ADVISOR II
™
ONE WAY FLEX
ALPHANUMERIC
PAGER
ADVISOR II ALPHANUMERIC PAGER
Alphanumeric
messaging
in a feature-rich
pager ideal
for demanding
business
environments.
Model Number
A03DXS5862AA - VHF
A05DXS5862AA - 900 MHz
Synthesized
Hard-working Business Tool
ADVISOR II™FLEX ALPHANUMERIC PAGER
The Advisor II pager provides exciting capabilities in
messaging and can become a vital part of your daily
business life. The pager’s four-line display and
expanded functionality incorporate many of the most
advanced paging features available. These features
include 52 message slots for storing multiple pages,
both a personal notebook and mail drop notebook
area for message management, and a large electro-
luminescent display with zoom feature for
easy readability.
The Advisor II pager is synthesized to allow for pro-
gramming in the field, utilizes FLEX technology, and
is available in either VHF or 900 MHz models.
Quick User Guide:
• Displays up to 4 Lines of Text and
80 Characters per Line
• Optimax®EL Electra Light for Optimum Readability
• Zooms in on 2 Lines for Larger View
• 52 Message Slots and 4 Individual Cap Codes

VHF FREQUENCY RANGE
900 MHz FREQUENCY RANGE
Band C 163-174 MHZ
Band A 929-932 MHz
SPECIFICATIONS VHF
Transmission Speed: 1600 / 3200 / 6400 Baud Rate
Modulation: +/- 4.8 KHz
Channel Band Width: 25KHz
Intermediate Frequency: 21.4 MHz
Sensitivity (typical): 8uv/m(1600BPS) / 11uv/m(3200BPS) /
13.5uv/m(6400BPS)
Adjacent Channel Selectivity: 55 dB
Image Frequency Rejection: 40 dB
Spurious Response Rejection: 50 dB
Intermodulation Rejection: 50 dB
Alert Response: 78 dB @ 12”
Ambient Working Temperature: +5° C to 40° C
Battery: 1.5 Volt "AA" Alkaline x 1
Dimension: 81mm(l) x 55mm(w) x 18.5mm(h)
UL Rating: Class I, Division 2, Groups A, B, C, D
Class II, Division 2, Groups F, G
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.
All other product or service names are the property of their respective owners.
© Motorola, Inc. 2004.
ADVISOR II
TM FLEX PAGER HAS THESE FEATURES:
DISPLAY:
• Displays up to 4 Lines of Text and
80 Characters per Line
• Up to 30,000 Maximum Character Capacity
• Optimax®EL Electra Light for Optimum Readability
• Zooms in on 2 Lines for Larger View
• Displays Time of Day and Date
INDICATORS/ALERT FEATURES:
• Built-in Alarm Clock
• Event Alarm that Allows the User to Set a
One-Time or Daily Alarm for up to 5
Personal Messages
• User-Selectable Alerts, Including
Vibrating Alert, Standard Alert,
Chirping Alert, Seven Different
Pleasing Alerts, or No Alert (Silent)
• Reminder Alert to Notify the User of
Unread Messages
• Graphic Battery Gauge that Shows
Battery Level
MESSAGING:
• 52 Message Slots for Storing
Multiple Pages
• 4 Individual Cap Codes to Allow the
User to Receive Individual or
Group Pages
• Message Time and Date Stamping
that Indicates When Each Message was Received
• Message Preview to Allow the User to View the
First Line of Each Message for Easy Reference
• Locks up to 10 Messages, Preventing Them From
Being Replaced When Memory is Full
• Duplicate Message Management that Indicates
When Additional, Identical Pages are Received
• Selective Erase/Erase All Feature that Allows the
User to Erase Messages Individually or All at Once
• Saves Messages When Off or When the Battery is
Being Changed
• 2 Notebook Areas, Including a Personal Notebook
for Storing Personal Messages and a Mail Drop
Notebook for Storing Information Service Messages
6880309S12
REV 10/04
For more information, please contact:
SPECIFICATIONS 900 MHZ
Transmission Speed: 1600 / 3200 / 6400 Baud Rate
Modulation: +/- 4.8 kHz
Channel Band Width: 25KHz
Intermediate Frequency: 44.45 MHz
Sensitivity (typical): 8uv/m(1600BPS) / 11uv/m(3200BPS) /
13.5uv/m(6400BPS)
Adjacent Channel Selectivity: 40 dB
Image Frequency Rejection: 40 dB
Spurious Response Rejection: 40 dB
Intermodulation Rejection: 40 dB
Alert Response: 78 dB @ 12”
Ambient Working Temperature: 5° C to 40° C (40° F to 105° F)
Battery: 1.5 Volt "AA" Alkaline x 1
Dimension: 81mm(l) x 55mm(w) x 18.5mm(h)
UL Rating: Class I, Division 2, Groups A, B, C, D
Class II, Division 2, Groups F, G
