Valley Classic User manual

Valley Classic
Control Panel
Owner's Manual
0997335_H
© 2019 Valmont Industries, Inc., Valley, NE 68064 USA. All rights reserved.
www.valleyirrigation.com

Valley Classic Control Panel
2

Valley Classic Control Panel
Table of Contents
3
Valley Classic Control Panel Owner's Manual ............................................................................................... 1
Table of Contents ............................................................................................................................................. 3
EC Declaration of Conformity.......................................................................................................................... 5
Electrical Safety Statement ............................................................................................................................. 6
About This Manual ........................................................................................................................................... 6
Ancillary Equipment Warranty ........................................................................................................................ 6
Safety................................................................................................................................................................. 7
Recognize Safety Information ............................................................................................................................ 7
Safety Messages........................................................................................................................................... 7
Information Messages ................................................................................................................................... 7
Use Of Personal Protective Equipment .............................................................................................................. 8
Conductive Materials And Equipment ................................................................................................................ 8
Fall Protection..................................................................................................................................................... 8
Minimum Working Clearance.............................................................................................................................. 9
Qualified Person ................................................................................................................................................. 9
Irrigation Equipment near Airports and Crop Dusting Aircraft ............................................................................ 9
Overhead Power Lines ..................................................................................................................................... 10
Minimal Lockout / Tagout Procedure................................................................................................................. 11
Sequence of Lockout................................................................................................................................... 11
Restoring Equipment to Service.................................................................................................................. 11
Operate Safely.................................................................................................................................................. 12
Safety Decals ................................................................................................................................................... 16
Overview.......................................................................................................................................................... 19
Controls and Components................................................................................................................................ 19
Main Disconnect Switch ................................................................................................................................... 20
Three Second Auto Restart.............................................................................................................................. 20
Start-Stop / Safety Override Switch.................................................................................................................. 21
Safety Return Light........................................................................................................................................... 21
Forward / Reverse Switch................................................................................................................................. 22
Without AR/AS Option................................................................................................................................. 22
With AR/AS Option* .................................................................................................................................... 22
Wet / Dry Switch............................................................................................................................................... 23
Auto Reverse / Auto Stop Switch* .................................................................................................................... 23
Stop-In-Slot (SIS) On / Off Switch .................................................................................................................... 24
Engine Run / Start Switch ................................................................................................................................ 24
Auxiliary On / Off Switch (Option)..................................................................................................................... 24
Volt Meter ......................................................................................................................................................... 25
Percent Timer ................................................................................................................................................... 26
Hour Meter........................................................................................................................................................ 26
Circuit Breaker.................................................................................................................................................. 26
Operation......................................................................................................................................................... 27
Starting The Machine Wet (With Water) ........................................................................................................... 27
Starting The Machine Dry (Without Water)....................................................................................................... 28
Stopping The Machine...................................................................................................................................... 29
Emergency Stopping ................................................................................................................................... 29
Stopping Under Normal Conditions............................................................................................................. 29
Percent Timer ................................................................................................................................................... 30
Testing the Percent Timer ................................................................................................................................. 31
Percent Timer Setting Calculations................................................................................................................... 32
Percent Timer Setting Calculation Worksheet .................................................................................................. 34
Appendix ......................................................................................................................................................... 36
Tire Pressure.................................................................................................................................................... 36
Replacing Tires................................................................................................................................................. 36

Valley Classic Control Panel
Table of Contents
4

Valley Classic Control Panel
EC Declaration of Conformity
5
EC Declaration of Conformity
We: Valmont Industries, Inc.
28800 Ida Street
Valley, NE 68064
+1 402.359.6312
+1 402.359.6143 (Facsimile)
declare under our sole responsibility that the product,
Crop Irrigation System
to which this documentation relates, is in conformity with the following documents:
Machinery Directive 2006/42/EC
Low Voltage Directive 2014/35/EU
Electromagnetic Compatibility Directive 2014/30/EU
The above-referenced equipment is in conformity with all safety-related clauses (Not all clauses reflecting com-
mercial preference are met) of the following documents:
EN 60204-1:2006 Safety of Machinery – Electrical Equipment of Machines
EN 12100:2010 Safety of Machinery
EN 909:1998+A1 Irrigation Machines
Statement regarding Pressure Equipment Directive 97/23/EC:
The Crop Irrigation System is excluded from the scope of the Pressure Equipment Directive, by the
language of Article 1, Sections 3.2, 3.6 & 3.10. This equipment is classified less than Category 1.
Statement regarding RoHS Directive 2011/65/EC:
The Crop Irrigation System is excluded from the scope of the RoHS Directive, by the language of Article
2, Section 4(e), being a “Large Scale Fixed Installation.”
Person Authorized to Compile the Technical File in Europe: Ruediger Claas
Relevant information will be transmitted via email Valmont Industries Inc.
in response to a reasoned request by national authorities Nordring 4
45894 Gelsenkirchen
Germany
[phone]
Ron Pollak Date of Issue: December 17, 2018
Senior Electrical Engineer Place of Issue: Valley, NE 68064
Valmont Industries, Inc.
Serial Number:
Purchase Order:

Valley Classic Control Panel
Electrical Safety Statement
6
Installation Of The Valley Electric Irrigation Machine
Valmont Industries Inc. does not install a differential (ground fault) circuit breaker in the control panel of the
Valley electric irrigation machine because the standards of protection vary according to country of destination.
The distributor must provide and install a differential (ground fault) circuit breaker that meets the standards of
the country where the Valley irrigation machine is installed.
In the European Union, differential circuit breaker protection is fixed at a maximum of 24 volts.
Good grounding of the Valley irrigation machine is required.
• If resistance to ground is lower than 80 ohms, a differential (ground fault) circuit breaker of 300 mA will meet
requirements.
• If resistance to ground is between 80 and 800 ohms, a differential (ground fault) circuit breaker of 30 mA will
meet requirements.
The power supply installation and inspection of equipment protection components or machines are the re-
sponsibility of the installer. Valmont Industries Inc. is not responsible for the failure of equipment protection
components or machines not of their manufacture.
Valley pivot irrigation machines receiving power from a generator must have a cable connected from the irriga-
tion machine structure to a ground rod and another cable from the irrigation machine structure to the ground
terminal on generator in order for the differential (ground fault) circuit breaker to work.
• The resistance between the irrigation machine and the generator must be substantially below 80 ohms.
About This Manual
This manual only covers the operation of the Valley Classic Control Panel. Sections related to safety, pivot
hardware, maintenance, towing, troubleshooting and winterization are covered in the appropriate Valley Pivot
Owners Manual.
You, as the owner/operator, should familiarize yourself with the capabilities of the system in order to obtain opti-
mum system performance. It should be remembered that the sprinkler will perform according to your knowledge
of the equipment, soil and water relationships and equipment application concepts.
Specifications, descriptions and illustrative material contained herein were as accurate as known at the time this
publication was approved for printing.
Valmont Industries Inc., reserves the right to change specification or design without incurring obligation. Speci-
fications are applicable to machines sold in the United States and may vary outside the United States.
Ancillary Equipment Warranty
The owner is responsible for warranty registration of all ancillary equipment such as engines, pumps, and
generators with its respective manufacturer.

Safety
Valley Classic Control Panel
7
Recognize Safety Information
This irrigation equipment may be powered by high voltage which can be extremely dangerous if used improp-
erly. For maximum safety and optimum performance of the machine, all owner’s operator’s and maintenance
personnel must read and understand the owner/operator manual(s), all safety messages in this manual and
safety signs/decals on the machine before operating this equipment.
Anyone assembling, operating, servicing or maintaining this machine must read and understand all opera-
tion, maintenance, troubleshooting, testing, installation, assembly instructions and all safety messages in this
manual before operating the machine or beginning any maintenance, troubleshooting, testing, installation or
assembly of components.
These instructions alert you to certain things you should do carefully; if you don’t, you could hurt yourself or
others, hurt the next person who operates the equipment, or damage the equipment.
Safety Messages
Safety messages in this manual are preceded by the hazard symbol and one of three words, danger, warning
or caution. These messages alert you to potential hazards that could hurt you or others and or cause property
damage.
!This HAZARD SYMBOL is used to alert you to information about unsafe actions or situations, and may
be followed by the word danger, warning, or caution.
!DANGER
The HAZARD SYMBOL used with the word DANGER, will describe immediate hazards that may result in
severe personal injury or death.
!WARNING
The HAZARD SYMBOL used with the word WARNING, will describe unsafe actions or situations that may
cause severe injury, death and/or major equipment or property damage.
!CAUTION
The HAZARD SYMBOL used with the word CAUTION, will describe unsafe actions or situations that may cause
injury, and/or minor equipment or property damage.
Information Messages
Important information messages in this manual are preceded by the word NOTE.
NOTE
•The word NOTE is used to alert you to information that describes procedures or tips to help you
install, operate or maintain your equipment properly.

Safety
Valley Classic Control Panel
8
Use Of Personal Protective Equipment
• People working in areas where there are potential electrical hazards must use, personal protective equipment
that is appropriate for the specific parts of the body to be protected and for the work to be performed. Refer to
U.S. Occupational Safety & Health Administration (OSHA) Regulations (Standards - 29 CFR) Safeguards for
personnel protection. - 1910.335, or applicable national, state or local regulations, for additional information.
• Personal protective equipment must be maintained in a safe, reliable condition and periodically inspected or
tested.
• Protective shields, protective barriers, or insulating materials must be used to protect each person from
shock, burns, or other electrically related injuries while that person is working near exposed energized parts
which might be accidentally contacted or where dangerous electric heating or arcing might occur. When nor-
mally enclosed live parts are exposed for maintenance or repair, they must be guarded to protect unqualified
persons from contact with the live parts.
• Safety signs and tags. Safety signs, safety symbols, or accident prevention tags must be used where neces-
sary to warn people about electrical hazards which may endanger them.
Conductive Materials And Equipment
Materials and equipment that may conduct electricity must be handled in a way that will prevent them from
contacting energized power lines, exposed conductors or circuit parts.
• When handling long conductive objects (such as but not limited to truss rods, pipes, angles and ladders) in
areas with energized power lines, exposed conductors or circuit parts, work practices (such as the use of
insulation, guarding, and material handling techniques) must be used to minimize the hazard.
• Portable ladders must have non-conductive side rails.
• Do not wear conductive articles of jewelry and clothing (such as but not limited to watch bands, bracelets,
rings, key chains, necklaces, metalized aprons, cloth with conductive thread, or metal headgear) that could
come in contact with energized power lines, exposed conductors or circuit parts.
Fall Protection
Identify potential fall hazards and determine if fall protection equipment is appropriate for the task, before begin-
ning the work. Pay attention to hazards associated with routine and non-routine tasks. Inspect fall protection
equipment (harnesses, lanyards) and devices (guardrails, tie-off points) before each use. Use fall protection
equipment if required for the job. Be sure the fall protection equipment is right for the task, fits properly, and is in
good condition. Refer to U.S. Occupational Safety & Health Administration (OSHA) Regulations Standards - 29
CFR 1926.500, 1926.501 and 1926.502, or applicable national, state or local regulations for more information.
• When using scaffolds, make sure there is proper access, full planking, stable footing, and guard railing.
• When using a boom lift, keep feet firmly on the platform of a boom lift, use fall protection equipment tied-off
at all times to the guardrail or tie-off point.
• When using a ladder, make sure the ladder is non-conductive and the correct size for the task. Read the
ladder user instructions and be sure the ladder is in good condition. Make sure ladder is set on stable footing
and at the correct angle.

Safety
Valley Classic Control Panel
9
Minimum Working Clearance
To reduce the risk of injury, all persons require adequate working clearance around the electrical panel or other
electrical equipment. The table below identifies the minimum working clearance needed. Refer to U.S. Occupa-
tional Safety & Health Administration (OSHA) Regulations (Standards - 29 CFR) Safeguards for personnel pro-
tection. -1910.303(g)(1)(i), or any other applicable national, state or local regulations, for additional information.
MINIMUM WORKING CLEARANCE 0-600 VOLTS
WIDTH
OF WORKING
CLEARANCE
AREA
HEIGHT
OF WORKING
CLEARANCE
AREA
MINIMUM WORKING CLEARANCE
IN FRONT OF ELECTRICAL PANEL/EQUIPMENT
EXPOSED LIVE PARTS
ON ONE SIDE OF WORK
SPACE AND NO LIVE
GROUNDED PARTS ON
THE OTHER SIDE.
EXPOSED LIVE PARTS
ON ONE SIDE OF WORK
SPACE AND LIVE
GROUNDED PARTS ON
THE OTHER SIDE.
EXPOSED LIVE PARTS
ON ONE SIDE OF WORK
SPACE AND EXPOSED
LIVE PARTS ON THE
OTHER SIDE.
30 in (760 mm)
MINIMUM OR
WIDTH OF
ENCLOSURE,
WHICH EVER IS
GREATER
78 in (1980 mm)
MINIMUM OR
HEIGHT OF
ENCLOSURE,
WHICH EVER IS
GREATER
36 in (915 mm) MINIMUM 42 in (1065 mm) MINIMUM 48 in (1220 mm) MINIMUM
Concrete, brick or tile walls shall be considered as grounded.
Qualified Person
A Qualified Person is one who, by possession of a recognized degree, certificate, or professional standing, or
who by extensive knowledge, training, and experience, has successfully demonstrated his/her ability to solve or
resolve problems related to the subject matter, the work, or the project.
Only qualified persons may work on electric circuit parts or equipment that have not been de-energized.
Refer to U.S. Occupational Safety & Health Administration (OSHA) Regulations Standards - 29 CFR 1926.32(m)
and 1910.333, or applicable national, state or local regulations for additional information.
Irrigation Equipment near Airports and Crop Dusting Aircraft
• If any part of the irrigation machine comes within 3200 ft (975 m) of an airport runway, especially the ap-
proach (ends) of the runway, additional warning markers may be required. In the United States, CFR Title 14,
Chapter I, Subchapter E, Part 77 – Safe, Efficient Use, and Preservation of the Navigable Airspace describes
when marking is needed.
This document is available at: www.ecfr.gov
• Marking requirements vary depending on the location of the irrigation equipment relative to the runway, the
type of airport (Civil, Military, or Heliport) and other factors. Contact the local airport authority for guidance
and specific recommendations. In the United States, guidelines for marking structures near airports are
published by the Federal Aviation Administration in Advisory Circular AC 70/7460-1L – Obstruction Marking
and Lighting.
Available here: www.faa.gov/regulations_policies/advisory_circulars
• For irrigation machines near private or unregulated airfields, including farm-based airstrips, Valley strongly
recommends complying with the same standards and requirements as Civil airports as shown in Part 77.
• Regulations vary by country, contact your local aviation authority for guidance.
Overhang cables, including overhang back cables are a particular danger. In locations where low-flying
aircraft are likely, such as within 1,500 ft (457 m) of an end of an airport runway, or where crop dusting aircraft
are common, Valley recommends adding obstruction markers to overhang cables to improve their visibility.
For large overhangs (36 ft / 10.97 m Heavy Duty and longer), five 12 in (300 mm) or 20 in (500 mm), aviation
orange marker balls are sufficient. One near the rabbit ears, two in the middle of the back cables and two in
the middle of the highest overhang cables. Refer to Section 3.5 in AC70/7460-1 for additional details. Aviation
marker balls are available online and from a variety of aviation and airport safety equipment providers.

Safety
Valley Classic Control Panel
10
Overhead Power Lines
Assembling, towing or transporting irrigation machine components such as but not limited to the pivot point,
linear cart, span/drive unit assemblies, overhangs and/or corner assemblies underneath or near power lines is
extremely dangerous because of the risk of electrocution.
Operating equipment that elevates irrigation machine components, such as but not limited to an aerial lift or
crane, near power lines is extremely dangerous because of the risk of electrocution. Only qualified personnel
should operate this type of equipment. Before operating the equipment, qualified personnel must read the
equipment manufacturers’ operating and safety instructions.
Refer to U.S. Occupational Safety & Health Administration (OSHA) Regulations (Standards - 29 CFR) Cranes
and derricks. - 1926.550, or any other applicable national, state or local regulations for additional information.
• Always presume that any overhead power line is an energized line unless and until the person(s) owning
the line and/or the electrical utility authorities indicate that it is not an energized line and it has been visibly
grounded.
• Before operating any equipment near any power line make sure the line has been de-energized and visibly
grounded at the point of work.
• Electrocution can occur without touching an electrical power line. Electricity, depending on the magnitude,
can jump or become induced into equipment or conductive materials that come in close proximity to, but do
not touch a power line. High wind, lightening, wet ground and other environmental conditions will increase
the possibility of electrocution and require additional consideration.
• Transmitter towers can induce the equipment or materials being handled with an electrical charge. Before
working or operating equipment near transmitter towers make sure the transmitter is de-energized.
• Select the location where the span/drive unit will be assembled to ensure that neither the irrigation machine,
or the equipment used during the assembly process, will violate the minimum clearance guidelines.
• Never operate equipment or allow the load, ropes or tag lines within 10 ft (3.05 m) of any power line rated 50
kV or lower whether it is energized or not. For lines rated over 50 kV, the minimum clearance shall be 10 ft
(3.05 m) plus 0.4 in (1.1 cm) for each kV over 50 kVs.
• Never assemble, tow, transport or allow irrigation machine components underneath or within 10 ft (3.05 m)
of any power line rated 50 kV or lower whether it is energized or not. For lines rated over 50 kV, the minimum
clearance shall be 10 ft (3.05 m) plus 0.4 in (1.1 cm) for each kV over 50 kVs. Overhang support angles,
cables and spinner drive components regularly extend 10 ft to 12 ft (3.1 m to 3.7 m) above the irrigation
pipeline (span).
• Use barricades to identify areas where interference with overhead power lines could occur. Keep the assem-
bly, towing or transporting of irrigation machine components and the operation of equipment including load,
ropes or tag lines away from any power line, in the distances described above, whether the line is energized
or not.
• Always designate a person to observe clearance between the power line and all equipment being operated
or moved in order to give timely warning for all operations to STOP if the minimum clearance is violated.

Safety
Valley Classic Control Panel
11
Minimal Lockout / Tagout Procedure
The following procedure establishes the minimum requirements for the lockout of energy isolating devices
whenever maintenance or servicing is done on machines or equipment. It is used to ensure that the machine
or equipment is stopped, isolated from all potentially hazardous energy sources and locked out before person-
nel perform any servicing or maintenance where the unexpectedly energized or start-up of the machine or
equipment or release of stored energy could cause injury. All personnel, upon observing a machine or piece of
equipment which is locked out to perform servicing or maintenance shall not attempt to start, energize, or use
that machine or equipment.
When the energy isolating devices are not lockable, tagout should be used and affected personnel must wear
full personal protection.
Refer to U.S. Occupational Safety & Health Administration (OSHA) Regulations (Standards - 29 CFR) Typical
minimal lockout procedures - 1910.147 App A, or applicable national, state or local regulations, for additional
information.
Sequence of Lockout
1. Notify all affected personnel that servicing or maintenance is required on a machine or equipment and that
the machine or equipment must be shut down and locked out to perform the servicing or maintenance.
2. The authorized personnel shall identify the type and magnitude of the energy that the machine or equip-
ment utilizes, shall understand the hazards of the energy, and shall know the methods to control the energy.
3. If the machine or equipment is operating, shut it down by the normal stopping procedure (depress the stop
button, open switch, close valve, etc.).
4. De-activate the energy isolating device(s) so that the machine or equipment is isolated from the energy
source(s).
5. Lock out the energy isolating device(s) with assigned individual lock(s).
6. Stored or residual energy (such as that in capacitors, springs, elevated machine members, rotating fly-
wheels, hydraulic systems, and air, gas, steam, or water pressure, etc.) must be dissipated or restrained by
methods such as grounding, repositioning, blocking, bleeding down, etc.
7. Ensure that the equipment is disconnected from the energy source(s) by first checking that no personnel
are exposed, then verify the isolation of the equipment by operating the push button or other normal operat-
ing control(s) or by testing to make certain the equipment will not operate.
!CAUTION
•RETURN OPERATING CONTROL(S) TO NEUTRAL OR “OFF” POSITION AFTER VERIFYING THE
ISOLATION OF THE EQUIPMENT.
8. The machine or equipment is now locked out.
!DANGER
•WHEN PERSONNEL WILL BE EXPOSED TO CIRCUIT ELEMENTS AND ELECTRICAL PARTS, A
QUALIFIED PERSON MUST USE TEST EQUIPMENT TO VERIFY THAT THE CIRCUIT ELEMENTS
AND EQUIPMENT PARTS OF THE EQUIPMENT ARE DE-ENERGIZED.
Restoring Equipment to Service
When the servicing or maintenance is completed and the machine or equipment is ready to return to normal
operating condition, the following steps shall be taken.
1. Check the machine or equipment and the immediate area around the machine to ensure that nonessential
items have been removed and that the machine or equipment components are operationally intact.
2. Check the work area to ensure that all personnel have been safely positioned or removed from the area.
3. Verify that the controls are in neutral.
4. Remove the lockout devices and reenergize the machine or equipment.
5. Notify affected personnel that the servicing or maintenance is completed and the machine or equipment is
ready to be used.

Valley Classic Control Panel
Safety
12
Operate Safely
Valley Irrigation Machines are designed with safety in mind. However, if this machine is operated incorrectly, it
may pose a safety threat to the operator. A good safety program is much like a chain, it is only as strong as its
weakest link. The manufacturer, dealer, and operator must maintain and improve all safety programs. Following
is a list of safety operating tips which you and all other persons servicing or operating the machine must read
and understand.
!CAUTION
•DO NOT OPERATE THIS MACHINE WITHOUT
FIRST READING THE OWNER’S MANUALS FOR
THE MACHINE.
•READ ALL SAFETY MESSAGES IN THIS MANU-
AL AND SAFETY SIGNS ON THE MACHINE.
•DO NOT LET ANYONE OPERATE THIS MACHINE
WITHOUT PROPER INSTRUCTIONS.
•UNAUTHORIZED MODIFICATIONS MAY IMPAIR
THE FUNCTION AND/OR SAFETY OF THE MA-
CHINE.
•IF YOU DO NOT UNDERSTAND ANY PART OF
THIS MANUAL, CONTACT YOUR VALLEY DEAL-
ER.
EMPLOYEE INSTRUCTION ON SAFETY
It is very important to instruct your employees on the
safe use of this equipment at the time of their initial
assignment to operate it. DO NOT let anyone operate
this equipment without proper instructions.
Safety training should be presented annually and
the service manager should ensure employees fully
understand the safety messages and what to do in
case of emergencies.
EMERGENCY STOPPING
The machine can be stopped at any time at any tower
by turning the disconnect switch, located underneath
the tower box, to the OFF position. See Figure 12-1.
Figure 12-1 1. Disconnect Switch
!WARNING
PROPER GROUNDING
DO NOT attempt to start the machine until the elec-
trical service is properly installed and grounded by a
qualified electrician as per the electrical standards.
See Figure 12-2.
If the power supplied to the machine is not grounded
properly, severe injury or death can result should an
electrical malfunction occur.
It is your responsibility to ensure that your power
supplier and/or electrical contractor has grounded
the irrigation machine as required by the National
Electrical Code and by applicable local electrical
codes. If a machine is properly grounded and fuse
sizing is correct, there is extremely low probability of
an individual being injured by electrical shock.
1
2
3
4
5
Figure 12-2 1. Ground Rod Installation
2. Service Conductor
3. Copper Ground Rod
4. Copper Ground Wire
5. Clamp
NOTE
•All 480 VAC, 60 Hz (380 VAC, 50 Hz) power sup-
ply services MUST be a 4 conductor service.
Three 480 VAC (380 VAC) power lines and one
ground conductor which is as large as the
power carrying conductors for that service.
•Each time a towable machine is moved, the
ground wire MUST be reattached to the ground
rod and checked for electrical integrity before
restarting the machine.
1

Valley Classic Control Panel
Safety
13
Operate Safely (Continued)
!DANGER
DISCONNECT POWER WHEN SERVICING
ALWAYS disconnect electrical power before ser-
vicing or performing maintenance to the machine.
If you are going to perform maintenance on the
machine, YOU MUST shut off and lock the main
power disconnect as shown below. See Figure
13-1.
1
2
Figure 13-1 1. Main Power Disconnect
2. Lock
The blue (OSHA safety color code) tag shown below
should also be filled out and attached to the discon-
nect after locking. See Figure 13-2.
The tag should reveal the name of a person to con-
tact before restoring power to the machine.
BACK
DANGER
DO NOT
OPERATE
____________________________________
SIGNED BY:
____________________________________
DATE:
0992009
FRONT
DANGER
________________________________________________
________________________________________________
________________________________________________
________________________________________________
DO NOT REMOVE
THIS TAG
REMARKS:
SEE OTHER SIDE
____________________________________
Figure 13-2 1. Lock Out Tags
!CAUTION
QUALIFIED SERVICE PERSONNEL
If you do not understand electricity or other parts
of the machine, have qualified service personnel
perform any hazardous repairs or maintenance.
!CAUTION
GUARD ALL POWER TAKE-OFF DRIVES
This includes all belt and power line drives.
Replace any guards and shields removed for
maintenance.
!
WARNING
MARK AND GUARD ALL POWER LINES
Do NOT deep rip or chisel near the buried power
service wires.
Do NOT deep rip in a circle at the drive unit. The
deep chisel track will cause severe stresses on
the structure.
If you do deep rip your field, run the machine with
the percent timer at 100% for the first revolution.
!
WARNING
SUSPECTED SHORT CIRCUITS
DO NOT touch the machine if you suspect a short-
circuit situation. Call a qualified electrician or an
authorized Valley dealer immediately.
Circumstances which may cause you to suspect
hazardous voltage situations may include:
• Physical damage to the machine or span cable
• Recent electrical storms (lightning)
• Unusual operating characteristics of the ma-
chine
If you suspect a short circuit due to feeling a rip-
pling tingle when touching the machine, DO NOT
touch the machine again. Call a qualified electri-
cian or an authorized Valley dealer immediately.

Valley Classic Control Panel
Safety
14
Operate Safely (Continued)
!WARNING
LIGHTNING AND THE MACHINE
Stay away from the machine during an electrical
storm. An irrigation machine makes a good path to
earth. It is also probably the tallest object in the field,
which makes it a good lightning receptor!
!CAUTION
DO NOT OVERSIZE FUSES
Fuses are sized for the protection of a specific ma-
chine.
Be certain you have the proper fuse sizes in place
before initial start-up and when replacing fuses.
!CAUTION
PLUG - IN CONNECTORS
Disconnect power before connecting or disconnect-
ing any plug-in connectors.
!CAUTION
DO NOT OPERATE AT FREEZING TEMPERATURES
Spraying water has a cooling effect and water will
freeze even though the air temperature is slightly
above freezing.
Shut the machine down at 40 degrees Fahrenheit
(4.5 degrees Celsius). Do not operate machine when
temperature is below 40° F (4.5° C).
•DAMAGE TO EQUIPMENT RESULTING FROM
FREEZE-UP IS NOT COVERED UNDER WAR-
RANTY.
•IT IS IMPORTANT TO MAKE SURE ALL PIPE
DRAINS FUNCTION PROPERLY TO PREVENT
PIPELINE FREEZE-UP DURING COLD WEATH-
ER.
!CAUTION
AVOID HIGH PRESSURE WATER STREAMS
Avoid body contact with high pressure water streams.
!WARNING
AVOID CHEMICALS
Avoid exposure to sprinkler spray while chemicals
are being injected into the water. Read EPA Label
Improvement Program (PR Notice 87-1) and all in-
structions for chemical applications.
If you plan on chemigating, make certain you have
complied with state or local regulations in regard to
safety equipment, certification, operation and calibra-
tion of the injector pump. Make certain you have first
aid and fresh water available in case of an accident.
You must also be familiar with the correct cleanup
procedures in case of a spill.
•USE OF PROTECTIVE CLOTHING IS RECOM-
MENDED WHEN HANDLING CHEMICALS.
SAFETY GLASSES, GLOVES AND PROTECTIVE
OUTERWEAR SHOULD BE WORN WHEN HAN-
DLING CHEMICALS.
•CONTAMINATION OF THE WATER SUPPLY MAY
OCCUR IF EFFECTIVE SAFETY DEVICES ARE
NOT INSTALLED/USED IN CONNECTION WITH
INJECTION EQUIPMENT FOR CHEMIGATION.
!DANGER
DRIVE SHAFTS START WITHOUT WARNING
An electric motor on each tower of the center pivot
powers two drive shafts connected to wheel gear
drives. These drive shafts start and stop without
warning.
•DO NOT TOUCH ROTATING DRIVE SHALT
OR SHIELD, CLOTHING OR LIMBS MAY BE-
COME ENTANGLED, RESULTING IN SEVERE
INJURY.
•DO NOT SERVICE THE MACHINE UNTIL THE
MAIN DISCONNECT IS LOCKED IN THE OFF
POSITION.
•ALWAYS REPLACE DRIVE SHAFT SHIELDS
AFTER SERVICING,
•DRIVE SHAFT SHIELDS MUST ALWAYS BE
IN PLACE WHEN OPERATING THE MACHINE.

Valley Classic Control Panel
Safety
15
Operate Safely (Continued)
!CAUTION
CHECK WHEEL TRACKS BEFORE STARTING
Make sure all objects, livestock or persons are
clear of the machine before starting. Drive trains
are powerful and can climb over vehicles, equip-
ment, etc.
!CAUTION
KEEP CHILDREN AWAY
Pivots are NOT playground equipment.
Prevent children from playing or climbing around
on the machine. This can be extremely danger-
ous, especially if the machine is operating.
!CAUTION
CHECK MACHINE DIRECTION
DO NOT operate the machine if it moves in the
direction opposite to that which was chosen.
Forward should be clockwise and reverse coun-
ter-clockwise.
!CAUTION
KEEP WATER OFF ROADWAYS
It is against the law in most states to allow water
to spray on state and county roadways. This is a
serious hazard to passing motorists.
If end guns are used, make sure you read and un-
derstand the correct procedures for setting the on
and off positions to avoid watering the roadways.
If an end gun is watering a roadway, immediately
discontinue use and adjust the shutoff setting or
call your Valley dealer to repair the end gun shut
off mechanism.
!CAUTION
PART CIRCLE OPERATION SAFETY
If the machine reverses direction at a roadway or a
physical object such as a building, tree line, power
pole etc., then you MUST provide a backup device
to stop the machine if the reversing mechanism
were to fail. See Figure 15-1.
Contact your Valley dealer for more information
concerning physical barricades for machines un-
der these circumstances.
1
Figure 15-1 1. Physical Barricade
!CAUTION
PROPER USE OF THE SAFETY OVERRIDE
Caution MUST be taken by the operator when us-
ing the safety override function as it will by-pass
or disable all of the machine’s automatic safety
shutdown circuits.
NEVER depress and hold the START/STOP
SAFETY OVERRIDE switch in the START posi-
tion for more than 3 to 5 seconds.
If the machine is not in full view by the operator,
do not use the Safety Override function.
The operator MUST inspect the entire machine
between each safety override start attempt.
Repeated safety override start attempts can
cause severe structural damage.
Call your Valley dealer if the machine fails to start.

Valley Classic Control Panel
Safety
16
Safety Decals
These Danger, Warning, and Caution decals appear in various locations on a Valley irrigation machine. You
MUST familiarize yourself and other operator’s with these safety decals. For replacement of any decal, contact
your local Valley dealer.
OFF
ON
TEST
Classic
CAUTION
DO NOT HOLD BUTTON DEPRESSED
LONGER THAN 3 SECONDS. REPEATED
START ATTEMPTS CAN CAUSE SERIOUS
STRUCTURAL DAMAGE
CAUTION
DO NOT HOLD BUTTON DEPRESSED
LONGER THAN 3 SECONDS. REPEATED
START ATTEMPTS CAN CAUSE SERIOUS
STRUCTURAL DAMAGE 0997302
LOCATED ON
INSIDE OF
OUTER DOOR

Valley Classic Control Panel
Safety
17
Safety Decals (Continued)
R
WARNING
TIRE AND RIM FOR
IRRIGATION USE ONLY.
ADJUST PRESSURE BEFORE USE.
SEE OWNERS MANUAL
FOR RECOMMENDED PRESSURE.
30 PSI [2.1 BAR] MAXIMUM
R
WARNING
TIRE AND RIM FOR
IRRIGATION USE ONLY.
ADJUST PRESSURE BEFORE USE.
SEE OWNERS MANUAL
FOR RECOMMENDED PRESSURE.
18 PSI [1.2 BAR] MAXIMUM
R
WARNING
TIRE AND RIM FOR
IRRIGATION USE ONLY.
ADJUST PRESSURE BEFORE USE.
SEE OWNERS MANUAL
FOR RECOMMENDED PRESSURE.
23 PSI [1.6 BAR] MAXIMUM
R
WARNING
TIRE AND RIM FOR
IRRIGATION USE ONLY.
ADJUST PRESSURE BEFORE USE.
SEE OWNERS MANUAL
FOR RECOMMENDED PRESSURE.
34 PSI [2.3 BAR] MAXIMUM

Valley Classic Control Panel
Safety
18
Safety Decals (Continued)
Do not touch rotating drive shaft or shield. Clothing
or limbs may become entangled, resulting in severe
injury.
Do not service until machine is locked in the off
position.
Always replace drive shaft shield after servicing.
Drive Shaft Starts Without Warning!
DANGER
WARNING
Improper installation of this motor may
result in fire, explosion, electrical shock or
other personal injuries. Read operating
instructions
Do not place fingers or objects near
openings.
Do not use eye bolts or lifting hooks to
lift anything except the product.
Disconnect power before maintenance.
Open all circuits before removing conduit
box cover. Be sure motor is properly
grounded per local and national codes.
Donottouch rotating drive shaft or shield. Clothing
orlimbsmay become entangled, resulting in severe
injury.
Donotservice until machine is locked in the off
position.
Alwaysreplacedrive shaft shield after servicing.
DriveShaftStarts Without Warning!
DANGER
Donottouch rotating drive shaft or shield. Clothing
orlimbsmay become entangled, resulting in severe
injury.
Donotservice until machine is locked in the off
position.
Alwaysreplacedrive shaft shield after servicing.
DriveShaftStarts Without Warning!
DANGER
Donottouch rotating drive shaft or shield. Clothing
orlimbsmay become entangled, resulting in severe
injury.
Donotservice until machine is locked in the off
position.
Alwaysreplacedrive shaft shield after servicing.
DriveShaftStarts Without Warning!
DANGER
Donottouch rotating drive shaft or shield. Clothing
orlimbsmay become entangled, resulting in severe
injury.
Donotservice until machine is locked in the off
position.
Alwaysreplacedrive shaft shield after servicing.
DriveShaftStarts Without Warning!
DANGER

Valley Classic Control Panel
19
Overview
Controls and Components
The inside door of the Classic control panel is shown below in Figure 19-1.
!DANGER
•480 VOLTS – DO NOT OPEN THE INTERIOR CONTROL PANEL DOOR, ELECTRICAL SHOCK MAY
OCCUR.
•ALL NEEDED CONTROLS AND MONITORING DEVICES ARE ON THE OUTSIDE OF THE INTERIOR
CONTROL PANEL DOOR.
•SERVICE WORK DONE ON THE CONTROL PANEL IS TO BE PERFORMED BY A QUALIFIED SER-
VICE PERSON ONLY.
* Only available on control panels equipped with Auto Reverse/Auto Stop.
** Switch included with optional Auxiliary Contactor.
Overview
OFF
ON
TEST
Classic
CAUTION
DO NOT HOLD BUTTON DEPRESSED
LONGER THAN 3 SECONDS. REPEATED
START ATTEMPTS CAN CAUSE SERIOUS
STRUCTURAL DAMAGE
14
15
3
2
5
13 12 11 10 74
6
8
9
1
Figure 19-1 1. Main Disconnect Switch
2. Start / Stop / Safety Override Switch
3. Safety Return Light
4. Forward / Reverse Switch
5. Forward Light*
6. Reverse Light*
7. Wet / Dry Switch
8. Percentage Timer
9. Voltage Meter
10. Auto Reverse / Auto Stop Switch*
11. Stop-In-Slot Switch
12. Engine Run / Start Switch
13. Expansion Slot
(Optional Auxiliary On / Off Switch**)
14. Hour Meter
15. Circuit Breaker

Valley Classic Control Panel
20
Overview
Main Disconnect Switch
The main disconnect switch controls power to the
machine and has three positions, ON, OFF, and Test.
See Figure 20-1.
In the ON position, the control panel is on and power
is provided to the machine.
In the OFF position, the control panel is off and
power is disconnected from the machine. However,
incoming voltage to the control panel still exists on
the upper terminals of the main disconnect switch
inside the control panel.
The Test position is for use by service personnel only.
!
WARNING
•ALWAYS TURN THE MAIN DISCONNECT
SWITCH OFF, LOCK IT IN THE OFF POSITION
AND TAG IT WHEN DOING ANY MAINTE-
NANCE OR REPAIRS AND WHEN THE MA-
CHINE IS NOT IN USE.
Three Second Auto Restart
A three second auto restart function is built into the
circuitry of the control panel.
In the event of a momentary power loss or voltage
drop while the machine is running, the machine will
automatically restart if power is returned within three
seconds.
When the control panel also controls an irrigation
pump that is set to automatically start, the irrigation
pump must be protected with a pump restart delay.
!CAUTION
•TO REDUCE THE POSSIBILITY OF DAMAGE
TO AN AUTOMATICALLY CONTROLLED
ELECTRIC PUMP DUE TO A MOMENTARY
POWER LOSS OF 3 SECONDS OR LESS,
A PUMP RESTART DELAY IS REQUIRED IN
THE PUMP CIRCUIT BETWEEN THE PIVOT
CONTROL PANEL AND THE PUMP.
CAUTION
DANGER
High Voltage!
480 Volts can kill.
Lock Machine Power
in the “OFF” position
before opening cover.
0997326
Do not operate system when temperature
is below 40° F (4.5° C)
Read and understand the valley operator
manual before operating this equipment.
CAUTION
0997300
CAUTION
DO NOT HOLD BUTTON DEPRESSED
LONGER THAN 3 SECONDS. REPEATED
START ATTEMPTS CAN CAUSE SERIOUS
STRUCTURAL DAMAGE 0997302
OFF
ON
TEST
Classic
1
2
Figure 20-1 1. Main Disconnect Switch
2. Test
