How to use UB-6035R / 6135R
Be aware of not dropping a remote control in water. It may cause out of order or malfunction.
All functions will be operational when the seat is occupied except Nozzle Cleaning.
Before operating, ensure that water tank is filled up completely.
Caution
- Press "stop" to stop current operation.
- When a user stands up, all operation will stop automatically.
Stop
Cleansing
Bidet
Dry (far infrared ray)
IIP (intensive impulse pulsation)
Kids
- Press "Cleansing" to clean your posterior. The function
will stop in 60 seconds automatically.
- Press this button again to activate oscillation. The nozzle
moves back and forth automatically to widen cleansing area.
- Oscillation wash stops if this button is pressed again.
- Press "Bidet" for feminine wash. The function will stop in
60 seconds automatically.
- Press this button again to activate oscillation. The nozzle
moves back and forth automatically to widen cleansing area.
- Oscillation wash stops if this button is pressed again.
- Press "Dry" after "cleansing" or "Bidet". Far infrared ray typed
warm air will comes out for 3 minutes.
- To alter the strength of air drying, press this button again.
- Press "IIP" for easy defecation. Intensive water pulsation may
help you to have easy defection.
- It works for 60 seconds and stops automatically.
- Press "IIP" again for changing the pulsation mode.
(3 different modes available)
- Press "Kids" to change all functions to be suitable for children.
- 1 minute for oscillation and 3 minutes for dry, level 1 of water
pressure and level 5 of nozzle position will be set.
- This unit should be used under the supervision of an adult.
Aerated spray
Dry (Strong/mild)
Cleansing
Bidet
Dry
Economy mode
Time
Water temperature
Seat temperature
Water spray pressure
Dry temperature
Strong / Mild
Seat
Warm water
- Press "Air" to use aerated wash to clean. Gentle, delicate but
strong water spray will save water consumption.
- Press this button again to release this function.
- "Cleansing" ; This function is always on.
- Water spray pressure can be adjustable by pressing or in 5 levels
- Temperature of dry can be adjustable by pressing or in 5 levels.
- Both levels will be initialized(level3) after each of use.
- Press "Auto" during the operation of "Cleansing", cleaning wash,
oscillating wash and dry will operate for each 20 seconds c
onsecutively.
- If Bidet Auto wanted, press "Bidet" and "Auto" consecutively.
- Press "Pulsation" to activate rhythmical wash for massage effect.
- Press "Pulsation" again to release this function.
- Nozzle position can be adjustable by pressing the nozzle position
button
- Position will be initialized (level 3) after each of use.
- Press "Economy" to activate the power saving function. The unit
will be in economy mode after 1 hour of last use.
- In the economy mode, temperature of water and seat will be kept
to 30 degrees Celsius. Economy mark(bulb) on the remote control
and green light in an extra panel will be shown.
- When the unit is occupied during the economy mode,
temperature will be returned to original setting levels and goes
back to economy mode after 1hour of last use.
- Press "Economy" again to release this function. Red light will be
turned on in the extra panel.
When the power is plugged in initially, nozzles for feminine wash
and posterior will come out in turn.
Water pressure / Dry temperature
Auto
Auto
Pulsation (massage)
Pulsation
Nozzle position
Nozzle
position
Economy
Economy
Air (aerated spray)
Dry
Stop
Cleansing
Oscillating Oscillating
Bidet
Kids
IIP
Air
