UTC Fire and Security interlogix VT7220 Installation instructions

P/N 1062794 • REV B • ISS 01AUG11
VT7220
VT7220-R3
VT7230
VT7230-R3
VT7230-FC
IFS Fiber Module
Installation & Operation
Instructions
VR7220
VR7220-R3
VR7230
VR7230-R3
VR7230-FC

ifsInternational
Fiber
Systems
Incorporated
VT7230
2 CHANNEL DIGITAL
VIDEO TRANSMITTER
POWER
VIDEO
INPUT
OPTICAL OUT
Simplex single mode
fiber optic cable
2 BNC Cables
(Fixed Video Inputs from Cameras)
2 BNC Cables
(Video Output to Monitors)
ifsInternational
Fiber
Systems
Incorporated
VR7230
2 CHANNEL DIGITAL
VIDEO RECEIVER
1 -
2 -
VIDEO
OUTPUT
OPTICAL INPUT
- 2
+12 VDC - 1
POWER
- 2
+12 VDC - 1
POWER
1
2
CAMERA ON
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.

Comprehensive
Lifetime Warranty
(a) Seller warrants to the original End User that products and any
services furnished hereunder will be free from defects in material
and workmanship as of the date of delivery, and will conform to
Seller’s published technical specications. The foregoing shall
apply only to failures to meet said warranties which appear within
that period of time during which the Products are installed in their
original installation for the original End User and operator of such
Products; provided, however, that in the event of product discontin-
uance, warranty support is limited to ve (5) years from the
announcement of discontinuance. Notwithstanding the preceding
sentence, the duration of the warranty period for products not
manufactured by Seller (e.g., ber optic cabling, test equipment,
power supplies or batteries) shall be the warranty period oered by
the original manufacturer, if any.
(b) The conditions of any tests shall be mutually agreed upon and
Seller shall be notied of, and may be represented at, all tests that
may be made. The warranties and remedies set forth herein are
conditioned upon (a) proper storage, installation, use and mainte-
nance, and conformance with any applicable recommendations of
Seller and (b) Buyer promptly notifying Seller of any defects and,
if required, promptly making the product available for correction.
(c) If any product or service fails to meet the foregoing warranties,
Seller shall thereupon correct any such failure either at its option,
(i) by repairing any defective or damaged product or parts of the
products, or (ii) by making available any necessary repaired or
replacement products or parts thereof. Any repaired or replacement
part or product shall be warranted for the remaining period of the
original Warranty Period. Seller shall pay, or credit Buyer for, the
cost of freight for all return shipments of products or parts to
Buyer. Where a failure cannot be corrected by Seller's reasonable
eorts, the parties will negotiate an equitable adjustment in price.
(d) The preceding paragraph sets forth the exclusive remedies for
claims based on defect in or failure of products or services,
whether the claim is in contract, indemnity, warranty, tort
(including Seller's negligence), strict liability or otherwise and
however instituted. Upon the expiration of the warranty period,
all such liability shall terminate and BUYER shall have a reason-
able time, within thirty days after the warranty period, to give
written notice of any defects which appeared during the warranty
period. The foregoing warranties are exclusive and in lieu of all
other warranties, whether written, oral, implied or statutory.
NO IMPLIED OR STATUTORY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSE SHALL APPLY. Seller does not warrant any
products or services of others which BUYER has designated.
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to cor-
rect the interference at his own expense.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesirable operation.
Changes or modifications not expressly approved by International Fiber Systems, Inc. could void
the user’s authority to operate the equipment.
CLASS 1 LASER PRODUCT
(For purposes of IEC 60825-1)
Complies with FDA Performance Standard for Laser Products
Title 21
Code of Federal Regulations
Subchapter J

Contacting us
For help installing, operating, maintaining, and troubleshooting this product, refer to this document and any
other documentation provided. If you still have questions, contact us during business hours (Monday through
Friday, excluding holidays, between 5 a.m. and 5 p.m. Pacific Time).
Note: Be ready at the equipment before calling.
Online
Another great resource for assistance with your Interlogix product is our online publication library. To access
the library, go to our website at the following location:
http://www.interlogix.com/transmission1
Sales and support contact information
North
America
Toll-free: 855.286.8889 in the US, including Alaska and Hawaii;
Puerto Rico; Canada.
Outside the toll-free area: 503.885.5700.
E-mail: [email protected]
Europe Select Contact Us at www.utcfssecurityproducts.eu
Australia security[email protected]
1. Many Interlogix documents are provided as PDFs (portable document format). To read these documents, you will
need Adobe Reader, which can be downloaded free from Adobe’s website at www.adobe.com.

Product Disassembly Instructions for WEEE
Per European Directive 2002/95/EC Waste Electrical and
Electronic Equipment
Required Tools:
One number 2 Phillips (crosstip) screwdriver.
One number 2 flat screwdriver.
For the enclosed box version:
1. Locate and remove box cover securement screws. Usually, but not limited to, at least
4 screws.
2. Lift off box top cover.
3. Locate and remove securement screws for printed circuit board.
4. If there are multiple boards to the assembly, continue removing securement screws
until none are left.
5. Lift off printed circuit board.
6. Disassembly of box version of product is complete.
For rack version:
1. Locate and remove securement screws for printed circuit board. Usually, but not
limited to, at least 4 screws.
2. If there are multiple boards to the assembly, continue removing securement screws
until none are left.
3. Lift off printed circuit board(s).
4. Disassembly of rack card version of product is complete.

Copyright © 2011 UTC Fire & Security. All rights reserved.
Trademarks and
patents Interlogix and IFS names and logos are trademarks of UTC Fire & Security.
Other trade names used in this document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective products.
Manufacture
r
UTC Fire & Security Americas Corporation, Inc.
2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification N4131
ACMA compliance Notice! This is a Class A product. In a domestic environment this
product may cause radio interference in which case the user may be
required to take adequate measures.
Canada This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
European Union
directives 2004/108/EC (EMC directive): Hereby, UTC Fire & Security declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive
2004/108/EC.
2002/96/EC (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
Contact information For contact information, see www.interlogix.com.
