For the installer
V 7-025 NW
V 7-035 NW
V 7-050 NW
Installation Manual
Heat Pump Air-conditioner - climaVAIR
Split Type
EN

2
Contents
Split Type Installation Manual
Contents
1 Your Safety
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
1.1 Symbols used
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
1.2 Correct Use of the Unit
. . . . . . . . . . . . . . . . . . . . . . .
3
2 Extreme Operating Conditions
. . . . . . . . . . . . . .
3
3 Identification of the Unit
. . . . . . . . . . . . . . . . . .
3
4 Declaration of Conformity
. . . . . . . . . . . . . . . .
4
5 Description of the Unit
. . . . . . . . . . . . . . . . . . .
4
5.1 Indoor Unit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
5.2 Outdoor Unit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
5.3
Infra
red
Controller
. . . . . . . . . . . . . . . . . . . . . . . . . .
6
5.4
Refrigeration pipe
connections
. . . . . . . . . . . . . . . .
6
5.5 Supplied accessories
. . . . . . . . . . . . . . . . . . . . . . . . .
6
5.6
Technical Specifications
. . . . . . . . . . . . . . . . . . . . . .
7
6 Transport
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
7 Unpacking
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
8 Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
8.1
Qualification of the Installation Personnel
. . . . . .
8
8.2 General precautions to be taken into account
before starting the installation
. . . . . . . . . . . . . . . .
8
8.3 General Installation Diagram
. . . . . . . . . . . . . . . . . .
9
9 Installation of the Indoor Unit
. . . . . . . . . . . . .
9
9.1 Selecting the Indoor Unit Location
. . . . . . . . . . . . .
9
9.2 Fixing the Assembly Plate
. . . . . . . . . . . . . . . . . . . .
9
9.3 Installation of the Pipe Work
. . . . . . . . . . . . . . . . .
1
0
9.3.1
Correct Removal of the Condensate Water
. . . . .
1
0
9.3.2 Handling the Refrigerant Pipes
. . . . . . . . . . . . . . .
1
0
9.3.3
Correct installation of the condensate pipe work
. .
1
1
9.3.4
Making Holes for the Pipes
. . . . . . . . . . . . . . . . . . .
1
2
9.3.5 Correct installation of the refrigerant pipe work
.
1
2
9.3.6 Installation of the Indoor Unit Body
. . . . . . . . . . . .
1
3
10 Installation of the Outdoor Unit
. . . . . . . . . . .
1
3
10.1 Selecting the Assembly Location
. . . . . . . . . . . . . .
1
3
10.2 Planning the Refrigerant Return
. . . . . . . . . . . . . .
1
4
10.3 Connection of the Refrigerant Pipe Work
. . . . . .
1
4
10.4 Connection of the Pipe for the Removal of
Condensate Water
. . . . . . . . . . . . . . . . . . . . . . . . . . .
1
5
11 Electric Wiring
. . . . . . . . . . . . . . . . . . . . . . . . . .
1
5
11.1 Safety Precautions
. . . . . . . . . . . . . . . . . . . . . . . . . . .
1
5
11.2
Remark with regard to Directive 89/336/EEC
. . . .
1
6
11.3 Electric Connection to the Indoor Unit
. . . . . . . .
1
6
11.4 Electric Connection to the Outdoor Unit
. . . . . . . .
1
7
11.5 Electrical Characteristics
. . . . . . . . . . . . . . . . . . . .
1
8
12 Preparation for Use
. . . . . . . . . . . . . . . . . . . . . .
1
9
12.1 Checking for Leaks
. . . . . . . . . . . . . . . . . . . . . . . . .
1
9
12.2 Evacuating the Installation
. . . . . . . . . . . . . . . . . . .
1
9
12.3 Start Up
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
0
12.4 Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
1
13
Error Codes
. . . . . . . . . . . . . . . . . . . . . . . . . . .
22

Split Type Installation Manual
3
EN
1 Your Safety
1.1 Symbols used
Danger!
Immediate danger to life and limb.
Danger!
Danger of electric shock.
Warning
!
Potentially dangerous situation for the product
and the environment.
Note!
Useful information and indications.
1.2 Correct Use of the Unit
This unit has been designed and manufactured for the
sole purpose of comfort cooling and heating occupied
residential and commercial premises. The use thereof
for other domestic or industrial purposes shall be the
exclusive responsibility of the persons specifying,
installing or using them in that way.
Prior to handling, installing, start up, using or
performing maintenance on the unit, the persons
assigned to perform these tasks should be familiar with
all the instructions and recommendations set forth in
the unit's installation manual.
Note!
Keep the manuals throughout the service life of
the unit.
Note!
The information relating to this unit is divided between
two manuals: installation manual and user manual.
Your Safety 1
Extreme operating conditions 2
Identification of the Unit 3
Note!
The relevant personnel performing any service of
maintenance operations involving the handling of
the refrigerant fluid must have the necessary
certification to comply with all local and
international regulations.
2 Extreme Operating Conditions
This unit has been designed to operate within the range
of temperatures indicated on Figure 2.1. Ensure that
these ranges are not exceeded.
CALEFACCIÓN
18ºC D.B.
24ºC D.B.
Fig. 2.1 Operating ranges of the unit.
Legend
D.B. Temperature measured by dry bulb
3 Identification of the Unit
This manual is valid for the Split system series. In order
to know the specific model of your unit please refer to
the unit nameplates.
The nameplates are located on the outdoor and indoor
units.
Note!
This equipment contains R-410A refrigerant. Do
not vent R-410A into atmosphere: R-410A, is a
fluorinated greenhouse gas, covered by Kyoto
Protocol, with a Global Warming Potential (GWP)
= 1975.
Note!
The refrigerant fluid contained in this
equipment must be properly recovered for
recycling, reclamation or destruction before
the final disposal of the equipment.
Indoor
Outdoor
43ºC D.B.
-10ºC D.B.
18ºC D.B.
18ºC D.B.
27ºC D.B.
24ºC D.B.
-15ºC D.B.
C
OOLING
HEATING
27ºC D.B.


Split Type Installation Manual
4
4 Declaration of Conformity
The manufacturer declares that this unit has been
designed and constructed in compliance with the
standard in force with regard to obtaining the CE
Marking.
5 Description of the Unit
This unit is comprised of the following elements:
- Indoor unit.
- Outdoor unit.
- Remote controller.
- Connections and accessories.
Figure 5.1 shows the unit components.
Fig. 5.1 Unit components.
Legend
1 Indoor Unit
2 Outdoor Unit
3 Remote controller
4 Interconnecting pipework (not supplied)
5 Condensed water drainage connection
5.1 Indoor Unit
The indoor unit heats and cools air as it circulates it
around the the room to be conditioned.
The dimensions and weights of the indoor unit are
shown on Figure 5.2 and Table 5.1, depending on the
model (please consult the model nameplate).
The dimensions are given in mm.
Fig. 5.2 Dimensions of the indoor unit.
Legend
H Height
L Length
D Depth
MODEL
H
L
D
kg
V 7-025 NHI
285
850
160
10
V 7-035 NHI
285
850
160
10
V 7-050 NHI
285
850
160
10
Table 5.1 Dimensions and weights of the indoor unit.
4 Declaration of Conformity
5 Description of the Unit

Split Type Installation Manual
5
EN
5.2 Outdoor Unit
The outdoor unit ensures that the absorbed heat is
transferred and released to the outside from the room
during operation in cooling mode and that the heat
introduced into the room during operation in heat pump
mode is absorbed from the outside air.
The dimensions and weights of the outdoor unit are
shown on Figure 5.3 and Table 5.2, depending on the
model (please consult the model nameplate).
The dimensions are given in mm.
Fig. 5.3 Dimensions of the outdoor unit.
Legend
H Height
L Length
D Depth
A Length of valves
B Distance between valves
C Distance from the highest valve to the unit base
I Distance between fixing holes
J Distance between fixing supports
MODEL
H
L
D
A
B
C
I
J
kg
V 7-025 NHO
545
780
245
45
55
80
265
500
30
V 7-035 NHO
545
780
245
45
55
80
265
500
30
V 7-050 NHO
643
783
255
48
58
70
255
500
40
Table 5.2 Dimensions and weights of the outdoor unit.
Description of the Unit 5

Split Type Installation Manual
6
5.3 Infra red Controller
The infra-red remote control controls the settings and
functions of the unit. The control will only operate when
there is a line of sight to the indoor unit.
5.4 Refrigeration pipe Connections
This outdoor unit has the following connections and shut
off valves:
- Gas (G) and liquid connections (L): they carry the
refrigerant between the outdoor and indoor unit.
- Drain connections for condensate water (in the
outdoor and indoor unit): these allow the water
(condensed in the unit during normal operation) to be
properly discharge.
- Electric connections: these allow connection of a
mains power supply to the outdoor unit and supply
electric energy and control interface to the unit.
5.5 Supplied Accessories
This unit is provided with the accessories shown on
Table 5.3.
No.
Accessory
Quantity
Indoor Unit
1
Remote control
1
2
Remote control bracket
1
3
Batteries
2
4
Mounting plate
1
5
Drain Pipe
1
Outdoor Unit
1
Rubber mounting feet
4
2
Drain elbow
1
3
Rubber Cap
2
Table 5.3 Accessories supplied with the unit.
5 Description of the Unit

Split Type Installation Manual
7
EN
5.6 Technical Specifications
Units
V 7-025 NW
V 7-035 NW
V 7-050 NW
Power supply
V/Ph/Hz
230/1/50
Cooling Capacity
kW
2,53
3,43
4,61
Power input
kW
0,74
1,07
1,53
Operating current
A
4,50
4,80
7,06
Heating Capacity
kW
3,03
3,98
5,32
Power input
kW
0,75
1,10
1,65
Operating current
A
4,50
4,70
7,70
Indoor Unit
Air Flow volume
m
3
/h
280/320/350
360/410/450
420/460/500
Sound Pressure level
dB(A)
24/30/36
26/34/38
36/41/45
Dimensions (HxLxD)
mm
285x850x160
285x850x160
285x850x160
Net Weight
kg
10
10
10
Outdoor Unit
Air Flow volume
m
3
/h
1800
2100
1800
Sound Pressure level
dB(A)
50
50
51
Refrigerant
R410A
Refrigerant charge
gr
700
1000
1350
Compressor type
Rotary
Scroll
Expansion system
Capillary
Dimensions (HxLxD)
mm
545x780x245
540x780x245
643x783x255
Net Weight
kg
30
30
40
Pipe Connections
Diameter liquid/gas pipes
Inches
1/4" - 3/8"
1/4" - 3/8"
1/4" - 1/2"
PM
bar
35
35
41,5
pm
bar
7
7
7
Max. piping length
m
15
15
15
Max. height IU under OU
m
10
10
10
Max. height OU under IU
m
10
10
10
Chargeless length
m
5
5
5
Additional charge per metre
gr
20
20
20
Table 5.4 Technical specifications.
Note!
As part of its policy for ongoing improvements of
its products, Vaillant reserves the right to modify
these specifications without prior notice.
Description of the Unit 5

Split Type Installation Manual
8
6 Transport
Danger of injury and physical damage!
During transport and unloading, the unit could
fall and injure anyone within the immediate
vicinity. To avoid this:
- Only use transport and lifting gear with
suitable load capacity for the unit weight.
- Use only the transport and lifting gear
correctly (consult the respective user
manuals).
- Use the slinging points provided for this
purpose on the unit.
- Secure the unit correctly using propriety
fixings in the mounting points provided.
- Always use suitable personal protection
equipment (helmet, gloves, safety boots and
protective glasses).
7 Unpacking
Danger of injury and physical damage!
During unpacking you could get injured. To avoid
this:
- Use lifting gear with suitable load capacity
for the unit weight.
- Only use the transport and lifting gear
correctly (consult the respective user
manuals).
- Observe correct manual handling techniques.
- Use the slinging points provided for this
purpose on the unit.
- Always use suitable personal protection
equipment (helmet, gloves, safety boots and
protective glasses).
Unpack the unit and check that:
- All parts have been supplied with the system.
- All the parts and accessories are in perfect condition.
If parts are damaged or missing please contact your
supplier immediately.
Warning
!
Protect the environment. Dispose of the
packaging following the local environmental
standards in force. Do not dispose of packaging
irresponsibly, recycle where possible.
8 Installation
8.1 Qualification of the Installation Personnel
Ensure that this unit is installed by suitable qualified
personnel.
All installers must hold a suitable safe handling of
refrigerants qualification.
8.2 General precautions to be taken into account
before starting the installation
Danger of injury and physical damage!
During unpacking you could get injured. To avoid
this:
- Only use lifting gear with suitable load
capacity for the unit weight.
- Use the transport and lifting gear correctly
(consult the respective user manuals).
- Use the slinging points provided for this
purpose on the unit.
- Always use suitable personal protection
equipment (helmet, gloves, safety boots and
protective glasses).
Danger of injury and physical damage!
The unit should be installed in accordance with
the Regulations and Standards for refrigeration,
electrical and mechanical installation pertaining
to the country in which the installation is being
undertaken.
Danger!
Danger of electric shock. All appliances must be
earthed.
Connect the earth cable to the correct earthing
point (do not connect to the gas pipe, water
pipe, lightning conductor or telephone line).
Danger!
Danger of electric shock.
Ensure the appliance is protected by a correctly
rated circuit breaker.
Warning
!
Danger of breakdowns or malfunction.
Only use the pipework specifically intended for
refrigerant R410A for the air conditioning
installation. Never use plumbing pipes.
6 Transport
7 Unpacking
8 Installation

Split Type Installation Manual
9
EN
8.3 General Installation Diagram
Warning
!
Danger of breakdowns or malfunction.
Observe the minimum clearences indicated in
Figure 8.1.
Fig. 8.1 General diagram of the installation and the minimum
assembly distances.
Legend
1 Indoor Unit
2 Outdoor Unit
3 Condensate connection for outdoor unit
A Clearance to the front of the internal unit (minimum 10 cm)
B Clearance to ceiling above (minimum 5 cm)
D Height in relation to the floor (minimum 2 m)
E Side clearance opposite side connections (minimum 20 cm)
F Rear clearance (minimum 20 cm)
G Side clearance connections side (minimum 30 cm)
H Front clearance (minimum 100 cm)
9 Installation of the Indoor Unit
9.1 Selecting the Indoor Unit Location
Warning
!
Danger of breakdowns or malfunction.
Observe the minimum clearances indicated in
Figure 8.1.
Note!
If a hole already exists in the wall or a refrigerant
pipe or condensed water pipe has already been
installed, the base plate should be mounted to
suit these conditions.
Recommendations
- Install the indoor unit close to the ceiling,ensuring
minimum clearances are met.
- Choose a position that will allow air to reach all parts
of the room evenly. Avoid beams, obstructions or
lights which would interfere with the airflow.
- Install the indoor unit at an adequate distance from
chairs or workstations in order to avoid unpleasant
draughts.
- Avoid installing close to heat sources.
9.2 Fixing the Mounting Plate
Carry out the steps described below:
• Place the mounting plate on the chosen installation
point.
• Level the plate horizontally and mark the position of
holes to be made on the wall.
• Remove the plate.
Warning
!
Danger of interference in the domestic installation.
Check that there are no electricity lines, pipes or
any other services which could be damaged
behind the spots where the holes are to be
drilled.
If other services are found, choose another
installation location and repeat the
aforementioned steps.
• Make the holes using a drill and insert the wall plugs .
• Place the mounting plate in position, level it
horizontally and fix it with the screws and the plugs.
Warning
!
Danger of breakdowns or malfunction.
Ensure that the mounting plate has been
correctly levelled. Otherwise, remove the plate
and re-fix it again correctly. Failure to do so
could lead to water leaks.
Installation 8
Installation of the indoor unit 9
