V-tech RM5722 User manual

Pair a new camera unit
Each newly purchased camera unit (RM5722) must be paired to your system (RM5762).
NOTESNOTE
• You can pair a maximum of four camera units to your parent unit. Each new camera unit must be
paired to the parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Press MENU when the parent unit is idle.
2. Press , , or to choose General Settings, then press SELECT.
3. Press or to choose Pair/Unpair CAM, then press SELECT.
4. Press SELECT again to select Pair CAM, and then select an empty camera slot.
5. Follow the instructions shown on screen to add the camera. When the camera is successfully
added to your parent unit, the parent unit displays the camera image.
User’s manual
For product support please call:
1300 369 193
Congratulations
on purchasing your new VTech product. Before using this product, please read Important safety
instructions.
This manual has all the feature operations and troubleshooting necessary to install and operate
your new VTech product. Please review this manual thoroughly to ensure proper installation and
operation of this innovative and feature-rich VTech product.
1Connect and power on the camera unit
What’s in the box
2Before use
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the camera unit are not connected to the switch controlled electric
outlets.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and the camera unit, so do not connect them to any
ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the
outlets.
• Make sure the parent unit, the camera unit and the power adapter cords are out of reach of children.
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs tobe at least three feet
away from the child at all times.Do not
use with an extension cord. Do not
remove this tag.
Éloignezce cordon desenfants.Le
cordondoit se trouver à au moinstrois
piedsd’unenfant etce, entout temps.
N’utilisezpas de rallonge.Ne retirez pas
cetteétiquette.
Mantengaeste cable fuera de la alcance
de los niños.Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
RM5722
Installation Guide
(for use with RM5762
parent unit)
Important safety instructions
When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or
caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will
continue working properly for any given period of time. Further, this is not a medical device and should not be
used as such. This product is intended to assist you in supervising your baby.
4. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement or shower.
5. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the
product. Camera unit power adapter: Output: 5V DC 1500mA.
6. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
7. For pluggable equipment, the socket-outlet (power adapter) shall be installed near the equipment and shall be
easily accessible.
8. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
9. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation.
10. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on
or crimped.
11. This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult your dealer or local power company.
12. Do not overload wall outlets or use an extension cord.
13. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
14. This product should not be placed in any area where proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for ventilation. To protect them from overheating, these
openings must not be blocked by placing the product on a so surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
15. Never push objects of any kind into this product through the slots because they may touch dangerous voltage
points or create a short circuit. Never spill liquid of any kind on the product.
16. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility.
Opening or removing parts of the product other than specified access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.
17. You should test the sound reception every time you turn on the units or move one of the components.
18. Periodically examine all components for damage.
19. Be aware of possible loss of privacy while using public airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
20. Children should be supervised to ensure that they do not play with the product.
21. The small parts of this monitor can be swallowed by babies or small children. Keep these parts out of reach of
children.
22. The product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 0oC and 40oC.
• Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source.
• Warning—Strangulation Hazard—Children have STRANGLED in cords. Keep this cord out of the reach of children
(more than 0.9 metres away). Do not remove this tag.
• Never place the camera unit(s) inside the baby’s crib or playpen. Never cover the camera unit(s) or parent unit
with anything such as a towel or a blanket.
• Other electronic products may cause interference with your camera unit. Try installing your camera unit as far
away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room
monitors, televisions, personal computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the pacemaker.
• Should NOT place wireless devices directly over the pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be used based on scientific evidence available today.
Positioning the HD video monitor
• Keep the camera unit out of the reach of your baby. Never place or mount the camera unit
inside the baby’s crib or playpen.
1. Place the camera unit more than 1 metre away from your baby.
2. Adjust the angle of the camera to aim at your baby. Refer to the online manual of
RM5762 on how to use the Pan/tilt and Zoom functions of the camera.
3. To avoid causing high-pitched screeching noise from your HD video monitor:
• Make sure your camera unit and parent unit are more than 3 metres apart; OR
• Turn down the volume of your parent unit.
> 1m
>3m
<3m
Test the location for the camera unit
Before you install your camera unit, you need to test which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your
parent unit’s Wi-Fi signal strength indicator to assist in checking. Once you have identified the suitable
location, you can install your camera unit. Adjust the distance between your camera unit and the Wi-Fi
router if needed.
• Depending on surroundings and obstructing factors, such as the effect distance and internal walls have on
signal strength, you may experience reduced Wi-Fi signal. To improve the Wi-Fi signal strength, adjust the
distance or direction of your parent unit. Check with your parent unit again.
1. Connect the power adapter to the camera
unit and a power supply.
2. Slide the ON/OFF switch leftward to
power on your camera.

Pair a new camera unit
Each newly purchased camera unit (RM5722) must be paired to your system (RM5762).
NOTESNOTE
• You can pair a maximum of four camera units to your parent unit. Each new camera unit must be
paired to the parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Press MENU when the parent unit is idle.
2. Press , , or to choose General Settings, then press SELECT.
3. Press or to choose Pair/Unpair CAM, then press SELECT.
4. Press SELECT again to select Pair CAM, and then select an empty camera slot.
5. Follow the instructions shown on screen to add the camera. When the camera is successfully
added to your parent unit, the parent unit displays the camera image.
User’s manual
For product support please call:
1300 369 193
Congratulations
on purchasing your new VTech product. Before using this product, please read Important safety
instructions.
This manual has all the feature operations and troubleshooting necessary to install and operate
your new VTech product. Please review this manual thoroughly to ensure proper installation and
operation of this innovative and feature-rich VTech product.
1Connect and power on the camera unit
What’s in the box
2Before use
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the camera unit are not connected to the switch controlled electric
outlets.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and the camera unit, so do not connect them to any
ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the
outlets.
• Make sure the parent unit, the camera unit and the power adapter cords are out of reach of children.
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs tobe at least three feet
away from the child at all times.Do not
use with an extension cord. Do not
remove this tag.
Éloignezce cordon desenfants.Le
cordondoit se trouver à au moinstrois
piedsd’unenfant etce, entout temps.
N’utilisezpas de rallonge. Neretirez pas
cetteétiquette.
Mantengaeste cable fuera de la alcance
de los niños.Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
RM5722
Installation Guide
(for use with RM5762
parent unit)
Important safety instructions
When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or
caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will
continue working properly for any given period of time. Further, this is not a medical device and should not be
used as such. This product is intended to assist you in supervising your baby.
4. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement or shower.
5. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the
product. Camera unit power adapter: Output: 5V DC 1500mA.
6. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
7. For pluggable equipment, the socket-outlet (power adapter) shall be installed near the equipment and shall be
easily accessible.
8. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
9. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation.
10. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on
or crimped.
11. This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult your dealer or local power company.
12. Do not overload wall outlets or use an extension cord.
13. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
14. This product should not be placed in any area where proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for ventilation. To protect them from overheating, these
openings must not be blocked by placing the product on a so surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
15. Never push objects of any kind into this product through the slots because they may touch dangerous voltage
points or create a short circuit. Never spill liquid of any kind on the product.
16. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility.
Opening or removing parts of the product other than specified access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.
17. You should test the sound reception every time you turn on the units or move one of the components.
18. Periodically examine all components for damage.
19. Be aware of possible loss of privacy while using public airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
20. Children should be supervised to ensure that they do not play with the product.
21. The small parts of this monitor can be swallowed by babies or small children. Keep these parts out of reach of
children.
22. The product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 0oC and 40oC.
• Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source.
• Warning—Strangulation Hazard—Children have STRANGLED in cords. Keep this cord out of the reach of children
(more than 0.9 metres away). Do not remove this tag.
• Never place the camera unit(s) inside the baby’s crib or playpen. Never cover the camera unit(s) or parent unit
with anything such as a towel or a blanket.
• Other electronic products may cause interference with your camera unit. Try installing your camera unit as far
away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room
monitors, televisions, personal computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the pacemaker.
• Should NOT place wireless devices directly over the pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be used based on scientific evidence available today.
Positioning the HD video monitor
• Keep the camera unit out of the reach of your baby. Never place or mount the camera unit
inside the baby’s crib or playpen.
1. Place the camera unit more than 1 metre away from your baby.
2. Adjust the angle of the camera to aim at your baby. Refer to the online manual of
RM5762 on how to use the Pan/tilt and Zoom functions of the camera.
3. To avoid causing high-pitched screeching noise from your HD video monitor:
• Make sure your camera unit and parent unit are more than 3 metres apart; OR
• Turn down the volume of your parent unit.
> 1m
>3m
<3m
Test the location for the camera unit
Before you install your camera unit, you need to test which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your
parent unit’s Wi-Fi signal strength indicator to assist in checking. Once you have identified the suitable
location, you can install your camera unit. Adjust the distance between your camera unit and the Wi-Fi
router if needed.
• Depending on surroundings and obstructing factors, such as the effect distance and internal walls have on
signal strength, you may experience reduced Wi-Fi signal. To improve the Wi-Fi signal strength, adjust the
distance or direction of your parent unit. Check with your parent unit again.
1. Connect the power adapter to the camera
unit and a power supply.
2. Slide the ON/OFF switch leftward to
power on your camera.

Pair a new camera unit
Each newly purchased camera unit (RM5722) must be paired to your system (RM5762).
NOTESNOTE
• You can pair a maximum of four camera units to your parent unit. Each new camera unit must be
paired to the parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Press MENU when the parent unit is idle.
2. Press , , or to choose General Settings, then press SELECT.
3. Press or to choose Pair/Unpair CAM, then press SELECT.
4. Press SELECT again to select Pair CAM, and then select an empty camera slot.
5. Follow the instructions shown on screen to add the camera. When the camera is successfully
added to your parent unit, the parent unit displays the camera image.
User’s manual
For product support please call:
1300 369 193
Congratulations
on purchasing your new VTech product. Before using this product, please read Important safety
instructions.
This manual has all the feature operations and troubleshooting necessary to install and operate
your new VTech product. Please review this manual thoroughly to ensure proper installation and
operation of this innovative and feature-rich VTech product.
1Connect and power on the camera unit
What’s in the box
2Before use
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the camera unit are not connected to the switch controlled electric
outlets.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and the camera unit, so do not connect them to any
ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the
outlets.
• Make sure the parent unit, the camera unit and the power adapter cords are out of reach of children.
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs tobe at least three feet
away from the child at all times.Do not
use with an extension cord. Do not
remove this tag.
Éloignezce cordon desenfants.Le
cordondoit se trouver à au moinstrois
piedsd’unenfant etce, entout temps.
N’utilisezpas de rallonge. Ne retirezpas
cetteétiquette.
Mantengaeste cable fuera de la alcance
de los niños.Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
RM5722
Installation Guide
(for use with RM5762
parent unit)
Important safety instructions
When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or
caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will
continue working properly for any given period of time. Further, this is not a medical device and should not be
used as such. This product is intended to assist you in supervising your baby.
4. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement or shower.
5. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the
product. Camera unit power adapter: Output: 5V DC 1500mA.
6. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
7. For pluggable equipment, the socket-outlet (power adapter) shall be installed near the equipment and shall be
easily accessible.
8. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
9. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation.
10. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on
or crimped.
11. This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult your dealer or local power company.
12. Do not overload wall outlets or use an extension cord.
13. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
14. This product should not be placed in any area where proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for ventilation. To protect them from overheating, these
openings must not be blocked by placing the product on a so surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
15. Never push objects of any kind into this product through the slots because they may touch dangerous voltage
points or create a short circuit. Never spill liquid of any kind on the product.
16. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility.
Opening or removing parts of the product other than specified access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.
17. You should test the sound reception every time you turn on the units or move one of the components.
18. Periodically examine all components for damage.
19. Be aware of possible loss of privacy while using public airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
20. Children should be supervised to ensure that they do not play with the product.
21. The small parts of this monitor can be swallowed by babies or small children. Keep these parts out of reach of
children.
22. The product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 0oC and 40oC.
• Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source.
• Warning—Strangulation Hazard—Children have STRANGLED in cords. Keep this cord out of the reach of children
(more than 0.9 metres away). Do not remove this tag.
• Never place the camera unit(s) inside the baby’s crib or playpen. Never cover the camera unit(s) or parent unit
with anything such as a towel or a blanket.
• Other electronic products may cause interference with your camera unit. Try installing your camera unit as far
away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room
monitors, televisions, personal computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the pacemaker.
• Should NOT place wireless devices directly over the pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be used based on scientific evidence available today.
Positioning the HD video monitor
• Keep the camera unit out of the reach of your baby. Never place or mount the camera unit
inside the baby’s crib or playpen.
1. Place the camera unit more than 1 metre away from your baby.
2. Adjust the angle of the camera to aim at your baby. Refer to the online manual of
RM5762 on how to use the Pan/tilt and Zoom functions of the camera.
3. To avoid causing high-pitched screeching noise from your HD video monitor:
• Make sure your camera unit and parent unit are more than 3 metres apart; OR
• Turn down the volume of your parent unit.
> 1m
>3m
<3m
Test the location for the camera unit
Before you install your camera unit, you need to test which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your
parent unit’s Wi-Fi signal strength indicator to assist in checking. Once you have identified the suitable
location, you can install your camera unit. Adjust the distance between your camera unit and the Wi-Fi
router if needed.
• Depending on surroundings and obstructing factors, such as the effect distance and internal walls have on
signal strength, you may experience reduced Wi-Fi signal. To improve the Wi-Fi signal strength, adjust the
distance or direction of your parent unit. Check with your parent unit again.
1. Connect the power adapter to the camera
unit and a power supply.
2. Slide the ON/OFF switch leftward to
power on your camera.

Pair a new camera unit
Each newly purchased camera unit (RM5722) must be paired to your system (RM5762).
NOTESNOTE
• You can pair a maximum of four camera units to your parent unit. Each new camera unit must be
paired to the parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Press MENU when the parent unit is idle.
2. Press , , or to choose General Settings, then press SELECT.
3. Press or to choose Pair/Unpair CAM, then press SELECT.
4. Press SELECT again to select Pair CAM, and then select an empty camera slot.
5. Follow the instructions shown on screen to add the camera. When the camera is successfully
added to your parent unit, the parent unit displays the camera image.
User’s manual
For product support please call:
1300 369 193
Congratulations
on purchasing your new VTech product. Before using this product, please read Important safety
instructions.
This manual has all the feature operations and troubleshooting necessary to install and operate
your new VTech product. Please review this manual thoroughly to ensure proper installation and
operation of this innovative and feature-rich VTech product.
1Connect and power on the camera unit
What’s in the box
2Before use
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the camera unit are not connected to the switch controlled electric
outlets.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and the camera unit, so do not connect them to any
ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the
outlets.
• Make sure the parent unit, the camera unit and the power adapter cords are out of reach of children.
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs tobe at least three feet
away from the child at all times.Do not
use with an extension cord. Do not
remove this tag.
Éloignezce cordon desenfants.Le
cordondoit se trouver à au moinstrois
piedsd’unenfant etce, entout temps.
N’utilisezpas de rallonge.Ne retirez pas
cetteétiquette.
Mantengaeste cable fuera de la alcance
de los niños.Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
RM5722
Installation Guide
(for use with RM5762
parent unit)
Important safety instructions
When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or
caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will
continue working properly for any given period of time. Further, this is not a medical device and should not be
used as such. This product is intended to assist you in supervising your baby.
4. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement or shower.
5. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the
product. Camera unit power adapter: Output: 5V DC 1500mA.
6. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
7. For pluggable equipment, the socket-outlet (power adapter) shall be installed near the equipment and shall be
easily accessible.
8. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
9. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation.
10. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on
or crimped.
11. This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult your dealer or local power company.
12. Do not overload wall outlets or use an extension cord.
13. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
14. This product should not be placed in any area where proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for ventilation. To protect them from overheating, these
openings must not be blocked by placing the product on a so surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
15. Never push objects of any kind into this product through the slots because they may touch dangerous voltage
points or create a short circuit. Never spill liquid of any kind on the product.
16. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility.
Opening or removing parts of the product other than specified access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.
17. You should test the sound reception every time you turn on the units or move one of the components.
18. Periodically examine all components for damage.
19. Be aware of possible loss of privacy while using public airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
20. Children should be supervised to ensure that they do not play with the product.
21. The small parts of this monitor can be swallowed by babies or small children. Keep these parts out of reach of
children.
22. The product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 0oC and 40oC.
• Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source.
• Warning—Strangulation Hazard—Children have STRANGLED in cords. Keep this cord out of the reach of children
(more than 0.9 metres away). Do not remove this tag.
• Never place the camera unit(s) inside the baby’s crib or playpen. Never cover the camera unit(s) or parent unit
with anything such as a towel or a blanket.
• Other electronic products may cause interference with your camera unit. Try installing your camera unit as far
away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room
monitors, televisions, personal computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the pacemaker.
• Should NOT place wireless devices directly over the pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be used based on scientific evidence available today.
Positioning the HD video monitor
• Keep the camera unit out of the reach of your baby. Never place or mount the camera unit
inside the baby’s crib or playpen.
1. Place the camera unit more than 1 metre away from your baby.
2. Adjust the angle of the camera to aim at your baby. Refer to the online manual of
RM5762 on how to use the Pan/tilt and Zoom functions of the camera.
3. To avoid causing high-pitched screeching noise from your HD video monitor:
• Make sure your camera unit and parent unit are more than 3 metres apart; OR
• Turn down the volume of your parent unit.
> 1m
>3m
<3m
Test the location for the camera unit
Before you install your camera unit, you need to test which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your
parent unit’s Wi-Fi signal strength indicator to assist in checking. Once you have identified the suitable
location, you can install your camera unit. Adjust the distance between your camera unit and the Wi-Fi
router if needed.
• Depending on surroundings and obstructing factors, such as the effect distance and internal walls have on
signal strength, you may experience reduced Wi-Fi signal. To improve the Wi-Fi signal strength, adjust the
distance or direction of your parent unit. Check with your parent unit again.
1. Connect the power adapter to the camera
unit and a power supply.
2. Slide the ON/OFF switch leftward to
power on your camera.

Pair a new camera unit
Each newly purchased camera unit (RM5722) must be paired to your system (RM5762).
NOTESNOTE
• You can pair a maximum of four camera units to your parent unit. Each new camera unit must be
paired to the parent unit before use.
• Make sure you power on the parent unit before pairing.
1. Press MENU when the parent unit is idle.
2. Press , , or to choose General Settings, then press SELECT.
3. Press or to choose Pair/Unpair CAM, then press SELECT.
4. Press SELECT again to select Pair CAM, and then select an empty camera slot.
5. Follow the instructions shown on screen to add the camera. When the camera is successfully
added to your parent unit, the parent unit displays the camera image.
User’s manual
For product support please call:
1300 369 193
Congratulations
on purchasing your new VTech product. Before using this product, please read Important safety
instructions.
This manual has all the feature operations and troubleshooting necessary to install and operate
your new VTech product. Please review this manual thoroughly to ensure proper installation and
operation of this innovative and feature-rich VTech product.
1Connect and power on the camera unit
What’s in the box
2Before use
NOTESNOTE
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the camera unit are not connected to the switch controlled electric
outlets.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and the camera unit, so do not connect them to any
ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the
outlets.
• Make sure the parent unit, the camera unit and the power adapter cords are out of reach of children.
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs tobe at least three feet
away from the child at all times.Do not
use with an extension cord. Do not
remove this tag.
Éloignezce cordon desenfants.Le
cordondoit se trouver à au moinstrois
piedsd’unenfant etce, entout temps.
N’utilisezpas de rallonge. Ne retirezpas
cetteétiquette.
Mantengaeste cable fuera de la alcance
de los niños.Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
RM5722
Installation Guide
(for use with RM5762
parent unit)
Important safety instructions
When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. This product is not a substitute for adult supervision of the infant. Supervising the infant is the parent’s or
caregiver’s responsibility. This product could cease operating, and therefore you should not assume it will
continue working properly for any given period of time. Further, this is not a medical device and should not be
used as such. This product is intended to assist you in supervising your baby.
4. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement or shower.
5. Use only the adapters included with this product. Incorrect adapter polarity or voltage can seriously damage the
product. Camera unit power adapter: Output: 5V DC 1500mA.
6. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
7. For pluggable equipment, the socket-outlet (power adapter) shall be installed near the equipment and shall be
easily accessible.
8. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
9. Do not cut off the power adapters to replace them with other plugs, as this causes a hazardous situation.
10. Do not allow anything to rest on the power cords. Do not install this product where the cords may be walked on
or crimped.
11. This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply in your home, consult your dealer or local power company.
12. Do not overload wall outlets or use an extension cord.
13. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
14. This product should not be placed in any area where proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for ventilation. To protect them from overheating, these
openings must not be blocked by placing the product on a so surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
15. Never push objects of any kind into this product through the slots because they may touch dangerous voltage
points or create a short circuit. Never spill liquid of any kind on the product.
16. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility.
Opening or removing parts of the product other than specified access doors may expose you to dangerous
voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.
17. You should test the sound reception every time you turn on the units or move one of the components.
18. Periodically examine all components for damage.
19. Be aware of possible loss of privacy while using public airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
20. Children should be supervised to ensure that they do not play with the product.
21. The small parts of this monitor can be swallowed by babies or small children. Keep these parts out of reach of
children.
22. The product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 0oC and 40oC.
• Do not expose the product to extreme cold, heat or direct sunlight. Do not put the product close to a heating source.
• Warning—Strangulation Hazard—Children have STRANGLED in cords. Keep this cord out of the reach of children
(more than 0.9 metres away). Do not remove this tag.
• Never place the camera unit(s) inside the baby’s crib or playpen. Never cover the camera unit(s) or parent unit
with anything such as a towel or a blanket.
• Other electronic products may cause interference with your camera unit. Try installing your camera unit as far
away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room
monitors, televisions, personal computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the pacemaker.
• Should NOT place wireless devices directly over the pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be used based on scientific evidence available today.
Positioning the HD video monitor
• Keep the camera unit out of the reach of your baby. Never place or mount the camera unit
inside the baby’s crib or playpen.
1. Place the camera unit more than 1 metre away from your baby.
2. Adjust the angle of the camera to aim at your baby. Refer to the online manual of
RM5762 on how to use the Pan/tilt and Zoom functions of the camera.
3. To avoid causing high-pitched screeching noise from your HD video monitor:
• Make sure your camera unit and parent unit are more than 3 metres apart; OR
• Turn down the volume of your parent unit.
> 1m
>3m
<3m
Test the location for the camera unit
Before you install your camera unit, you need to test which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you have powered on your parent unit, you can use your
parent unit’s Wi-Fi signal strength indicator to assist in checking. Once you have identified the suitable
location, you can install your camera unit. Adjust the distance between your camera unit and the Wi-Fi
router if needed.
• Depending on surroundings and obstructing factors, such as the effect distance and internal walls have on
signal strength, you may experience reduced Wi-Fi signal. To improve the Wi-Fi signal strength, adjust the
distance or direction of your parent unit. Check with your parent unit again.
1. Connect the power adapter to the camera
unit and a power supply.
2. Slide the ON/OFF switch leftward to
power on your camera.

When you are not going to use the baby monitor for some time, remove the rechargeable battery from the
parent unit. Store the parent unit, the camera unit and the adapters in a cool and dry place.
Storage
Technical specifications
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and batteries, or on their
respective packaging, indicates they must not be disposed of in domestic waste as
they contain substances that can be damaging to the environment and human health.
The chemical symbols Hg, Cd or Pb, where marked, indicate that the battery contains
more than the specified value of mercury (Hg), cadmium (Cd) or lead (Pn) set out in
Battery Directive (2006/66/EC).
The solid bar indicates that the product was placed on the market after 13th August,
2005.
Help protect the environment by disposing of your product or batteries responsibly.
IMPORTANT
Please retain this booklet with your sales receipt as proof of the date of purchase.
Customer Service
If you require assistance in operating this product, please call the TecHelp Information Line on
1300 369 193 or contact VTech by e-mail at: [e-mail].
Voluntary Product Enquiry
In addition to your Statutory Rights and subject to the conditions below, VTech warrants that this product will be
free from any defect in materials or workmanship under conditions of normal use for a period of 24 months from
date of purchase.
VTech does not warrant that the product will be free from defects if defects are caused by an accident,
misuse, abuse, improper installation or operation, vermin infestations, lack of reasonable care, unauthorised
modification, loss of parts, tampering or attempted repair by a person not authorised by VTech; or where the
product has been damaged by lightning or a mains power surge.To make a claim under this Voluntary Product
Warranty you must call the TecHelp Information Line on 1300 369 193 or contact VTech by e-mail at: tcpsupport_
[e-mail] where a Customer Service Representative will inform you of the product return process. You will
need to ensure that:
• You provide proof of purchase;
• Your product is suitably packaged (original packaging is not required); and
• You have included all components from the original purchase.
For your records
Date of purchase:
Place of purchase:
Serial number:
Customer service and product warranty
To keep this product working well and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors
or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the parent unit and the camera unit in water and do not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the camera unit and parent unit are dry before you connect them to the mains again.
General product care
Specifications are subject to change without notice.
© 2019 VTech Telecommunications Ltd.
All rights reserved. 09/19. RM5722_AU_CIB_V3
Mount the camera unit (optional)
Frequency Camera unit: 2412 - 2462 MHz
Channels 11
Nominal effective range Actual operating range may vary according to environmental conditions
at the time of use.
Power requirement Camera unit power adapter:
Output: 5V DC 1500mA
1. Place the wall mount bracket on a wall and then use
a pencil to mark the top and the bottom holes as
shown. Remove the wall mount bracket and drill
two holes in the wall
(7/32 inch drill bit).
NONO
Notes
• Check for reception strength and camera angle before drilling the holes.
• The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your camera units.
2. If you drill the holes into a stud, go to step 3.
• If you drill the holes into an object other than a stud, insert the wall
anchors into the holes. Tap gently on the ends with a hammer until the
wall anchors are flush with the wall.
3. Align the wall mount bracket and screws with the
holes in the wall as shown. Tighten the screw in the
middle hole first, so that the wall mount bracket
position is fixed. You can tighten the other screw in
the top hole.
3. Insert the screws into the holes and tighten the screws until only 1/4 inch
of the screws are exposed.
4. Place the camera unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the camera
unit. Align the holes on the wall mount
bracket with the screws on the wall, and slide
the wall mount bracket down until it locks into
place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the joint and
secure the angle.
OR
4. Place the camera unit on the wall mount bracket.
Tighten the screw into the threaded socket at the
bottom to secure the camera unit.
For Voluntary Product Warranty purposes, proof of purchase is required so please keep your receipt.
The benefits conferred by this Voluntary Product Warranty are in addition to other rights and remedies
that are available to you under law, which cannot be excluded. The processes for this Voluntary Product
Warranty in no way limit your rights which arise as a result of your Statutory Rights.
This Voluntary Product Warranty is given by:
VTech Telecommunications (Australia) Pty Ltd ABN 70 136 672 627
Address: 24 Gilby Road, Mount Waverley 3149
IMPORTANT NOTE: THIS IS NOT A PRODUCT RETURN OR SERVICE ADDRESS – PLEASE CONTACT
TECHELP BY PHONE OR EMAIL FOR PRODUCT AND WARRANTY SUPPORT. NO LIABILITY WILL BE
ACCEPTED BY VTECH FOR PRODUCTS RETURNED TO THIS ADDRESS UNDER THIS VOLUNTARY
PRODUCT WARRANTY.
Phone number: 1300 369 193
Email address: [e-mail]
Statutory Rights
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
Camera unit overview
1
11
10
2
3
7
8
9
4
5
6
12
1Microphone
2Camera lens
3Light sensor
4LED indicators
• Flash yellow and blue alternately
when the camera unit is in pairing
mode.
• Yellow is steady on when the camera
unit is connecting to the Internet.
• Yellow and blue are steady on when
the camera unit is idle.
• Flash yellow and blue slowly during
video streaming.
• Flash yellow and blue quickly and
alternately when the camera unit is
updating its firmware.
5Infrared LEDs
Allow you to see clearly in a dark
surrounding.
6ON/OFF switch
7Antenna
Connect to router with Wi-Fi.
8Speaker
Caution
• For hearing protection, do not
stand close to the HD camera
when the camera’s alarm goes off.
The loud alarm may damage your
hearing.
9Temperature sensor
10 Power jack
11 Threaded socket
12 Pair/reset button
• Press and hold for three seconds to
enter pairing mode.

When you are not going to use the baby monitor for some time, remove the rechargeable battery from the
parent unit. Store the parent unit, the camera unit and the adapters in a cool and dry place.
Storage
Technical specifications
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and batteries, or on their
respective packaging, indicates they must not be disposed of in domestic waste as
they contain substances that can be damaging to the environment and human health.
The chemical symbols Hg, Cd or Pb, where marked, indicate that the battery contains
more than the specified value of mercury (Hg), cadmium (Cd) or lead (Pn) set out in
Battery Directive (2006/66/EC).
The solid bar indicates that the product was placed on the market after 13th August,
2005.
Help protect the environment by disposing of your product or batteries responsibly.
IMPORTANT
Please retain this booklet with your sales receipt as proof of the date of purchase.
Customer Service
If you require assistance in operating this product, please call the TecHelp Information Line on
1300 369 193 or contact VTech by e-mail at: [e-mail].
Voluntary Product Enquiry
In addition to your Statutory Rights and subject to the conditions below, VTech warrants that this product will be
free from any defect in materials or workmanship under conditions of normal use for a period of 24 months from
date of purchase.
VTech does not warrant that the product will be free from defects if defects are caused by an accident,
misuse, abuse, improper installation or operation, vermin infestations, lack of reasonable care, unauthorised
modification, loss of parts, tampering or attempted repair by a person not authorised by VTech; or where the
product has been damaged by lightning or a mains power surge.To make a claim under this Voluntary Product
Warranty you must call the TecHelp Information Line on 1300 369 193 or contact VTech by e-mail at: tcpsupport_
[e-mail] where a Customer Service Representative will inform you of the product return process. You will
need to ensure that:
• You provide proof of purchase;
• Your product is suitably packaged (original packaging is not required); and
• You have included all components from the original purchase.
For your records
Date of purchase:
Place of purchase:
Serial number:
Customer service and product warranty
To keep this product working well and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors
or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the parent unit and the camera unit in water and do not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the camera unit and parent unit are dry before you connect them to the mains again.
General product care
Specifications are subject to change without notice.
© 2019 VTech Telecommunications Ltd.
All rights reserved. 09/19. RM5722_AU_CIB_V3
Mount the camera unit (optional)
Frequency Camera unit: 2412 - 2462 MHz
Channels 11
Nominal effective range Actual operating range may vary according to environmental conditions
at the time of use.
Power requirement Camera unit power adapter:
Output: 5V DC 1500mA
1. Place the wall mount bracket on a wall and then use
a pencil to mark the top and the bottom holes as
shown. Remove the wall mount bracket and drill
two holes in the wall
(7/32 inch drill bit).
NONO
Notes
• Check for reception strength and camera angle before drilling the holes.
• The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your camera units.
2. If you drill the holes into a stud, go to step 3.
• If you drill the holes into an object other than a stud, insert the wall
anchors into the holes. Tap gently on the ends with a hammer until the
wall anchors are flush with the wall.
3. Align the wall mount bracket and screws with the
holes in the wall as shown. Tighten the screw in the
middle hole first, so that the wall mount bracket
position is fixed. You can tighten the other screw in
the top hole.
3. Insert the screws into the holes and tighten the screws until only 1/4 inch
of the screws are exposed.
4. Place the camera unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the camera
unit. Align the holes on the wall mount
bracket with the screws on the wall, and slide
the wall mount bracket down until it locks into
place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the joint and
secure the angle.
OR
4. Place the camera unit on the wall mount bracket.
Tighten the screw into the threaded socket at the
bottom to secure the camera unit.
For Voluntary Product Warranty purposes, proof of purchase is required so please keep your receipt.
The benefits conferred by this Voluntary Product Warranty are in addition to other rights and remedies
that are available to you under law, which cannot be excluded. The processes for this Voluntary Product
Warranty in no way limit your rights which arise as a result of your Statutory Rights.
This Voluntary Product Warranty is given by:
VTech Telecommunications (Australia) Pty Ltd ABN 70 136 672 627
Address: 24 Gilby Road, Mount Waverley 3149
IMPORTANT NOTE: THIS IS NOT A PRODUCT RETURN OR SERVICE ADDRESS – PLEASE CONTACT
TECHELP BY PHONE OR EMAIL FOR PRODUCT AND WARRANTY SUPPORT. NO LIABILITY WILL BE
ACCEPTED BY VTECH FOR PRODUCTS RETURNED TO THIS ADDRESS UNDER THIS VOLUNTARY
PRODUCT WARRANTY.
Phone number: 1300 369 193
Email address: [e-mail]
Statutory Rights
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
Camera unit overview
1
11
10
2
3
7
8
9
4
5
6
12
1Microphone
2Camera lens
3Light sensor
4LED indicators
• Flash yellow and blue alternately
when the camera unit is in pairing
mode.
• Yellow is steady on when the camera
unit is connecting to the Internet.
• Yellow and blue are steady on when
the camera unit is idle.
• Flash yellow and blue slowly during
video streaming.
• Flash yellow and blue quickly and
alternately when the camera unit is
updating its firmware.
5Infrared LEDs
Allow you to see clearly in a dark
surrounding.
6ON/OFF switch
7Antenna
Connect to router with Wi-Fi.
8Speaker
Caution
• For hearing protection, do not
stand close to the HD camera
when the camera’s alarm goes off.
The loud alarm may damage your
hearing.
9Temperature sensor
10 Power jack
11 Threaded socket
12 Pair/reset button
• Press and hold for three seconds to
enter pairing mode.

When you are not going to use the baby monitor for some time, remove the rechargeable battery from the
parent unit. Store the parent unit, the camera unit and the adapters in a cool and dry place.
Storage
Technical specifications
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and batteries, or on their
respective packaging, indicates they must not be disposed of in domestic waste as
they contain substances that can be damaging to the environment and human health.
The chemical symbols Hg, Cd or Pb, where marked, indicate that the battery contains
more than the specified value of mercury (Hg), cadmium (Cd) or lead (Pn) set out in
Battery Directive (2006/66/EC).
The solid bar indicates that the product was placed on the market after 13th August,
2005.
Help protect the environment by disposing of your product or batteries responsibly.
IMPORTANT
Please retain this booklet with your sales receipt as proof of the date of purchase.
Customer Service
If you require assistance in operating this product, please call the TecHelp Information Line on
1300 369 193 or contact VTech by e-mail at: [e-mail].
Voluntary Product Enquiry
In addition to your Statutory Rights and subject to the conditions below, VTech warrants that this product will be
free from any defect in materials or workmanship under conditions of normal use for a period of 24 months from
date of purchase.
VTech does not warrant that the product will be free from defects if defects are caused by an accident,
misuse, abuse, improper installation or operation, vermin infestations, lack of reasonable care, unauthorised
modification, loss of parts, tampering or attempted repair by a person not authorised by VTech; or where the
product has been damaged by lightning or a mains power surge.To make a claim under this Voluntary Product
Warranty you must call the TecHelp Information Line on 1300 369 193 or contact VTech by e-mail at: tcpsupport_
[e-mail] where a Customer Service Representative will inform you of the product return process. You will
need to ensure that:
• You provide proof of purchase;
• Your product is suitably packaged (original packaging is not required); and
• You have included all components from the original purchase.
For your records
Date of purchase:
Place of purchase:
Serial number:
Customer service and product warranty
To keep this product working well and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors
or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the parent unit and the camera unit in water and do not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the camera unit and parent unit are dry before you connect them to the mains again.
General product care
Specifications are subject to change without notice.
© 2019 VTech Telecommunications Ltd.
All rights reserved. 09/19. RM5722_AU_CIB_V3
Mount the camera unit (optional)
Frequency Camera unit: 2412 - 2462 MHz
Channels 11
Nominal effective range Actual operating range may vary according to environmental conditions
at the time of use.
Power requirement Camera unit power adapter:
Output: 5V DC 1500mA
1. Place the wall mount bracket on a wall and then use
a pencil to mark the top and the bottom holes as
shown. Remove the wall mount bracket and drill
two holes in the wall
(7/32 inch drill bit).
NONO
Notes
• Check for reception strength and camera angle before drilling the holes.
• The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your camera units.
2. If you drill the holes into a stud, go to step 3.
• If you drill the holes into an object other than a stud, insert the wall
anchors into the holes. Tap gently on the ends with a hammer until the
wall anchors are flush with the wall.
3. Align the wall mount bracket and screws with the
holes in the wall as shown. Tighten the screw in the
middle hole first, so that the wall mount bracket
position is fixed. You can tighten the other screw in
the top hole.
3. Insert the screws into the holes and tighten the screws until only 1/4 inch
of the screws are exposed.
4. Place the camera unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the camera
unit. Align the holes on the wall mount
bracket with the screws on the wall, and slide
the wall mount bracket down until it locks into
place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the joint and
secure the angle.
OR
4. Place the camera unit on the wall mount bracket.
Tighten the screw into the threaded socket at the
bottom to secure the camera unit.
For Voluntary Product Warranty purposes, proof of purchase is required so please keep your receipt.
The benefits conferred by this Voluntary Product Warranty are in addition to other rights and remedies
that are available to you under law, which cannot be excluded. The processes for this Voluntary Product
Warranty in no way limit your rights which arise as a result of your Statutory Rights.
This Voluntary Product Warranty is given by:
VTech Telecommunications (Australia) Pty Ltd ABN 70 136 672 627
Address: 24 Gilby Road, Mount Waverley 3149
IMPORTANT NOTE: THIS IS NOT A PRODUCT RETURN OR SERVICE ADDRESS – PLEASE CONTACT
TECHELP BY PHONE OR EMAIL FOR PRODUCT AND WARRANTY SUPPORT. NO LIABILITY WILL BE
ACCEPTED BY VTECH FOR PRODUCTS RETURNED TO THIS ADDRESS UNDER THIS VOLUNTARY
PRODUCT WARRANTY.
Phone number: 1300 369 193
Email address: [e-mail]
Statutory Rights
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
Camera unit overview
1
11
10
2
3
7
8
9
4
5
6
12
1Microphone
2Camera lens
3Light sensor
4LED indicators
• Flash yellow and blue alternately
when the camera unit is in pairing
mode.
• Yellow is steady on when the camera
unit is connecting to the Internet.
• Yellow and blue are steady on when
the camera unit is idle.
• Flash yellow and blue slowly during
video streaming.
• Flash yellow and blue quickly and
alternately when the camera unit is
updating its firmware.
5Infrared LEDs
Allow you to see clearly in a dark
surrounding.
6ON/OFF switch
7Antenna
Connect to router with Wi-Fi.
8Speaker
Caution
• For hearing protection, do not
stand close to the HD camera
when the camera’s alarm goes off.
The loud alarm may damage your
hearing.
9Temperature sensor
10 Power jack
11 Threaded socket
12 Pair/reset button
• Press and hold for three seconds to
enter pairing mode.

When you are not going to use the baby monitor for some time, remove the rechargeable battery from the
parent unit. Store the parent unit, the camera unit and the adapters in a cool and dry place.
Storage
Technical specifications
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and batteries, or on their
respective packaging, indicates they must not be disposed of in domestic waste as
they contain substances that can be damaging to the environment and human health.
The chemical symbols Hg, Cd or Pb, where marked, indicate that the battery contains
more than the specified value of mercury (Hg), cadmium (Cd) or lead (Pn) set out in
Battery Directive (2006/66/EC).
The solid bar indicates that the product was placed on the market after 13th August,
2005.
Help protect the environment by disposing of your product or batteries responsibly.
IMPORTANT
Please retain this booklet with your sales receipt as proof of the date of purchase.
Customer Service
If you require assistance in operating this product, please call the TecHelp Information Line on
1300 369 193 or contact VTech by e-mail at: [e-mail].
Voluntary Product Enquiry
In addition to your Statutory Rights and subject to the conditions below, VTech warrants that this product will be
free from any defect in materials or workmanship under conditions of normal use for a period of 24 months from
date of purchase.
VTech does not warrant that the product will be free from defects if defects are caused by an accident,
misuse, abuse, improper installation or operation, vermin infestations, lack of reasonable care, unauthorised
modification, loss of parts, tampering or attempted repair by a person not authorised by VTech; or where the
product has been damaged by lightning or a mains power surge.To make a claim under this Voluntary Product
Warranty you must call the TecHelp Information Line on 1300 369 193 or contact VTech by e-mail at: tcpsupport_
[e-mail] where a Customer Service Representative will inform you of the product return process. You will
need to ensure that:
• You provide proof of purchase;
• Your product is suitably packaged (original packaging is not required); and
• You have included all components from the original purchase.
For your records
Date of purchase:
Place of purchase:
Serial number:
Customer service and product warranty
To keep this product working well and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors
or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the parent unit and the camera unit in water and do not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the camera unit and parent unit are dry before you connect them to the mains again.
General product care
Specifications are subject to change without notice.
© 2019 VTech Telecommunications Ltd.
All rights reserved. 09/19. RM5722_AU_CIB_V3
Mount the camera unit (optional)
Frequency Camera unit: 2412 - 2462 MHz
Channels 11
Nominal effective range Actual operating range may vary according to environmental conditions
at the time of use.
Power requirement Camera unit power adapter:
Output: 5V DC 1500mA
1. Place the wall mount bracket on a wall and then use
a pencil to mark the top and the bottom holes as
shown. Remove the wall mount bracket and drill
two holes in the wall
(7/32 inch drill bit).
NONO
Notes
• Check for reception strength and camera angle before drilling the holes.
• The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your camera units.
2. If you drill the holes into a stud, go to step 3.
• If you drill the holes into an object other than a stud, insert the wall
anchors into the holes. Tap gently on the ends with a hammer until the
wall anchors are flush with the wall.
3. Align the wall mount bracket and screws with the
holes in the wall as shown. Tighten the screw in the
middle hole first, so that the wall mount bracket
position is fixed. You can tighten the other screw in
the top hole.
3. Insert the screws into the holes and tighten the screws until only 1/4 inch
of the screws are exposed.
4. Place the camera unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the camera
unit. Align the holes on the wall mount
bracket with the screws on the wall, and slide
the wall mount bracket down until it locks into
place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the joint and
secure the angle.
OR
4. Place the camera unit on the wall mount bracket.
Tighten the screw into the threaded socket at the
bottom to secure the camera unit.
For Voluntary Product Warranty purposes, proof of purchase is required so please keep your receipt.
The benefits conferred by this Voluntary Product Warranty are in addition to other rights and remedies
that are available to you under law, which cannot be excluded. The processes for this Voluntary Product
Warranty in no way limit your rights which arise as a result of your Statutory Rights.
This Voluntary Product Warranty is given by:
VTech Telecommunications (Australia) Pty Ltd ABN 70 136 672 627
Address: 24 Gilby Road, Mount Waverley 3149
IMPORTANT NOTE: THIS IS NOT A PRODUCT RETURN OR SERVICE ADDRESS – PLEASE CONTACT
TECHELP BY PHONE OR EMAIL FOR PRODUCT AND WARRANTY SUPPORT. NO LIABILITY WILL BE
ACCEPTED BY VTECH FOR PRODUCTS RETURNED TO THIS ADDRESS UNDER THIS VOLUNTARY
PRODUCT WARRANTY.
Phone number: 1300 369 193
Email address: [e-mail]
Statutory Rights
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
Camera unit overview
1
11
10
2
3
7
8
9
4
5
6
12
1Microphone
2Camera lens
3Light sensor
4LED indicators
• Flash yellow and blue alternately
when the camera unit is in pairing
mode.
• Yellow is steady on when the camera
unit is connecting to the Internet.
• Yellow and blue are steady on when
the camera unit is idle.
• Flash yellow and blue slowly during
video streaming.
• Flash yellow and blue quickly and
alternately when the camera unit is
updating its firmware.
5Infrared LEDs
Allow you to see clearly in a dark
surrounding.
6ON/OFF switch
7Antenna
Connect to router with Wi-Fi.
8Speaker
Caution
• For hearing protection, do not
stand close to the HD camera
when the camera’s alarm goes off.
The loud alarm may damage your
hearing.
9Temperature sensor
10 Power jack
11 Threaded socket
12 Pair/reset button
• Press and hold for three seconds to
enter pairing mode.
