Valore TRU20A User manual
TRU20A 18W 20000mAh
Power Bank (PD05)
Thank you for purchasing the Valore TRU20A 18W 20000mAh Power Bank (PD05).
• Dual input design to conveniently charge power bank using USB-C
or Micro USB charging cable
• Dual USB & USB-C output for simultaneous device charging
• Power Delivery (PD) technology provides fast charging for most USB-C enabled devices
Important: Please read the user manual thoroughly before using your Power Bank.
Specifications: Package Contents:
• Battery type: Lithium Polymer
• Battery capacity: 20000mAh – 74Wh
• USB 1&2 output: 5V/3A, 9V/2A, 12V/1.5A (max)
• USB-C input & output: 5V/3A, 9V/2A,
12V/1.5A (Max PD18W)
• Micro USB input: 5V/2A, 9V/2A (Max)
• Charging time: Approximately 5 hours (PD 9V/2A)
Approximately 8 hours (5V/2A)
• Recharging cycle: 300 times cycle
• Dimensions (L x W x D): 123 x 67 x 25.5mm
• Material: ABS + PC
• Operating temperature: -10°C to 40°C
• Weight: 355g
UNDERSTANDING THE PRODUCT
• TRU20A 18W 20000mAh
power bank
• USB to USB-C charging cable
• Soft pouch
①USB output ports
②Digital indicator
③Touch power button
④ Micro USB input port
⑤ Type-C PD input/output
④
①
②
③
⑤
START USING THE 2000MAH PD POWER BANK
1) Charging the power bank
Connect your power bank to the USB adaptor (2.0A) using the charging cable provided.
When the LED indicator is all lit, it indicates that the battery is fully charged.
Press the touch power button once to display battery percentage.
While charging the power bank, the last digit will blink.
Note: Fully charge the power bank for at least 14-16 hours before first use. This is to
maximise the battery performance and prolonging the life of lithium ion batteries.
Recharge your power bank once every three months when not in use or seldom used.
2) Charging of devices
Connect your power bank to your mobile device’s charging port using a 8-pin, Micro USB,
Type-C cable.
TROUBLESHOOTING
Issue 1:
Power bank is unable to charge your mobile device
Problem 1: Power bank battery is flat
Solution: Fully charge the power bank and resume charging your mobile device.
Issue 2:
Power bank drains off quickly
Problem: Running multiple applications on your mobile device
Solution: Turn off all running applications on the mobile device and leave it to charge till full.
Extra consumption of energy would be due to heat produced during the charging of your
mobile device.
Issue 3:
Unable to charge (power indicator is not flashing)
Problem 1: The voltage of the power adapter is too low.
Solution: Use 5V supply with at least 800mAh for charging.
Problem 2: Faulty cable
Solution: Check the cable to ensure that it is well connected or replace damaged cables.
TECHNICAL SUPPORT & WARRANTY
• For Warranty Registration, visit www.valore.sg.
Cautions:
Read all the instructions and warnings carefully prior to using this product.
• Do not dismantle or open the power bank
• Do not subject the power bank to mechanical shock such as crushing, bending, puncturing
or shredding. Avoid dropping or placing heavy object on the power bank.
• Do not expose the power bank to water or other liquids
• Do not expose the power bank to hear and/or fire. Avoid storage in direct sunlight.
• Do not attempt to insert foreign objects into the power bank. Do not short-circuit the power
bank by storing it haphazardly in receptacle where it may be short-circuited by other metallic
or conductive objects.
• Do not use any charger* other than that specifically provided for use with the power bank.
Battery usage by children should be supervised.
*The charger may also be known as the adaptor, and is used to charge the power bank
DISCLAIMER & TRADEMARKS
All information, trademarks, logos, graphics, and images (“Materials”) provided on this user manual are
copyrighted or trademarked and are the property of Challenger Technologies Limited. Any unauthorized use of
any material contained on the instruction manual may violate copyright laws, trademark laws, laws of privacy
and communications statutes.The trademarks, service marks and logos used and displayed in the Materials
are registered and unregistered
trademarks and service marks of Valore and others. All other registered and unregistered company
names,product names and marks mentioned herein the (“Materials”) are the property of their respective
owners and may be trademarks or registered trademarks.
Inspired by Valore Singapore
For full range of Valore products visit www.valore.sg
