US Alert watchdog Operating and installation instructions

USAlert WatchDog Voice
Pager
WatchDog Features
* 2-Tone Voice Coding Format
* IP66 Certified
* 1, 2, or up to 5 Selectable Channels
* 15 Addresses per Channel
* Fully Synthesized
* Wideband and True Narrowband Models
* 16 Character True Alphanumeric Display
* 4 Minutes of Stored Voice Optional
* 2 Year Warranty
* Built in the USA
The USAlert WatchDog is a 2-Tone Voice pager specifically developed for the public safety market to alert firemen and other
emergency personnel monitoring or responding to time critical emergency situations. Operational in the VHF or UHF
frequency bands, the pager is fully synthesized and comes in both wideband and true narrowband models. With separate
receiver boards for wideband and narrowband operation, the pager is not only narrowband capable, it is narrowband
compliant. 15 individual addresses are available on each channel, 10 standard 2-Tone addresses and 5 long tone addresses.
The pager is designed for harsh and rugged environments, has a very loud and clear audio output, and is easy to operate.
Holding an IP66 certification, the highest IP rated pager on the market today, the WatchDog is protected against dust and high
pressure jets of water from all directions.
The WatchDog pager ships with "AAA" sized rechargeable NiMH batteries and a charger. Standard "AAA" Alkaline batteries
can also be used with this product if desired. A battery charger with an antenna to extend the range of message reception is
available as an option. All pagers come with a standard 2 year warranty, an optional 5 year warranty and are built in the USA.
A free 30 day demo unit is available upon request.
WATCHDOG PAGER CONTROLS AND FUNCTIONS
On / Off and Volume Control
The On / Off Volume Control is located on the top of the pager and allows turning the pager on or off. The control also
provides a continuous adjustment for the audio and alert levels, providing the alert is not programmed for the maximum
volume setting.
3-Position Function Switch
The 3-Position Function Switch is located on the top of the pager in the center. Each position can be individually programmed
for the desired channel and type of alerting. Scan is only selectable in switch position two.
Reset Button
The Reset Button is located on the top of the pager and is typically used to reset the audio and put the pager back into the
standby mode. It can also be used to place the pager into the "quick monitor" or "audio lock on" mode of operation. Depress
the reset button and release in less than .75 seconds and the pager will return to the standby mode. Press and hold for .75
but less than 1.5 seconds and the pager will enter monitor mode. Press for more than 1.5 seconds and the audio will lock on

and remain on continuously until reset.
LCD Display
The WatchDog pager incorporates a 16 character true alphanumeric front panel display. One display function provides
personalized start up screen text that can be customized in the WatchDog programmer. There is also a provision to add
standby screen text if desired.
Additionally, the WatchDog pager will display TEXT assigned to an address, date and time that an alert was received, and the
sequence number of the message.
The WatchDog also allows programming special text in the code plug programmer of up to 14 characters to be displayed
when that address has been alerted. The display will alternately show the pre-programmed text, then the alert number with
date and time stamp.
Front Control Buttons
There are three buttons located on the front of the pager. The far left button provides entry into the pagers menu and controls
advancing thru the menu in a forward direction. The center button also provides entry into the pagers menu and controls
advancing thru the menu in a reverse direction. The right button provides the playback function for models with voice memory
and the select function if any item needs to be changed as s elected in the pagers menu.
Voice Memory Playback
WatchDog models with voice memory can dynamically record up to 4 minutes of messages. Messages can be played back
using the right button to initiate play back and then using the left and center buttons to select which message to replay. If no
messages are stored, the display will show "NO VOICE MESSAGE".
Stored messages are retained in memory even if the pager is powered off or the batteries removed. Messages can be deleted
individually or all at one time. A message can also be protected from accidental removal by using the "Protect Message"
feature.
WatchDog Scan Operation
The WatchDog pager has three types of scan, "Priority Scan", "Selective Call Scan", and "Channel Scan". To enable any
scanning feature, position 2 of the 3-Position Function Switch must be programmed to the "Scan" setting.
2-Channel WatchDog models can be setup to scan between frequency 1 (F1) and frequency 2 (F2). 5-Channel WatchDog
models can be setup to scan between frequency 1 (F1) and up to four other channels with the channel being monitored
designated as (F2). Enabling up to four channels for (F2) operation is performed in the WatchDog programming software.
Changing which channel is designated as (F1) and which is (F2) is accomplished through the three front panel buttons of the
pager and the menu items shown in the LCD display. With the latest version of the WatchDog firmware, all enabled channels
can be scanned, regardless of which channel is designated as (F2).
If "Priority Scan" is selected, the WatchDog pager will alternately search from (F1) to (F2) looking for the presence of a carrier.
Alerting can only occur on the priority channel (F1). If channel activity is detected on (F2), the WatchDog pager will process
voice on (F2) and periodically scan back to (F1) looking for the presence of a carrier.
The "Selective Call Scan" mode allows the WatchDog to silently scan from channel to channel looking for address tones. The
pager will only open the audio path based on detection of an address and not just channel activity. If a proper address is
detected, the WatchDog will alert and open the audio path for messaging.
"Channel Scan" mode will alternately search from (F1) to (F2) looking for the presence of carrier. The primary function of
"Channel Scan" is to allow monitoring any activity on either channel. Only one channel can be actively monitored at a time

and no alerting can occur on either channel.
