usha FH 3213-H User manual

FAN HEATER
Model No.: FH 3213-H
INsTRucTIoN MANuAl

2
Dear Customer,
Congratulations!
You are now the proud owner of Usha Fan Heater (Model No.: FH 3213-H)
Innovatively designed, using only the highest quality material and components,
your Usha Fan Heater (Model No.: FH 3213-H) is designed for years of trouble
free performance.
Please read this Instruction Manual carefully before using and keep it cautiously
after reading for future reference.
Best Wishes

3
Before using the unit, read the present instructions carefully and keep them for
future reference.
• Beforeswitchingtheunitonreadthisinstructioncarefully.
• Beforeusingtheapplianceforthefirsttimemakesurethatoperatingvoltage
of the unit corresponds to the voltage in your mains.
• In order to avoid risk of fire, do not use adapters while connecting the
appliance to the outlet. Never insert the plug into defective or worn-out
outlets.
• In order to avoid network overloading, provide that no other electrical
appliances with higher power consumption are connected to the same outlet
the unit is connected to.
• Duringoperationthegridheatsupheavily.Becareful.Avoidcontactofthe
unit with your skin to prevent getting burns.
• The distance between the unit and furniture, pillows, furnishing, papers,
clothes, and curtains should be at least 1m far from the front of the fan heater
and keep them away from the sides and rear.
• Nevercoverthefanheaterwithclothesorfabricmaterialsduringoperation.
• Closesupervisionisnecessarywhenchildrenordisabledpersonsarenear
the unit.
• Thisunitisnotintendedtobeusedbychildrenordisabledpersons.
• Donotmove,hanguporcarrythecordoftheappliance
• Donotoperatethefaninarestrictedspace(forinstance,inbuilt-inclosetsor
wall alcoves - for tubes defrosting or to prevent their freezing).
• Neverwindthecordoverthecaseoftheunit.
• Do not switch on and do not use the fan heater if the cord or the plug is
damaged or if the fan heater works irregularly, fell or is damaged. In this
case, please contact your nearest authorized Usha service centre.
• Donotusethefanheaterinoutdoors.
• Thisfanheaterisnotintendedforuseinbathroomsorinplaceswithhigher
moisture.
• Donotplacethefanheaterinplaces,whereitcanfallinabathorother
container filled with water.
• Ifsomewatergetsonthefanheater,beforetouchingityoushouldunplugit
in order to avoid risk of getting electric shock.
• Do not cover the cord with mats, carpet strips etc. The cord should be
situated away from walking route and do not place any objects on it.
IMpoRTANT pREcAuTIoNs

4
• Donotpoursodawaterorperfumeadditivesintothewatertank.
• Donotblocksteamoutletsandprovidethatforeignobjectsdonotgetinside
them.
• Do not insert any object into gratings of the fan heater in order to avoid
electrical shock, fire or damage of the unit.
• Makesurethatairinletsandoutletsarenotblockedduringoperation.Do
not place the fan heater on soft surfaces, for instance, bed in order to avoid
blockage of air openings and fire.
• Alwaysunplugtheunitandpouroutwaterfromthewatertankduringcleaning
the unit, if you do not use it. If you want to move the unit to another place,
unplug the unit first.
• Donotusethefanheaterinplacesnearpetrol,paintsorinflammableliquids
storage.
• Donotleavethefanheateroperatingwhilesleeping.
• Alwaysswitchoffandunplugthefanheaterifitisnotbeingused.
• Thefanheaterisintendedonlyforhouseholduse.
FuNcTIoN
Description
1. Support
2. Front grid
3. Steam outlet
4. Steam intensity control
5. Display
6. Control panel
7. On/Off button (0/I)
8. Carrying handle
9. Water tank
10. Water tank removing handle
11. Water tank tray
12. Power cord
Control panel
13. Temperature“+”“-“buttons
14. Steam intensity control
15. Low heating power button
16. Maximal heating power button
17. Timersettingbutton
18. Rotation on/off button

5
19. ON/OFF button
20. Humidifying function button
Display
21. Temperatureindicator(˚C,˚F)
22. Automatictemperaturemaintenanceindicator
23. Low power indicator
24. Maximal power indicator
25. Humidifying function indicator
26. Timebeforeendoftheoperationindicator
27. Empty water tank indicator
28. Power indicator
29. Fan mode indicator
30. Heating mode indicator
Remote control
31. Temperatureincrease/decreasebutton
32. Humidifying function on button
33. Rotation on/off button
34. Timersettingbutton
35. Heating power selection button
36. On/Off button

6
opERATIoN
Insertthe plug(12)into theelectricalsocket, andsetthe button(7)tothe“I”
position. The light indicator (28) will light up and sound signal will be heard.
Using the buttons on the control panel:
• Press the ON/OFF button (19), sound signal will be heard and fan mode
indicator (29) will light up, room temperature indicator (21) will be displayed.
• Toselectlowpower,pressthe(15)button,theindicators(23)and(30)will
light up; to select maximal heating power, press the (16) button, the indicators
(24) and (30) will light up.
Note
- Use low power for small rooms heating, and max. power for large rooms
heating.
• Set the required temperature for heating by pressing the (13) “- “or “+”
buttons, the indicator (22) will light up
Note
- When room temperature exceeds the preset temperature by 2°, the fan
heater will switch off.
- Thefanheaterwillswitchonagainwhentemperaturedecreasesby1°lower
than the preset temperature.
• Youcansettemperaturefrom4˚C(39˚F)to32˚C(90˚F),settingstepis1˚C.
Note
- In this unit possibility to change temperature indication is intended from
Celsius(˚C)toFahrenheit(˚F).Pressandholdthe(13)buttons“-“and“+”
more than 3 seconds.
• Toswitchonhumidifyingfunctionpressthe(20)button,theindicator(25)will
light up.
Note
- If the water tank is not full, when you press the (20) button the indicator (27)
will light up, it means that the water tank is empty.
• Switching on the fan heater rotation mode during heating the room is
performed with the (18) button, to switch off the rotation press the (18) button
again.
• Timertimeselectionisperformedwiththe(17)button,theresettimewillbe
displayed. You can set operation time from 1 till 8 hours (1h, 2h, 4h, 8h).
• Toswitchoffthefanheaterpressthe(19)button,setthe(7)buttontothe“0”
position, and then unplug the unit.

7
HuMIDIFYING FuNcTIoN
Note:
- If the unit was subjected to negative temperatures, then before first switching
on it is recommended to keep the unit for 30 minutes at room temperature.
- Usetheunitwhentheroomtemperatureisfrom+5 to+40˚Candrelative
humidity is lower than 80%.
- Watertemperatureshouldnotbeabove+40˚C.
1. Unplug the unit.
2. Takethehandle(10),removethetray(11)andthewatertank(9).
3. Turnoverthewatertank(9),openthelid,turningitanticlockwise.
4. Fill the water tank (9) with the necessary quantity of water and close the lid,
by matching the ledges on the lid with the grooves on the water tank and then
rotate the lid clockwise.
5. Place the filled water tank (9) on the tray (11), and then install the assembled
construction into the unit. Wait for some time, which is necessary for filling
the operation chamber with water.
6. Connecttheunittothemains,setthebutton(7)tothe“I”position,thepower
indicator (28) will light up and you will hear a sound signal.
7. Switch on the unit, by pressing the on/off button (19), you will hear a sound
signal, unit operation in the fan mode indicator (29) will light up and the room
temperature (21) indicator will be displayed.
8. Press the (20) button to switch on the humidifying function.
9. You can control steam output intensity by turning the handle (14).
10. If during the humidifying function operation the water tank (9) becomes
empty, the (27) indicator will light up on the display, and the unit will give a
signal to the user. In 3 minutes the unit will switch off automatically.
Note:
- If the water tank (9) becomes empty, the (27) indicator will light up; You
should take off the water tank and fill it with water.
- If during the humidifying function operation the tray with the water tank is
removed, the unit will switch off automatically.
clEANING AND MAINTENANcE
Warning! Always switch off and unplug the unit before cleaning. Hard water
causes appearance of mineral deposits on the sprayer, inner parts of the body
and in the water tank that leads to depression of operation of the unit and
appearanceofwhitebloomontheinnerpartsofthecontainerandthetray.To

8
avoid it, it is necessary to clean the sprayer weekly and to change water as often
as possible. If you are not going to use the humidifying function for a long time:
- pour out water from the water tank and the sprayer, wash the water tank,
wash and clean the operating chamber of the sprayer and the sprayer itself,
dry thoroughly and take the unit away for storage.
Daily care
• Thoroughlywashthewatertank(9)andthetrayunderthewatertank(11)
once a week with a solvent with a neutral detergent. After it rinse them
thoroughly with water.
• Add5-10dropsofpurifyingdetergentonthesprayer;waitabout2-5minutes.
Thenremovethebloomfromthesurfaceofthesprayer.
Using the remote control
Open the lid of the battery compartment of theremote control and insert 2
batteries of “AAA” type, strictly following the polarity, close the battery
compartment lid.
• Presstheon/offbutton(36),youwillhearasoundsignal,operationofthe
unit in the fan mode indicator (29) will light up and the room temperature
indicator (21) will be displayed.
• Power is selected with the (35) button. Use low power for small rooms
heating, and max. power for large rooms heating.
• Setthenecessaryroomtemperatureusingthebuttons(31)«+»«-».
• Toswitchonrotationpressthe(33)button,pressthebutton(33)againto
switch off rotation.
• Youcanselectthetimeroperationtimeusingthe(34)buttonontheremote
control or the (17) button on the control panel.
• Pressthe(32)buttontoswitchonhumidifyingfunction.
• Toswitchonthefanheaterpressthe(36)buttonontheremotecontrol,set
thebutton(7)tothe“0”position,andthentaketheplugoutofthesocket.
AuToMATIc sWITcHING oFF FuNcTIoN
Thefanheaterisequippedwithautoswitchingofffunctionwhenoverheated.
• If the unit starts overheating, automatic thermal switch will be on, the fan
heater will switch off.
• Inthiscaseimmediatelytaketheplugoutofthesocket.
• Make sure that the rear and the front grids are unrestricted and nothing
prevents air flow.
• Letthefanheatertocooloffforabout10-15minutesbeforeswitchingiton
again.

9
• Plugtheappliance,switchitonandsetpowerandroomtemperatureagain.
• Theunitwillnotswitchonifthewatertankandthetrayarenotinstalled.
• Iftheunitdoesnotswitchonitmaymeanthattherearedamages.Inthis
case contact an authorized service center for repair.
clEANING AND MAINTENANcE
• Unplugandtaketheplugoutofthesocketbeforecleaning.
• Wipetheunitcasewithadrycloth.
• Donotusesolventsorabrasivesubstancesforcleaning.
• Do not immerse the fan heater in water or any other liquids. Provide that
liquid does not get into the fan heater case in order not to damage it or avoid
electric shock.
• Tocleanairinletsontherearofthefanheaterusethevacuumcleanerwith
the corresponding attachment.
• Aftercleaningputthefanheaterintheboxandkeepinadryplace.
• Providethatthecorddoesnottouchsharpobjects.
• Before using the fan heater for the next time check its functionality and
isolation of the cord.
TEcHNIcAl spEcIFIcATIoNs
Voltage: 220-240VAC,50Hz
Wattage: Low: 1000W/ High: 1800W

10
NoTEs

11
ThisFanHeateriswarrantedforoneyearagainstallmanufacturingdefects
from the date of sale. In the event of any complaint, please contact your
nearestCompanyServiceCentreorcallatourTollFreeno:1800-1033-111.
This Warranty is valid only when…
1. The Fan Heater has not been opened or tempered with, by any
unauthorized person.
2. Thewarrantycardorcashmemodulysignedbytheauthorizeddealer
are presented with the complaint.
3. TheFanHeaterhasbeeninstalled,usedandmaintainedinaccordance
with the instructional manual.
This Warranty does not apply for…
1. Damages due to chipping, peeling, plating and denting.
2. BreakageordamagetocomponentsmadeoutofBakelite,Urea,ABS,
SANandsuchplastic,materials,rubberpartsandcord.
3. Normal wear and tear of parts.
4. Damage resulting from accidents, mishandling or negligence on part of
the customer.
Liability for consequential loss or damage is neither accepted nor implied.
S.NO: ______________________________________________________
CASHMEMO_______________________DATE:___________________
DEALER'SNAMEANDADDRESS:_______________________________
___________________________________________________________
OWNER'SNAME&ADDRESS:__________________________________
___________________________________________________________
WARRANTY cARD
