VADO Zoo Installation and operating instructions

Zoo Sense
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel [phone]. fax [phone]
[email protected]
www.vado-uk.com
Guarantee
Customer/technical services
For any technical or installation queries please contact Vado on 01934 745163.
GUARANTEE REGISTRATION
NAME
ADDRESS
RETAILER
ADDRESS
PURCHASE DATE
PRODUCT DESCRIPTION
WHO INSTALLED THE PRODUCT?
FOR VADO USE
POSTCODE
POSTCODE
ARTICLE NUMBER (SEE BOX)
RETAILER PLUMBER BUILDER SELF
This product is guaranteed against manufacturing defects from the date of purchase until the expiry of the relevant
guarantee period shown below.
The guarantee is only valid if:-
1. The product has been installed, used and maintained in accordance with Vado’s instructions and subjected to
normal use only.
2. The defect is not due to use of an unsuitable or inadequate water or power supply.
3. The defect is not due to accident, misuse, neglect or repair other than by Vado or Vado authorised agents or
damage caused by foreign objects or substances.
4. We have received from you the completed Guarantee Registration Form. Vado accepts no responsibility for any
forms lost in the post and returns by registered means is therefore recommended.
Under this guarantee (which is non-transferable) Vado will, at its option, repair or replace free of charge any product
(or replacement part) found to be defective. The guarantee does not extend to any consequential loss or damage.
After repair or replacement the relevant guarantee period will be calculated from the original date of purchase.
The relevant guarantee periods are:-
1. Twelve years on chrome nish products.
2. Three years on all other products with the exception of Stuart Turner Pumps which carry a 2 year Guarantee on
Monsoon Range and 1 Year Guarantee on Showermate Range.
All claims under the guarantee must be submitted in writing to the person who supplied the product to you and
must be received no later than the last day of the relevant guarantee period. All claims must be accompanied by
proof of purchase (sales receipt or delivery note).
Vado operates a policy of continuous product development and therefore reserves the right to change the product,
packaging and documentation specications without notice.
This guarantee is in addition to and does not aect your statutory rights as a consumer.
Mono basin mixer with
1¼” pop-up waste
Installation & maintenance instructions
Please leave these instructions with the customer
Mono bidet mixer with 1¼”
pop-up waste
NOTE: For illustrative purposes only the Mono basin mixer with pop-up waste is shown.
Please follow the same procedure to install the Mono bidet mixer.

Important - please read
General installation
27
Maintenance
ow straightener
aerator (tted)
The mixer is supplied with an aerator
tted as standard. To improve the ow
rate in low pressure conditions this
aerator can be changed for the plastic
ow straightener provided. Carefully
unscrew the mixer nozzle taking great
care not to damage the plated nish.
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and ttings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
These ttings are mixing devices and therefore water supplies must be reasonably
balanced.
Where connections are made to the mains cold water supply, WRC approved single
check valves must be tted to both hot and cold inlets. This is a stated requirement of
Water Supply (Water Fittings) Regulations 1999 Schedule 2, Section 6 G15.13.2
Before making any inlet pipe connections, all supply pipes MUST be thoroughly
ushed to remove debris. Failure to do so could result in damage or low ow from the
mixer unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 4 G13.1
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Care of the mixer
Our products are nished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the
event of a problem occurring.

Operation
6
Dimensions
3
Operating Specications
ZOO (1129.002)
Moving the mixer lever upwards/downwards will increase/decrease the ow of water.
Moving the mixer lever from right to left will increase the water temperature.
Pull the vertical control rod up to close the waste outlet and push down to open.
on = up o = down hot = left cold = right
45mm
145mm
1/2”
Mono basin mixer -
Minimum operating pressure 0.2 bar.
Maximum operating pressure 5 bar
Mono bidet mixer -
Minimum operating pressure 0.3 bar
Maximum operating pressure 5 bar
1 1/4”
300mm
138mm

Installation
4
Pop-up waste assembly and installation
5
Before installing your new mixer, ush
through the pipework to ensure removal
of debris, turn o the water supply.
Screw the two exible pipes to the mixer
body, tighten using the correct size
spanner, but do not over tighten.
Screw the threaded rod into the back
hole in the base of the mixer body.
Position the base ring onto the bottom
of the mixer body (ensure the rubber‘O’
ring is in place).
Position the mixer on the basin. From
the underside of the basin t the rubber
washer onto the threaded rod followed
by the metal washer and the nut.
Tighten the nuts to clamp the mixer to
the basin.
CAUTION: Do not over tighten the nuts
as this may damage the basin.
Connect the water supply to the
inlet pipes. The hot water should be
connected to the left hand pipe.
Base ring
Rubber washer
Metal washer
Threaded
rod
Nut
Flexible pipes
Control
handle
Aerator
Dissemble the pop-up waste and
reassemble onto the basin.
Insert the vertical control rod (with
knob) down through the hole in the
back of the mixer body.
Unscrew the ball joint retainer on the
side opening of the pop-up waste. Insert
the short end of the horizontal control
rod (with ball joint) into the waste and
clamp in position by retting the ball
joint retainer. Do not over tighten.
Slide the control rod link onto the
horizontal control rod and vertical
control rod and loosely tighten.
Test the action of the pop-up waste and
fully tighten the rod link. Adjust the ball
joint retainer as required.
Turn on the water supply and turn the
mixer on fully to ush through any
possible debris from the mixer. Finally
check all new connections for leaks.
Vertical
control
rod
Horizontal
control rod
Ball joint
retainer
Control
rod link
Seal
Plug
Plug
housing
Seal
