USR-G806 Software Manual
File version: V1.0.5

USR-G806 software manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
2
Content
1. Product Overview...............................................................................................................................................4
1.1. Product feature................................................................................................................................... 4
1.2. Band..................................................................................................................................................... 4
2. Product Functions.............................................................................................................................................. 6
2.1. Configuration Process.......................................................................................................................6
2.2. Basic Function.................................................................................................................................... 7
2.2.1 Network Diagnostic Function...................................................................................................... 7
2.2.2 Host Name and Time Zone............................................................................................................ 7
2.2.3 Password...........................................................................................................................................8
2.2.4 Restore to Factory Setting..............................................................................................................8
2.2.5 Upgrade Firmware Version.............................................................................................................8
2.2.6 Reset.................................................................................................................................................. 9
3. Advanced Function..........................................................................................................................................10
3.1. DDNS................................................................................................................................................. 10
3.2. WIFI-Dog........................................................................................................................................... 11
3.3. SMS AT Commands........................................................................................................................ 11
3.4. LAN Interface....................................................................................................................................12
3.4.1 DHCP Function.............................................................................................................................. 13
3.4.2 WAN Interface................................................................................................................................ 13
3.4.3 WLAN Function.............................................................................................................................. 13
3.4.4 4G Interface.................................................................................................................................... 15
3.4.5 APN............................................................................................................................................... 16
3.5. VPN Client.........................................................................................................................................17
3.5.1 PPTP Client............................................................................................................................ 17
3.5.2 L2TP Client....................................................................................................................... 20
3.5.3 IPSEC...................................................................................................................................... 24
3.5.4 OPENVPN........................................................................................................................ 26
3.5.5 GRE................................................................................................................................... 30
3.5.6 SSTP Client...................................................................................................................... 33
3.6. Static Router..................................................................................................................................... 34
3.7. NAT Function.................................................................................................................................... 34
3.7.1 MASQ.............................................................................................................................................. 34
3.7.2 SNAT........................................................................................................................................35
3.7.3 DNAT........................................................................................................................................36
3.8. Access Restrictions......................................................................................................................... 37
3.8.1 Domain Blacklist.............................................................................................................. 38
3.8.2 Whitelist................................................................................................................................... 38
3.9. Rate Limiting.....................................................................................................................................38
4. AT Commands.................................................................................................................................................. 39
4.1. AT+VER.............................................................................................................................................40
4.2. AT+MAC............................................................................................................................................ 40

USR-G806 software manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
3
4.3. AT+ICCID.......................................................................................................................................... 40
4.4. AT+IMEI.............................................................................................................................................40
4.5. AT+SYSINFO................................................................................................................................... 40
4.6. AT+APN.............................................................................................................................................41
4.7. AT+CSQ............................................................................................................................................ 41
4.8. AT+TRAFFIC.................................................................................................................................... 41
4.9. AT+UPTIME......................................................................................................................................41
4.10. AT+WANN......................................................................................................................................... 42
4.11. AT+LANN.......................................................................................................................................... 42
4.12. AT+WEBU......................................................................................................................................... 42
4.13. AT+PLANG....................................................................................................................................... 42
4.14. AT+RELD.......................................................................................................................................... 43
4.15. AT+Z...................................................................................................................................................43
4.16. AT+DHCPEN.................................................................................................................................... 43
4.17. AT+ LINUXCMP............................................................................................................................... 43
5. Contact us......................................................................................................................................................... 44
6. Disclaimer..........................................................................................................................................................44
7. Updated History................................................................................................................................................44

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
4
1. Product Overview
1.1. Product feature
One RJ45 for WAN/LAN port. 1 RJ45 for LAN port only.
Support 1 WLAN
Support Web Server
Support multiple LED communication indicators
Support Reload button to restore default settings by hardware way
The wired net ports support 10/100Mbps rate
Support VPN Client (PPTP/L2TP/IPSEC/GRE/OPENVPN/SSTP) and supports VPN encryption and static
IP functions.
Support APN special network card.
Support for wired wireless multi network simultaneous online and multi network intelligent switching
backup function
Support remote upgrade and remote monitoring
Support Dynamic Domain Name System (DDNS)
Support mandatory portal (WIFIDOG), this function needs to be customized according to customer needs.
Support SMS AT command
1.2. Band
USR-G806 has different band model to support different area. To check whether the USR-G806 works in
specific country, please check which 3G/4G technology and band is used in this country and operator. Then
please contrast our form of different model.
G806-43
Asia
G806-E
Europe
G806-A
America AT&T
G806-AU
Australia

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
5
G806-43 Operating Band
FDD-LTE
1
3
8
TDD-LTE
38
39
40
41
WCDMA
1
8
CDMA1X
800MHz
CDMA2000-EVDO
GPRS
3
8
G806-E Operating Band
FDD-LTE
1
3
5
7
8
20
TDD-LTE
38
40
41
WCDMA
1
5
8
GPRS
3
8
G806-A Operating Band
FDD-LTE
2
4
12
WCDMA
2
4
5

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
6
G806-AU Operating Band
FDD-LTE
1
2
3
4
5
7
8
28
TDD-LTE
40
WCDMA
1
2
5
8
GPRS
2
3
5
8
2. Product Functions
This chapter introduces the functions of USR-G806, as the following diagram shown, you can get an overall
knowledge of it.
Figure 1 Product function
2.1. Configuration Process
（1）Connect the 4G antenna and Wi-Fi antenna to the router. (Longer one is 3G/4G antenna and Shorter
one is Wi-Fi antenna.)
（2）Plug the SIM card in G806.
（3）Power on the module by power adaptor and check the LED status.
（4）Connect PC or mobile to the G806 router via LAN interface or Wi-Fi interface. Wi-Fi password is
“www.usr.cn”.
（5）Log in Web Server of router. (Default IP address of router is 192.168.1.1, either the username and
password is “root”.)

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
7
（6）Configure APN parameters according to SIM card. Some SIM card APN can be recognized
automatically.(Network->APNSET)
（7）Configure other parameters according to user applications.
2.2. Basic Function
2.2.1 Network Diagnostic Function
User can use network diagnosis function by Web Server as follow:
Figure 2 network diagnosis
Ping is a Ping tool, which can directly test Ping at a specific address on the router side.
Traceroute is the routing parsing tool, which can get the routing path when accessing an address.
Nslookup is a DNS view tool, which can resolve domain names to IP addresses.
2.2.2 Host Name and Time Zone
G806 default module name is USR-G806 and default Time Zone is Beijing time zone.
User can configure module name and Time Zone by Web Server as follow:

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
8
Figure 3 hostname and time zone
2.2.3 Password
Default password is root, this password is used to enter Web Server.
User can change password by Web Server as follow:
Figure 4 change web server password
2.2.4 Restore to Factory Setting
Hardware restore: Press Reload button over 5 seconds and release, G806 will restore default settings and
reset.
User can restore default settings by Web Server as follow:
Figure 5 restore default settings
2.2.5 Upgrade Firmware Version
Upgrade by Web Server as follow:

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
9
Figure 6 upgrade firmware
Note:
The whole upgrade process will last about one minute , user can enter Web Server after about 1 minute.
User can choose saving settings.
User should keep powering up and LAN/WIFI connection during the whole upgrade process.
2.2.6 Reset
Reset time is about 40~60 seconds.
Reset by Web Server as follow:
Figure 7 reset

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
10
3. Advanced Function
3.1. DDNS
Figure 8 DDNS
Function
Intro
Note
Enable
Enable/disable DDNS function
Default disable
Event interface
Choose the WAN port
e.g. choose wan_wired
Service/URL
Fill in the service address of DDNS.
e.g.
http://ouclihuibin123:ouclih
[e-mail]
/ph/update?hostname=1a5
16r1619.iask.in
Hostname
Fill in the domain name
e.g. 1a516r1619.iask.in
User name
Fill in account name
e.g. ouclihuibin123
Password
Fill in password
e.g. ouclihuibin1231
Source of IP
address
Choose the interface

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
11
Interface
Choose the interface name
e.g. choose eth0.2
Check for changed
IP/check-time unit
The interval between detecting IP
address changes, domain name
pointing to the IP may change
frequently, the smaller the value, the
more frequent the detection.
e.g. 1 min
Force update time
/force-time unit
Mandatory update interval
e.g. 72 h
3.2. WIFI-Dog
After clicking on open and save, the router needs to be restarted, and the authentication server needs to be
customized.
Figure 9 wifi-dog
3.3. SMS AT Commands
You should send SMS in this format: root#AT+COMMAND

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
12
Figure 10 SMS AT commands
3.4. LAN Interface
G806 supports two LAN interface (one is WAN/LAN interface).
Default settings: One LAN interface (WAN/LAN used as WAN interface; IP address: 192.168.1.1; Subnet mask:
255.255.255.0; Open DHCP function).
User can configure LAN interface by webpage as follow:
Figure 11 LAN interface

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
13
3.4.1 DHCP Function
DHCP default range of distribution is from 192.168.1.100 to 192.168.1.250 and default address lease time is
12 hours. Address range and lease time can be changed.
After you enter Web Server LAN interface, you can find ‘DHCP Server’ on Web Server as follow:
Figure 12 DHCP function
3.4.2 WAN Interface
G806 supports one WAN interface and WAN interface can switch between WAN/LAN interface. WAN interface
supports DHCP and Static IP, and default setting is DHCP.
User can configure WAN interface by Web Server as follow:
Figure 13 WAN interface
3.4.3 WLAN Function
G806 supports at most 24 STA devices connected. The maximum coverage of WIFI is 180m
Default parameters as follows:
SSID
USR-G806-XXXX(XXXX is MAC)

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
14
Password
www.usr.cn
Channel
Auto
Bandwidth
40MHz
Encryption Mode
WPA2-PSK
WLAN interface on Web Server as follow:
Figure 14 WLAN interface
After clicking “Edit” and entering WLAN interface configuration web, user can change follow parameters.
User can configure SSID on Web Server as follow:
Figure 15 Configure SSID
User can configure password on Web Server as follow:

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
15
Figure 16 Configure password
Other settings on Web Server as follow:
Figure 17 Other settings
User can close WLAN interface by changing ‘Radio on/off’ to off.
3.4.4 4G Interface
G806 supports one 4G interface to access internet. Functional diagram as follow:

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
16
Figure 18 4G interface
User can configure 4G interface by Web Server as follow:
Figure 19 4G interface
3.4.5 APN
APN configuration by Web Server as follow:

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
17
Figure 20 APN configuration
To choose the network type, please configure the LTE.
Figure 21 LTE configuration
3.5. VPN Client
3.5.1 PPTP Client
We first create VPN Server on the server.
Open the network connection page on the server (remote server) and click File - > New incoming connection.
Then, select Add account, please enter user name, password and other information..
Click Next and check through Internet to connect to this computer.
Then, select "Internet Protocol Version 4" to set the properties of the incoming IP, IP address assignment
select "Specify IP Address", then select "OK" and "Allow Access".
Now we create a VPN server.
Let's talk about the use of VPN Client. We are looking for a computer in the LAN to ensure that it can access
the server above. Then create a new VPN connection.
In the connection box, click "Properties", the tab can set the target address (the address of the VPN server),

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
18
security options to select "PPTP protocol", after the point is determined, enter the username, password.
Click the "Connect" button, after the connection is successful, you can see the VPN network card connection,
from grey to bright color, representing the VPN connection has been successfully established.
Next we use the PPTP Client on the router to replace the way of computer dialing.
Assuming that the user has obtained the VPN server address, account and password, we create an interface,
select the PPTP protocol, and write the other parameters in turn.
Figure22 the webpage1 of VPN

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
19
Figure23 the webpage2 of VPN
Select WAN, because it is dialing at WAN port, then save and apply.

USR-G806 software Manual Technical Support: h.usriot.com
Jinan USR IOT Technology Limited www.usriot.com
20
Figure24 the webpage3 of VPN
Wait a minute or restart the router, when you see the "VPN" interface in the router page, there is a run time (not
0), indicating that the current VPN has been successfully started.
Note:
Currently PPTP supports MPPE encryption and a variety of authentication methods. Specific settings can
be viewed in advanced settings for authentication.
Only MSChapV2 indicates that MPPE encryption is only supported.
MSChapV2 EAP PAP CHAP supports MPPE encryption and multiple authentications.
Other means do not handle, default status, only CHAP authentication by default.
3.5.2 L2TP Client
L2TP is a layer 2 tunneling protocol, similar to PPTP. At present, G806 supports various authentication
methods such as tunnel password authentication, CHAP, etc., supporting encryption methods of MPPE and
pre-shared key encryption methods of L2TP OVER IPSEC.
