V-tech RM5766HD User manual

RM5766HD
RM5766HD-2
Smart Wi-Fi 1080p
Pan & Tilt Monitor
5”
User Guide
This guide contains important information.
Please keep it for future reference.

2
Contents
Important Safety Instructions�������������������������������������������������������������������������������3
Setup�����������������������������������������������������������������������������������������������������������������������5
What’s Included? .....................................................................................................................5
Overview..................................................................................................................................6
Parent Unit Icons....................................................................................................... 10
How the System Works?........................................................................................... 13
Protect Your Privacy and Online Security ..............................................................................15
Connect the Baby Monitor .....................................................................................................16
Charge the Parent Unit Battery..............................................................................................17
Basic Operation���������������������������������������������������������������������������������������������������18
Power on/o󰀨...........................................................................................................................18
Use the Menu ........................................................................................................................20
Adjust Speaker Volume .........................................................................................................20
Zoom, Pan and Tilt the Camera.............................................................................................21
Talk to Your Baby via the Baby Unit.......................................................................................22
Turn on/o󰀨 the Parent Unit Screen ........................................................................................23
Test the Sound Level and Position the Baby Monitor ............................................................24
Advanced Operation �������������������������������������������������������������������������������������������26
Download App for Mobile Access ..........................................................................................26
Set up Wi-Fi Connection........................................................................................................27
Monitoring Modes (RM5766HD-2 only) .................................................................................28
Night Light..............................................................................................................................28
Melodies and Soothing Sounds .............................................................................................30
Sound, Motion, Temperature Alerts .......................................................................................31
Parent Unit Settings...............................................................................................................35
Baby Unit Settings .................................................................................................................36
Software and Firmware Update ............................................................................................37
Reset .....................................................................................................................................37
Test the Best Location for the Baby Unit................................................................................38
Additional Information ����������������������������������������������������������������������������������������39
Wall Mount (Optional) ............................................................................................................39
Frequently Asked Questions..................................................................................................42
General Product Care............................................................................................................42
Storage .................................................................................................................................43
Adult Supervision..................................................................................................................43
Technical Specications.........................................................................................................43
Disposal of Batteries and Product .........................................................................................43
Customer Service and Product Warranty ..............................................................................44

3
The applied nameplate is located at the bottom of
the baby unit’s base. When using your equipment,
basic safety precautions should always be followed
to reduce the risk of re, electric shock and injury,
including the following:
1. Follow all warnings and instructions marked on
the product.
2. Adult setup is required.
3� CAUTION: Do not install the baby unit at a height
above 6.5 feet (2 metres).
4. This product is intended as an aid. It is not
a substitute for responsible and proper adult
supervision and should not be used as such.
5. This product is not intended for use as a medical
monitor.
6. Do not use this product near water. For example,
do not use it next to a bath tub, wash bowl,
kitchen sink, laundry tub or swimming pool, or in
a wet basement or shower.
7� CAUTION: Use only the battery provided. There
may be a risk of explosion if a wrong type of
battery is used for the parent unit. The battery
cannot be subjected to high or low extreme
temperature and low air pressure at high altitude
during use, storage or transportation. Disposal
of battery into re or a hot oven, or mechanically
crushing or cutting or the battery can result in an
explosion. Leaving the battery in an extremely
high temperature surrounding environment can
result in an explosion or the leakage of ammable
liquid of gas. Battery subjected to extremely low
air pressure may result in an explosion or the
leakage of ammable liquid or gas. Dispose of
used battery according to the instructions.
8. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Power adapters information:
Baby Unit Output: 5V DC 1000mA
VTech Telecommunications Ltd.
Model: VT05EAU05100
Parent Unit Output: 5V DC 2A
VTech Telecommunications Ltd.
Model: VT07EAU05200
Rechargeable battery information:
3.7V 5000mAh, 18.5Wh Lithium-ion battery
Zhuhai Great Power Energy Co., Ltd.
Model: GSP806090-5Ah-3.7V-1S1P
9. The power adapter is intended to be correctly
oriented in a vertical or oor mount position. The
prongs are not designed to hold the plug in place
if it is plugged into a ceiling, under-the-table or
cabinet outlet.
10. For pluggable equipment, the socket-outlet (power
adapter) shall be installed near the equipment and
shall be easily accessible.
11. Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners. Use a
damp cloth for cleaning.
12. Do not cut o󰀨 the power adapters to replace them with
other plugs, as this causes a hazardous situation.
13. Do not allow anything to rest on the power cords. Do
not install this product where the cords may be walked
on or crimped.
14. This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or local power company.
15. The equipment is to be supplied from an identied
USB port complying with the requirements of Limited
Power Source.
16. Do not overload wall outlets or use an extension cord.
17. Do not place this product on an unstable table, shelf,
stand or other unstable surfaces.
18. This product should not be placed in any area where
proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for
ventilation. To protect them from overheating, these
openings must not be blocked by placing the product
on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator
or heat register.
19. Never push objects of any kind into this product
through the slots because they may touch dangerous
voltage points or create a short circuit. Never spill
liquid of any kind on the product.
20. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specied access doors may expose
you to dangerous voltages or other risks. Incorrect
reassembling can cause electric shock when the
product is subsequently used.
21. You should test the sound reception every time you
turn on the units or move one of the components.
22. Periodically examine all components
for damage.
23. There is a very low risk of privacy loss when using
certain electronic devices, such as baby monitors,
cordless telephones, etc. To protect your privacy,
make sure the product has never been used before
purchase, reset the baby monitor periodically by
powering o󰀨 and then powering on the units, and
power o󰀨 the baby monitor if you will not use it for
some time.
Important Safety Instructions

4
24. Children should be supervised to ensure that
they do not play with the product.
25. The small parts of this monitor can be swallowed
by babies or small children. Keep these parts out
of reach of children.
26. The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature
between 0oC and 40oC.
• Burn hazard, re hazard, explosion hazard
associated with mishandling of the battery.
• Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to
a heating source.
• Warning—Strangulation Hazard—Children
have STRANGLED in cords. Keep
this cord out of the reach of children
(more than 3 ft (0.9m) away). Do not
remove this tag.
• Never place the camera unit(s) inside the baby’s
crib or playpen. Never cover the camera unit(s)
or parent unit with anything such as a towel or a
blanket.
• Other electronic products may cause interference
with your camera unit. Try installing your
camera unit as far away from these electronic
devices as possible: wireless routers, radios,
cellular telephones, intercoms, room monitors,
televisions, personal computers, kitchen
appliances and cordless telephones.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an
independent research entity, led a multidisciplinary
evaluation of the interference between portable wireless
devices and implanted cardiac pacemakers. Supported by
the U.S. Food and Drug Administration, WTR recommends
to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from
the pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is
turned ON.
WTR’s evaluation did not identify any risk to bystanders
with pacemakers from other persons using wireless
devices.
Electromagnetic elds (EMF)
This VTech product complies with all standards regarding
electromagnetic elds (EMF). If handled properly and
according to the instructions in this user’s manual, the
product is safe to be used based on scientic evidence
available today.

5
Setup
What’s Included?
Parent Unit
Baby Unit
Wall Mount Bracket
Parent Unit Adapter Baby Unit Adapter
Quick Start
Guide
x 2 x 2
Learn to set up your units and have all
detailed instructions on using your audio
baby monitor.
1 set for RM5766HD
2 sets for RM5766HD-2

6
Overview
Baby Unit
7
8
9
10
4
6
5
2
11
12
13
1
3
7
8
9
10
4
6
5
2
11
12
13
1
3
7
8
9
10
4
6
5
2
11
12
13
1
3

7
1 Light Sensor
2 Camera Lens
3 Infrared LEDs
• Allow you to see clearly in a dark environment.
4 Microphone
5 Night Light
6Night Light Control Key
• Go to Night Light section to learn more.
7 LED Indicator
• Red is steadily on when the baby unit is connecting to the parent unit in direct mode.
• Green is steadily on when the baby unit is connected in Wi-Fi router mode.
• Red ashing slowly during video streaming in direct mode.
• Green ashes slowly during video streaming in Wi-Fi router mode.
8ON/OFF Switch
• Power it on or o󰀨.
9 Speaker
10 Temperature Sensor
11 Power Jack
12 Wall Mount Slots
13 PAIR
• The parent unit and baby unit(s) provided are already paired.
• Reset the baby unit to factory default.
1. Press and hold PAIR key until you hear a beep sound.
2. Release the PAIR key, and then press the PAIR key again ve times until you
hear another beep sound.
3. The baby unit will sound another beep when the reset completes. Then, the baby
unit will reboot.

8
Parent Unit
2
1
3
4
5
6
7
8
9
10
14
15
13
12
11

9
1 LINK LED Light
• On when the parent unit is linked to the baby unit.
• Flashes when the link to the baby unit is lost.
2LED light
• On when the parent unit is connected to AC power, and the battery is charging.
• Flashes when the parent unit battery is low and needs to be charged.
3 3 - Level Sound Indicator Light
• Green: low sound level is detected by the baby unit.
• Green and amber: moderate sound level is detected by the baby unit.
• Green, amber and red: high sound level is detected by the baby unit.
4TALK /
• Press and hold to talk to the baby unit.
• While in a sub-menu, press to exit.
5 MENU |SELECT
• Press to enter the main menu.
• While in a menu, press to choose an item, or save a setting.
6|||Arrow keys
• Press to navigate leftward, upward, rightward or downward, within the main menu
and sub-menus.
• While viewing a zoomed image, press to move the image leftward, upward, rightward
or downward.
• While in normal viewing mode, press the arrow button to pan and tilt the baby unit, or
hold-on the button to move continuously.
7 Microphone
8|Increase or decrease parent unit volume.
9Zoom
• Press to zoom in/out.
• While in a sub-menu, press to view the help menu.
10 Power | LCD ON/OFF
11 Antenna
12 Speaker
13 Power Jack
14 RESET Force reboot the parent unit.
15 Stand

10
Parent Unit Icons
Main Menu Options
Monitoring Mode (*For RM5766HD-2 only)
• View baby units in Single mode.
• View baby units in Patrol mode.
• View baby units in Split screen.
Night Light
• Turn on or turn o󰀨 night light.
• Select a night light colour.
• Adjust night light brightness.
• Set a night light timer.
Melodies and Soothing Sounds
• Select to play all melodies, or play one of the ve melodies and ve
soothing sounds.
• You can also set the timer to stop playing after 15, 30 or 60 minutes, or
playing non-stop.
Alerts - Sound, Motion and Temperature
• Select the sound and motion sensitivity level.
• Turn on/o󰀨 sound and motion detection alerts.
• Select maximum and minimum temperature for alert range.
• Turn on/o󰀨 temperature alert.
• Turn on/o󰀨 Auto Wake Up function.
Parent Unit Settings
• Adjust parent unit screen brightness.
• Adjust Low Battery Alert Tone.
• Adjust No Link Alert Tone.
• Turn on/o󰀨 Dim mode.
Baby Unit Settings
• Turn on/o󰀨 Night Vision.
• Turn on/o󰀨 baby unit Status LED.
• Adjust baby unit speaker volume.

11
General Settings
• Congure Wi-Fi.
• Connect mobile phone.
• Reset Settings to factory default.
• Software Update.
Status Icons
Direct Mode
Parent unit, baby unit 1 and baby unit 2 (*For RM5766HD-2 only) are
connected to each others directly.
Red bars indicate no connection.
Wi-Fi Router Mode
Parent unit, baby unit 1 and baby unit 2 (*For RM5766HD-2 only) are
connected to home Wi-Fi network.
The red icon on the baby unit or parent unit, indicates no connection
between the respective unit(s) and the router.
Baby unit 1 and 2 are being viewed in Patrol mode (*For RM5766HD-2
only).
Baby unit 1 and 2 are being viewed in Split mode (*For RM5766HD-2 only).
Night vision is turned on.
Motion detection alert is turned on.
Sound detection alert is turned on.
Melodies and soothing sounds are playing.

12
Night light is turned on.
Auto night light brightness is activated.
Temperature alert is turned on.
Parent unit is muted.
( ) Temperature detected is below setting.
( ) Temperature detected is within setting range.
( ) Temperature detected is above setting.
Battery indicator
Alert Icons
Displays when motion that exceed the set sensitivity level is
detected at a baby unit.
Displays when sound that exceed the set sensitivity level is
detected at a baby unit.
Displays when baby unit detects temperature reaches or
exceeds the set maximum.
Displays when baby unit detects temperature is at or is lower
than the set minimum.

13
How the System Works?
For better security and more stable connectivity, this baby monitor requires
connecting to a Wi-Fi network and operating in Router mode connection.
Direct Mode
Your baby monitor parent unit and baby unit connect to each other in Direct mode
by default, which allows you to immediately stream video out of the box.
It is NOT recommended to continue using Direct Mode connection after
initial installation�
Local access
Tip: You may experience reduced signal strength if your parent unit and baby unit are far
apart, or there are obstructing factors, such as internal walls, between them. You have to set
up Router mode to connect the units via your home Wi-Fi network to improve the connection
between your parent unit and baby unit.
Local access, for
start up quick view
and setup stage�

14
Router Mode
You are required to set up your monitor in Router mode to enjoy live video
streaming via your parent unit with an enhanced connection. Router mode is the
recommended mode for stable connectivity.
Router mode uses your home Wi-Fi network to connect your video monitor. It
supports live video streaming through the parent unit and smartphone app.
If you want to stream live video remotely with your mobile device, download and
install the MyVTech Baby Pro mobile app. With the mobile app, your Wi-Fi router
(not included) provides Internet connectivity to your HD video monitor system. It
serves as a communicating channel between your baby unit and mobile device,
allowing you to monitor and/or control your baby unit wherever you are. For
details, see Download App for Mobile Access section.
Mobile access
Connecting Wi-Fi to
enhance local access
NOTE
When both parent unit and app are viewing the camera simultaneously, the video quality will be
optimised to deliver the best possible viewing result.

15
Protect Your Privacy and Online SecurityProtect Your Privacy and Online Security
VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of
industry-recommended best practices to help keep your wireless connection private and your
devices protected when online. We recommend you carefully review and consider complying with
the following tips.
Ensure your wireless connection is secure.
• Before installing a device, ensure your router’s wireless signal is encrypted by selecting the “WPA2-PSK with
AES” setting in your router’s wireless security menu.
Change default settings.
• Change your wireless router’s default wireless network name (SSID) to something unique.
• Change default passwords to unique, strong passwords. A strong password:
- Is at least 10 characters long.
- Is complex.
- Does not contain dictionary words or personal information.
- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.
Keep your devices up to date.
• Download security patches from manufacturers as soon as they become available. This will ensure you always
have the latest security updates.
• If the feature is available, enable automatic updates for future releases.
Disable Universal Plug and Play (UPnP) on your router.
• UPnP enabled on a router can limit the e󰀨ectiveness of your rewall by allowing other network devices to open
inbound ports without any intervention or approval from you. A virus or other malware program could use this
function to compromise security for the entire network.
For more information on wireless connections and protecting your data, please review the
following resources from industry experts:
1� Federal Communications Commission: Wireless Connections and Bluetooth Security Tips –
www.fcc.gov/consumers/guides/how-protect-yourself-online.
2� U.S. Department of Homeland Security: Before You Connect a New Computer to the Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3� Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4� Wi-Fi Alliance: Discover Wi-Fi Security –
http://www.wi-.org/discover-wi-/security.

16
Connect the Baby Monitor
Connect the parent unit and baby unit to a power supply with the included power
adapters.
Notes:
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the baby unit are not connected to the switch controlled
electric outlets.
• Connect the power adapters in a vertical or oor mount position only. The adapters’ prongs
are not designed to hold the weight of the parent unit and the baby unit, so do not connect
them to any ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not
properly connect to the outlets.
• Make sure the parent unit, the Baby Unit and the power adapter cords are out of reach of
children.

17
Charge the Parent Unit Battery
The parent unit runs on rechargeable battery or AC power. To continuously monitor
your baby, keep the parent unit connected to AC power.
The parent unit turns on automatically after it connects to the power socket for the
rst time using, and its battery will charge at the same time.
Notes:
• Before using the baby monitor for the rst time, charge the parent unit battery for 12 hours.
When the parent unit battery is fully charged, the battery icon becomes solid .
• The standby time varies depending on your actual use.
The battery icon on the screen indicates the battery status (see the following
table).
Battery Indicators Battery Status Action
The screen displays
or .
The LED light
ashes.
The battery power is very
low and may only be usedused
for a short time.for a short time.
Charge without interruption
(about 30 minutes).
The battery icon
becomes solid .
The battery is fully
charged.
To keep the battery
charged, connect it to AC
power when in use.

18
Basic Operation
After powering up your baby monitor, the parent unit streams live video in direct
mode. We recommend you follow the instructions on screen to set up home Wi-Fi
network with your monitor for functionality enhancements and mobile access. See
Download App for Mobile Access and Set up Wi-Fi Connection in this user
guide.
Power on/o󰀨
1� Slide the power switch to ON to turn on your baby unit. Slide to the opposite
direction to turn o󰀨.
Notes:
• When powering up, the baby unit’s status LED turns on. It will turn o󰀨 after a while and keeps
o󰀨.
• The status LED is set to off by default. If you want to keep the LED on, press MENU/
SELECT, then go to > Status LED and turn it on.
• WARM
WARM
Camera lens and surface may get warm during normal operation.

19
2� Press Power to turn on the parent unit, the welcome screen appears and
the LINK LED flashes. You can press and hold Power to turn it off after
using.
3� Once your baby unit and parent unit are powered on, the parent unit and baby
unit will pair each other automatically. When they are connected successfully,
the LINK LED lights steadily. And your parent unit displays image from the baby
unit.
4� Raise the parent unit antenna for better reception.

20
Use the Menu
Press MENU on the parent unit to enter the main menu, choose a menu item,
or save a setting. You can use the parent unit menu for advanced settings or
operations, such as to play or stop the baby unit lullaby, or adjust the baby unit
sound sensitivity.
While in the menu:
• Press |||to scroll among the menu options.
• Press MENU to select an item.
• Press TALK / to return to the live video.
• Press to go to the Help & info page.
Note: When you use MENU to nish an operation or setting, press TALK / to exit. Or if no
other operations, it will return to live video mode automatically after 5 seconds.
Adjust Speaker Volume
Press |to adjust the parent unit speaker volume level received from
the baby unit.
Muted
