UTEPO UTP3-SW08-TP120 User manual

8PortsPoEEthernetSwitch
UTP3SW08TP120
Product:8PortsPoEEthernetSwitch
Model:UTP3SW08TP120
Description:8portsPoEEthernetSwitchisasecuritysurveillanceEthernetSwitchwhichaimsatEthernethighdefinition
surveillanceandEthernetprojectsecuritysystem.Theproductfullycombinesthecharacteristicsofsecuritysurveillance,
providesfastpacketforwardingabilityandabundantbackplanebandwidth,whichensuresclearimageandfluent
transmission.Insertedstatic,surgeprotectioncircuitcanimproveproductstability.TheproductsupportsonekeyCCTV
mode,canachieveVLANafterconfiguration,controltheNetstorm,protecttheinformationsecurity,preventtheviral
transmissionandEthernetattack,fullysatisfytheEthernetvideosecuritysurveillancesystemandEthernetprojectneeds.
【Certification】
 
【Features】
1.Majorports:1pc100MbpsuplinkEthernetport,8pcs100Mbpsdownlink
Ethernetports,everyportsupportsMDI/MDIX;
2.Specialfunction:OnekeyCCTVmodel;1～8downlinkportscanonlycommunicatewith
uplinkports;
3.Powerinput:DC48V～57V;
4.TransmissionDistance:Ethernetport0～100m;
5.Standard:MeetIEEE802.3,IEEE802.3u,IEEE802.3af/atstandards,PoEuseEndSpan,
thesparecablecanbeofotheruse;
6.Protection:Excellentantithunder,antistaticandantiinterferenceability;
7.Appearance:Delicatedesignandeasyinstallation,configuretheantitheftlockhole,guard
againsttheft;
8.Operation:PlugandPlay,NoSettingrequired.
【Specification】





【Description】
1)Theequipmentmustconnectthegroundaccordingtotherequest.
2)Turnthedialswitchforleft,theequipmentcanentersurveillancemodeafter
providingpowerfortheequipment.


【Installation】

1)Pleaseturnoffthesignalpoweranddisplaydevicepowerbeforeinstallation,

installation
withpowerwilldamagethetransmissionequipment;
2)UsenetworkcableconnectPoEIPcameraand1～8downlinkportsofproduct
respectively;
3)UseanetworkcableconnectequipmentuplinkportandNVRorcomputer;
4)Turnonthepoweroftheequipment;
5)Checkiftheinstallationiscorrect,equipmentisingoodcondition,theconnectionis
stable,thenprovidepowerforsystem;
6)EnsuretheEthernetequipmentwithpowerandworkproperly.



【Scenario】
1.Securitysurveillancesystem
2.WirelessAPnetworksystem
3.IPphonesystem
4.VoIPnetworktelephonesystem

【Accessories】
1.8PortsPOEEthernetswitch1pc
2.Poweradapter1pc
3.ACpowercable1pc
4.Accessory1set
5.Usermanual1set

