USX-MOUNT SML025-01 User manual

SML025-01
INSTRUCTION MANUAL
R
USA-B1
For 37-90" TV
If you have any questions along the way, just message
to us. We’re ready to help!

2
MAX:600mm/23.62"
(MIN:200mm/7.87")
MAX:400mm/15.75"
(MIN:100mm/3.94")
Before getting started, let’s check below lists to make sure it is just right for you!
2
3
4
5
Does your TV
(including accessories)
weigh MORE than
150 lbs. (68.2 kg)?
What is your
wall made of?
Do you have
all the tools
needed?
(NOT INCLUDE)
CAUTION
No? Perfect – you may continue.
Yes? This mount is NOT compatible.
CAUTION: DO NOT exceed the maximum weight
indicated. This mounting system is intended for use only
with the maximum weights indicated. Use with products
heavier than the maximum weights indicated may result
in collapse of the mount and its accessories, causing
possible injury.
● This product is designed for use in wood stud, solid concrete walls - DO NOT install into drywall alone
● The wall must be capable of supporting five times the weight of the TV and mount itself
● Do not use this product for any purpose not explicitly specified by manufacturer
● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
1
Check your TV
VESA is within
Min and Max size
No? This mount is NOT compatible.
Yes? Perfect !
Tape
Measure Pencil Screw driver
Electric
Drill
1/2 in.
(13 mm)
Socket
Wrench
?Unsure?
Mail to us via Amazon.
Stud
Finder
7/32 in.
(5.5 mm)
Wood
Drill Bit
3/8 in.
(10 mm)
Masonry
Drill Bit
Hammer
150 lbs
(68.2 kg)
Drywall with
wood studs? CAUTION: Solid concrete
DO NOT
install into
drywall alone
Per fect !Per fect !
CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS
Wood Stud Install
Concrete Install

TV INTERFACE 3-D
WALL PLATE
FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED
TOP VIEW - EXTENDED SIDE VIEW - EXTENDED
3
+5°
-15°
SIDE VIEW - EXTENDED
+45°
422mm
[16.61in]
64mm
[2.52in]
420mm
[16.54in]
679mm
[26.73in]
638mm
[25.12in]
277mm
[10.91in]
164mm
[6.46in]
200mm
[7.87in]
600mm
[23.62in]
400mm
[15.75in]
15mm
[0.59in]
245mm
[9.65in]
9mm
[0.35in]
203.2mm
[8.00in]
406.4mm
[16.00in]
609.6mm
[24.00in]
Dimensions

WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts
are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact
Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
4
Parts and Hardware for STEP 1
TV Brackets
x2
Parts and Hardware
M4x12mm
M6x12mm
M4x30mm
M6x35mm
Spacers
TV Screws
x4 x4
x4 x4
M8x45mm
M6x17mm
M8x22mm
M4 M6
10mm
2.5mm
Washers
x4
x4
x4 x4
x8 x4
x4
a
b
f
e
d
gh
ij
k l
M8x25mm
x4
c
05

5
Parts and Hardware for STEP 2
Lag Bolt M8x60mm
x4
Wall Plate Unit
x1
Allen Key
x1
M6x16mm Bolt
x2
Velcro x3
Mounting template
203.2mm(8")
406.4mm(16")
609.6mm(24")
R
04
01
02 03
Contact us and message to us to have these
additional pieces shipped directly to you.
Concrete Wall Anchor
4pcs
Concrete wall anchor (NOT INCLUDED)
Level x1

6
M8
M6
M4
1-1 Select TV Screws
STEP 1 Attach Brackets to TV

1-2 Figure out the suitable position of brackets
7
INSTALL UP/DOWN IF NEEDED TV BRACKETS MUST BE LEVEL
LOW MOUNTING HOLES HIGH MOUNTING HOLES

Tips: If you need to combine M6/M8(c/e/f) screws with
2.5mm spacers( i ), you have to remove the inner circle.
Yes, choose suitable screws, washers and spacers.
1-4 Attach the TV Plate
No!
No, choose suitable screws and washers.
1-3 Need Spacer?
8
b
ac
k l
e
df
kl
i
hj
g

Centre line
CAUTION: Avoid potential personal injury or property damage!
● Drywall covering the wall, must not exceed 5/8 in. (16 mm)
● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm)
● Maximum horizontal space between fasteners: 24 in. (609 mm)
● Stud center must be verified
1. Locate your studs. Verify and mark the center of the stud by finding the stud edges using a thin nail,
or an edge to edge stud finder.
2. Position the mounting template at your desired height and line up the holes with your stud center line.
Level the wall plate and mark the hole locations.
Again, find another wood stud
16"/24"
Mounting template
9
R
203.2mm(8")
406.4mm(16")
609.6mm(24")
STEP 2A Attach Wall Plate to Wall Wood Stud Option

3. Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2.5 in. (64 mm). Be sure to drill into the center
of the studs.
4. Install wall plate using four lag bolts . Tighten the lag bolts only until they are pulled firmly
against the wall plate.
CAUTION: Improper use could reduce the holding power of the lag bolt.
DO NOT over-tighten the lag bolts.
Go to STEP 3 on PAGE 13.
2.5"(64mm)
7/32"
(5.5mm)
No!
10
UP
04 01
04
01

3/8"
(10mm) 2.5"(64mm)
CAUTION: Avoid potential personal injury or property damage!
● Mount the wall plate assembly directly onto the concrete surface
● Minimum solid concrete thickness: 8 in. (203 mm)
1. Position the mounting template on the wall at your desired height. Level the wall plate and mark the
hole locations.
2. Drill four pilot holes using a 3/8 in. (10 mm) diameter masonry drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2.5 in. (64 mm).
11
Mounting template
R
203.2mm(8")
406.4mm(16")
609.6mm(24")
STEP 2B Attach Wall Plate to Solid Concrete Wall
04

3. Insert four anchors.
CAUTION: Be sure the anchors are seated flush with the concrete surface.
CAUTION: Improper use could reduce the holding power of the lag bolt.
DO NOT over-tighten the lag bolts.
4. Insert wall plate using four lag bolts . Tighten the lag bolts only until they are pulled firmly
against the wall plate.
Concrete Wall Anchor
(Not included)
No!
12
UP
Please contact us and message to us to have
these additional pieces shipped directly to you.
04 01
04
01

Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall
tightly.
13
STEP 3 Wall Plate lnstallation lntegrity Test
04

Hang TV/bracket assembly onto wall plate, wrap clips on bracket around extension arms and tighten
them using bolts .
TV
1 2
14
STEP 4 Hang and Secure TV to Wall Plate
02
02

5-1 TV leveling adjustment (±4°):
Loosen 4 leveling bolts on the rear of TV plate by
maximum 2 turns, adjust to level, and retighten to secure.
15
Loosen
Tighten
±4°
STEP 5 Adjustments
03

5-2 Tilting angle adjustment (+5°/-15°)：
Loosen handle and tilting bolt, adjust TV to your desired position,
then tighten handle and tilting bolt. Put the handle level when finish.
16
Tilting bolts
+5°
-15°
Tighten
Loosen
Tighten
Loosen
+5° -15° Tilting bolts
Handle Level
03 03

5-3 Cables manage:
Manage TV cables orderly and guide them through the velcros.
Velcro
17
