SMC Networks EZ Switch SMCFS1601P User manual

USER GUIDE
EZ SwitchTM 10/100
16-Port Unmanaged Fast Ethernet PoE Switch
SMCFS1601P

No. 1, Creation Road III,
Hsinchu Science Park,
30077, Taiwan, R.O.C.
TEL: [phone]
Fax: [phone]
EZ SwitchTM 10/100
User Guide
From SMC’s EZ line of low-cost workgroup LAN solutions
November 2012
SMC-UG-1112-02

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate
and reliable. However, no responsibility is assumed by SMC for its use, nor for
any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implication or otherwise under any patent
or patent rights of SMC. SMC reserves the right to change specifications at any
time without notice.
Copyright © 2012 by
SMC Networks, Inc.
No. 1, Creation Road III,
Hsinchu Science Park,
30077, Taiwan, R.O.C.
All rights reserved
Trademarks:
SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are
trademarks of SMC Networks, Inc. Other product and company names are
trademarks or registered trademarks of their respective holders.

– 4–
W ARRANTY AND P RODUCT R EGISTRATION
To register SMC products and to review the detailed warranty statement, please
refer to the Support Section of the SMC Website at http://www.smc.com.

– 5 –
COMPLIANCES AND SAFETY
STATEMENTS
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
◆Reorient or relocate the receiving antenna
◆Increase the separation between the equipment and receiver
◆Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
◆Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
N OTE : The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.

C OMPLIANCES AND S AFETY S TATEMENTS
– 6 –
CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)
This information technology equipment complies with the requirements of the
Council Directive 89/336/EEC on the Approximation of the laws of the Member
States relating to Electromagnetic Compatibility and 73/23/EEC for electrical
equipment used within certain voltage limits and the Amendment Directive 93/
68/EEC. For the evaluation of the compliance with these Directives, the following
standards were applied:
RFI Emission: ◆Limit according to EN 55022:2006+A1:2007
◆Limit for harmonic current emission according to EN 61000-3-
2:2006+A2:2009
◆Limitation of voltage fluctuation and flicker in low-voltage supply
system according to EN 61000-3-3:2008
Immunity: ◆Product family standard according to EN 55024:2010
◆Electrostatic Discharge according to EN55024 &4.2.1
◆Radio-frequency electromagnetic field according to EN55024 &4.2.3.1
◆Electrical fast trsnsient/burst according to EN55024 &4.2.2
◆Surge immunity test according to EN55024 &4.2.5
◆Immunity to conducted disturbances, Induced by radio-frequency
fields: EN55024 &4.2.3.2
◆Power frequency magnetic field immunity test according to EN55024
&4.2.4
◆Voltage dips, short interruptions and voltage variations immunity test
according to EN55024 &4.2.6
LVD: ◆EN60950-1:2006+A11:2009+A1:2010+A12:2011

C OMPLIANCES AND S AFETY S TATEMENTS
– 7 –
INDUSTRY CANADA - CLASS A
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of
Communications.Cet appareil numérique respecte les limites de bruits
radioélectriques applicables aux appareils numériques de Classe A prescrites
dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003
édictée par le ministère des Communications.
PLEASE READ THE FOLLOWING SAFETY INFORMATION CAREFULLY BEFORE
INSTALLING THE SWITCH:
WARNING: Installation and removal of the unit must be carried out by qualified
personnel only.
◆This guide is intended for use by network administrators who are
responsible for setting up and installing network equipment; consequently it
assumes a basic working knowledge of LANs (Local Area Networks).
◆The unit must be connected to an earthed (grounded) outlet to comply with
international safety standards.
◆Do not connect unit to an A.C outlet (power supply) without an earth
(ground) connection.
◆The appliance coupler (the connector to the unit and not the wall plug)
must have a configuration for mating with an EN 60320/IEC 320 appliance
inlet.
◆The socket outlet must be near to the unit and easily accessible. You can
only remove power from the unit by disconnecting the power cord from the
outlet.
◆This unit operates under SELV (Safety Extra Low Voltage) conditions
according to IEC 60950. The conditions are only maintained if the
equipment to which it is connected also operates under SELV conditions.

C OMPLIANCES AND S AFETY S TATEMENTS
– 8 –
SAFETY PRECAUTIONS
Read the following information carefully before operating the device. Please
follow the following precaution items to protect the device from risks and
damage caused by fire and electric power:
◆Use the power adapter that is included with the device package.
◆Pay attention to the power load of the outlet or prolonged lines. An
overburdened power outlet or damaged cords and plugs may cause electric
shock or fire. Check the power cords regularly, if you find any damage,
replace it at once.
◆Proper space for heat dissipation is necessary to avoid any damage caused
by device overheating. The ventilation holes on the device are designed for
heat dissipation to ensure that the device works normally. Do not cover
these ventilation holes.
◆Do not put this device close to a place where a heat source exits or high
temperature occurs. Avoid placing the device in direct sunshine.
◆Do not put this device close to a place which is damp or wet. Do not spill
any fluid on this device.
◆Please follow the instructions in the user manual/quick install guide carefully
to connect the device to your PC or other electronic product. Any invalid
connection may cause a power or fire risk.
◆Do not place this device on an unstable surface or support.
PRÉCAUTIONS DE SÉCURITÉ
Lisez attentivement les informations suivantes avant d’utiliser votre appareil.
Respectez toutes les précautions afin de protéger l’appareil des risques et dégâts
provoqués par un incendie et l’alimentation électrique :
◆Utilisez exclusivement l’adaptateur d’alimentation fourni avec cet appareil.
◆Faites attention à la puissance de charge de la prise de courant ou des
rallonges électriques. Une prise surchargée ou des cordons et des fiches
endommagés peuvent provoquer une électrocution ou un incendie. Vérifiez
régulièrement votre câble électrique. Si vous constatiez le moindre défaut,
remplacez-le immédiatement.
◆Il est primordial de laisser suffisamment d’espace autour de l’appareil pour
permettre la dissipation de la chaleur et éviter les dégâts provoqués par une

C OMPLIANCES AND S AFETY S TATEMENTS
– 9 –
surchauffe de l’appareil. Les orifices de ventilation de l’appareil sont conçus
pour permettre la dissipation thermique et garantir le bon fonctionnement
de l’appareil. Ne couvrez jamais ces orifices.
◆Ne placez pas cet appareil à proximité d’une source de chaleur ou dans un
endroit exposé à des températures élevées. Evitez également de l’exposer à
la lumière directe du soleil.
◆Ne placez pas cet appareil à proximité d’un lieu humide ou mouillé. Prenez
garde à ne renverser aucun liquide sur cet appareil.
◆Merci de suivre les instructions du manuel d'utilisateur / guide d’installation
rapide attentivement pour connecter l'appareil à votre PC ou à tout autre
produit électronique. Toute connexion non valide peut provoquer un
problème électrique ou un risque d'incendie.
◆Ne placez pas cet appareil sur une surface ou un support instable.
SICHERHEITSMAßNAHMEN
Lesen Sie vor der Inbetriebnahme des Gerätes aufmerksam die nachstehenden
Informationen. Bitte befolgen Sie die nachstehenden Sicherheitsmaßnahmen,
damit das Gerät nicht beschädigt wird oder Gefahren durch Brand oder
elektrische Energie entstehen:
◆Verwenden Sie nur das beim Gerät mitgelieferte Netzteil.
◆Achten Sie auf die Last der Steckdose oder des Verlängerungskabels. Eine
überlastete Steckdose oder beschädigte Kabel und Stecker können
Stromschläge und Brand verursachen. Prüfen Sie die Netzkabel regelmäßig.
Ersetzen Sie sie umgehend, falls sie beschädigt sind.
◆Achten Sie zur Vermeidung von Geräteschäden aufgrund von Überhitzung
darauf, dass genügend Freiraum zur Wärmeabfuhr vorhanden ist. Die
Belüftungsöffnungen am Gerät dienen der Wärmeabfuhr und damit der
Gewährleistung eines normalen Gerätebetriebs. Decken Sie diese
Belüftungsöffnungen nicht ab.
◆Stellen Sie dieses Gerät nicht in der Nähe von Wärmequellen oder an Orten
mit hohen Temperaturen auf. Platzieren Sie das Gerät nicht im direkten
Sonnenlicht.
◆Stellen Sie dieses Gerät nicht an feuchten oder nassen Orten auf. Achten
Sie darauf, keine Flüssigkeiten über dem Gerät zu verschütten.

C OMPLIANCES AND S AFETY S TATEMENTS
– 10 –
◆Befolgen Sie die Hinweise im Benutzerhandbuch (bzw. in der Kurzanleitung)
zum Anschluß des Gerätes an einen PC oder ein anderes Elektrogerät.
Jegliche unzulässige Verbindung birgt die Gefahr von Stromschlägen und
Brandgefahr.
◆Platzieren Sie dieses Gerät nicht auf einer instabilen Oberfläche oder
Halterung.
PRECAUCIONES DE SEGURIDAD
Lea la siguiente información detenidamente antes de utilizar el dispositivo. Siga
las indicaciones de precaución que se mencionan a continuación para proteger el
dispositivo contra riesgos y daños causados por el fuego y la energía eléctrica:
◆Utilice el adaptador de alimentación incluido en el paquete del dispositivo.
◆Preste atención a la carga de potencia de la toma de corriente o de los
alargadores. Una toma de corriente sobrecargada o líneas y enchufes
dañados pueden provocar descargas eléctricas o un incendio. Compruebe
los cables de alimentación con cierta frecuencia. Si detecta algún daño,
reemplácelos inmediatamente.
◆Deje un espacio adecuado para que se disipe el calor y evitar así cualquier
daño en el dispositivo causado por sobrecalentamiento. Los orificios de
ventilación del dispositivo están diseñados para disipar el calor y garantizar
que dicho dispositivo funciona con normalidad. No tape estos orificios de
ventilación.
◆No coloque este dispositivo cerca de un lugar donde haya una fuente de
calor o temperaturas elevadas. Evite exponer el dispositivo a la luz solar
directa.
◆No coloque este dispositivo junto a un lugar húmedo o mojado. No derrame
ningún fluido sobre el dispositivo.
◆Por favor, siga cuidadosamente las instrucciones que figuran en el manual/
guía de instalación rápida para conectar el dispositivo a su PC o a cualquier
otro producto electrónico. Cualquier conexión no válida podría causar riesgo
de descarga o de incendio.
◆No coloque este dispositivo en una superficie o soporte inestable.
◆Precauções de Segurança

C OMPLIANCES AND S AFETY S TATEMENTS
– 11 –
◆Leia atentamente as seguintes informações antes de utilizar o dispositivo.
Respeite as seguintes indicações de segurança para proteger o dispositivo
contra riscos e danos causados por fogo e energia eléctrica:
◆Utilize o transformador incluído na embalagem do dispositivo.
◆Respeite a potência da tomada eléctrica e das extensões. Uma tomada
eléctrica sobrecarregada ou cabos e fichas danificadas podem causar
choques eléctricos ou fogo. Verifique regularmente os cabos de
alimentação. Caso algum se encontre danificado, substitua-o
imediatamente.
◆É necessário deixar algum espaço livre em volta do dispositivo para
dissipação de calor, de forma a evitar danos causados pelo
sobreaquecimento do dispositivo. Os orifícios de ventilação do dispositivo
foram concebidos para dissipar o calor e assegurar que o mesmo funciona
normalmente. Não bloqueie esses orifícios de ventilação.
◆Não coloque este dispositivo junto a fontes de calor ou em locais com
temperaturas elevadas. Evite colocar o dispositivo sob luz solar directa.
◆Não coloque este dispositivo junto a locais molhados ou com humidade. Não
derrame líquidos sobre o dispositivo.
◆Por favor siga atentamente as instruções do manual / guia de instalação
rápida para conectar o dispositivo ao seu PC ou a qualquer outro dispositivo
electrónico. Atenção que qualquer tipo de ligação inválida pode originar
risco de choque eléctrico ou de incêndio.
◆Não coloque este dispositivo numa superfície ou suporte instáveis.

C OMPLIANCES AND S AFETY S TATEMENTS
– 12 –

– 13 –
ABOUT THIS GUIDE
PURPOSE
This guide details the hardware features of the switch, including the physical and
performance-related characteristics, and how to install the switch.
AUDIENCE
The guide is intended for use by network administrators who are responsible for
installing and setting up network equipment; consequently, it assumes a basic
working knowledge of LANs (Local Area Networks).
CONVENTIONS
The following conventions are used throughout this guide to show information:
REVISION HISTORY
This section summarizes the changes in each revision of this guide.
NOVEMBER 2012 REVISION
This is the second revision of this guide. It includes the following changes:
◆Update Compliances section.
N OTE : Emphasizes important information or calls your attention to
related features or instructions.
C AUTION : Alerts you to a potential hazard that could cause loss of data,
or damage the system or equipment.
W ARNING : Alerts you to a potential hazard that could cause personal
injury.

A BOUT T HIS G UIDE
– 14 –
APRIL 2012 REVISION
This is the first revision of this guide.

– 15 –
CONTENTS
WARRANTY AND PRODUCT REGISTRATION 4
COMPLIANCES AND SAFETY STATEMENTS 5
ABOUT THIS GUIDE 13
CONTENTS 15
1I
NTRODUCTION 17
Overview 17
Features 17
PoE Features 18
IEEE 802.1p QoS 18
2HARDWARE DESCRIPTION 21
Front Panel 21
Port and System Status LEDs 21
RJ-45 Ports 22
Rear Panel 22
AC Power Socket 22
3INSTALLING THE SWITCH 23
Package Contents 23
Precautions 23
Safety Requirements 23
Location Requirements 24
Installation 24
Desktop Installation 25
Rack Installation 25
Connecting to Ground 27

C ONTENTS
– 16 –
Powering On 28
Connecting Network Devices 28
Cabling Guidelines 28
Connecting to PCs, Servers, Hubs and Switches 29
4PRODUCT APPLICATION 31
Department/Workgroup PoE Switch 31
Power over Ethernet Powered Devices 32
ATROUBLESHOOTING 33
Diagnosing Switch Indicators 33
The Power LED is Off 33
The Link/Act LED is Off when a Device is Connected to the Corre-
sponding Port 33
Power and Cooling Problems 33
Installation 34
BSPECIFICATIONS 35
Physical Characteristics 35

– 17 –
1INTRODUCTION
OVERVIEW
The EZ Switch 10/100 SMCFS1601P PoE switch provides 16 10/100 Mbps auto-
negotiating RJ-45 ports. Each port on the switch support auto MDI/MDI-X, which
eliminates the need for crossover cables or uplink ports. The switch is plug-and-
play; any port can be connected to a server, a hub, or a switch, using straight-
through or crossover cable.
FEATURES
◆Complies with IEEE 802.3, IEEE 802.3u standards
◆16 10/100 Mbps auto-negotiating RJ-45 ports supporting Auto-MDI/MDIX
◆Supports PoE power up to 30W for each PoE port
◆PoE total power budget 200W for all PoE ports
◆Supports IEEE 802.3x flow control for full-duplex mode and backpressure
for half-duplex mode
◆LED indicators for monitoring power, link, activity
◆Rack-mountable steel case
◆Support for IEEE 802.3az Energy-Efficient Ethernet, which can save up to
56% of power consumption
◆Support for IEEE 802.1p QoS

C HAPTER 1 | Introduction
Overview
– 18 –
POE FEATURES
The SMCFS1601P can provide up to 30 Watts of power to attached devices, such
as VoIP phones, wireless access points, surveillance cameras, etc, all over
existing Cat. 5 cables. The switch can deliver up to 30 Watts on 8 ports, or 15.4
Watts on 16 ports. This eliminates the need for individual power sources for
devices in the network, saving on costs for power cables and avoiding power
outlet availability issues.
IEEE 802.1PQOS
The SMCFS1601P switch supports 802.1p priority queuing Quality of Service,
which is an implementation of the IEEE 802.1p standard. With the 802.1p QoS
function, network traffic that requires high priority, such as VoIP (Voice-over
Internet Protocol), web browsing applications or video conferencing, can be
forwarded before other traffic. The switch has separate hardware queues for
each physical port, when packets are received with an 802.1p priority tag, they
are sent to the appropriate output queue.
The illustration below shows how 802.1p priority queuing is implemented on the
switches.
Figure 1: Mapping QoS on the Switch
There are four priority levels labeled TC0, TC1, TC2 and TC3. The untagged
packets and the eight IEEE 802.1p priority tags (defined by the standard) are
mapped to the four priority queues on the switch. TC3 has the highest priority of
the four priority queues while TC0 has the lowest priority. The untagged packets
and eight priority tags, specified in IEEE 802.1p, are mapped to the switch’s
priority tags as follows:
◆Untagged packets, and packets with priority tag 1 and 2 are assigned to the
switch’s TC0 level queue.
◆Packets with priority tag 0 and 3 are assigned to the switch’s TC1 level
queue.
Tag untag 0 1 2 3 4 5 6 7
Priority Level
Weight Value 1 2 4 8
TC0 TC1 TC2 TC3

C HAPTER 1 | Introduction
Overview
– 19 –
◆Packets with priority tag 4 and 5 are assigned to the switch’s TC2 level
queue.
◆Packets with priority tag 6 and 7 are assigned to the switch’s TC3 level
queue.
The SMCFS1601P switch uses Weighted Robin Round (WRR) for scheduling. The
WRR queue-scheduling algorithm schedules all the queues in turn with every
queue assured a certain service time. For both WFQ and WRR mode, the default
weight values of TC0, TC1, TC2 and TC3 are 1:2:4:8.

C HAPTER 1 | Introduction
Overview
– 20 –
