Utopian Systems UPD6295 User manual

REV 42015
READ AND SAVE THESE INSTRUCTIONS
95 Pint Portable Dehumidifier
WARNING
Features
• 35%to85%relativehumidityrange
• Two-speedfanoperation
• Digitaldisplay
• Auto-shutofffunction
• Auto-restartfunction
• 24-hourprogrammabletimer
• Removableandwashablelter
• Continuousdraincapability
• Automatedcomfortmode
• One-yearwarranty
Topreventelectricshock,seriouspersonalinjuryordamagetoequipmentorotherproperty,
• Ensurethepowersourcemeetstherequirementslistedonthespecicationlabel.
• Donotmodifythepowercordoroperatetheunitwithanextensioncord.
• Donotoperatetheunitifthecordorplugbecomesdamaged.
• Donotoperatewithoutproperelectricalground.
• Donotoperatenearaheatsource.
• Donotoperateneargasappliances,openameorcombustibleliquidsorgases.
• Donotoperatewherewatermaybespilledorsprayedontheunit.
• Operate,moveandstoretheunituprightatalltimes.
• Allowatleast8”ofspacearoundtheunitforproperventilation.
• Donotrestrictairowbycoveringintakeoroutletgrilles.
• Donotmovetheunitwhilethereiswaterinthetank.
• Donotremovethewatertankwhiletheunitisoperating.
• Donotdrinkorusethewaterdrainedfromtheunit.
• Donotclimborsitontheunit.
• Theroomtemperaturewheretheunitisoperatingmustbebetween41°Fand95°F(5°Cand35°C).
• Disconnecttheunitfromthepowersourcebeforecleaningorservicing.
• Disconnecttheunitfromthepowersourceifnotinuseforaprolongedperiodoftime.
• Operatetheunitindoorsonly.
• Donotattempttorepairtheunit.Anyunauthorizedattempttorepairtheunitwillvoidthewarranty.
• Donotoperatethisdevicebeyondtheusageindicatedinthismanual.SunleavesGardenProducts®isnotresponsiblefordamagecausedby
 inappropriateoperationofthisdevice.
Controlpanel
Drainhoseoutlet
Airintakelter
Casters Powercordandplug
Powercordstorageband
Handle(bothsides)
Airoutletgrille
Watertank
Front Back
Specifications
Volts:115
Watts:730
Amps:6.8
Hertz:60
MoistureRemoval:95pts./day
WaterTankCapacity:21.13pts.
CFM(Normal/Turbo):244/260
OperatingTemperature:41°Fto95°F
Refrigerant:R410A
NetWeight:58lbs.
Dimensions:18.8”x14.2”x24.6”

2
Installation
Control Panel
 1.Continuousmodelight:Indicatesthedehumidierisoperatingincontinuousmode.
 2.Cont.button:Presstoactivateordeactivatecontinuousoperationmode.
 3.Comfortmodelight:Indicatesthedehumidierisoperatingincomfortmode.
 4.Comfortbutton:Presstoactivateordeactivatethecomfortmode.
 5.Filterlight:Indicatesthatthelterneedstobecleaned.
 6.Filterbutton:PresstoresettheFilterlightaftercleaningthelter.
 7.Turbolight:IndicatesthefanspeedissettoTurbo(high).
 8.Turbobutton:PresstoactivateordeactivatetheTurbofanspeed.
 9.Powerbutton:PresstoturnthedehumidierONorOFF.
10.Upbutton:Presstosetahigherhumidityortimervalue.
11.Digitaldisplay:Displaystheselectedhumiditylevelorauto-start/stoptimewhilesetting.Thedefaultdisplayshows
ambienthumiditylevel(between30percentand90percent)whiletheunitisON.
12.Downbutton:Presstosetalowerhumidityortimervalue.
13.Fulllight:Indicatesthewatertankisfullandneedstobeemptied.
14.Defrostlight:Indicatestheauto-defrostfunctionisactive.
15.TimerOnandOfflights:Indicatesauto-ONandauto-OFFsettingsareprogrammed.
16.Timerbutton:Presstoactivateordeactivatethetimerfunctionandtoprogramtheauto-ONandauto-OFFsettings.
2
3
4
5 7
6 8
10
13 914
1516
12 11
1
1. Positiontheunituprightonalevel,stablesurfacetominimizenoiseandvibration.
2. Closealldoorsandwindowsinthearea.Theunitismosteffectiveinanenclosedspace.
3. Plugtheunitintoa120-voltpowersource.

3
Operating Instructions
Programming the Timer
1. Tosettheauto-OFFtime,presstheTimerbuttonuntiltheOfflightilluminates.
2. UsetheUpandDownbuttonstoadjustthetimersettinginhalf-hourincrementsupto10hoursandhour 
 incrementsupto24hours.
3. Tosettheauto-ONtime,presstheTimerbuttonuntiltheOnlightilluminates.
4. UsetheUpandDownbuttonstoadjustthetimersetting.
5. Waitvesecondsfortheunittoacceptthesetting.
Continuous Mode
PresstheCont.buttontoconstantlyrunthedehumidier.Thehumiditylevelcannotbemanuallysetwhentheunitis
operatingincontinuousmode.
Emptying the Water Tank
Whenthewatertankisfull,theFulllightilluminatesandthedisplayreads“P2.”Ifthedehumidierisrunning,the
compressorturnsOFF(thoughthefanmaycontinuetorun).
1. Gripthehandlesonthesidesofthewatertankandslowlypullthetankoutoftheunit.Donot   
 placethetankontheoorasitsunevenbottommaycauseittospill.
2. Emptythetankandcarefullyreplaceitintheunit.IftheunitisON,operationwillresumeoncethetankis 
 properlyreinstalled.
Continuous Drainage
Tocontinuouslydrainwaterfromtheunit,
1. ConrmtheunitispoweredOFF.
2. Removethecoverfromthedrainhoseoutlet.
3. Threadthefemaleendofagardenhose[orotherhose(5/16-inch-IDorgreater)withgardenhosethread,not 
 included]ontotheunit’sdrainhoseoutlet.Ensurethehoseissecurelyattachedtotheoutlet.
4. Directtheotherhoseendtoaoordrainorothersuitabledisposalarea.
5. TurntheunitON,thenselecttheoperationmodeandprogramsettingsasdesired.
Detachthedrainhoseandreplacetheoutletcoverwhenthecontinuousdrainagefunctionisnotinuse.
Auto-Shutoff
TheunitwillturnOFFwhenthewatertankreachescapacity.TheunitwillalsoturnOFFautomaticallywhentheset
humiditylevelisreached.Thefanmotormaycontinuetorunevenwhendehumidifyingfunctionhasceased.
Auto-Defrost
Whenfrostaccumulatesontheevaporatorcoils,thecompressorwillautomaticallyturnOFFandthefanwillcontinue
torununtiltheevaporatorcoilsdefrost.
Auto-Restart
Afterapowerinterruption,theunitwillrestartautomaticallyusingthepreviouslyprogrammedsettings.
Toprotecttheunit,thecompressorwillnotrestartuntilthreeminutesaftershuttingdown.
Comfort Mode
Whenoperatingincomfortmode,theunitautomaticallyadjuststhehumiditylevelaccordingtotheambient
temperaturetomaintainacomfortableenvironment.Theautomatedhumiditylevelsareshowninthechartbelow.
Whencomfortmodeisactive,thehumiditylevelcannotbemanuallyset.
Ambient Temperature Humidity Setting
<64.4°F 55%
64.4°Fto77°F 50%
>77°F 45%

4
Storage and Maintenance
Troubleshooting
Cleaning the Air Filter
TheFilterlightwillilluminateafter250hoursofoperation.Tocleantheairlter,
1. EnsurethattheunitispoweredOFF.
2. Pulluponthetabatthebottomoftheairintakeltertoremoveitfromtheunit.
3. Washthelterwithcleanwater,andletitdry.
4. Reinstallthelterontheunit.
5. PowertheunitON,andpresstheFilterbuttontoresettheindicatorlight.
Cleaning the Unit
• ConrmtheunitisturnedOFF.
• Useasoftclothdampenedwithwaterandmilddetergent.Donotusesolventonplasticparts.
• Useavacuumorbrushtocleantheoutletgrilleaswellastheairintakebehindtheairlter.
• Cleanthetankwithwaterandmilddetergenteveryfewweekstopreventthegrowthofmold,mildewand
 bacteria.Donotputthewatertankinthedishwasher.
Storing the Unit
1. WaitonedayafterturningOFFtheunitbeforeemptyingthewatertank.
2. Cleantheunit,watertankandairlter.
3. Wrapthepowercordonthestoragebandandsecureittothebackoftheunit.
4. Covertheunitwithaplasticbag.
5. Storetheunituprightinadry,well-ventilatedarea.
Problem Cause Solution
Unitisnotrunning. •Unithasreacheditspresetlevel.
•Watertankisfull.
•Circuitbreakertripped.
•Unitisunplugged.
•Emptywatertankandreinstallinunit;ensure
 tankisseatedproperly.
•Resetcircuitbreaker;donotplugotherdevices
 intothesameoutletasthedehumidier.
•Ensureunitisfullypluggedintopowersource.
Unitisnot
removing
enoughmoisture
fromtheair.
•Unitmustoperatelonger.
•Anobjectisobstructingtheairintake.
•Thehumiditycontrolisnotset
 lowenough.
•Doorsorwindowsareopen.
•Roomtemperatureistoolow.
•Thereisasourceofexcessivewatervapor
 suchasakeroseneheaterintheroom.
•Allowunitmoretimetooperate.
•Moveanyobjects,includingcurtainsor
 furniture,awayfromtheunit.
•Settheunitatalowerhumiditylevel.
•Ensurealldoorsandwindowsare
 securelyclosed.
•Raiseroomtemperatureabove41°F.
•Removethedevicecreatingexcessive
 watervapor.
Noisyoperation •Theairlterisclogged.
•Theunitistiltedinsteadofupright.
•Theoorsurfaceisnotlevel.
•Removeandwashtheairlter.
•Ensuretheunitisonalevelsurfaceandis
 sittingupright.
•Movetheunittoalevelsurface.
Frostappearson
thecoils.
•Normaloperation •Theunithasanauto-defrostfeature
 whichwillactivateuntilfrostdisappears.
Wateronoor •Hosedrainoutletcoverislooseormissing.
•Hoseconnectionisloosewhenusing
 continuousdrainmode.
•Replaceortightenoutletcover.
•Ensurehoseconnectionistight
 andfreeofleaks.

5
Error Codes
Error Code Meaning Solution
AS Humiditysensorerror Unplugtheunitandplugitbackin.Iferrorre-
peats,contactforservice.
ES Temperaturesensorerror Unplugtheunitandplugitbackin.Iferror
repeats,contactforservice.
P2 Watertankisfull. Emptythewatertank.
EC Unitmalfunction Theambienttemperaturemaybeoutsidethe
unit’soperatingrange.Ensuretheambient
temperatureisbetween41and95°F.Ifthe
temperatureiswithinthisrangeandtheerror
repeats,followthewarrantyclaimsteps.
E3 Unitmalfunction Unplugtheunitandplugitbackin.Iferror
repeats,followthewarrantyclaimsteps.
Eb Watertankisremovedorincorrectlyinstalled. Replacethewatertankinthecorrectposition.

Error Codes Utopian Systems Limited Warranty
Utopian Systems Portable Dehumidifier Limited Warranty
What This Warranty Covers
This warranty covers defects in materials and workmanship under normal use, with the exceptions
stated below.
Who This Warranty Covers
This warranty applies to the original purchaser of this Utopian Systems product with the original proof
of purchase.
How Long Warranty Coverage Lasts
This warranty is in effect for a period of one year from the original date of purchase.
What This Warranty Does Not Cover
This warranty does not cover damage or defects resulting from the improper installation, alteration,
abuse, accidental damage, unauthorized repair or misuse of this product. Misuse includes but is not
limited to outdoor use. This warranty does not apply to cosmetic defects or other defects that do not
affect the functionality of the product, and is void if the product has been damaged as a result of fire,
flood, or other natural disaster. Sunleaves Garden Products®(“Sunleaves”) shall not be responsible for
any incidental or consequential damages of any nature, including damage or injury caused to other
products, machinery, buildings or property; loss of profits, time or product; or inconvenience. The
original proof of purchase MUST accompany the Utopian Systems product for this warranty to be valid.
This warranty is given in lieu of all other warranties, express or implied, including without limitation
merchantability and fitness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental and consequential damages, or
limitations on how long an implied warranty lasts, so the above limitation(s) may not apply to you.
What Sunleaves Will Do
If Sunleaves determines the warranted product is defective in materials or workmanship during the
warranty period, then Sunleaves, at its option, will either repair or replace the product. In no event shall
the cost of repair or replacement exceed the original purchase price.
How to Obtain Warranty Service
Return this product along with the original proof of purchase to the place of purchase in accordance with
store policy.
How State Law Applies
This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state.
For technical support and warranty information, call toll-free 888-464-9676 or email [email protected].
