V-tech VM5251 User manual

VM5251
What’s in the box
Dim mode
With dim mode preset to on, your
parent unit display will dim to
conser ve energy after 10 minutes
of inactivity, in which there is
neither key pressed nor alert
received from the baby unit.
Connect and power on/off - Baby unit Connect and power on - Parent unit
CAUTION
The default volume of your parent unit is
level 4, and the maximum volume is level 7.
If you experience high-pitched screeching
noise from your baby monitor while
positioning:
Make sure your baby unit and parent unit
are more than 3 feet (1 meter) apart, OR
Turn down the volume of your parent unit.
•
-
-
Once you power on both your baby unit and parent unit, your parent unit displays image from the baby unit,
and the LI NK LED light turns on. The ON/OFF LED light of the baby unit also turns on.
Status check
VM5251 baby monitor system
Baby’s room Living room
Sound activation
When the baby unit detects no sound, the parent unit screen
stays off to save power. Once a sound is detected, the parent unit
screen turns on automatically. It will then turn off again after
50 seconds of no sound detection.
Sound-activated Screen
On
O
Night vision
The baby unit has infrared LEDs that allow you to
see your baby at night or in a dark room. When the
baby unit detects low light levels, the infrared LEDs
turn on automatically. The images from the baby
unit are in black and white, and appears on
screen.
NOTES
It is normal if you see a short white glare on your pare nt
unit scree n as the baby unit is ad apting to the da rk
environment.
When the i nfrared LEDs are on, t he image s are in black
and whit e. This is no rmal.
TIP
Depending on the surroundings and other interfering
factors, like lightings, objects, colors and backgrounds,
the display resolution may vary. Adjust the baby unit’s
angle, or place the baby unit at a higher level to prevent
glare and blurry display.
•
•
•
Install the battery
THIS SIDE UP
Slide t he ON/OFF switch to OFF to power of f
your baby unit.
•
NOTES
5
Positioning - Baby unit
If you do not w ant LCD to dim a utomatically, tur n off the D im Mod e. •
NOTES
>3ft (1m)
>
<3ft (1m)
3ft (1m)
Strangulation
Hazard
Keepthiscordoutofreachofchildren.
Thecordneedstobeatleastthreefeet
awayfromthechildatalltimes.Donot
usewithanextensioncord.Donot
removethistag.
Éloignezcecordondesenfants.Le
cordondoitsetrouveràaumoinstrois
piedsd’unenfantetce,entouttemps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefueradelaalcance
delosniños.Estecabledebeestarpor
lomenostrespiesfueradelaalcance
delniñoentodomomento.Nolouse
conunaextensióninalámbrica.Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
63ē
LCD
Brightness
Dim Mode
Dim Mode
On
10 min inactivity
Press any buttons
Strangulation
Hazard
Keepthiscordoutofreachofchildren.
Thecordneedstobeatleastthreefeet
awayfromthechildatalltimes.Donot
usewithanextensioncord.Donot
removethistag.
Éloignezcecordondesenfants.Le cordondoitsetrouveràaumoinstrois
piedsd’unenfantetce,entouttemps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefueradelaalcance delosniños.Estecabledebeestarpor
lomenostrespiesfueradelaalcance
delniñoentodomomento.Nolouse
conunaextensióninalámbrica.Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
Strangulation
Hazard
Keepthiscordoutof reach of children.
Thecordneedstobeatleast three feet
awayfromthechildat all times.D o not
usewithanextensioncord. Do not
removethistag.
Éloignezcecordondesenfants.Le
cordondoitsetrouveràaumoinstrois
piedsd’unenfantetce,entouttemps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefueradelaalcance
delosniños.Estecabledebeestarpor
lomenostrespiesfueradela alcance
delniñoentodomomento.No lo use
conunaextensióninalámbrica.Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
Strangulation
Hazard
Keepthiscordoutof reach of children.
Thecordneedstobeatleast three feet
awayfromthechildat all times. Do not
usewithanextensioncord. Do not
removethistag.
Éloignezcecordondesenfants.Le
cordondoitsetrouveràaumoinstrois
piedsd’unenfantetce,entouttemps.
N’utilisezpasderallonge.Neretirezpas
cetteétiquette.
Mantengaestecablefueradelaalcance
delosniños.Estecabledebeestarpor
lomenostrespiesfuerade la alcance
delniñoentodomomento.No lo use
conunaextensióninalámbrica.Noquite
estaetiqueta.
Risque
d’étranglement
Riesgode
estrangulación
6U]KXOTMUT
6U]KXOTMUT
Long press
Go to www.vtechcanada.com
for the latest VTech product news.
Quick start guide
(Canada version)

Specifications are subject to change without notice.
© 2017 VTech Technologies Canada Ltd. All rights reserved.
11/17. VM5251_CA_QSG_V1.
Document order number: 96-012028-010-100
Basic operation - Parent unit
Adjust speaker volume
Press or to adjust your parent unit
speaker volume. It determines the volume of sound
transmitted from your baby unit.
Zoom
Press to zoom in or out.
Overview - Parent unit Overview - Baby unit
Turn off the parent unit
Press and hold POWER to power off your parent unit.
Use the menu
Press MENU/SELECT to enter the menu, choose
a menu item, or save a setting. You can use
the parent unit menu for the advanced settings
or operations, such as to play or stop the baby
unit lullaby, or to adjust the baby unit sound
sensitivity.
While in the menu:
Press or to scroll up or down.
Press to select an item.
Press to return to the main menu or idle
screen.
•
•
•
Talk to your baby unit
Press and hold TALK and speak to your parent unit.
Your voice is transmitted to the baby unit.
Turn off the screen
Press and hold LCD ON/OFF to switch off the
screen. You can still hear sound from the baby
unit.
Press any key s on the pare nt unit to t urn on the
screen a gain.
•
LCD is turning off...
TIP
AlertTone
LowBatteryTone
NoLinkAlert
Soundalertin split-view
POWER
TALK
Zoom
Microphone
LED lights
Arrow keys
MENU / SELECT
Volume
VIEW / LCD ON/OFF
Antenna
Stand
Power jack
Speaker
Battery compartment
cover
6U]KXOTMULL
6U]KXOTMULL
ē
63ē
ē
63ē
63ē
Press and hold
63ē
63ē
63ē
Camera
Light sensor
Infrared LEDs
Microphone
ON/OFF
LED light
ON/OFF
switch
Temperature
sensor
Speaker
Wall mount
holes for upright
mounting
Wall mount holes
for lateral mounting
Long press
Long press
Mount the baby unit (optional)
Drill two holes in the wall.
If you drill the holes into a stud, go to
step 3.
-OR-
If you drill the holes into an object other
than a stud, insert the wall anchors into
the holes. Tap gently on the ends with a
hammer until the wall anchors are flush
with the wall.
Use a pencil to mark two holes in parallel.
Make sure they are the same distance
apart as the wall mount holes on the baby
unit.
NOTES
Check for reception strength and camera
angle before drilling the holes.
•
Depending on your preference, choose the upright or lateral orientation to
mount your unit. Align the wall mount holes at the bottom or at the rear side
of the baby unit with the screws on the wall. Slide the baby unit down until it
locks into place.
OR
Insert the screws into the holes and tighten
the screws until only 1/4 inch of the screws
are exposed.
Tilt or rotate to adjust camera angle.
OR
You will need to purchase the
following items separately to mount
your baby unit:
2 screws
2 anchors
