VADO AXCES METIZ Instruction Manual

This instruction booklet covers model:
AX-MET-149-CP
Version 1, 1-8-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail] SHOWER MIXER
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
METIZ

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General installation
Important - please read
Operating Specifications
Operating Pressure
Minimum operating pressure 1 bar
Maximum operating pressure 5 bar
This fitting is a mixing device and therefore water supplies should be reasonably
balanced.
When installed, the fitting must comply with the requirements of the Water Supply
(Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
For further information, contact the Water Regulations department of your local water
supplier (see the WRAS website www.wras.co.uk for details) or the Water Regulations
Advisory Scheme by email ([e-mail]) or telephone: [phone].
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed
to remove debris. Failure to do so could result in damage or low flow from the mixer
unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 13.
The fitting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Contents of Packaging
Valve body
Shrouds x 2
Filter/washer x 2
Offset connector x 2
FIXING KIT BOX
INSTALLATION /
USER MANUAL
SHOWER MIXER
KEEP FOR FUTURE REFERENCE
METIZ
Installation guide &
User manual

4 5
Dimensions
61mm
126mm
42mm
1/2”
100mm
150±20mm
1/2”
Installation - Quick guide
2
1
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
1
2 3
4
0 5
150mm

6 7
Installation
Before installing your new mixer, flush through the pipe work to ensure removal of
debris, turn off the water supply.
Prepare the wall with 2 flush ½” connectors at 150mm centres. Connect the water
supply to the inlet pipes. The hot water should be connected to the left hand pipe.
Using PTFE tape screw on the 2 offset connectors followed by the shroud.
Place a rubber filter/washer in each of the locking nuts on the valve and screw onto
the connectors, some adjustment can be made to the offset connectors to align the
centres and level up the valve.
Note: The valve must be connected to rigid pipe work for support.
Installation - Shower hose
Shower handset and hose (not supplied)
Place one of the rubber washers into the nut end of the hose and attach it to
the mixer outlet.
Place the second washer into the cone end of the hose and screw to the
handset.
Nut end
of hose
Rubber
washer
Shroud
Locking nuts
Rubber filter/washer
Shower hose
connection
Cold
Hot
Offset connector
Offset connector
½” connector

8 9
Operation:
Pulling the mixer lever outwards
will increase the flow of water.
Lever in the off position
Moving the mixer lever from left to right
will decrease the water temperature.
Moving the mixer lever from right to left
will increase the water temperature.
On
Off
Cold
Hot
Cleaning instructions:
Our products are finished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the event
of a problem occurring.
