ENGLISH
- 7 -
IMPORTANT INFORMATION
For any installation problem please contact our Customer
Serviceat the number +39-0172.812411 operating Monday to
Fridayfrom 8:30 to 12:30 and from 14:00 to 18:00
V2 reserves the right to make modifications to the product
without any prior warning; furthermore, the company
declines all responsibility for damages to people or property
resulting from improper use or incorrect installation.
mRead the following instruction manual thoroughly prior to
proceeding with installation and programming of the system.
• This instruction manual is intended solely for use by technical
staff, qualified in the field of installation of automation devices.
• None of the information contained in the manual is of interest
or use to end users.
• All maintenance or programming operations should be
conducted exclusively by qualified staff.
The installation, testing and commissioning of door and
gate automation devices should be performed by qualified
and skilled personnel, who must assume responsibility
for setting up the tests envisaged depending on the risks
present; and verify compliance in accordance with legal and
regulatory requirements.
• V2 accepts no responsibility for injuries and damage resulting
from improper use of the product; other than that described in
this manual.
• Packing materials must be disposed of in full compliance with
local regulations.
• Ensure that the back-up battery cannot become immersed in
water or other liquids. Should any liquids penetrate inside the
device, disconnect it immediately from the automation device
and contact the V2 assistance service; use of the device under
such conditions may be hazardous.
• Do not store the back-up battery close to strong sources of
heat or expose it to naked flames; such actions can damage it
and be the cause of malfunctions, fire or other hazards.
• In order to avoid the risk of leakage of hazardous substances
from the back-up battery in the case where the device is not
used for long periods of time, it is preferable to disconnect it
from the automated device and store it in a dry place.
EU DECLARATION OF CONFORMITY
V2 S.p.A. hereby declares that the product ECO-LOGIC complies
with the essential requirements established in the following
directives:
- 2014/30/UE (EMC directive)
- ROHS2 2011/65/CE
Racconigi, 01/06/2016
V2 S.p.A. legal representative
Antonio Livio Costamagna
DISPOSAL
As for the installation operations, even at the end of this product’s
life span, the dismantling operations must be carried out by
qualified experts.
This product is made up of various types of materials: some can
be recycled while others need to be disposed of.
Find out about the recycling or disposal systems envisaged by your
local regulations for this product category.
Important! – Parts of the product could contain pollutants or
hazardous substances which, if released into the environment,
could cause harmful effects to the environment itself as well as to
human health.
As indicated by the symbol opposite, throwing away this product
as domestic waste is strictly forbidden. So dispose of it as
differentiated waste, in accordance with your local regulations,
or return the product to the retailer when you purchase a new
equivalent product.
Important! – the local applicable regulations may envisage heavy
sanctions in the event of illegal disposal of this product.

ENGLISH
- 8 -
PRELIMINARY CHECKS
AND LIMITS OF USE
Perform the checks described in this chapter to ensure that the
product is suited to the characteristics of the automation device to
be supplied.
Nearby the automation device to be supplied, identify the most
suitable point for installing the solar panel and the most suitable
point for installing the accumulator unit, taking the following
points into consideration.
Solar panel
• The maximum length of the solar panel cable should not
exceed 10 m.
Use a 2x1 mm2cable (maximum outer diameter 6.5 mm)
• The surface selected for fixing both devices should be of solid
material and should guarantee stable fixing
• The location selected for installation of the panel should
guarantee 100% direct sunlight throughout the year
• The location selected for installation of the panel should
be away from plants, walls or anything else that might cast
shadows, even partial, over the sensitive surface.
Partial shadows significantly reduce the energy capacity of the
panel.
Accumulator
• The maximum length of the cable carrying power to the
control unit should not exceed 3 m.
Use a 2x1,5 mm2cable (maximum outer diameter 10 mm)
• The device should be installed in a location protected from
direct sunlight and possibly also at low temperature.
Such extreme conditions compromise battery yield and
lifespan.
• Never allow the battery to discharge to the point where the
red LED remains on, since this risks irreparable damage to the
battery.
TECHNICAL INFORMATION
Accumulator unit
Voltage output toward the
control unit
24-28Vdc*
Maximum current 16A
Battery capacity 18Ah
Protection level IP44
Operating temperature 0 ÷ +40°C charging
-20 ÷ +50°C in use
Mains recharge time ~ 15 h
Dimensions 267x188,2x198 mm
Weight 12 Kg
* NOTE: when no load is connected or drains are very low,
the accumulator output voltage can reach the value of the
voltage generated by the solar panel.
Solar panel
Maximum voltage without
load
42Vdc
Voltage at maximum power
point
33,6Vdc
Peak nominal power 20W
Operating temperature -20 ÷ +80°C
Dimensions 308x28x604 mm
Weight 2,2 Kg
Mains power supply
Power supply 230Vac - 50Hz
Max. nominal power 36W
Operating temperature 0 ÷ +30°C
Dimensions 99x78x153 mm
Weight 1,7 Kg

ENGLISH
- 9 -
DESCRIPTION AND INTENDED USE
ECO-LOGIC can only be installed on gate automation systems
with V2 control units.
mATTENTION: the control unit supplied by the
ECO-LOGIC must have the mode of operation ENERGY
SAVING active.
To ensure proper operation of the system, all the added
accessories must be connected to the accessory output of
the control unit and, during the stand-by, they will not be
supplied.
The system consists of an accumulator unit, a solar panel and en
external power supply.
The automation device is powered by the accumulator unit, which
is recharged during daylight hours.
The external power supply (accessory - code 172802) may be used
for recharging the batteries in the case of prolonged periods of
lack of sunlight.
NOTE: If the panel fails to provide sufficient charge to the
accumulator group, it is possible to install a second panel in
parallel to the first one.
• CAUTION: Before you connect the two panels, disconnect the
grey connector from the accumulator
• Exclusively use the panel with code 172801 provided by V2
• To connect the two panels in parallel, use a 2x1mm2cable
• If the cable between the accumulator and the first panel is
longer than 3m, use a 2x1, 5mm2cable.
ATTENTION: the connections must be insulated inside a
waterproof container

ENGLISH
- 10 -
INSTALLATION
CAUTION: do not connect the grey terminal until
installation of the panel is complete.
1. Fix the bracket to the wall using appropriate rawplugs
2. Position the accumulator unit on the bracket and tighten the
V-screws on the base
3. Fix the solar panel using the adjustable brackets
4. Position the panel (see the section on POSITIONING THE PANEL)
5. Connect the panel to the grey connector fixed to the
accumulator unit:
• Loosen screw Aand extract the connector
• Remove gasket Band open the connector, by using a
screwdriver as a lever in slot C.
• Connect the +terminal of the panel to the terminal 2of the
accumulator connector
• Connect the -terminal of the panel to the terminal 1of the
accumulator connector
• Replace gasket B, insert the connector and tighten screw A
PLEASE NOTE: Do not remove the pre-wired jumper inside
the connector
6. Connect the control unit power supply to the black connector:
positive to terminal 3 and negative to the earth terminal
7. Insert the black connector first followed by the grey connector.
Check that all LEDs come on a for a few seconds and then the
green LED continues to flash; if the panel is lit by sunlight then
the yellow LED should also flash.

+ -
12
3
  
12
3
Accumulator unit
Solar panel

ENGLISH
- 11 -
90° 90° 90°
L
POSITIONING THE PANEL
Position the panel facing south, with inclination L with respect
to the horizontal axis equal to the latitude of the installation
location.
PLEASE NOTE: If the installation is in the southern
hemisphere, the panel should be facing north.
Considering it is preferable to obtain maximum yield during the
winter (when there are less hours of sunlight), we recommend
the inclination Lbe increased by several degrees, for better panel
illumination when the sun is lower.

ENGLISH
- 12 -
NOTIFICATIONS
The battery charge status is displayed by means of LEDs located
on the front of the box.
Checking must be performed with the gate resting.
The yellow LED flashes to indicate the batteries are charging; if
the LED is fixed, it means the charge current is very low, or there is
very little sun or the batteries are already fully charged.
The green LED flashes to indicate the batteries are charged.
The rate of flashing increases as the charge level decreases.
The red LED flashes when the batteries have lost their charge.
The red LED remains on if the charge level is dangerously low.
mPLEASE NOTE: Never allow the battery to discharge
to the point where the red LED remains on, since this risks
irreparable damage to the battery.
RECHARGING THE BATTERIES FROM
THE MAINS SUPPLY
In the case of prolonged absence of charging from the sun,
the batteries may be recharged using the mains power
supply (accessory code 172802). This operation may also be
recommended prior to installation in order to be certain of
maximum battery life.
Disconnect both connectors and optionally remove the fixing bolt
and remove the module from the bracket.
Move the accumulator unit close to a power socket in a protected
environment.
mPLEASE NOTE: The mains charger is not built to
operate outdoors.
Connect the power supply to the grey connector; insert the plug
into a power socket: the yellow LED starts to flash.
When the LED remains on, charging is complete and the unit may
be disconnected.
mPLEASE NOTE: both before and after charging,
when the accumulator unit is inactive, do not connect
anything to the grey terminal; this way, the batteries
remain disconnected and there is no unnecessary power
consumption.
REPLACING THE BATTERIES
mPLEASE NOTE: the batteries should only be replaced by
qualified technical staff
Replacement of the accumulators becomes necessary when
battery life is significantly reduced due to ageing.
In any case, it is recommended they should be replaced after five
years of use.
mPLEASE NOTE: always replace both batteries with new
batteries of the same model (12 V – 18 Ah). NEVER mix new and
old batteries at the same time.
mPLEASE NOTE: accumulators contain lead and other
pollutants; certain electronic components may contain pollutants:
do not dispose of them with normal waste, but use the methods
prescribed in local regulations.
To replace the batteries, proceed as follows:
1. Disconnect both connectors
2. Open the casing by unscrewing the 4 screws under the handles
3. Disconnect the batteries by unscrewing the screws on the
terminals
4. Remove the old batteries and insert new ones in the same
positions
5. Reconnect the cables, ensuring the polarities are correct, and
tighten the screws properly
6. Close the casing and reconnect the grey and black connectors

V2 S.p.A.
Corso Principi di Piemonte 65/67
12035 RACCONIGI CN (ITALY)
Tel. [phone] - Fax [phone]
[email protected]
www.v2home.com
