VADO AXCES MATRIX AX-MAT-145A-CP Instruction Manual

KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
This instruction booklet covers model:
AX-MAT-145A-CP
Version 1, 1-9-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail]
MATRIX
MANUAL VALVE

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General installation
Important - please read
This fitting is a mixing device and therefore water supplies should be reasonably
balanced.
When installed, the fitting must comply with the requirements of the Water Supply
(Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
For further information, contact the Water Regulations department of your local water
supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations
Advisory Scheme by email ([e-mail]) or telephone: [phone].
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed
to remove debris. Failure to do so could result in damage or low flow from the mixer
unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 13.
The fitting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Operating Specifications
Operating Pressure
Minimum operating pressure for shower 0.2 bar
Minimum operating pressure for bath 1.5 bar
Maximum operating pressure 5 bar
Contents of Packaging
Plate Hex Key
Wall plugs
FIXING KIT
Screws
Handle with grub
screw and cover
Valve
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
MATRIX
MANUAL VALVE
Installation guide &
User manual

45
Dimensions
16mm
72mm
1/2”
40-65mm
Ø40mm
Cover plate
Ø40mm
25mm
5mm
Ø140mm
102mm
Installation - Quick guide
2
1
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5

6 7
Installation
Wall plugs Hot inlet
Outlet
Before installing your new mixer, flush through the pipework to ensure removal of
debris, turn off the water supply.
Warning! Please check for any hidden cables and pipes before drilling holes in
the wall.
The valve must be set into the wall by 40-65mm (see dimension page).
If you are fitting the valve to a partition wall or a wall of particularly soft substrate
you will need specialist fixings.
Select the position for the shower valve and offer the shower valve to the wall,
mark the 4 fixing points at the top and bottom with a suitable pencil. Remove the
shower valve from the wall and secure with suitable fixings.
Make all connections to the valve. Connect hot supply to left inlet of the valve and
cold supply to right inlet.
Connect the outlet to the shower.
Finish the wall, keep the final finished wall surface between the min and max
dimensions.
Cold inlet
3
Installation - Quick guide
Screws
1
3
2
4

8 9
Installation
Remove the backing paper from the seal located on the back of the plate. Slide the
plate over the valve, push onto the wall until it makes contact.
Carefully slide the control handle onto the valve and secure in position with the
grub screw located within the handle using the hexagonal key supplied, replace the
screw cover.
Note: If the valve is sited within in a wet environment, it is recommended that once
the valve is installed the plate is sealed with an adequate of sealant around three
sides to provide a water-tight seal between the plate and the wall material, leaving
the bottom edge free to allow for maintenance purposes.
Valve
Backing paper Plate
Grub screw
Handle
Screw cover
Operation
Pulling the mixer lever outwards will
increase the flow of water.
Lever in the off position.
Moving the mixer lever from right to left
will increase the water temperature.
Moving the mixer lever from left to right
will decrease the water temperature.

10
Cleaning instructions:
Our products are finished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the event
of a problem occurring.
11
Guarantee
All AXCES by VADO products come with a 2 year guarantee as standard. Within this
guarantee period VADO will provide replacement parts and any labour [SEE NOTE 1,
GUARANTEE CONDITIONS] needed to complete the product repair.
This standard guarantee may be extended by registering your product to give a 10 year
guarantee (2 years parts and labour plus 8 years on parts supply only.).
Operational components such as, but not limited to; thermostatic cartridges, diverters,
headworks and flow control, waste mechanisms, shower hoses, O-rings and seals are
guaranteed for 2 years parts and labour plus 3 years on parts supply only.
Guarantee Conditions
Our products are guaranteed against manufacturing defects from the date of purchase until
the expiry of the relevant guarantee period shown above.
The guarantee is only valid if:
•The product has been installed, used and maintained in accordance with VADO's
instructions and subjected to normal use only.
•The defect is not due to use of an unsuitable or inadequate water or power supply.
•The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair (other
than by VADO or VADO authorised agents) or damage caused by foreign objects
or substances.
•The extended guarantee is only available if you have completed the Guarantee Registration
Process. This can be done via the VADO website or via phone to our aftersales team.
Registration must be completed within 6 months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any
replacement product (or component part) assessed to be defective [SEE NOTE 2].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner.
All claims under the guarantee should be notified in the first instance to our Aftersales
department, contact details below, this must be done no later than the last day of the
relevant guarantee period. All claims must be accompanied by proof of purchase (sales
receipt or delivery note) from an official AXCES by VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the
original date of purchase.
VADO operates a policy of continuous product development and therefore reserves the right
to change the product, packaging and documentation specifications without notice.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO
engineer or sub-contract engineer will be under our standard terms and conditions.
[2] VADO reserves the right to charge in advance for a product (or replacement part) pending
collection and investigation (at VADO expense) to confirm a defect is due to a manufacturing
issue. If a defect is found the charge will be refunded or cancelled.
This guarantee is in addition to and does not affect your statutory rights as a consumer.
Tel: [phone]
Email: [e-mail]
