VADO ARRONDI TAB-128/3WO-B-ARR-CP User manual

3 handle, 3 outlet thermostatic shower valve
Installation Guide
TAB-128/3WO-B-ARR-CP
TAB-128/3WO-S-ARR-CP
ARRONDITM
This installation guide covers 2 model:
TAB-128/3WO-B-ARR-CP
TAB-128/3WO-S-ARR-CP
Version 1, 1-4-22
VADO
Wedmore Road Cheddar Somerset England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail]

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General Installation
Operating Specifications
Important - Please Read
Operating Pressure
Minimum operating pressure 0.2 bar (1 bar if used as a bath fill)
Maximum operating pressure 5 bar
This fitting is a mixing device and therefore water supplies should be reasonably
balanced.
When installed, the fitting must comply with the requirements of the Water Supply
(Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
For further information, contact the Water Regulations department of your local water
supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations
Advisory Scheme by email ([e-mail]) or telephone: [phone].
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed
to remove debris. Failure to do so could result in damage or low flow from the mixer
unit.
The fitting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Contents of Packaging
Installation guide &
User manual
3 handle, 3 outlet thermostatic shower valve
Installation Guide
TAB-128/3WO-B-ARR-CP
TAB-128/3WO-S-ARR-CP
ARRONDI
TM
3 handle, 3 outlet thermostatic shower valve
User Guide
Keep for f uture referen ce
ARRONDI
TM
Valve with
Mortar guard
Control handles x 2
Temperature handle
Cover plate
with outlet bracket

4 5
Contents of Packaging
Shower hose with 2 washers
Handset
Hex key
Adaptors ¾" to ½" x 4
Dimensions
50mm
74mm
314mm
80mm 80mm
58mm
50mm
58mm
50mm
80mm
61.5mm 61.5mm

6 7
Installation - Quick Guide
1
2
77mm
250mm
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
2
3
90mm
4
2
1
Installation - Quick Guide
7
1
2
56
8mm

8 9
Installation - Quick Guide
8
9
Installation - Quick Guide
10
11

10 11
Installation
Flush pipe work thoroughly before fitting the valve.
Warning! Please check for any hidden cables and pipes before drilling holes in
the wall.
The valve must be set into the wall between (79.5mm min – 101.5mm max).
If you are fitting the valve to a partition wall or a wall of particularly soft substrate
you will need specialist fixings.
Please contact VADO or retailer for WG-STUDFAST-C-S/S fixing.
Mortar guard
During installation please leave the mortar guard secured to the valve to avoid
damage to the product and protect the internals during tiling etc.
Valve
Mortar
guard
Installation
Select the position for the shower valve and offer the shower valve to the wall,
make sure the valve is level and mark the 6 fixing points with a suitable pencil, see
above for dimensions. Remove the shower valve from the wall, drill the holes to a
suitable depth for the wall plugs and secure with suitable screws.
Mortar
guard
Fixing
screws
77mm
Fixing points
90mm
250mm
MAX
MIN
Wall
Mortar guard (wall shown in minimum position)

12 13
Installation
Finish the wall by tiling up to the
mortar guard, keep the final finished
wall surface between the min and max
marks.
Unscrew the 2 mortar guard screws
and remove from the wall.
Pull out the spigot from the outlet on
the left side of valve.
Cold inlet
Hot inlet Outlet 1
Outlet 2
Connect cold supply to the lower left
inlet of the valve and hot supply to the
upper left inlet.
Connect outlet 1 to the desired channel
e.g. to the shower head.
Note: outlet 2 will be connected to the
bath.
Mortar
guard
Mortar guard
screws
Spigot
Screw spigot into the outlet on the back
of the plate. Tighten using a 8mm hex
key.
Spigot
8mm
hex key
Plate
Installation - Trim
Guide the handset holder with spigot attached partially onto the valve and then
slide the cover plate over the threaded cartridge covers. Push on the cover plate
and handset holder. Apply a thin bead of silicone around the outside to seal against
the tiled surface.
Handle
shroud
Carefully slide the temperature handle onto the centre spline of the valve. While holding
the handle in the vertical/horizontal position screw the shroud until touches the cover
plate. The handle is etched to show alignment to the 38°c position on the plate.
Handset
holder and
outlet
Cover plate
Spigot
Threaded cartridge
covers

14 15
Installation
Handle
shroud
Handle
shroud
Carefully slide on both control handles onto spline of the valve. While holding the
handle in the horizontal position screw the shroud until touches the cover plate.
Installation - Handset
Handset outlet
Place a rubber washer into either
end of the hose and attach it to the
handset outlet (see above).
Handset
Place the other rubber washer into
the end of the hose and screw to the
handset (see right).
Rubber
washer
Hose
Rubber washer
Handset
Hose

16 17
Temperature Commissioning
Note: mixed water temperature at terminal tting should never exceed 46°C.
The valve has been factory set under balance pressures and hot water supply at 65°C.
When your specific operating conditions are significantly different from the above, the
temperature of the water may vary from the setting.
When the difference is too great, you can adjust the calibration of the valve to suit
individual requirements of the installation:
1. Check the temperature of the water being delivered from the outlet with a
thermometer, when the stop arm is located at 12 o'clock.
Note: temperature readings should be taken at normal flow rate after allowing for the
system to stabilise.
2. If the temperature is not 38°C proceed to reset the calibration as follows:
Remove the stop adaptor.
Ensure the step on the stop ring is located at 8 o'clock.
Do not remove the plastic stop ring.
Please continue on next page.
Stop adapter
Screw
Temperature Commissioning
Turn the spline of the thermostatic valve clockwise to decrease the temperature and
anti-clockwise to increase the temperature until 38°C is achieved at outlet.
Note: the sensing part of the thermometer probe must be fully submerged in the water
that is to be tested.
Replace the stop adaptor making sure that the stop arm is located at 12 o’clock.
When the handle is attached (see page 13) ensure the temperature does not exceed
46°C when turned entirely anti-clockwise.
Your valve setting is now commissioned.
Stop ring
Step on stop
ring located
at 8 o'clock
Stop arm
Stop
Temperature
valve spline

18
