VADANIA VF1245 User manual

7KHRႈFLDOZHEVLWH
https://vadania.com/
Email: [email protected]
Page 1
&RQWDFW8V
3DFNDJH
1Pair of drawer slide
8 x Mount screws
)DFHERRN3DJH
Hardware for your life
VF1245 PUSH TO OPEN DRAWER SLIDES MANUAL
https://vadania.com/
Email: [email protected]
VF1245 PUSH TO OPEN DRAWER SLIDES MANUAL

Page 2
NAME：VADANIA PUSH TO OPEN DRAWER SLIDES VF1245
MATERIAL: COLD-ROLLED （COLD ROLLED）STEEL
INSTALLATION METHOD: SIDE MOUNT
MAXIMUM LOAD CAPACITY: 100LB / 45KG.
MINI DEPTH OF CABINET: DRAWER LENGTH + 0.12IN / 3MM
SURFACE TREATMENT: GALVANIZED / CHROME
SLIDE STYLE: 3 FOLDS FULL EXTENSION, SIDE MOUNT, SEPARABLE
PLATE THICKNESS: OUTER SLIDER 0.04IN(1.2MM) / MIDDLE SLIDER
0.04IN(1.2MM) / INNER SLIDER 0.06IN(1.5MM)
SIZE: 10-24IN / 250-600MM
SCOPE OF APPLICATION: &,9,/)851,785(2ႈ&()851,785(
KITCHEN CABINETS/WARDROBES, ETC
A
A
C
Visible hole for screwing
B
' 2GZKXGRGJP[YZSKTZNURKŐSSȕ
( <KXZOIGRGJP[YZSKTZNURKŐSSȕ
) ,O^NURKŐSSȕ
'B(LUXLO^OTMGTJGJP[YZOTM)UTR_LUXLO^OTM
:NKVXUJ[IZNGYGYZXUTM[TO\KXYGRJKYOMTGRRZNK'()NURKYIGTHKOT-
YZGRRKJYIXK]Y
<'*'4/'9IXK]YŐSSȕ
9[OZGHRKLUX'()

High Quality Plate
+LJKWHQVLRQFROGUROOHGႋHHOSODWHV
WLPHVRIOESXVKSXOOWHႋVZLWKRXW
GDPDJH
6ROLGႋHHOEDOOEHWWHUEHDULQJ
FDSDFLW\
3-Fold Slides
(QDEOHWKHVOLGHVWRIXOO\H[WHQG
Solid Ball Bearing
Provides slient and friction-free
motionwhen open drawer
Page 3
Push-to-open-Device
3URGXFW)HDWXUHV
A dierent chhoice for installing a drawer,
Drawer
Drawer
also preventing drawer from slamming shut

0.5±0.01” / 12.56±0.25mm
1.7” / 45.10mm Drawer floor
Space Between Drawer and Cabinet
Page 4
Step2
Installation Instruction
Make sure the slides are leveled during the
installation process
Step1 Separate drawer and base portion before
mounting with provided lever
Step3 ①Frameless Cabinet: Place the outer member
ush with the front edge of cabinet
②The thickness of the drawer panel should be
reserved for cabinets with face frames.
Step5 Adjust and level the inner member. mount the
screws in the permanent mounting holes
Step4 Mount the screws in the permanent mounting
(Breathing) holes
Step6 Move the metal retainer to the front of cabinet
member and insert the drawer box carefully.
Installation Precautions
12

How to Chose Size
Measure the depth of the drawer ( for example, if the depth is 13in/330mm,
choose 12in/300mm drawer slides. Deviations of 0.7in/20mm-1in/30mm are suitable)
Original Length
9.9’’/250mm
11.9”/300mm
13.7”/350mm
15.7”/400mm
17.7”/450mm
19.7”/500mm
21.7”/550mm
23.7”/600mm
Extended Length [A+B]
19[9.9+9.1]”/493[250+233]mm
23.5[11.9+11.6]”/598[300+298]mm
27.3[13.7+13.6]”/697[350+347]mm
31.3[15.7+15.6]”/796[400+396]mm
35.2[17.7+17.5]”/896[450+446]mm
39.2[19.7+19.5]”/996[500+496]mm
43.2[21.7+21.5]”/1097[550+547]mm
47.1[23.7+23.4]”/1194[600+594]mm
Width Thickness
1.7”/45mm 0.5”/12.7mm
Dimension
(Refer to the below table)
Extended Length Pull Back
Thickness
Gap of Installation: 0.51” / 13mm
Original Length
1.7” / 45mm
0.5” / 12.7mm
Full Extend
Page 5
Size Table
A deviation of 0.2”/5mm may apply to the actual extended length.
A
B
Item Size
10’’/250mm
12’’/300mm
14’’/350mm
16’’/400mm
18’’/450mm
20’’/500mm
22’’/550mm
24’’/600mm
8
