VALCOBABY ION Installation and operation manual

Thank you for purchasing a quality Valco Baby product. Please read and follow the instructions outlined in this
guide carefully. Familiarise yourself with the construction and safety features; be sure that you understand all
the warnings and safety guidelines before use.
Retain this guide in a safe place for future reference.
PRODUCT REFERENCE GUIDE
© Copyright VE 2009
Due to our policy of continuous product development, this product is
constantly evolving. It is possible that some features or procedures outlined
here have changed since this document was written.
If you are unsure of any procedure shown here, please contact us via the web
at [email protected] to obtain the most up to date information before use.
Include the batch number, which can be found on a sticker on the frame.
All pictures and diagrams herein are provided for illustration purposes only.
Actual product, colour or fabric may vary. Valco Baby reserves the right to
modify or alter any specication or colour without notice or obligation to
modify any product previously purchased
FURTHER INFORMATION
In Australia/New Zealand
www.valco.com.au
In North America only
www.valcobaby.com
1800 610 7850
NEWBORN
BASSINET
ION AND ION FOR 2

NEWBORN BASSINET
BASSINET ASSEMBLY
FIGURE A
1. Remove the Bassinet from the packaging and
dispose of all packaging thoughtfully.
2. Unsnap seat fabric from sides of stroller. Remove
the bumper bar from your stroller and store.
3. Recline the seat fully. HINT: Raise the footrest to a
horizontal position to help support baby’s head in the
bassinet.
PLEASE NOTE THAT THE HOOD OF YOUR BASSINET IS
ATTACHED TO THE BASSINET BODY AND
CANNOT BE REMOVED.
FIGURE B
4. Unfold the mattress base of the bassinet fully.
Slide bassinet into the seat area of the stroller.
Make sure that the long security straps remain
inside the bassinet.
FIGURE C
5. Align the plastic housings of the bassinet with the
housing on the sides of the stroller chassis.
6. Slide the bassinet into the housing along the
housing tracks until it locks into place.
FIGURE D
7. Pull the sides of the seat fabric over the bassinet
side bars and snap into position.
8. To remove the bassinet, Unsnap seat fabric from
sides of bassinet.
9. Lift both bumper bar latches found on the
underside of each side of the housing, while
simultaneously lifting the bassinet and slide it
free.
A
B
C
D

E
F
G
H
FIGURE E
10. Pass the security straps over either side of the
bassinet and under the front of the stroller frame.
11. Buckle the security straps together and tighten
with the adjustable slider.
IMPORTANT WARNING: ALWAYS TEST THAT ALL LATCHES
ARE SECURELY ENGAGED BEFORE USE.
FIGURE F -
12. The bassinet comes with an extendable hood. To
close the hood push the hood forward completely
and lock into position with the hood locks found
on either side of the hood.
FIGURE G
The bassinet can be folded with stroller.
13. Fold the mattress in as indicated on Figure G.
14. Incline the seat.
15. Close the hood on the stroller and on the
bassinet.
FIGURE
16. To fold your stroller, turn the release key
clockwise and push the handle forward releasing
the stroller frame slightly.
17. Lift the secondary locking latch clear of the
plastic frame catch. This latch is spring loaded
and you may need to hold it open as you push the
handle forward.
18. Push the handle forward.
19. Continue to fold the frame forward until you
create the smallest fold possible.
IMPORTANT WARNING: ALWAYS TEST THAT ALL LATCHES
ARE SECURELY ENGAGED BEFORE USE.
Fold
mattress
flat

WARNING
• Follow the manufacturer’s instructions.
• Put on all the brakes whenever you park the pram/stroller.
• Do not leave children unattended
• Do not carry extra children or bags on this pram/stroller.
• Make sure children are clear of any moving parts if you adjust the pram/stroller. Otherwise they may be injured.
Remember: Your child’s safety is your responsibility
• Never use on stairs or on an escalator.
• The correct use and maintenance of this vehicle are essential
• When in the stroller a child must always wear a safety harness, correctly tted and adjusted, at all times.
• Always use the tether strap when the stroller is in use.
• Check all parts before use for breakage or fatigue. Discontinue use immediately if any part is found to be damaged or broken.
• Should the chassis become wet, dry off promptly before storing. If the pram is used near the ocean or salted roads, spray the
chassis & seat with water & dry. We recommend a rust inhibiting product should be used to prevent rust and fatigue on metal
parts.
• Maximum load of baskets: 3.5kgs.
• Always be aware of the risks provided by re and other signicant sources of heat such as radiators, etc. which may be in the
immediate vicinity of your stroller.
• It may be unsafe to use any accessories other than Valco approved ones.
• Be sure that all clamps and buckles are securely xed and in place before use.
• Can be used from a newborn baby onwards. A bassinet or cocoon, specially designed to be used with a stroller, is
recommended when any fully reclining stroller is used with a newborn.
• Always hold the bassinet in such a way that you keep the bassinet balanced and the bassinet with the child remains in the
horizontal position.
• The bassinet is only suitable for a child that cannot sit up on its own or roll onto its side and cannot support itself on its hands
and knees.
• Only place the bassinet down on a rm, horizontal and dry surface.
• Do not allow other children to play near the bassinet unattended
• Do not use the bassinet or the stroller if any parts are broken, torn or missing
• The maximum weight of a child for which this stroller was intended is 20 kgs.
• Never run with a newborn baby in any pram or stroller until the child can sit up unassisted (approximately 6 months).
• This product is intended for domestic use only. It is not intended for commercial use.
AVOID SUFFOCATION HAZARDS:
• Unlike cribs that have rigid sides, the bassinet mattress is specially designed to prevent suffocation. The mattress is designed
to be a snug t and should not exceed 30mm in thickness. Using a thicker or different sized mattress may allow a child’s
head to bet between the mattress and the side of the bassinet causing suffocation. To help prevent suffocation from
entrapment, USE ONLY THE MATTRESS PROVIDED.
• NEVER use additional mattress or padding. Use only the mattress provided.
CARE & MAINTENANCE
• Continued and extended exposure to sunlight and the elements can change the colours of many materials. To avoid fading,
always cover and store in a shaded area.
• DO NOT use any bleach based products to clean the stroller and bassinet.
• The Stroller and Bassinet can be cleaned using a damp sponge and mild detergent.
• The mattress sheet and the inner lining are both removable and may be gentle machine washed. Line dry only.
• To prevent mould or mildew always allow fabrics to dry COMPLETELY before storing. Always store in a well ventilated area.
• Should the chassis become wet, dry off promptly before storing. If this pram is used near the ocean or salted roads, spray
the chassis and seat frame with water and dry. We recommend a rust inhibiting product should be used to prevent rust and
fatigue on metal parts.
• We recommend that you wipe down axles and lubricate the wheels every 3 months. Sand and dirt can grind down axles, if you
live near the beach or in a dusty environment you must wipe down the axles and wheels then lubricate them monthly.
AXLES ARE BEST LUBRICATED WITH GREASE OR PETROLEUM JELLY. MOVING PARTS ARE BEST LUBRICATED WITH SILICONE
BASED PRODUCTS. DO NOT USE OIL BASED PRODUCTS.
