GWM Cannon Double Cab
Sports Bar Load-Lid™
Under Rail Liner
Despatch list:
CT5
M8 Fender
Washer
M8 Spring
Washer
TK-M8x25
x4
x4
x4
x4
M6 Medium
Washer
M6x40 Buon
Head Bolt
x4
x4
x4
M6 Spring
Washer
90-120 minutes

© Copyright Utemaster NZ Ltd. 2
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
Remove the sports bars
from the vehicle
(if installed)
2
1
Remove the three bolts
from each side of the
wellside, as indicated
below:

© Copyright Utemaster NZ Ltd. 3
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
3
Remove the rubber
feet from the sports
bar.
4
Remove the
mounng brackets
from the sports bar.
5
Highly recommend watching
the video before installaon.
Scan the QR code.
Cut the rubber feet as
per the video.
Sports Bar
Preparaon
Video
hps://wi.st/2Zx4JOI

© Copyright Utemaster NZ Ltd. 4
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
6
Sit the rubber feet back
onto the respecve
sports bar feet
7
1) M6 x 40mm
2) M6 medium
washer
3) M6 spring
washer
x4
x4
x4
Bolts go into exisng
threaded holes in the
sport bar.
Begin threading the
bolt using a hex key to
prevent cross-
threading
Use lubricant if the
thread is too ght
3
2
1
3
2
1

© Copyright Utemaster NZ Ltd. 5
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
Note: Place cardboard
between cab and tray
to protect the paint
from scratching during
installaon.
9
8
1. Customer provided
cardboard.
Load-Lid™
Fing Video
hps://wi.st/2OW7L7N
1.

© Copyright Utemaster NZ Ltd. 6
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
Pull Load-Lid™ back to ensure face plate tab is sing rmly against the tray.
10

© Copyright Utemaster NZ Ltd. 7
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
11
Make sure the Load-Lid is
sing rmly on BOTH
SIDES.
Ensure
Load-Lid™
Is sing
square on
the tray.

© Copyright Utemaster NZ Ltd. 8
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
1.
2.
3.
4.
12
Only clamp through the rear
two slots marked ‘A’ at this
stage.
x2
x2
x2
x2
1.______
2.______
3.______
4.______
A
A

© Copyright Utemaster NZ Ltd. 9
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
Clamp through the two
remaining slots.
13
x2
x2
x2
1.______
2.______
3.______

© Copyright Utemaster NZ Ltd. 10
Australia Support:
P: 1800 43 345
E: [email protected]
W: www.utemaster.com.au
NZ Support:
P: 0800 683 352
E: [email protected]
W: www.utemaster.co.nz
14
1. Adjust the nuts shown on
the lock strike to aect
the nal closing height of
the Load-Lid™
2. Refer to the video shown
on the QR code below for
details.
Slam Lock
Adjustment
Video.
hps://wi.st/2Bp7XJ9
IMPORTANT NOTE:
When removing and reng lock the lid into the mounng frame before undoing
the clamps and removing the lid (this prevents damaging the tray).
Your Load-Lid™ is now fully ed and ready to use. We recommend frequently ghtening the clamps and
greasing the lock to enjoy the full benets of your Load-lid.
