UTEPO UTP3-SW04-TP60 User manual

Please follow the below installation steps
Please check the following items before installation, if it is missing, please contact the
dealer .
4 ports PoE Ethernet Switch 1pcs
Power adaptor 1 pcs
AC power cable 1 pcs
Accessory 1 pcs
User manual 1 pcs
1) Please turn off the signal power and display device power before installation, or it will
damage the transmission equipment;
2) Use network cable connect PoE IP camera and
Use a network cable connect equipment uplink port and NVR or computer;
4)
5) Check if the installation is correct, equipment is in good condition, the connection is stable,
then power on for system;
6) Ensure the Ethernet equipment with power on can work properly.
1～4 downlink ports of product respectively;
3)
Connect power adapter;
Installation steps
Feature
4 Ports PoE Ethernet Switch
4 Ports PoE Ethernet Switch
User Manual
12
4 ports PoE Ethernet Switch is a aims at Ethernet
high definition surveillance and security system. The product fully combines the characteristics
of security surveillance, provides fast packet forwarding ability and abundant backplane
bandwidth, which ensures clear image and fluent transmission. ESD and surge protection
circuit can improve product stability. The product supports one key CCTV model, with
security surveillance Ethernet Switch which
VLAN
function can restrain the nentwork storm, protect the information security, prevent the viral
transmission and cyber attack, fully satisfy the Ethernet video security surveillance system and
Ethernet project needs.
Board Diagram
Front board
VerB 1.3
● Major ports: 1pcs*100Mbps uplink Ethernet port, 4pcs*100Mbps downlink Ethernet
ports , every port supports MDI/MDIX;
● Special function: ; downlink ports can only communicate
with uplink ports;
● Power input: DC48V～57V;
● Transmission Distance : Ethernet port 0～100m;
● Standard: Meet IEEE802.3 ,IEEE802.3u,IEEE802.3 af/at standards, PoE use
End-Span, the spare cable can be of other use;
● Protection: Excellent anti-thunder, anti-static and anti-interference ability;
● Appearance: Delicate design and easy installation, configure the anti-theft lock
hole, guard against theft;
●Operation: Plug and Play, No Setting required.
One key CCTV model 1 4～
the furthest transmission distance
could reach 250m in CCTV model; Uplink port can reach 100m;
Anti-Theft Lock
Back board
Side board
Notice
The transmission distance is related to the connected cable. We suggest standard
Cat5e/6 network cable, so the transmission distance can up tofurthest!
1
2
)
) Turn the dial switch for left, the equipment can enter surveillance module after providing
equipment power.
Device must be connected with lightning protection grounding; otherwise protection
level will reduce; please use above No.20 wire to connect the grounding terminal.
4 Ports PoE Ethernet Switch
Cat5/5e/6 network cable
LCD
NVR
PoE PTZ Camera
PoE IP Camera
PoE Dome Camera
PoE IP Camera
power
PoE downlink
Ethernet port Ethernet port Ground
Power
input port
Surveillance module
indicated light
normally on
Power
indicated light
Notice
Application

Please follow the below installation steps
Please check the following items before installation, if it is missing, please contact the
dealer .
4 ports PoE Ethernet Switch 1pcs
Power adaptor 1pcs
AC power cable 1pcs
Accessory 1pcs
User manual 1pcs
1) Please turn off the signal power and display device power before installation, or it will
damage the transmission equipment;
2) Use network cable connect PoE IP camera and
Use a network cable connect equipment uplink port and NVR or computer;
4)
5) Check if the installation is correct, equipment is in good condition, the connection is stable,
then power on for system;
6) Ensure the Ethernet equipment with power on can work properly.
1～4 downlink ports of product respectively;
3)
Connect power adapter;
Installation steps
Feature
4 Ports PoE Ethernet Switch
4 Ports PoE Ethernet Switch
User Manual
12
4 ports PoE Ethernet Switch is a aims at Ethernet
high definition surveillance and security system. The product fully combines the characteristics
of security surveillance, provides fast packet forwarding ability and abundant backplane
bandwidth, which ensures clear image and fluent transmission. ESD and surge protection
circuit can improve product stability. The product supports one key CCTV model, with
security surveillance Ethernet Switch which
VLAN
function can restrain the nentwork storm, protect the information security, prevent the viral
transmission and cyber attack, fully satisfy the Ethernet video security surveillance system and
Ethernet project needs.
Board Diagram
Front board
VerB 1.3
● Major ports: 1pcs*100Mbps uplink Ethernet port, 4pcs*100Mbps downlink Ethernet
ports , every port supports MDI/MDIX;
● Special function: ; downlink ports can only communicate
with uplink ports;
● Power input: DC48V～57V;
● Transmission Distance : Ethernet port 0～100m;
● Standard: Meet IEEE802.3 ,IEEE802.3u,IEEE802.3 af/at standards, PoE use
End-Span, the spare cable can be of other use;
● Protection: Excellent anti-thunder, anti-static and anti-interference ability;
● Appearance: Delicate design and easy installation, configure the anti-theft lock
hole, guard against theft;
●Operation: Plug and Play, No Setting required.
One key CCTV model 1 4～
the furthest transmission distance
could reach 250m in CCTV model; Uplink port can reach 100m;
Anti-Theft Lock
Back board
Side board
Notice
The transmission distance is related to the connected cable. We suggest standard
Cat5e/6 network cable, so the transmission distance can up tofurthest!
1
2
)
) Turn the dial switch for left, the equipment can enter surveillance module after providing
equipment power.
Device must be connected with lightning protection grounding; otherwise protection
level will reduce; please use above No.20 wire to connect the grounding terminal.
4 Ports PoE Ethernet Switch
Cat5/5e/6 network cable
LCD
NVR
PoE PTZ Camera
PoE IP Camera
PoE Dome Camera
PoE IP Camera
power
PoE downlink
Ethernet port Ethernet port Ground
Power
input port
Surveillance module
indicated light
normally on
Power
indicated light
Notice
Application

连接接口
Specification 连接 接 口
4 Ports PoE Ethernet Switch
34
Specification change will not be noticed
4 Ports POE Ethernet Switch
Trouble Shooting
Please follow the steps if the equipment has trouble.
Make sure the equipment is installed according to the manufactures installation guide.
Confirm RJ45 cable order meets EIA/TIA568A or 568B standard.
Every PoE port can provide PoE equipment maximum power less than 30W, please do not
connect the PoE equipment with power over 30W.
Replace the equipment with a proper functioning 4 ports PoE Ethernet Switch to check if
the equipment is damaged.
Please contact your vendor if trouble still exists.
Instruments to be used: wire crimper, network tester. Wire sequence of RJ45 plug should
conform with EIA/TIA568A or 568B.
1) Please remove 2cm long the insulating layer, and bare 4 pairs UTP cable;
2) Separate the 4 pairs UTP cable and straighten them;
3) Line up the 8 pieces of cables per EIA/TIA 568A or 568B;
4) Cut off the cables to leave 1.5cm bare wire;
5) Plug 8 cables into RJ45 plug, make sure each cable is in each pin;
6) Use the wire crimper to crimp it;
7) Repeat above 5 steps to make the another end;
8) Use network tester to test the cable if it works.
Plug Producing Method
Pin Color
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
1
2
3
4
5
6
7
8
Pin Color
1
2
3
4
5
6
7
8
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
EIA/TIA 568A EIA/TIA 568B
When choose RJ45 make sure if one end is EIA/TIA568A,the other end should also be EIA/TIA568A.
When choose RJ45 make sure if one end is EIA/TIA568B,the other end should also be EIA/TIA568B.
Notice
Item
Description
Power
Power Supply
Power Adaptor
Voltage Range
DC48V~54V
Consumption
＜5W
Ethernet
Speed
1-4 port:Default:10/100Mbps;
CCTV:10Mbps;
UPLINK:100Mbps
Transmission Distance
1-4 port:Default:0～100m;
CCTV:0~250m;
UPLINK:100m
Network Switch
Ethenet Standard
IEEE 802.3/802.3u/802.3af/at
Backplane Bandwidth
1.0G
Packet Forwarding Rate
0.75Mbps
Packet Buffer
768K
MAC
2K
Status Indicator
Power Light
1pcs( )Red
Ethernet Port Light
2pcs(Yellow&Green) on RJ45,yellow indicates PoE,
green indicates / ctLink A
Surveillance Module Light
1pcs(Green), green indicates CCTV
Protection Level
Pluse Group
Level 2
Standard: IEC61000-4-4
ESD
1a Contact Discharge Level 3
1b Air Discharge Level 3
Standard: IEC61000-4-2
Anti-thunder Level
Level
Standard: IEC61000-4-5
3
Working
Environment
Working Temperature
0 ~55℃℃
Storage Temperature
-40 ~85℃℃
Humidity(Non-condesing)
0~95%
Mechanical
Dimension(L*W*H)
135mm×85.6mm×27mm
Out Shell
Galvanized Sheet
Color
Black
Weight
315g
Power/Distance
54V
Distance
100m
150m
200m
250m
Power
26W
24W
23W
21W

连接接口
Specification 连 接 接 口
4 Ports PoE Ethernet Switch
34
Specification change will not be noticed
4 Ports POE Ethernet Switch
Trouble Shooting
Please follow the steps if the equipment has trouble.
Make sure the equipment is installed according to the manufactures installation guide.
Confirm RJ45 cable order meets EIA/TIA568A or 568B standard.
Every PoE port can provide PoE equipment maximum power less than 30W, please do not
connect the PoE equipment with power over 30W.
Replace the equipment with a proper functioning 4 ports PoE Ethernet Switch to check if
the equipment is damaged.
Please contact your vendor if trouble still exists.
Instruments to be used: wire crimper, network tester. Wire sequence of RJ45 plug should
conform with EIA/TIA568A or 568B.
1) Please remove 2cm long the insulating layer, and bare 4 pairs UTP cable;
2) Separate the 4 pairs UTP cable and straighten them;
3) Line up the 8 pieces of cables per EIA/TIA 568A or 568B;
4) Cut off the cables to leave 1.5cm bare wire;
5) Plug 8 cables into RJ45 plug, make sure each cable is in each pin;
6) Use the wire crimper to crimp it;
7) Repeat above 5 steps to make the another end;
8) Use network tester to test the cable if it works.
Plug Producing Method
Pin Color
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
1
2
3
4
5
6
7
8
Pin Color
1
2
3
4
5
6
7
8
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
EIA/TIA 568A EIA/TIA 568B
When choose RJ45 make sure if one end is EIA/TIA568A,the other end should also be EIA/TIA568A.
When choose RJ45 make sure if one end is EIA/TIA568B,the other end should also be EIA/TIA568B.
Notice
Item
Description
Power
Power Supply
Power Adaptor
Voltage Range
DC48V~54V
Consumption
＜5W
Ethernet
Speed
1-4 port:Default:10/100Mbps;
CCTV:10Mbps;
UPLINK:100Mbps
Transmission Distance
1-4 port:Default:0～100m;
CCTV:0~250m;
UPLINK:100m
Network Switch
Ethenet Standard
IEEE 802.3/802.3u/802.3af/at
Backplane Bandwidth
1.0G
Packet Forwarding Rate
0.75Mbps
Packet Buffer
768K
MAC
2K
Status Indicator
Power Light
1pcs( )Red
Ethernet Port Light
2pcs(Yellow&Green) on RJ45,yellow indicates PoE,
green indicates / ctLink A
Surveillance Module Light
1pcs(Green), green indicates CCTV
Protection Level
Pluse Group
Level 2
Standard: IEC61000-4-4
ESD
1a Contact Discharge Level 3
1b Air Discharge Level 3
Standard: IEC61000-4-2
Anti-thunder Level
Level
Standard: IEC61000-4-5
3
Working
Environment
Working Temperature
0 ~55℃℃
Storage Temperature
-40 ~85℃℃
Humidity(Non-condesing)
0~95%
Mechanical
Dimension(L*W*H)
135mm×85.6mm×27mm
Out Shell
Galvanized Sheet
Color
Black
Weight
315g
Power/Distance
54V
Distance
100m
150m
200m
250m
Power
26W
24W
23W
21W
