Inficon RC1000 Series Quick guide

Translation of the original operating instructions
RC1000
Remote control for leak detectors
lina15en1-07-(2212)
Catalog No.
551-010, 551-015
From software version
V1.5

INFICON GmbH
Bonner Strasse 498
50968 Cologne, Germany

INFICON Table of Contents
RC1000-Operating-instructions-lina15en1-07-(2212) iii
Table of Contents
1 Operating instructions................................................................................................................................... 5
1.1 How to use this manual............................................................................................................................ 5
1.2 Warning and danger symbols .................................................................................................................. 5
1.3 Glossary ................................................................................................................................................... 6
2 Important safety instructions........................................................................................................................ 7
2.1 Intended use ............................................................................................................................................ 7
2.2 User requirements.................................................................................................................................... 7
2.3 Restrictions of use.................................................................................................................................... 7
2.4 Hazards in the event of intended use....................................................................................................... 8
3 Description of the RC1000........................................................................................................................... 11
3.1 Use ......................................................................................................................................................... 11
3.2 Operating Elements ............................................................................................................................... 12
3.3 Back of the RC1000 ............................................................................................................................... 14
3.4 Supplied equipment ............................................................................................................................... 15
4 Installation .................................................................................................................................................... 16
4.1 Connection to the leak detector ............................................................................................................. 16
4.2 Connecting radio transmitter and leak ................................................................................................... 17
4.3 Inputs and outputs.................................................................................................................................. 18
4.4 Wall plug-in power supply ...................................................................................................................... 20
5 Operating the remote control...................................................................................................................... 21
5.1 Starting up the RC1000.......................................................................................................................... 21
5.2 Touch display operation ......................................................................................................................... 22
5.3 Main menu for configuration................................................................................................................... 24
5.3.1 Buttons with basic functions........................................................................................................ 24
5.3.2 Connecting / disconnecting WL1000 .......................................................................................... 25
5.3.3 Setting the trigger level ...............................................................................................................26
5.3.4 Scale: scaling of the leak-rate curve ........................................................................................... 27
5.3.5 Sound volume ............................................................................................................................. 29
5.3.6 Recorder ..................................................................................................................................... 30
5.3.7 Info: device information............................................................................................................... 33
5.3.8 Miscellaneous ............................................................................................................................. 34
5.3.8.1 Language selection............................................................................................................ 34
5.3.8.2 Energy-saving options (RC1000WL) ................................................................................. 35

Table of Contents INFICON
iv RC1000-Operating-instructions-lina15en1-07-(2212)
5.3.8.3 Set Time and Date............................................................................................................. 36
5.4 Operating the leak detector.................................................................................................................... 37
5.5 Paging function ...................................................................................................................................... 39
6 Maintenance tasks ....................................................................................................................................... 40
6.1 Spare parts............................................................................................................................................. 40
6.2 Maintenance........................................................................................................................................... 40
6.3 Cleaning ................................................................................................................................................. 41
7 Transport and disposal................................................................................................................................ 42
7.1 Transporting ........................................................................................................................................... 42
7.2 Disposal ................................................................................................................................................. 42
8 Technical Data .............................................................................................................................................. 43
8.1 Weight / dimensions...............................................................................................................................43
8.2 Characteristics ....................................................................................................................................... 43
8.3 Environmental Conditions ...................................................................................................................... 43
8.4 Mains power for wall plug-in power supply ............................................................................................ 44
8.5 Wireless permits of RC1000WL ............................................................................................................. 44
9 Ordering information ................................................................................................................................... 45
10 Appendix ....................................................................................................................................................... 46

INFICON Operating instructions | 1
RC1000-Operating-instructions-lina15en1-07-(2212) 5 / 48
1 Operating instructions
1.1 How to use this manual
Read this manual before commissioning the wireless RC1000WL or the wire-bound
RC1000C remote control.
Keep the manual so that you can use it any time.
Enclose the operating manual if the device is ever passed on to third parties.
We reserve the right to alter the design or any data given in this manual.
The illustrations are not binding.
1.2 Warning and danger symbols
DANGER
Imminent hazard resulting in death or serious injuries
WARNING
Hazardous situation resulting in potential death or serious injuries
CAUTION
Hazardous situation resulting in minor injuries
NOTICE
Hazardous situation resulting in damage to property or the environment

1 | Operating instructions INFICON
6 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
1.3 Glossary
Menu
The menu enables the operator of the RC1000WL or RC1000C remote control to
program the remote control to reflect their personal preferences. The menu has a tree
structure.
"As delivered" status
The condition of the RC1000WL or RC1000C remote control as it left the factory.
RC1000
RC1000C (non-wireless) or RC1000WL (wireless) remote control. If this manual talks
about general functions that apply to both versions, it is called only RC1000.

INFICON Important safety instructions | 2
RC1000-Operating-instructions-lina15en1-07-(2212) 7 / 48
2 Important safety instructions
Before commissioning the RC1000 remote control, carefully read all
safety instructions and make sure that you have properly understood
them.
2.1 Intended use
The RC1000 remote control has been designed to operate the UL1000, UL1000Fab,
UL3000Fab/Ultra, UL5000, UL6000Fab/Ultra and Modul1000 leak test devices.
The former wired remote control (catalog no. 200 99 022) can be replaced by the
RC1000. The RC1000 remote control must only be used for the purpose and within
the context outlined in this manual.
Use only INFICON accessories.
2.2 User requirements
The RC1000 remote control must only be connected and operated by
properly trained staff.
• The user must be familiar with the function of the device; he or she may only
connect and operate the device after having read and understood the operating
instructions.
• The user should consult local, state, and national agencies regarding specific
requirements and regulations for devices with wireless transmission capability.
• In case of more questions regarding safety, operation and/or maintenance, the
user should contact our nearest representative.
2.3 Restrictions of use
WARNING
Danger in explosive environments
The RC1000C remote control may only be used away from explosive environments.

2 | Important safety instructions INFICON
8 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
2.4 Hazards in the event of intended use
DANGER
Possible interference with pacemakers.
Pacemakers can be affected in their function by the speaker magnet on the back of
the RC1000 remote control.
► As a wearer of such devices, keep at least 10 cm distance between the
loudspeaker magnet and the implant.
► Furthermore, take into account distances specified by the manufacturer of the
implant.
When handling the remote control RC1000:
WARNING
Possible liquid crystal hazard
If the display has broken, prevent liquid crystals from entering people's mouths or
eyes.
► Use soap and water to wash hands, feet or clothes that have come into contact with
liquid crystals.
WARNING
Possible radiation hazard
When the device is operated, a minimum distance of 7 cm between the remote control
and people must be observed, with the exception of hands and wrists.
► Operation at a shorter distance than indicated above is not allowed. The RC1000
remote control complies with part 15 of the FCC regulations (1).
(1) FCC: Federal Communications Commission, approval authority for communication
devices (USA)
When handling the rechargeable battery and power supply
WARNING
Possible short circuit hazard
In case of a short-circuit the battery might ignite, explode, leak battery fluid, or become
overheated and cause burns.
► Do not short-circuit the battery of the RC1000WL remote control.

INFICON Important safety instructions | 2
RC1000-Operating-instructions-lina15en1-07-(2212) 9 / 48
Charging the battery at higher temperatures (> 40° C) decreases its
service life.
NOTICE
Possible risk of damage
The electronics of the RC1000WL remote control may be damaged by an incorrect
supply voltage.
► Only use the accompanying wall plug-in power supply.
Environmental conditions of the remote control
See also 8.3 Technical Data.
NOTICE
Possible risk of damage
The RC1000 remote control may be damaged in the open through moisture, strong
insolation, or intense dust.
► Only use the device inside buildings.
NOTICE
Possible risk of destruction
Aggressive substances may damage the RC1000 remote control beyond repair.
► Avoid contact between the RC1000 and bases, acids, and solvents, and do not
expose it to extreme climatic conditions.
NOTICE
Possible risk of destruction
The RC1000 remote control may be damaged beyond repair by penetrating liquid.
► Do not switch on the RC1000 remote control if liquid has penetrated the unit.
► Contact the INFICON Service Department.

2 | Important safety instructions INFICON
10 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
Storage and transportation of the remote control
NOTICE
Possible risk of damage
The RC1000 remote control may be damaged by being stored in unfavourable
conditions (too damp, too hot, too cold, too high above sea level) for months or years
(see Technical specifications chapter 8.3).
► If the RC1000 remote control has been stored under such conditions, leave it
switched off and contact the INFICON Service Department.
NOTICE
Possible risk of damage
The RC1000 remote control may be damaged by improper transport.
► Always transport the RC1000 remote control in its original packaging.
Cleaning the remote control
Clean the plastic housing of the RC1000 remote control, the front foil and the display
using a soft cloth, moistened with some water or soap suds. Do not use any solvents
Operating the remote control
The performance and reliability of the RC1000 remote control can only be guaranteed
if it is operated under the specified conditions of use (see Technical specifications
chapter 8).
Any changes made to the RC1000 remote control by the user may result in a violation
of statutory provisions or may affect the EMC properties and safety of the product.
INFICON does not accept any liability for the consequences of such changes.
See also
2Environmental Conditions [}43]
2Technical Data [}43]

INFICON Description of the RC1000 | 3
RC1000-Operating-instructions-lina15en1-07-(2212) 11 / 48
3 Description of the RC1000
3.1 Use
The RC1000 remote control has been designed to operate the selected INFICON leak
detectors.
The RC1000 remote control is accommodated in a robust housing the shape of which
enables ergonomic working. Magnets on the underside of the unit enable it to be
attached to horizontal or vertical metal surfaces.
The wireless version RC1000WL enables remote operation up to a distance of over
100 m, depending on the reception conditions. The integrated rechargeable battery
enables over 8 hours of operation, depending on the battery level.
The leak rates can be displayed in digits or in a curve on the 3.5" colour display.
Measured values of up to several hours of recording can be stored in an internal
memory. The data storage interval is adjustable. The data can easily be downloaded
to a USB stick via the integrated USB interface to save it.
An internal trigger can be set to provide a warning if the limit leak rates are exceeded.
An optical warning is shown on the display and an acoustic warning signal with
variable pitch proportionally to the leak rate is sounded on the integrated loudspeaker
or the connected headphones.

3 | Description of the RC1000 INFICON
12 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
3.2 Operating Elements
1
2
3
4
5
6
7
Fig.1: RC1000 remote control
Pos. Description Pos. Description
1 Touch Display 5 Charge LED
2 STOP button 6 ZERO button
3 Operating LED 7 START button
4 POWER button
Touch Display
Shows measurements displayed numerically or as a curve, indicates statuses and
offers operating interfaces.
STOP button
Ends leak testing (See 5.4).
Operating LED
Flashes during normal operation.
POWER button
RC1000WL: Power switch. After pressing and briefly holding the switch, the operating
LED lights up as confirmation and flashes when the remote control is ready for use.
Switch off by pressing and holding the button for more than 2 seconds.
RC1000C: The remote control turns on when the cable is plugged in.
Pressing the Power button turns the display of the remote control on and off.

INFICON Description of the RC1000 | 3
RC1000-Operating-instructions-lina15en1-07-(2212) 13 / 48
Charging LED (RC1000WL)
Lights up while the battery is being charged.
ZERO button
Activates the ZERO function (See 5.4).
START button
Starts the leak test of the leak detector (See 5.4). (See the Technical Manual of the
leak detector, and observe the menu option "Control location").

3 | Description of the RC1000 INFICON
14 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
3.3 Back of the RC1000
NOTICE
Risk of damage
Use screws that reach max. 6 mm into the housing.
11
2
1
3
4
Fig.2: Back of the RC1000 remote control
Pos. Description Pos. Description
1 Magnets for attaching the unit to
metal surfaces, e.g. to the leak
detector.
3 Sound outlet aperture for the
integrated loudspeaker.
2 M3 threaded bushings to attach
holders
4 Eye for attaching carrying
devices (e.g. wrist band, to be
ordered separately).

INFICON Description of the RC1000 | 3
RC1000-Operating-instructions-lina15en1-07-(2212) 15 / 48
3.4 Supplied equipment
Cat.-No. 551-015 Remote control RC1000WL, wireless
Item Quantity
Remote control RC1000WL 1
Connection cable, 4 m 1
Wall plug-in power supply (for integrated battery) 1
Radio transmitter 1
Connection cable for radio transmitter 1
Sealing plug for RJ25 socket 1
Operating instructions 1
Cat.-No. 551-010 Remote control RC1000C, non-wireless
Item Quantity
Remote control RC1000C 1
Connection cable, 4 m 1
Operating instructions 1
Cat.-No. 551-020 Radio transmitter (for operating a second leak
detector)
Item Quantity
Radio transmitter 1
Connection cable 1
Installation instructions 1

4 | Installation INFICON
16 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
4 Installation
4.1 Connection to the leak detector
The leak detectors should have at least following software versions:
UL1000/UL1000 Fab, UL3000Fab/Ultra,UL5000, UL6000Fab/Ultra: SW
V4.4, Modul1000: SW V1.6.
RC1000WL (wireless)
The RC1000WL remote control is connected to the leak detector by means of a
wireless data connection. Connect the leak detector to the radio transmitter for this
purpose (see chapter 4.2).
The RC1000WL remote control is shipped set-up for connection with the supplied
radio transmitter. This way, the connection is immediately established upon turning the
unit on.
Alternatively, it can also be connected by means of the enclosed cable, similar to
connecting the RC1000C (nonwireless) remote control. In this case only one
connection cable must be used with the RC1000WL, not more.
RC1000C (non-wireless)
The RC1000C (non-wireless) remote control is connected to the leak detector by
connecting the enclosed connection cable to the RJ 25 socket (see Fig. 4).
With the wired version of the RC1000C, leak detectors can be operated over a
maximum distance of 34 m using the connection cable (4 m) and a maximum of three
extension cables (10 m each) available as accessories.

INFICON Installation | 4
RC1000-Operating-instructions-lina15en1-07-(2212) 17 / 48
See also
2Connecting radio transmitter and leak [}17]
4.2 Connecting radio transmitter and leak
1
2
Fig.3: Connecting radio transmitter and leak detector (RC1000WL)
1Use Velcro to position the radio transmitter (1) in a suitable location on the
SmartTest leak detector so that there is a direct line of sight between the
antenna and the remote control.
2Connect the connecting cable of the radio transmitter to the RJ25 socket of the
leak detector (2).
To extend the wireless operating range an extension cable also can be used to
position the radio transmitter away from the leak detector, if reception is poor (e.g. at
the ceiling of the room).
The operating range of the radio transmitter will be affected by metal objects in its
near, avoid installing the antenna near such objects.

4 | Installation INFICON
18 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
4.3 Inputs and outputs
RJ25 socket
The RJ25 socket is located at the underside of the RC1000 remote control and closed
with a protective plug when delivered.
Fig.4: RJ25 socket on the bottom of the remote control
RC1000C
The RJ25 socket is used exclusively for communication with the leak detector.
RC1000WL
The RJ25 jack is used for communication to the leak detector and for charging the
battery.
Fig.5: Sealing plug for RC100WL
As delivered, the RC1000WL remote control (for IP42) is sealed with a protective plug.
Leave the protective plug in the socket when the cable is not connected.
We recommend only inserting and removing the RJ25 plug as often as is necessary
for operation.

INFICON Installation | 4
RC1000-Operating-instructions-lina15en1-07-(2212) 19 / 48
Connections on the side
Fold the protective strip upwards before connecting a plug.
Fig.6: RC1000WL: Side connections with transparent cover
123
Fig.7: Connections on the side (without cover)
Pos. Description
1 USB connection Insert the USB stick (FAT formatted) to record data.
2 3.5 mm jack for stereo headphones
Standard stereo headphones with a 3.5 mm jack plug and >2x32 Ohm
impedance can be connected to the jack.
If the headphones are inserted, the volume of the integrated loudspeaker is
automatically lowered.
3 Charging socket for the enclosed power supply

4 | Installation INFICON
20 / 48 RC1000-Operating-instructions-lina15en1-07-(2212)
4.4 Wall plug-in power supply
DANGER
Possible risk of voltage hazard
Do not open the external power supply of the RC1000WL remote control.
► This might result in electric shock and/or injuries.
WARNING
Risk due to incorrect power supply unit.
Using an external power supply which has not been approved by the manufacturer of
the remote control may result in electric shock, damage and/or injuries.
► Only use the power supply which was enclosed with the RC1000WL remote control.
Fig.8: Wall plug-in power supply of the RC1000WL
Connect the plug of the power supply with the socket of the RC1000WL (see Fig. 7,
Pos. 3), to charge the integrated battery.
The RC1000WL is always switched on while the power supply cable is connected and
the battery is being charged, the Charging LED is lit.
Short pressing of the „POWER“ button reduces the backlight intensity, pressing it for a
time longer than about 10 s performs a reset of the remote control.
The LED switches off as soon as the battery has fully charged.
The battery can be charged during operation.
You can use the enclosed power supply all over the world; adapt it with the
interchangeable blades to the national design (Europe, North America, Japan, UK,
China, Australia, see also 8.4).
