Vangaa lighting Vg-lp1818hs User manual

VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual

6in1 Waterproof Flat LED Par Can

VG-LP1818HS

CE RoHS

User Manual

Please read this user manual before using this product！

Keep it for further reference!

www.vangaa.com

VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual

INDEX

ⅠGENERAL ......................................................................... 01

ⅡSAFETY WARNING ........................................................... 01

ⅢOPERATION ATTENTION ................................................ 02

ⅣINSTALLATION INSTRUCTION ........................................ 03

ⅤOPERATION OF THE CONTROL PANNEL......................... 05

ⅥFUNCTION MENU............................................................. 06

ⅦDMX CHANNEL CHART ................................................... 07

ⅧTECHNICAL SPECIFICATION ........................................... 09

Ⅰ. GENERAL

Thank you for using our products. This product is designed for indoor use. It is suitable for

disco, stage, building etc. As the Outdoor LED Par lighting, this product can be operated as

a single unit or in multiple units for large applications. Direct input of DMX512 signal to unit

to allow it can be controlled by any DMX512 controller. Powerful internal programs and

friendly and convenient operation interface allow customers to program freely to any

different lighting project requirements for installation or shows.

The operation is very simple, user-friendly design, dimming without flicker, jitter

phenomena. Can be adapted to photography, television and other strict demanding

situations for lighting

This product complies with the following standards:

IEC60598-1:2003

IEC60598-2-17:1984+A2:1990

On receiving products, please carefully check that there has been no damage caused in

transportation and that the following parts are enclosed:

Power Cable ------- 1pc

User Manual ------- 1pc

Signal Output Cable ------- 1pc

Signal Input Cable --------- 1pc

Ⅱ. SAFETY WARNING

VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual

Every person involved with the installation, operation and maintenance of this device has to

know:

1). This product must be installed by a qualified professional;

2). This product left the place of manufacture in perfect condition. In order to maintain this

condition and for safe operation, the user must always follow the instructions and safety

warnings described in this user manual;

3). Manufacturer will not with responsibility for those operations not according to this

Instruction.

Ⅲ. OPERATION ATTENTION

Do not connect power cable of other electric products with this unit;

Do not connect DMX512 Signal cable of other electric products with this unit;

Always make sure that you are connecting to the proper voltage, and that the

line voltage you are connecting to is not higher than that stated on the decal or

rear panel of the fixture;

Always ground (earth) the fixture electrically;

During long periods of non-use, disconnect the unit’s main power;

Do not attempt to operate this unit if the power cord has been frayed or broken;

There are no user serviceable parts inside the unit. Do not open the housing or

attempt any repairs yourself;

Maximum ambient temperature (Ta) is 35°C. Do not operate fixture at

temperatures higher than this;

The surface temperature of the light can reach to 65° C, cool down at least

before you operate the light;

The minimum distance between light-output and the illuminated surface must be

more than 1 meters. Keep all combustible materials (for example fabric, wood,

paper) at least 0.5 meters away from the fixture;

Avoid looking directly into the light source (especially those who suffer from

epileptic fits);

Always mount this unit in safe and stable matter;

When suspending the fixture above ground level, verify that the structure can

hold at least 10 times the weight of all installed devices;

Verify that all external covers and rigging hardware are securely fastened and

use an approved means of secondary attachment such as a safety cable;

Block access below the work area whenever installing or removing the fixture.

Avoiding hit the Light when you are move or install the light;

If the exterior cord of the fixture is damaged, it must be replaced by manufactory,

agent or a qualified technician.

ⅣINSTALLATION INSTRUCTION

Before plug-in the power, please make sure the voltage, frequency of the light are

correspond to the power. And ensure the grounding line of the light working reliable.

You can distinguish the different power cords as below:

VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual

Color of the Power Cord

Connection

Brown

Live line

Blue

Neutral/Null line

Yellow green

Earth line

1. Signal Connection

This light provide 3 pins cannon seats, Pin1 for signal ground, Pin2 for signal-, Pin3 for

signal+.

DMX-IN DMX-OUT

The controller, light and light will be connected by 3 pins signal cables one by one.

You can connect the output of the controller with input of the first light, and connect the

output of the first light with the input of the second light in the DMX control mode, and so

on one by one. And please connect the output of the last light with the terminal seat. You

can don’t need the controller and circuit terminal seat in the master/slave controller mode.

You can use one 120Ω& 0.25W resistance to insert into and weld the pin2 & pin3 of one

male cannon plug to make the circuit terminal seat. The circuit terminal seat can avoid

DMX-512 signal reflex and interference effectively.

If the output of your controller is using 5 pins cannon seat, please use 5pins into 3pins

signal change cable.

2 Installation Method

The light can be placed on the solid plane places, then loosen the screw on both sides of the

handles to adjust the right project angle. Please pay attention the places are

non-flammable.

Install the clamp into the hole of the handle, and hang it on the truss then. You can

adjust the right project angle through the screw of the both sides of the light. It’s

important that you have to use one or more protection measures to prevent the light will

fall, such as the safety rope. You can buy the clamps and safety ropes from our

company.

ⅤOPERATION OF THE CONTROL PANEL

DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT

DMX Controller Circuit Terminal Seat

-05-

VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual VG-LP1818HS 6in1 Waterproof Flat LED Par Can User Manual

☆Basic using

MENU: Main menu change

UP: Scroll up the menu items or browse increasing parameters

DOWN: Scroll down the menu items or browse diminishing parameters

ENTER: Confirm/Save/Access submenu

Instructions: Press the MENU key will cycle out of eight different functional effects, digital

tube in which the first two digits represent the current function (see menu). After two digits

to represent the kinds of functions which Address yards. Or speed parameters. Press the UP

or DOWN button to modify its parameter values. Press ENTER to confirm.

ⅥFUNCTION MENU

ALL MENUS ACCORDING TO THE SELECTED AND THEN PRESS THE DKEY TO CONFIRM

LED Display

Function

A001

10Channels address code（001—512）

Press UP/DOWN keys to choice address code

D001

6Channels address code（001—512）

Press UP/DOWN keys to choice address code

CC 00

Colors jump(01—99)

Press UP/DOWN keys to modify the jump speed

EE 00

Colors ramp(01—99)

Press UP/DOWN keys to modify the ramp speed

FF 00

colors pulse（01—99）

Press UP/DOWN keys to modify the speed of the composite

BEBF

colors voice control change

R220

Red（000—255）
