Vacon NXI User manual

vacon nxi
inverters
fi9-fi14
user manual
®

AT LEAST THE 10 FOLLOWING STEPS OF THE START-UP QUICK GUIDE MUST BE PERFORMED
DURING THE INSTALLATION AND COMMISSIONING.
IF ANY PROBLEMS OCCUR, PLEASE CONTACT YOUR LOCAL DISTRIBUTOR.
Start-up Quick Guide
1. Check that the delivery corresponds to your order, see Chapter 3.
2. Before taking any commissioning actions, read carefully the safety instructions
in Chapter 1.
3. Before the mechanical installation, check the minimum clearances around the
unit and check the ambient conditions in Chapter 5.
4. Check the size of the motor cable, DC supply cable, and mains fuses, and check
the cable connections. Read Chapters 6.1.1.1 – 6.1.1.6.
5. Follow the installation instructions, see Chapter 6.1.1.8.
6. The sizes and earthing of control connections are explained in Chapter 6.2.1.
7. If the Start-Up wizard is active, select the language you want the keypad and the
application to use and confirm by pressing the enter button. If the Start-Up
wizard is not active, follow the instructions in 7a and 7b below.
8. 7a. Select the language of the keypad from Menu M6, page 6.1. Instructions on
using the keypad are given in Chapter 7.
9. 7b. Select the application you want to use from Menu M6, page 6.2. Instructions
on using the keypad are given in Chapter 7.
10. All parameters have factory default values. To ensure proper operation, check
the rating plate data for the values below and the corresponding parameters of
parameter group G2.1.
•nominal voltage of the motor
•nominal frequency of the motor
•nominal speed of the motor
•nominal current of the motor
•motor cosϕ
All parameters are explained in the All in One Application Manual.
11. Follow the commissioning instructions, see Chapter 8.
12. The Vacon NX Inverter is now ready for use.
Vacon Plc is not responsible for the use of the inverters against the
instructions.

CONTENTS
VACON NXI USER’S MANUAL
INDEX
1SAFETY
2EU DIRECTIVE
3RECEIPT OF DELIVERY
4TECHNICAL DATA
5INSTALLATION
6CABLING AND CONNECTIONS
7CONTROL KEYPAD
8COMMISSIONING
9FAULT TRACING

4 • vacon SAFETY
Puhelin: 0201-2121 • Fax: [phone]
1
ABOUT THE VACON NXI USER'S MANUAL
AND THE ”All in One” APPLICATION MANUAL
Congratulations for choosing Vacon NX Inverters!
The User's Manual will provide you with the necessary information about the installation,
commissioning and operation of Vacon NX Inverters. We recommend that you carefully study these
instructions before powering up the inverter for the first time.
In the All in One Application Manual you will find information about the different applications
included in the All in One Application Package. Should these applications not meet the requirements
of your process, please contact the manufacturer for information on special applications.
This manual is available in both paper and electronic editions. We recommend you to use the
electronic version if possible. If you have the electronic version at your disposal, you will be able to
benefit from the following features:
The manual contains several links and cross-references to other locations in the manual, which
makes it easier to move around in the manual. The reader can thus easily find and check things.
The manual also contains hyperlinks to web pages. To visit these web pages through the links, you
must have an internet browser installed on your computer.

SAFETY vacon • 5
Päivystys: 040-8371 150 • Email: [email protected]
1
Vacon NXI User's Manual
Index
Document code: DPD00909A
Date: 11/03/2014
1. SAFETY............................................................................................................................. 7
1.1 Warnings ................................................................................................................................... 7
1.2 Safety instructions.................................................................................................................... 7
1.3 Earthing and earth fault protection ......................................................................................... 8
1.4 Running the motor.................................................................................................................... 8
2. EU DIRECTIVE .................................................................................................................. 9
2.1 CE marking ............................................................................................................................... 9
2.2 EMC directive ............................................................................................................................ 9
2.2.1 Introduction....................................................................................................................... 9
2.2.2 Technical criteria.............................................................................................................. 9
2.2.3 Vacon inverter EMC classification ................................................................................... 9
2.2.4 Manufacturer's declaration of conformity....................................................................... 9
3. RECEIPT OF DELIVERY................................................................................................... 11
3.1 Type designation code............................................................................................................ 11
3.1.1 FI9 – FI14......................................................................................................................... 11
3.1.2 The standard features of NXI inverters ......................................................................... 12
3.2 Storage.................................................................................................................................... 13
3.3 Maintenance............................................................................................................................ 13
3.4 Warranty.................................................................................................................................. 14
4. TECHNICAL DATA .......................................................................................................... 15
4.1 Introduction............................................................................................................................. 15
4.2 Power ratings.......................................................................................................................... 17
4.2.1 Vacon NXI_xxxx 5 – Supply voltage 465-800 Vdc, Motor voltage 380—500 Vac ........... 17
4.2.2 Vacon NXI_xxxx 6 – Supply voltage 640-1100 Vdc, Motor voltage 525—690 Vac.......... 18
4.3 Technical information............................................................................................................. 19
5. INSTALLATION............................................................................................................... 22
5.1 Mounting ................................................................................................................................. 22
5.2 Fan cooling.............................................................................................................................. 29
5.2.1 Frames FI9 to FI14.......................................................................................................... 29
5.2.2 Arranging ventilation of the enclosure .......................................................................... 30
6. CABLING AND CONNECTIONS ....................................................................................... 33
6.1 Power unit............................................................................................................................... 33
6.1.1 Power connections ......................................................................................................... 41
6.1.1.1 DC supply and motor cables .................................................................................. 41
6.1.1.2 Control cable .......................................................................................................... 41
6.1.1.3 Fuses, NXI_xxxx 5................................................................................................... 41
6.1.1.4 Fuses, NXI_xxxx 6................................................................................................... 42
6.1.1.5 Inverter supply and motor cables , NXI_xxxx 5 ..................................................... 43
6.1.1.6 Terminal sizes, NXI_xxxx 5 .................................................................................... 44
6.1.1.7 Inverter supply and motor cables, NXI_xxxx 6 ...................................................... 45

6 • vacon SAFETY
Puhelin: 0201-2121 • Fax: [phone]
1
6.1.1.8 Terminal sizes, NXI_xxxx 6 .................................................................................... 46
6.1.2 Installation instructions ................................................................................................. 47
6.1.2.1 Vacon NXI frames .................................................................................................. 49
6.1.3 Cable installation and the UL standards ....................................................................... 51
6.1.4 Cable and motor insulation checks ............................................................................... 51
6.2 Control unit ............................................................................................................................. 52
6.2.1 Control connections ....................................................................................................... 53
6.2.1.1 Control cables ........................................................................................................ 54
6.2.1.2 Galvanic isolation barriers ..................................................................................... 54
6.2.2 Control terminal signals ................................................................................................ 55
6.2.2.1 Digital input signal inversions................................................................................ 56
6.2.2.2 Jumper selections on the OPT-A1 basic board..................................................... 57
7. CONTROL KEYPAD ......................................................................................................... 59
7.1 Indicators on the keypad display............................................................................................ 59
7.1.1 Drive status indications.................................................................................................. 59
7.1.2 Control place indications................................................................................................ 60
7.1.3 Status LEDs (green – green – red)................................................................................ 60
7.1.4 Text lines......................................................................................................................... 61
7.2 Keypad push-buttons.............................................................................................................. 62
7.2.1 Button descriptions ........................................................................................................ 62
7.3 Navigation on the control keypad........................................................................................... 63
7.3.1 Monitoring menu (M1) .................................................................................................... 65
7.3.2 Parameter menu (M2) .................................................................................................... 66
7.3.3 Keypad control menu (M3) ............................................................................................. 68
7.3.3.1 Selection of control place ...................................................................................... 68
7.3.3.2 Keypad reference ................................................................................................... 68
7.3.3.3 Keypad direction..................................................................................................... 68
7.3.3.4 Stop button activated.............................................................................................. 69
7.3.4 Active faults menu (M4).................................................................................................. 70
7.3.4.1 Fault types .............................................................................................................. 70
7.3.4.2 Fault codes ............................................................................................................. 72
7.3.4.3 Fault time data record............................................................................................ 76
7.3.5 Fault history menu (M5) ................................................................................................. 77
7.3.6 System menu (M6).......................................................................................................... 78
7.3.6.1 Selection of language............................................................................................. 81
7.3.6.2 Application selection .............................................................................................. 81
7.3.6.3 Copy parameters .................................................................................................... 82
7.3.6.4 Parameter comparison .......................................................................................... 84
7.3.6.5 Safety ...................................................................................................................... 85
7.3.6.6 Keypad settings ...................................................................................................... 87
7.3.6.7 Hardware settings.................................................................................................. 89
7.3.6.8 System info ............................................................................................................. 91
7.3.7 Expander board menu (M7)............................................................................................ 95
7.4 Further keypad functions ....................................................................................................... 96
8. COMMISSIONING............................................................................................................ 97
8.1 Safety....................................................................................................................................... 97
8.2 Commissioning the inverter................................................................................................... 97
9. FAULT TRACING........................................................................................................... 100

SAFETY vacon • 7
Päivystys: 040-8371 150 • Email: [email protected]
1
1. SAFETY
1.1 Warnings
1
The components of the power unit of the inverter are
live
when the Vacon
NX is connected to DC supply.
Coming into contact with this voltage is
extremely dangerous and may cause death or severe injury.
The
control unit is isolated from mains potential.
2
The DC supply and motor terminals are
live
when the Vacon NX is
connected to DC supply,
even if the motor is not running
.
3
The control I/O-terminals are isolated from the mains potential.
However, the relay outputs and other I/O-terminals may have dangerous
control voltage present even when the Vacon NX is disconnected from the
DC supply.
4
The inverter has a large capacitive leakage current.
5
If the inverter is used as a part of a machine, the machine manufacturer
is responsible for providing the machine with a main switch (EN 60204-1).
6
Only spare parts delivered by Vacon can be used.
1.2 Safety instructions
1
The Vacon NX inverter is meant for fixed installations only.
2
Do not perform any measurements when the inverter is connected to the
DC supply.
3
After having disconnected the inverter from the DC supply, wait until the
fan stops and the indicators on the keypad go out (if no keypad is
attached see the indicator through the keypad base). Wait 5 more
minutes before doing any work on Vacon NX connections. Do not even
open the cover before this time has expired.
4
Do not perform any voltage withstand tests on any part of Vacon NX.
There is a certain procedure according to which the tests shall be per-
formed. Ignoring this procedure may result in damaged product.
5
Prior to measurements on the motor or the motor cable, disconnect the
motor cable from the inverter.
6
Do not touch the components on the circuit boards. Static voltage dis-
charge may damage the components.
7
Before connecting the inverter to DC supply, make sure that the Vacon
NX front and cable covers are closed.
ONLY A COMPETENT ELECTRICIAN MAY CARRY OUT
THE ELECTRICAL INSTALLATION
WARNING

8 • vacon SAFETY
Puhelin: 0201-2121 • Fax: [phone]
1
1.3 Earthing and earth fault protection
The Vacon NX inverter must always be earthed with an earthing conductor connected to the earthing
terminal.
The earth fault protection inside the inverter only protects the inverter against earth faults in the
motor or the motor cable.
Due to the high capacity currents present in the inverter, fault current protective switches may not
function properly. If fault current protective switches are used, they need to be tested with earth
fault currents present during possible fault situations.
1.4 Running the motor
Warning symbols
For your own safety, please pay special attention to the instructions marked with the following
symbols:
=
Dangerous voltage
WARNING
=
General warning
HOT SURFACE
=
Hot surface – Risk of burn
MOTOR RUN CHECK LIST
1
Before starting the motor, check that the motor is mounted properly and
ensure that the machine connected to the motor allows the motor to be
started.
2
Set the maximum motor speed (frequency) according to the motor and
the machine connected to it.
3
Before reversing the motor, make sure that this can be done safely.
4
Make sure that no power correction capacitors are connected to the
motor cable.
5
Make sure that the motor terminals are not connected to mains
potential.
NOTE! You can download the English and French product manuals with applicable safety, warning
and caution information from www.vacon.com/downloads.
REMARQUE Vous pouvez télécharger les versions anglaise et française des manuels produit
contenant l’ensemble des informations de sécurité, avertissements et mises en garde applicables
sur le site www.vacon.com/downloads.
WARNING

receipt of delivery vacon • 9
24-hour support: [phone] • Email: [email protected]
3
2. EU DIRECTIVE
2.1 CE marking
The CE marking on the product guarantees the free movement of the product within the EEA
(European Economic Area). It also guarantees that the product complies with applicable directives
(for example, the EMC directive and other possible so-called new method directives).
Vacon NX inverters carry the CE label as a proof of compliance with the Low Voltage Directive (LVD)
and the Electro Magnetic Compatibility (EMC) directive. SGS FIMKO has acted as the Competent
Body.
2.2 EMC directive
2.2.1 Introduction
The EMC Directive provides that the electrical apparatus must not excessively disturb the
environment it is used in, and, on the other hand, it shall have an adequate level of immunity toward
other disturbances from the same environment.
The compliance of Vacon NX inverters with the EMC directive is verified with Technical Construction
Files (TCF) and checked and approved by SGS FIMKO, which is a Competent Body. The Technical
Construction Files are used to authenticate the conformity of Vacon inverters with the Directive
because it is impossible to test such a large product family in a laboratory environment and because
the combinations of installation vary greatly.
2.2.2 Technical criteria
Our basic idea was to develop a range of inverters offering the best possible usability and cost-
efficiency. EMC compliance was a major consideration from the outset of the design.
2.2.3 Vacon inverter EMC classification
Factory delivered Vacon NX inverters are Class T equipment, which fulfil all EMC immunity
requirements (standards EN 50082-1, 50082-2 and EN 61800-3).
Class T:
Class T equipment have a small earth leakage current and can be used with floating DC input.
2.2.4 Manufacturer's declaration of conformity
The following page presents the photocopy of the Manufacturer's Declaration of Conformity assuring
the compliance of Vacon Inverters with the EMC-directives
Warning:
This product is of the restricted sales distribution class according to IEC 61800-3. In
residential areas, this product may cause radio interference in which case the user may be required
to take adequate measures.

10 • vacon receipt of delivery
Tel: [phone] • Fax: [phone]
3
EU DECLARATION OF CONFORMITY
We
Manufacturer's name:
Vacon Oyj
Manufacturer's address:
P.O.Box 25
Runsorintie 7
FIN-65381 Vaasa
Finland
hereby declare that the product
Product name:
Vacon NX Common DC bus Products
Model designation:
Vacon NXI 0004 5… to 2700 5
Vacon NXI 0004 6… to 2250 6
Vacon NXA 0004 5… to 2700 5
Vacon NXA 0004 6… to 2250 6
Vacon NXF 0004 6… to 2700 5
Vacon NXF 0004 6… to 2250 6
Vacon NXN 0400 5… to 0650 5
Vacon NXN 0400 6… to 0650 6
Vacon NXB 0004 5… to 2700 5
Vacon NXB 0004 6… to 2250 6
has been designed and manufactured in accordance with the following standards:
Safety:
EN61800-5-1 (2003)
EMC:
Factory delivered Vacon NX inverter modules comply with
the requirements of category 4 equipment according to EN
61800-3 (2004).
It is ensured through internal measures and quality control that the product conforms at all times
to the requirements of the current Directive and the relevant standards.
In Vaasa, 3rd of April, 2006
Vesa Laisi
President
The year the CE marking was affixed: 2005
