URC equipment This limited warranty
specically excludes the URC equipment sold by unauthorized resellers
With the exception of URC’s IR-only, broad-based consumer remotes, none of
URC’s PC programmable remotes or any of our Total Control® whole-house
equipment are authorized for online internet sales Buying URC’s PC
programmable remotes or any of our Total Control® whole-house equipment
online means buying equipment that does not have URC’s limited warranty
Such equipment is not eligible for URC tech support or software support,
either
2 URC’s Limitation of Liability
IN NO EVENT SHALL URC BE LIABLE FOR INDIRECT, SPECIAL, INCIDENTAL,
EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES OF ANY KIND OR
LOSS OF PROFITS OR BUSINESS OPPORTUNITY, EVEN IF URC IS ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES
IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO DATA,
COMPUTER SYSTEMS OR COMPUTER PROGRAMS
URC’S LIABILITY, IF ANY, FOR DIRECT DAMAGES OF ANY FORM SHALL BE
LIMITED TO ACTUAL DAMAGES, NOT IN EXCESS OF AMOUNTS PAID BY
END USER FOR THE URC EQUIPMENT
IN NO EVENT SHALL URC BE LIABLE FOR ANY EVENTS BEYOND ITS
CONTROL, INCLUDING ANY INSTANCE OF FORCE MAJEURE
IN NO EVENT SHALL URC BE LIABLE FOR THE ACTS OR OMISSIONS OF END
USER OR ANY THIRD PARTY
THE LIMITATIONS OF LIABILITY MAY NOT APPLY TO END USER IN WHOLE
OR IN PART, WHERE SUCH ARE RESTRICTED LIMITED OR EXCLUDED BY
APPLICABLE LAW AND SUCH SHALL APPLY TO THE MAXIMUM EXTENT

17
Total Control HDA-IO
Owner’s Manual
PERMITTED BY APPLICABLE LAW
URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS MADE BY
OTHERS
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO END USER THIS
LIMITED WARRANTY GIVES END USER SPECIFIC LEGAL RIGHTS AND END
USER MAY HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR
JURISDICTION TO JURISDICTION
Dolby Audio
Manufactured under license from Dolby Laboratories Dolby and the double-D symbol
are trademarks of Dolby Laboratories
DTS 2.0
For DTS patents, European patent numbers 0864146 and 1741093 and U S patent
numbers 5,956,674, 5,974,380, 5,978,762, 6,487,535, 7,333,929 and 7,548,853
Manufactured under license from DTS, Inc DTS, Digital Surround, DTS 2 0 + Digital
Out, and the DTS logo are registered trademarks or trademarks of DTS, Inc in the
United States and other countries ©2020 DTS, Inc ALL RIGHTS RESERVED
End User Agree ent
The terms and conditions of the End User Agreement are available at:
https://www urc-automation com/legal/end-user-agreement/
