Vankyo Performance 700 W User manual

Performance 700 W
User Manual •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3 –22
Slovenčina
23 –42
Magyar
43 –62
Deutsch
63 –83

3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
󲐜󲐝󲐞󲐟󲐠www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

4
What’s included
Projector
Remote (Batteries Not
Included)
User Manual
HD Cable
Power Cable
Product Overview
Lens
Infrared Receiver
Keystone
Corection Ring
IR Receiver
HDMI Port2
HDMI Port 1
Audio Out
USB Port 1
USB Port 2
Power Inlet
Power Switch

5
Ok (Short press) /
Focus (Long press)
Up (focus adjustment)
Right
Down (focus adjustment)
Left
Power Button
Back
Mute
Focus
Right
Down
Home page
Menu
Volume +
Input Source
Power On / Off
Focus
Up
Left
Back
Volume -

6
Quick Start
1. Projector Installation
1 Horizontal Placement
2 Ceiling Mounting
Note: Whichever installation option you select, make sure that:
1. The projector is centred directly in front of the wall/ screen, but not tilted or
positioned at a non-standard angle to the wall/screen.
2. Select the correct mode before projection via Menu > Picture Setting > Projection
mode.
Air Inlet

7
2. Power On / Off
Plug the power cord into
an outlet and press the
Power Switch
Take off the lens cover
After 8 seconds, press the
Power Button to turn on the
projector.
Press the Power Button twice tot run off the projector, then press the Power
Swtich
3. Image Adjustment
1. Rotate the keystone correction ring to correct the vertical keystone distortion until the
image is evenly rectangular.
2. Press the focus buttons on the remote to sharpen the image focus until the blurry
image becomes clear.

8
Tip: You can also press and hold the button on the projector to centre the focus
interface, then press the Up and Down buttons on it to adjust the focus.
3. Go to the Homepage > Down Button > Setting > Picture Setting > Image Scaling to
enlarge or reduce the image size.
4. Homepage Overview
The projector will enter the homepage after you will power it on and select the language
for the first time use. Press the down button to show more options as below.
Submenu for input
Source MultiMedia
HDMI 1
HDMI 2
Setting
Input Source
Mulltiscreen
Bluetooth
Connection Status
/ Bluetooth Setup
USB Disk Status
Wi-Fi Connection
Status / Wi-Fi Setup

9
Projector Connection and Input Source
Connect your device to the projector correctly, then press on the remote to access
the page below and select the right input source, or directly select the right input source
on the homepage.
1. USB Connections
Supported Photo Format:
BMP / JPG / PNG / GIF / JPEG
Supported Audio Format:
AC3 / AAC / MP2 / MP3 / PCM / FLAC / WMA
Supported Video Format:
AVI / MP4 / MKV / FLV / MOV / RMVB / 3GP / MPEG2 /
H.264 / XVID
Supported Text Format
TXT
2. Screen Mirroring
MultiScreen
MultiMedia

10
3. HDMI Connection
This option is for connecting a device with and HDMI output port.
HDMI®, the HDMI® logo, and High-Definition multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
4. Wired Speaker and Headphone Connection
This option does not require to select any input source.
Screen Mirroring
For iOS System
Screen Mirroring Wirelessly
1. Go to the Homepage > Input source, select MULTISCREEN as the input to enter the
CAST interface.
HDMI 1
HDMI 2

11
2. Select Cast Settings > Wi-Fi setting to search and connect the projector to your router’s
Wi-Fi.
Tip: You can also go to the homepage and select the icon , or go to Settings > Other
Settings > Wi-Fi Setting to connect the projector to your router’s Wi-Fi.
3. Enter the Wi-Fi settings of your iOS device and connect it to the same router’s Wi-Fi.
4. Return the screen back to the CAST interface, then select iOS Cast to enter the
following interface.
Mirror your iPhone, iPad or iPod touch:
Make sure that your iOS device is connected to the same network as your projector, or
connect iOS device with AP by projector:
1. On your iOS device, open control centre and tap Screen Mirroring
2. Looking for devices that can be mirrored on.
3. Select V700W-XXXX-(icast) from the list.

12
5. Activate Screen Mirroring / AirPlaying Mirroring in the Control Centre of your iOS
device and search for the projector.
6. Select V700W-XXXX-(icast) from the searching list. The contents on your iOS device will
be mirrored on the projection screen/wall after a successful connection.
Tip: To activate screen mirroring function on your MacBook, please follow the steps
below:
1. Click on the icon of the control centre on top of the Mac Screen.
2. Click on the Mirroring to search for the projector.
3. To connect select V700W-XXXX-(icast).
Screen mirroring via a Lightning Cable
1. Go to Homepage >. Input Source, select MULTISCREEN as the input source to centre
the CAST interface.
2. Select iOS Cable Cast to enter the following interface
Windows Cast
Miracast
iOS Cast
DLNA
iOS Cable Cast
Cast Settings

13
iOS Cable Cast:
1. Connect the lightning connector to the phone. Connect the other end to the
projector.
2. Click “Trust” on the window that pops up on the screen.
3. Enter device password.
3. Connect your iOS mobile device to the USB port 1 by using original Lightning cable.
4. Confirm, that you trust the connected device.
5. The contents on your iOS device will be mirrored to the wall/screen after a successful
connection.
For Android System
To activate this function, please make sure your Android device supports Multi-
screen/Smart View/Wireless Display. Names may vary on different Android devices.
1. Go to the Wi-Fi settings of your Android mobile device to switch on the option of Wi-Fi.
Note: Successful Wi-Fi connection is not a must, but please make sure the Wi-Fi switch
on your Android device is ON.
2. Go to Homepage > Input Source, select MULTISCREEN as the input source to enter the
Cast interface.
3. Select Miracast to enter the following interface
Windows Cast
Miracast
iOS Cast
DLNA
iOS Cable Cast
Cast Settings

14
Miracast:
1. To connect Android / Pad Device with Projector Based on Wi-Fi-Display
Technology:
1. On your Android Mobile / Pad, open the settings menu.
2. Access your display settings or screen-mirroring.
3. Select your Miracast receiver NETLINK-XXXX.
4. Wait for the connection.
4. Activate Multi-Screen / Wireless display / Smart View function on your Android device
and search for the projector.
5. Select V700W-XXXX from the searching list to connect.
6. The contents on your Android device will be mirrored to the wall / screen after a
successful connection.
For Windows 10 System
To activate this function, your windows 10 device must support the Miracast feature.
1. Turn on the Wi-Fi switch on your Windows 10 device.
Note: Successful Wi-Fi connection is not a must, but please make sure the Wi-Fi switch is
on your Windows 10 device on.
2. Go to Homepage > Input Source, select MULTISCREEN as the input source to enter the
CAST interface.
3. Select Windows Cast to enter the following interface.

15
4. Press the Windows logo + P key combination on your keyboard to enter the PROJECT
interface, then select “Connect to a wireless display” to search for the projector.
5. Select V700W-XXXX from the searching list to connect.
6. The contents on your Windows 10 device will be mirrored to the wall / screen after a
successful connection.
Notes:
1. The fluency of screen mirroring will be affected by the network environment. A
bandwidth of 100 Mbit or more is recommended when using the screen
mirroring.
2. Make sure that your mobile device is close to the projector when using wireless
connection. A distance within 3 ft is recommended.
3. Some mobile devices may not support screen mirroring due to the compatibility.
4. Due to copyright restrictions of Hulu, Netflix and other similar services, the
copyrighted contents on these streaming services CAN NOT be mirrored or cast.
5. If the projected image freezes, please reboot the projector, then go to the
Homepage, select Input Source, then Multiscreen, then Cast Settings, then
Restore Factory Default and select Confirm to do a reset on the screen mirroring
module.
PC screen only
Duplicate
Extend
Second screen only
Connect to a wireless display

16
Screen Casting
1. Connect your mobile device and the projector to the same router’s Wi-Fi.
2. Go the Homepage, then select Input Source, then select MULTISCREEN as the input
source to enter the cast interface.
3. Select DLNA to enter the following interface.
4. Launch a video player App on your mobile and select a video to play.
5. Tap to search for the projector.
6. Select V700W-XXXX-(dlna) to connect.
7. The contents on your device will be casted on the wall / screen.
Note: When you cast a video from your mobile device, the video will be only displayed
on the projected screen and you can still use your mobile device without interrupting
the video or showing any of your other content.
Bluetooth Connection
1. Use as a Bluetooth Speaker
You can connect to your mobile device with this projector via Bluetooth connection and
use it as a Bluetooth speaker.
Step 1: Press the power button to enter the interface shown below, then press right
button to change to the amplifier mode.

17
Tip: Panel off means that the projection screen is off when the projector is playing
audio, panel on means that he projection screen is on when the projector is playing
audio.
Step 2: Go to the Bluetooth setting of your mobile device to turn on the Bluetooth, then
search for V7OOW from the searching list to pair the mobile device with the projector.
Tip: Press the back button to exit this mode.
Connect to an Internal Bluetooth Speaker
Except for the wired 3,5mm audio output port connection, you also can connect a
Bluetooth speaker or a pair of Bluetooth headphones to this projector via Bluetooth
connection.
Step 1: Turn on your Bluetooth device and make it ready for a Bluetooth Connection.
Step 2: Go to the homepage and select the Bluetooth icon, or go to Setting then
Bluetooth to enter the interface shown here:
Step 3: Press the left or right buttons to turn on or off the Bluetooth of the projector.
Tip: It takes about 4 seconds to turn off the Bluetooth, so please wait patiently.
Step 4: Select find Bluetooth and press OK to start searching for available Bluetooth
devices.
Step 5: Select your Bluetooth Device and pair it with the projector.
Tip: Compared with the wired connection, Bluetooth connection and screen mirroring
technology taky more time to process digital audio data, convert said data to an audio
signal and stream signal. However, the processing time varies depending on different
Bluetooth speakers and headphones. Therefore, there may be a delay or slight lag due
to the processing time and signal interference.

18
Settings
The settings include Picture Setting, System Setting and Other Setting.
Picture Setting:
Flip the image, adjust the image size / image colour / aspect ratio / picture mode.
System Setting:
Set the language of the projector, update the software of the projector with a USB disk,
restore the projector to factory settings and set the time duration for the projector to
power off automatically.
Other Settings:
Set the time duration for a pop-up window to disappear, connect the projector to Wi-Fi
and Bluetooth.
Projection Distance and Size
* The recommended projection distance varies with different projection contents.
Please adjust the distance between the wall/screen and the projector properly as
needed.
* Ambient darkness will improve the clarity of the projected images.

19
Specifications
Display
Technology
LCD
Light Source
LED
Resolution
Native 1920 x 1080
Input Signal
576i/720P/1080i/1080P
Aspect Ration
4:3/16:9/Auto
Focus
Manual
Keystone
±15°
Installation Type
Front/Rear/Ceiling
Speaker
5 W/4 ohm x2
Power Supply
AC 100-240 V, 50/60 Hz
Unit Dimension
290*220*93 mm
(11,4*8,7*3,7inches)
Unit Net Wight
2,23 kg (4,92 lbs)
Ports
USB Port x2 / HDMI Port x2 / Audio Out x1
Troubleshooting Guide
1. The content from Hulu, Netflix, and similar services cannot be mirrored or cast.
•Due to the copyright restriction from Hulu, Netflix, and similar services, the
contents MAY NOT be mirrored or cast.
2. What should I do if I want to watch the content from Hulu, Netflix, and similar services
via the projector?
•Please prepare a Fire TV stick, Roku stick or Chromecast™(not included), then
connect it to the projector to watch the content.
3. Blurry Image
•Adjust focus ring/keystone.
•Projector and screen/wall must be in effective distance.
•4. Remote Unresponsive
•Make sure remote points at IR receiver directly.
•Do not cover IR receiver.
•Replace the old AAA batteries with new ones.
5. Upside Down Images
•Go to Homepage > Settings > Projection Setting > Projection Mode to flip the
projection image.
6. Factory Reset
•Go to Homepage > Settings > System Setting > Restore Factory Default to restore
the projector to default settings.

20
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
