USFilter PHARM40 RO Installation guide

Serial # ____________________
PHARM40 RO
Reverse Osmosis
System
Operation & Maintenance
Manual
S.O. # XXPXXX
Covers:
Model
P43PP06 P43SS06
P43PP09 P43SS09
P43PP12 P43SS12
P44PP16 P44SS16
P44PP20 P44SS20
P44PP24 P44SS24
PN 68/S1501
June 2003
Revision C
USFilter
10 Technology Drive
Lowell, MA 01851 USA
Tech Support [phone]
Customer Service [phone]

NOTICE
U.S. Filter is constantly striving to improve its products and services.
Consequently, the information in this document is subject to change without
notice and should not be construed as a commitment by U.S. Filter. Also, U.S.
Filter assumes no responsibility for any errors that may appear in this
document. This manual is believed to be complete and accurate at the time of
publication. In no event shall U.S. Filter be liable for incidental or
consequential damages in connection with or arising from the use of this
manual.
U.S. Filter warrants its products against defects in materials and workmanship
as described in the Warranty statement on the preceding pages.
U.S. Filter is a trademark of United States Filter Corporation.
1996 United States Filter Corporation
Printed in the United States of America. All rights reserved.
THIS MANUAL OR PARTS THEREOF MAY NOT BE REPRODUCED
IN ANY FORM WITHOUT THE WRITTEN PERMISSION OF THE
PUBLISHERS.

U.S. FILTER
TABLE of CONTENTS
SECTION PAGE
TECHNICAL ASSISTANCE..................................................................... i
I. QUICK START INSTRUCTIONS...................................................... 1
A) Warnings & Cautions..................................................................... 1
1) Installation Precautions............................................................. 1
2) Operating & Maintenance Precautions ................................... 3
B) Getting Started................................................................................ 3
1) Installation Summary................................................................ 3
2) Startup Summary....................................................................... 4
II. INTRODUCTION.................................................................................. 5
A) About Your Pharmaceutical RO System...................................... 5
B) About This Manual......................................................................... 6
III. SYSTEM INSTALLATION................................................................ 8
A) Pre-Installation Requirements....................................................... 8
1) Tools............................................................................................ 8
2) Additional Equipment............................................................... 8
3) Feed Water Requirements......................................................... 9
4) Operating Environment ............................................................ 10
5) Space Requirements................................................................... 10
6) Drain Requirements................................................................... 11
7) Power Requirements.................................................................. 11
B) Inspection......................................................................................... 11
C) Unpacking The System................................................................... 11
D) Check Plumbing Fittings................................................................ 12
E) Plumbing Connections.................................................................... 12
F) Electrical Connections.................................................................... 13
1) Power Connections..................................................................... 13
2) Call for Water Connection........................................................ 13

U.S. FILTER
TABLE of CONTENTS
SECTION PAGE
IV. INITIAL SYSTEM STARTUP ........................................................... 14
A) Initial Startup Prep......................................................................... 14
B) RO Membrane Installation & Removal........................................ 15
C) Pre-Startup Checklist..................................................................... 18
D) Adjust Control System Settings For Startup ............................... 18
E) Startup & Membrane Flushing Procedure .................................. 19
F) Set Operating Flow Rates .............................................................. 20
G) Place RO Unit In Service................................................................ 21
V. SYSTEM OPERATION........................................................................ 22
A) Operating Modes ............................................................................ 22
1) Introduction................................................................................ 22
2) Standby Mode ............................................................................ 22
3) Rinse Mode................................................................................. 23
4) Service Mode .............................................................................. 23
5) System Shutoff............................................................................ 23
6) Sequence of Operations............................................................. 23
B) Controls & Indicators..................................................................... 24
1) Introduction................................................................................ 24
2) Monitoring Devices.................................................................... 24
3) Selector Switches........................................................................ 24
4) Push Button Switches ................................................................ 25
5) Status Pilot Lights...................................................................... 25
6) Alarm Pilot Lights...................................................................... 26
C) Alarms.............................................................................................. 26
1) Shutdown Alarms ...................................................................... 26
2) General Alarms.......................................................................... 26
3) Alarm Chart............................................................................... 27
4) High Product Flow Rate Alarm Chart..................................... 27
5) Low Reject Flow Rate Alarm Chart ........................................ 28

U.S. FILTER
TABLE of CONTENTS
SECTION PAGE
VI. RO CLEANING & SANITIZATION PROCEDURES .................... 29
A) Introduction..................................................................................... 29
B) Handling Chemicals........................................................................ 30
1) Protective Clothing .................................................................... 30
2) First Aid...................................................................................... 30
3) Precautions ................................................................................. 30
C) Cleaning........................................................................................... 32
1) Required Cleaning Equipment................................................. 23
2) Cleaning Frequency Guidelines................................................ 33
3) Cleaning Chemicals ................................................................... 33
4) Cleaning Connections................................................................ 35
5) Operational Considerations...................................................... 36
6) Preparation for Cleaning .......................................................... 37
7) Cleaning Procedures.................................................................. 37
D) Sanitization...................................................................................... 39
1) Sanitization Chemicals .............................................................. 39
2) Sanitization Connections........................................................... 40
3) Sanitization Procedures............................................................. 40
VII. MAINTENANCE ............................................................................... 44
A) Long Term Shutdown .................................................................... 44
B) Membrane Preservation................................................................. 44
C) Membrane Replacement ................................................................ 46
D) Maintenance Schedule.................................................................... 46
E) Recording Data ............................................................................... 46
VIII. TROUBLESHOOTING..................................................................... 48

U.S. FILTER
TABLE of CONTENTS
SECTION PAGE
IX.THEORY OF OPERATION ................................................................ 50
A) Introduction..................................................................................... 50
B) Operating Modes ............................................................................ 50
1) Standby Mode ............................................................................ 50
2) Rinse Mode................................................................................. 51
3) Service Mode .............................................................................. 54
X. SYSTEM DESCRIPTION & SPECIFICATIONS............................. 56
A) General Description........................................................................ 56
B) Design Parameters.......................................................................... 56
C) Mechanical Description.................................................................. 56
D) Electrical Description..................................................................... 57
E) Control System Components ......................................................... 57
F) Alarm Conditions............................................................................ 58
G) Unit Shutdowns............................................................................... 58
H) Pretreatment & Post Treatment Communications Signals......... 58
I) Component Specifications.............................................................. 60
J) Operating Limits............................................................................. 62
K) Specifications For Standard Models............................................. 63
APPENDIX………………………………………………………………... 66
Material Safety Data Sheets
PLC Program
Mechanical & Electrical Drawings
Manufacturer’s Data

TECHNICAL ASSISTANCE
Page - i
TECHNICAL ASSISTANCE
Please write the system serial number in the space provided on the manual
cover. Keep this information available when you phone U.S. Filter for
assistance.
If you require technical assistance in the United States, please contact U.S.
Filter at the address and phone/fax numbers listed below:
U.S. Filter
10 Technology Drive
Lowell, MA 01851
Telephone: [phone]
800-875-7873 (ext. 5000)
Fax: [phone]
Outside the U.S.A., please contact the nearest U.S. Filter office among those listed below:
France
USF/Ionpure
1/3 Rue Pavlov BP #150
78196 Trappes Cedex
FRANCE
Telephone: [phone]
Fax: [phone]
Belgium
USF/Ionpure
Parc Scientifique
Rue du Bosquet, 7
1348 Louvain la Neuve
BELGIUM
Telephone: [phone]
Fax: [phone]
Germany
USF/Seral
Industriegebiet Struth
Eulerstrasse
56235 Ransbach-Baumbach
GERMANY
Telephone: [phone]
Fax: [phone]
Ireland
USF/Ionpure
Brace Business Park
Bracetown
Clonee, County Meath
IRELAND
Telephone: [phone]
Fax: [phone]
Italy
USF/Ionpure
Via Cesare Pavese, 5/7
20090 Zerbo Opera
ITALY
Telephone: [phone]
Fax:[phone]
The Netherlands
USF/Ionpure
Mon Plaisir, 87B
4879 Am Etten-Leur
THE NETHERLANDS
Telephone: [phone]
Fax: [phone]

TECHNICAL ASSISTANCE
Page - ii
TECHNICAL ASSISTANCE (continued…..)
England
USF/Ionpure
Harforde Court
John Tate Road
Hertford, SG 13 7NW
ENGLAND
Telephone: [phone]
Fax: [phone]
Sweden
USF/Ionpure
Vasermalmvagen 5
791 77 Falun
SWEDEN
Telephone: [phone]
Fax: [phone]
Spain
USF/Ionpure
San Romualdo, 12-14 1Dcha
28037 Madrid
SPAIN
Telephone: [phone]
Fax: [phone]
Mexico
U.S. Filter de Mexico
Av. Homero #229-102
Col. Polanco
MEXICO, D.F. 11560
Telephone: [phone]
Fax: [phone]
Spain
USF/Ionpure
Sation
Luchana, 77
08005 Barcelona
SPAIN
Telephone: [phone]
Fax: [phone]
Mexico
U.S. Filter de Mexico
Av. Alejandro Humboldt 17606-4
Fracc. Garrita de Otay
Tijuana, B.C. 22500
MEXICO
Telephone: [phone]
Fax: [phone]
Venezeula
U.S. Filter Sistems De Venezuela, S.A.
Calle Gualcalpuro, Torre Taeca
Piso 3, Oficina 34, El Rosal
Caracas
VENEZUELA
Telephone: [phone]
Fax: [phone]
Argentina
U.S. Filter Argentina S.A.
Tucuman 141
Piso 5 Oficiana A
(1049) Buenos Aires
ARGENTINA
Telephone: [phone]
541 311 4461
Fax: [phone]

TECHNICAL ASSISTANCE
Page - iii
TECHNICAL ASSISTANCE (continued…..)
Australia
USF/Permutit Company
3/4 Skyline Place
Frenchs Forest
New South Wales 2086
AUSTRALIA
Telephone: [phone]
Fax: [phone]
New Zealand
USF/Permutit Company
3 Gloucester Park Road
Onehunga, Auckland 6
NEW ZEALAND
Telephone: [phone]
Fax: [phone]
Puerto Rico
USF/Ionpure Puerto Rico
PMB 339 HC-01
Cauguas, PUERTO RICO 00725-8900
Telephone: [phone]
Fax: [phone]
Hong Kong
USF/Ionpure Hong Kong
3208 Shell Tower
Times Square
Causeway Bay, HONG KONG
Telephone: [phone]
Fax: [phone]

I. QUICK START INSTRUCTIONS
Page - 1
I. QUICK START INSTRUCTIONS
ATTENTION!
This manual covers installation, operation, maintenance and troubleshooting of
the U.S. Filter PHARM40 ROSystem. Additional manuals are required for
any related equipment (e.g., softeners, prefilters). If you do not have all the
required manuals, call U.S. Filter Technical Support at one of the locations
listed on the Guide to Technical Assistance that immediately precedes these
Quick Start instructions.
Although U.S. Filter strongly recommends that all users read the entire
contents of the PHARM40 RO manual, we also recognize that some
experienced technicians may desire a quick start summary of essential
information.
Your warranty may be voided if installation or operation instructions contained in
the PHARM40 RO System manual are not followed exactly.
At a minimum, please read these Quick Start instructions before attempting to
install or operate your RO system.
A. Warnings & Cautions
This manual uses the following conventions to present information:
WARNING
WARNING: Situation could lead to personal injury. You should not proceed until you
read and thoroughly understand the WARNING message.
CAUTION
CAUTION: To avoid equipment malfunction or damage. You should not proceed until
you read and thoroughly understand the CAUTION message.
NOTES
NOTE: Provides additional information about an activity or concept.
1) Installation Precautions
WARNING
Potentially dangerous electrical power is present inside both the Main Control
Panel and the High Voltage Control Panel.
THEREFORE, BEFORE TOUCHING THE INSIDE OF EITHER ENCLOSURE,
CONFIRM THAT AC POWER TO THE RO SYSTEM HAS FIRST BEEN
DISCONNECTED AND LOCKED OUT ACCORDING TO STANDARD
LOCKOUT/TAGOUT PROCEDURES.
