VADO Axces IRLO AX-IRO-130+K-CP Instruction Manual

This instruction booklet covers model:
AX-IRO-130+K-CP
Version 1, 1-8-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail]
BATH SHOWER MIXER
WITH SHOWER KIT
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
IRLO

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General installation
Operating Specifications
Important - please read
Operating Pressure
Minimum operating pressure 0.2 bar
Maximum operating pressure 5 bar
This fitting is a mixing device and therefore water supplies should be reasonably
balanced.
When installed, the fitting must comply with the requirements of the Water Supply
(Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
For further information, contact the Water Regulations department of your local water
supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations
Advisory Scheme by email ([e-mail]) or telephone: [phone].
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed
to remove debris. Failure to do so could result in damage or low flow from the mixer
unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 13.
The fitting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Contents of Packaging
Mixer
with base seals
Fixing Kit
Rubber washers x 2
Nuts x 2
BATH SHOWER MIXER
WITH SHOWER KIT
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
IRLO
Installation guide &
User manual
Shower hose with 2 washers
Handset Holder
Holder
Handset

4 5
1
23
Dimensions
142mm
46mm
80mm
180mm
216mm
¾"
25mm
150mm
69mm
½"
36mm
Installation - Quick guide
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
4
2
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2
3
4
x 2 x 2
1
1
3

6 7
4
7
5
6
Installation - Quick guide Installation
Before installing your new mixer, flush through the pipework to ensure removal of
debris, turn off the water supply.
Position both seals into the bottom of the mixer body.
Position the mixer on the bath. From the underside of the bath fit the rubber
washers and nuts. Tighten the nuts to clamp the mixer to the bath.
CAUTION: Do not over tighten the nuts as this may damage the bath.
Connect the water supply to the inlet pipes. The hot water should be connected to
the left hand pipe and cold to the right.
Place a rubber washer into the nut end of the hose and attach it to the mixer outlet.
Hot control
handle
Rubber
washer
Nut
Hot inlet
Seal
Cold inlet
Seal
Cold control
handle
Rubber
washer
Nut
Rubber
washer
Nut

89
Handset
Place one of the rubber washers into the
cone end of the hose and screw to the
Showerhead.
Installation
Handset
Cone end
of hose
Washer
Handset holder
Warning! Please check for any hidden
pipes and cables before drilling holes in
the wall.
If you are fitting the unit to a partition wall
or a wall of particularly soft substrate you
will need specialist fixings.
Select the position for the shower holder
bracket and mark the 2 fixing positions
with a suitable pencil.
Remove the holder from the wall.
Suitably fix the holder to the wall using
appropriate fixings.
Holder
Pencil
Holder
Screws
Wall plugs
(if required)
Operation
Cold
Hot
Hot tap - moving the tap
lever to the left will increase
the flow of water.
Cold tap - moving the tap
lever to the right will increase
the flow of water.
Diverter
Pull the shower control
knob up to turn on the
shower, turn clockwise to
lock in position.
Turn clockwise again to
release the diverter and go
back to the primary outlet.

11
All AXCES by VADO products come with a 2 year guarantee as standard. Within this
guarantee period VADO will provide replacement parts and any labour [SEE NOTE 1,
GUARANTEE CONDITIONS] needed to complete the product repair.
This standard guarantee may be extended by registering your product to give a 10 year
guarantee (2 years parts and labour plus 8 years on parts supply only.).
Operational components such as, but not limited to; thermostatic cartridges, diverters,
headworks and flow control, waste mechanisms, shower hoses, O-rings and seals are
guaranteed for 2 years parts and labour plus 3 years on parts supply only.
Guarantee Conditions
Our products are guaranteed against manufacturing defects from the date of purchase until
the expiry of the relevant guarantee period shown above.
The guarantee is only valid if:
•The product has been installed, used and maintained in accordance with VADO's
instructions and subjected to normal use only.
•The defect is not due to use of an unsuitable or inadequate water or power supply.
•The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair (other
than by VADO or VADO authorised agents) or damage caused by foreign objects
or substances.
•The extended guarantee is only available if you have completed the Guarantee Registration
Process. This can be done via the VADO website or via phone to our aftersales team.
Registration must be completed within 6 months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any
replacement product (or component part) assessed to be defective [SEE NOTE 2].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner.
All claims under the guarantee should be notified in the first instance to our Aftersales
department, contact details below, this must be done no later than the last day of the
relevant guarantee period. All claims must be accompanied by proof of purchase (sales
receipt or delivery note) from an official AXCES by VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the
original date of purchase.
VADO operates a policy of continuous product development and therefore reserves the right
to change the product, packaging and documentation specifications without notice.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO
engineer or sub-contract engineer will be under our standard terms and conditions.
[2] VADO reserves the right to charge in advance for a product (or replacement part) pending
collection and investigation (at VADO expense) to confirm a defect is due to a manufacturing
issue. If a defect is found the charge will be refunded or cancelled.
This guarantee is in addition to and does not affect your statutory rights as a consumer.
Tel: [phone]
Email: [e-mail]
Guarantee
10
Cleaning instructions
The electroplating on this product is finished to the highest standard. Due care needs
to be taken to ensure the appearance is retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of all aggressive/corrosive cleaning products i.e. powders and liquids.
If these instructions are not followed, this may invalidate your guarantee in the event
of a problem occurring.
