Valtra T Series User manual

OPERATOR'S MANUAL
T SERIES
Versu
Ref no 39 885 21 4 ( 08/2015 )
YOUR
WORKING
MACHINE

Find manuals at https://best-manuals.com

About this manual
This operator's manual is for the Valtra T Series Versu tractors. The T Series
Versu models are T144 V, T154 V, T174e V, T194 V, T214 V and T234 V.
The manual is meant for agricultural tractors only. If the tractor is used for other
applications, it is the owner's responsibility to ensure compliance with local
regulations. In this case, always contact your dealer first.
The purpose of this manual is to enable the owner and operator to use the tractor
in a proper manner. Providing that the instructions are followed carefully, the
tractor will provide years of service in the tradition of Valtra.
WARNING: Before using the tractor, read and understand all the
instructions in this manual. They must then be strictly followed when
operating and maintaining the tractor.
IMPORTANT: When using the tractor, always follow all valid laws and regulations
even if they are not specifically pointed out in this manual.
The manual contains detailed instructions for operating, servicing and
maintaining the tractor.
Optional equipment in the manual refers to equipment that can be selected when
ordering the tractor.
Due to the continual development of the products, the content of this manual may
not always correspond to the new product. Therefore, we retain the right to make
alterations without prior notification.
Maintenance, repairs and adjustments which are not described in this manual
require special tools and exact technical data. For such work contact your dealer
who has specially trained personnel to help you.
Valtra Inc.
- 1 -
Find manuals at https://best-manuals.com

Tractor serial numbers
When ordering spare parts or service, give the model indication and serial
numbers and, in some cases, the engine, front axle, cab and transmission
numbers.
2
5
3
1
7
6
4
GUID-83FD881F-92C4-4883-87A2-FEFA9521C800
1. Cab number and Type plate EEC
• Model = model indication
• Identification number = tractor serial number
2. Power take-off identification number
3. Engine number
4. Tractor serial number
5. Transmission Identification number
6. Tractor technical details used by service/spare part department
7. Front axle number
- 2 -
