VADO Origins Installation and operating instructions

Origins
Floor mounted bath shower mixer with shower kit
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel [phone]. fax [phone]
[email protected]
www.vado-uk.com
Guarantee
Customer/technical services
For any technical or installation queries please contact Vado on 01934 745163.
GUARANTEE REGISTRATION
NAME
ADDRESS
RETAILER
ADDRESS
PURCHASE DATE
PRODUCT DESCRIPTION
WHO INSTALLED THE PRODUCT?
FOR VADO USE
POSTCODE
POSTCODE
ARTICLE NUMBER (SEE BOX)
RETAILER PLUMBER BUILDER SELF
This product is guaranteed against manufacturing defects from the date of purchase until the expiry of the relevant
guarantee period shown below.
The guarantee is only valid if:-
1. The product has been installed, used and maintained in accordance with Vado’s instructions and subjected to
normal use only.
2. The defect is not due to use of an unsuitable or inadequate water or power supply.
3. The defect is not due to accident, misuse, neglect or repair other than by Vado or Vado authorised agents or
damage caused by foreign objects or substances.
4. We have received from you the completed Guarantee Registration Form. Vado accepts no responsibility for any
forms lost in the post and returns by registered means is therefore recommended.
Under this guarantee (which is non-transferable) Vado will, at its option, repair or replace free of charge any product
(or replacement part) found to be defective. The guarantee does not extend to any consequential loss or damage.
After repair or replacement the relevant guarantee period will be calculated from the original date of purchase.
The relevant guarantee periods are:-
1. Twelve years on chrome nish products.
2. Six years on Vado Identity products.
3. Three years on all other products with the exception of Stuart Turner Pumps which carry a 2 year Guarantee on
Monsoon Range and 1 Year Guarantee on Showermate Range.
All claims under the guarantee must be submitted in writing to the person who supplied the product to you and
must be received no later than the last day of the relevant guarantee period. All claims must be accompanied by
proof of purchase (sales receipt or delivery note).
Vado operates a policy of continuous product development and therefore reserves the right to change the product,
packaging and documentation specications without notice.
This guarantee is in addition to and does not aect your statutory rights as a consumer.
Installation & maintenance instructions
Please leave these instructions with the customer

Important - please read
General installation
27
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and ttings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
These ttings are mixing devices and therefore water supplies must be reasonably
balanced.
Where connections are made to the mains cold water supply, WRC approved single
check valves must be tted to both hot and cold inlets. This is a stated requirement of
Water Supply (Water Fittings) Regulations 1999 Schedule 2, Section 6 G15.13.2
Before making any inlet pipe connections, all supply pipes MUST be thoroughly
ushed to remove debris. Failure to do so could result in damage or low ow from the
mixer unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 4 G13.1
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Care of the mixer
Our products are nished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the
event of a problem occurring.
Installers/users notes

6
Dimensions
3
Operation
Installation - showerhead
Pull the shower control knob
in to turn on the shower, pull
out to close.
Rotate the handle to
increase/decrease
the temperature.
Pull the handle to
increase/decrease
the ow of water.
Shower holder
Operating Specications
Minimum operating pressure 3 bar.
Maximum operating pressure 5 bar.
251mm
997mm
1095mm
850mm
80mm 60mm
Min 115mm
191mm
½"
79mm
93mm
755mm
54mm
90mm
74mm
Showerhead
Place one of the rubber washers into the
cone end of the hose and screw to the
Showerhead.
Place the second rubber washer into the
other end of the hose and attach it to
the mixer outlet.

Installation
45
Installation
Before installing your new mixer, ush
through the pipework to ensure removal
of debris, turn o the water supply.
Warning! Please check for any
hidden cables and pipes before drilling
holes.
Position the seat and mark the 3 xing
holes, remove the seat and drill the 3 x
12mm holes to the required depth.
Insert the expansion bolts into the holes.
Slide the seat over the studs followed
by the 3 washers and nuts. Use the
adjusting screws to level the seat, when
satised with the level nally tighten
down the bolts.
Connect the inlet pipes to the seat with
the hot on the left and cold on the right.
Nut
Washer
Seat
Bolts
Adjusting
screw
Bolts
Hot inlet
Cold inlet
Seat
Front
Finish the oor covering down to a
diameter of 78mm.
Remove the 2 screws and pull out
the safety cover.
Insert the main body assembly into
the seat, tighten the fastening plate,
and cover with the escutcheon.
Seat
78mm
Safety
cover
Screws
Seat
Escutcheon
Fastening
plate
Floor
