Valcom IP Solutions VIP-802 User manual

1 947987
ISSUE 1
VIP-802
DUAL NETWORKED PAGE ZONE EXTENDER
INTRODUCTION
The VIP-802 Dual Networked Page Zone Extender
enables voice access to two zones of one-way
paging over an IP-based LAN/WAN. This allows
page zone extension anywhere on the network.
SPECIFICATIONS
Features
•2 Audio Outputs
•2 Audio Inputs
•2 Form A relay contacts
•2 Contact Closure Inputs
•RJ-45 for network connection
•Front panel activity LED
•Provides audio for up to 150 Valcom one-way
amplified speaker assemblies
•AUX audio input via RCA jack
•Contact closure or VOX operation of audio
input
•Removable screw terminal connectors
provided for audio and relay interface
•Page with music output, music mutes during
page
•Output control contact closure provided
during paging output
•Compatible with 25 or 70 Volt amplifiers
•2.5mm jack for DC power
•Power over Ethernet 802.3af Compliant
Dimensions/Weight
•1.75 H x 6.75" W x 9.5" D
(4.45cm H x 17.15cm W x 24.13cm D)
•Weight: 1.75 lbs. (0.80 kg)
Nominal Specifications
Input Impedance: 600 Ohms
Input Level: -10dBm nominal
Voice Switch Sensitivity: -21dBm
Music Source Input Impedance: 8 to 600 Ohms
Music Input Level: -10dBm nominal
Output Impedance: 50 Ohms
Output Level: - 10dBm nominal
Relay Current: 1 AMP @ 24VDC
Nominal Power Requirements
Via back panel barrel connector:
Voltage: 24VDC
Current: 325mA
Via 802.3af PoE Ethernet Switch:
802.3af: Class 3
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Packing List
Qty Item
1 VIP-802
1 VIP-101 Setup CD
1 VSP Document
2 Mounting Brackets
4 Rubber Feet
6 Wood Screws
3 RJ-45 Patch Cables
2 RJ-45 Terminal Blocks

2 947987
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
INSTALLATION
NOTE: The telephone system referred to in this
manual is the customer premise equipment
such as an electronic key system, a PBX or a
dedicated single line telephone sets. The
VIP-802 is not intended for direct or indirect
connection to the public telephone network.
When used with a customer premise telephone
system such as a key system or PBX system,
these units are interfaced to the system via a
fully protected page port or system central
office port, which is a fully protected interface
device. Also, the host system must be
configured to disallow central office trunk
conferencing in order to prevent indirect
connection to the public network.
Precautionary Designations
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses and can radiate radio
frequency energy and if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment
in a residential area may cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
Mounting
The VIP-802 is designed for wall, table or rack
mounting.
Table: Provided with the VIP-802 are four rubber
stick on feet. Peel these feet off their carrier
backing and place at the four corners of the bottom
of the unit.
Wall: Using the template and instructions provided,
secure the VIP-802 to the wall.
Rack: Following the assembly drawing, attach the
two mounting ears to the VIP-802 unit. Using rack
screws, mount the VIP-802 in an available 1U rack
slot.
Power Connections
The preferred method of powering a VIP-802 is via
a power over Ethernet switch meeting the 802.3af
specification. The Valcom VIP-908 Ethernet switch
which is ideal for this purpose and will power up to
7 VIP-800 series devices.
If the rear panel barrel connector is used for power,
the preferred power supply is a Valcom VIP-324.
Make all required signal connections before
applying power to the unit. If powering via 802.3af,
make sure all signal connections via the back
panel are made then connect the VIP-802 to the
Ethernet switch.
If power is supplied via the barrel connector, make
sure all signal connections are secure. Attach the
unit to the network via the front panel RJ-45
Ethernet connector. Apply power by plugging the
power supply into the VIP-802 via the barrel
connector on the rear of the VIP-802.
Network Connection
The VIP-802 has one CAT-5 RJ-45 network
connector on the front panel.
Use one of he supplied CAT-5 patch cables to
connect the VIP-802 to an Ethernet switch. If the
Ethernet switch is 802.3af compliant the VIP-802
will draw power from it.

3 947987
Signal Connections
The VIP-802 has 3 signal connectors on the rear
panel.
•1 RCA jack for AUX audio input
•2 RJ-45 connectors for audio and relay
connections for each networked channel
AUX Input: Local audio input is via the rear panel
RCA jack. Nominal input impedance is 600 Ohms.
Connect any compatible audio source using an
RCA patch cable.
VIP-802 Front Panel
VIP-802 Rear Panel
Networked Channels: Access to the networked
audio is via two rear panel RJ-45 connectors.
These connectors may be wired using standard
RJ-45 terminations. Provided with the VIP-802 are
two 3 foot RJ-45 patch cables and two RJ-45
“Biscuit Block” style connectors. You may easily
connect to the signals by plugging one end of a
patch cable to the VIP-802 and the other in to a
“Biscuit Block” connector. Access to the signals is
via screw terminal under the block cover. Signals
are present on pairs of pins.
Pins Wire Color Signal
1,2 Blue & Orange Audio Input
7,8 Brown & Grey Audio Output
3,6 Black & Yellow Contact Closure Input
4,5 Red & Green N.O. Relay Closure Output
Status Indicator Lights
The VIP-802 has 3 status indication lights on the
front panel.
STATUS: Flashes then illuminates to indicate
power.
LINK: Indicates 100 Mbit Ethernet connection
when illuminated. No activity indicates 10 Mbit
connection.
ACT: Indicator flashes to indicate network activity.
TECHNICAL ASSISTANCE
When trouble is reported, verify power is being
supplied to the unit and there are no broken
connections. Check voltages for proper polarity to
the one-way amplified speakers. If a spare unit is
available, substitute a spare unit for the suspected
defective unit.
Assistance in troubleshooting is available from the
factory. Call [phone] and press 1 for
Technical Support or via email at
[email protected].
When requesting assistance, you should include
all available information. It is strongly suggested
that you go to the website and follow the trouble
resolution procedure at http://voip.valcom.com.
Valcom equipment is not field repairable. Valcom,
Inc. maintains service facilities in Roanoke, VA.
Should repairs be necessary, attach a tag to the
unit clearly stating your company name, address,
phone number, contact person and the nature of
the problem. Send the unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
VALCOM LIMITED WARRANTY
Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service for a
period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or refund of any
such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (a service charge plus
parts and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Valcom are prepaid;
5. all units ‘out of warranty’ are subject to a service charge. The service charge will cover minor repairs (major repairs will be subject to
additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Valcom, Inc. be liable for any
anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the purchase, operation or
use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the carrier should
be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the F.O.B. point.
