Overview
The WEBBi is an inexpensive room A/V control
system for use with the EasyUSB Tools product
family. The WEBBi is a complete room control
system for the EasyUSB™ Tools devices including
EasyMic™ MicPODs, EasyUSB Mixer/Amp,
ClearVIEW™ HD-USB PTZ Camera and
AutoPresenter™ products. Simply connect to the
WEBBi’s web server with a PC browser and
control the room’s camera, display and audio.
The WEBBi control functions are intended to be used with any device equipped with a web browser and internet
access providing an intuitive user interface for control of the room audio and video devices. An embedded web
server serves the room’s user interface control page to a connected client like a PC, tablet, or smartphone.
The room UI includes interactive user controls for room audio volume, microphone mute, camera PTZ and preset
execution, and LCD display power control via IR probe. The WEBBi is easily configured from administration
pages allowing the installer the flexibility to select Vaddio EasyUSB devices used in application, communication
interfaces, and button labeling.
Intended Use:
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Important Safeguards:
Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged.
In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock,
do not immerse in water or other liquids and avoid extremely humid conditions. Do not connect Ethernet or
Power over Ethernet (POE) cables directly to the RJ-45 ports on the device as damage may result.
Save These Instructions:
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
Use only the power supply provided with the system. Use of any unauthorized
power supply will void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not work
well for professional installations and can be the cause of intermittent connections which can result in
the RS-232 control line failing and locking up. For best results please use standard RJ-45 connectors
and test all cables for proper pin-outs prior to use.

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 5 of 24
Unpacking
All components within the shipping box are individually packaged as described in the sections below. Carefully
remove all parts included in the individual packaging.
WEBBi - Part Number 999-8700-000 for North America
North American Pack-out includes:
One (1) WEBBi Web Controller Appliance
One (1) 12 VDC 1.0 Amp PowerRite™ Switching Power Supply
One (1) Power Cord for North America
One (1) 6’ (1.83m) USB Type A to Type B Cable (Black)
WEBBi - Part Number 999-8700-001 for International
International Pack-out includes:
One (1) WEBBi Web Controller Appliance
One (1) 12 VDC 1.0 Amp PowerRite Switching Power Supply
One (1) Euro Power Cord
One (1) UK Power Cord
One (1) 6’ (1.83m) USB Type A to Type B Cable (Black)
Option: Rack Mounting Kit
The rack kit provides a method for the WEBBi to be installed in
a 1-RU space within a rack. The rack kit includes two rack
ears (one long and one short). The rack ears are mounted in
the sides of the WEBBi enclosure using the existing screws
included on the device.
Rack Kit Part Number 998-6000-004

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 6 of 24
Equipment Descriptions and Call-outs
Diagram: WEBBi Front Panel
1) Recessed Power/Reset Button: Resets and reboots the WEBBi device with push button activation.
2) LCD Display: Scrolls current IP Address across the screen when the unit is plugged in.
3) RS-232 LED Indicators: Blue LED indicators for both the Audio & Video port connection to the EasyUSB
Tool devices. LED will flash when communication activity is detected with the device under control.
4) Network LED Indicators: LEDs will flash blue to indicate detection of Ethernet activity between web server
and attached browser client.
5) Power LED Indicator: This LED will illuminate blue when power is detected.
Diagram: WEBBi Rear Panel
1) Power Connector: 5.5mm OD x 2.5mm ID coaxial connector, positive center for supplying power to device.
Use with 12 VDC, 1.0A power supply included in package only.
2) DIP Switches: Used to reset device to factory defaults. Setting all dip switches to the off-position will reset
the unit to factory defaults on the next power cycle. User will lose all programmed configurations on the
factory default operation.
3) Audio Control: RJ-45 connector with RS-232 functionality (see appendix for pin-out). RS-232 Control port
for use with Vaddio EasyUSB Mixer/Amp. .
4) Video Control: RJ-45 connector with RS-232 functionality (see appendix for pin-out). RS-232 Control port
for use with Vaddio HD-USB PTZ Camera or AutoPresenter.
5) USB: For future use.
6) Network: 10/100 Ethernet port for connection to the Local Area Network.
7) IR Port: For future use.
➌➎
➍
➊ ➋
➌➎
➍
➊ ➋➏➐

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 7 of 24
Connecting the WEBBi
WEBBi System Connection Diagrams
The WEBBi control system is for use with Vaddio A/V equipment providing a plug & play connection scheme
using standard RJ-45 connectors and CAT-5 cable for the physical connection between devices. Supported
devices include the EasyUSB Mixer/Amp, ClearVIEW HD-USB PTZ Camera, and AutoPresenter products. The
applications below depict common applications that can be supported with the WEBBi control system.
WEBBi Configuration with EasyUSB and HD-USB Camera
Below are the connections for enabling web control of an EasyTalk Audio solution and an HD-USB PTZ Camera.
Web pages will be served up via the Ethernet connection.
Diagram: WEBBi with EasyUSB Mixer/Amp and HD-USB PTZ Camera
Ethernet
Two (2) EasyMic
MicPOD Table Mics
Two (2) EasyTalk
Bose DS16F Ceiling
Speakers
Ethernet
RS-232 for
Video Device
RS-232 for
Audio Device
USB 2.0
Video with
UVC Drivers
USB 2.0
Audio with
UAC Drivers
RS-232 RS-232
ClearVIEW
HD-USB PTZ
Camera
EasyUSB
Mixer/AMP
Rear Panel
WEBBi
PC with UC
Client and
WEBBi control
web Page

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 8 of 24
WEBBi with AutoPresenter
The WEBBi can be used with the AutoPresenter providing camera controls, video input selection, preset
activation, and PIP controls from the embedded Web Pages. The physical connection is a simple RJ-45 with
CAT-5 cable along with a 9-pin (DE-9 or DB-9 for the conventionalists) to RJ-45 adapter for use on the
AutoPresenter RS-232 back panel connector. The WEBBi will serve up web pages via the network connection.
Diagram: WEBBi with Multiple Cameras and Auto Presenter
RS-232
for Audio
EasyUSB Mixer/Amp
With Mics and Speakers
WEBBi
RS-232 for
Video Device
USB 2.0 - Video with UVC Drivers
USB 2.0
Audio with
UAC Drivers
AV Bridge - Audio and Video Encoder
HD Video IN USB 2.0
Video OUT
Ethernet
Ethernet
PC with UC
Client and
WEBBi control
web Page
WallVIEW HD-20’s with CONCEAL Mounts

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 9 of 24
Installation Instructions
WEBBi
Locate the WEBBi near a Network jack for control over the Local Area Network. Follow the steps below to install
all of the devices.
Diagram: WEBBi Installation Steps











STEP 1: Plug 12 VDC, 1.0 Amp power supply included in package into the WEBBi. Power LED on the front
panel should light solid blue when powered.
STEP 2: Connect RJ-45 using CAT-5 or better cable between WEBBi audio control RS-232 RJ-45 jack and
EasyUSB Mixer/Amp RS-232 RJ-45 jack for audio control via web pages.
STEP 3: Connect RJ-45 using CAT-5 or better cable between WEBBi video control RS-232 RJ-45 jack and
ClearVIEW HD-USB PTZ Camera (RJ-45 jack) or AutoPresenter RS-232 9-pin jack.
STEP 4: Connect WEBBi to the LAN for serving web pages over an IP address configured by the
administrator**.
**Note: The WEBBi can be directly connected to a PC using a network crossover cable for
initial installation configuration purposes. In absence of a DHCP server in this scenario, the
WEBBi will default to a static IP address of 169.254.1.1. Once connected with the Network
crossover cable, the installer can use this static IP address in the browser to navigate to the
web pages**.
1
2 3
4
WEBBI - Web Controller
Cessna 174
Not Included
PC
HD-USB PTZ
Camera
EasyUSB
Mixer/Amp
12 VDC, 1.0
Amp Power
Supply

WEBBi - Web Controller
Vaddio WEBBi - Web Controller - Document Number 342-0445 Rev B Page 10 of 24
System Configuration and Programming
WEBBi Administrator Pages
The WEBBi is configured by the administrator pages accessible by log-in to the Admin account on the embedded
web server.
A/V Configuration Page
The A/V Configuration page allows the installer to select the Audio, Video, and Display device to be controlled by
the WEBBi. These selections automatically generate the room user interface web pages that are served to the
user allowing room audio & video controls of the devices. A “none” selection will eliminate that control feature
from the room user interface (UI). Supported audio devices are limited to the EasyUSB Mixer/Amp. Supported
video devices include the ClearVIEW HD-USB camera and the AutoPresenter. Only one device for each type is
available for selection.
Diagram: A/V Configuration Page
UI (user interface) Selections:
Audio:
None
EasyUSBMixer/Amp
Video:
None,
AutoPresenterand
ClearVIEWHD‐USBPTZCamera
Today there is a limited amount of UI’s available, but more will be added in future releases. The combinations
will be covered later in the manual.
