ViewSonic VS15871 User manual

PJD5151/VS15871/PJD5153/
VS15872/PJD5153P/PJD5155/
VS15873/PJD5155N/PJD5250/
VS15874/PJD5250P/PJD5253/
VS14115/PJD5253P/PJD5255/
VS15875/PJD5255N/PJD5255P/
PJD5555w/VS15876/PJD5154/
PJD5254
DLP Projector
User Guide
Model No. VS15871/VS15872/VS15873/VS14115/VS15874/
VS15875/VS15876
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
ZZZYLHZVRQLFFRP LQ(QJOLVKRULQ VSHFL¿FODQJXDJHV XVLQJWKH 5HJLRQDOVHOHFWLRQ
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”

i
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the follow-
ing two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses, and can radiate radio frequency energy, and
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
yConsult the dealer or an experienced radio/TV technician for help.
Warning:<RXDUHFDXWLRQHGWKDWFKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHG
by the party responsible for compliance could void your authority to operate the
equipment.
For Canada
CAN ICES-3 (B)/NMB-3(B)
CE Conformity for European Countries
The device complies with the EMC Directive 2014/30/EU and Low Voltage
Directive 2014/35/EU.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE).
The mark indicates the requirement NOT to dispose the equipment
including any spent or discarded batteries or accumulators as unsorted
municipal waste, but use the return and collection systems available.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery
has a heavy metal content of more than 0.0005% Mercury or more than,
0.002% Cadmium, or more than 0.004% Lead.

ii
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean with a soft, dry cloth.
7. Do not block any ventilation openings. Install the unit in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
RURWKHUGHYLFHVLQFOXGLQJDPSOL¿HUVWKDWSURGXFHKHDW
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade and the third
SURQJDUHSURYLGHGIRU\RXUVDIHW\,IWKHSURYLGHGSOXJGRHVQRW¿WLQWR\RXU
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs.
Convenience receptacles and the point where they exit from the unit. Be sure
that the power outlet is located near the unit so that it is easily accessible.
 2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFL¿HGE\WKHPDQXIDFWXUHU
 8VHRQO\ZLWKWKHFDUWVWDQGWULSRGEUDFNHWRUWDEOHVSHFL¿HGE\
the manufacturer, or sold with the unit. When a cart is used, use
caution when moving the cart/unit combination to avoid injury from
tipping over.
13. Unplug this unit when unused for long periods of time.
 5HIHUDOOVHUYLFLQJWRTXDOL¿HGVHUYLFHSHUVRQQHO6HUYLFLQJLVUHTXLUHGZKHQWKH
unit has been damaged in any way, such as: if the power-supply cord or plug is
damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed
to rain or moisture, or if the unit does not operate normally or has been dropped.

iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. 0HUFXU\LQFROGFDWKRGHÀXRUHVFHQWODPSVDQGH[WHUQDOHOHFWURGHÀXRUHVFHQW
lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.
(3) Long length (＞1,500 mm): maximum 13 mg per lamp.
2. Lead in glass of cathode ray tubes.
3. /HDGLQJODVVRIÀXRUHVFHQWWXEHVQRWH[FHHGLQJE\ZHLJKW
4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.

iv
Copyright Information
Copyright © ViewSonic®Corporation, 2017.All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Mi-
crosoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trade-
marks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and
DDC are trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omis-
sions contained herein; nor for incidental or consequential damages resulting from furnishing
this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right
WRFKDQJHSURGXFWVSHFL¿FDWLRQVZLWKRXWQRWLFH,QIRUPDWLRQLQWKLVGRFXPHQWPD\FKDQJH
without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.
Product Registration
To fulfill possible future product needs, and to receive additional product information as it
becomes available, please visit your region section on ViewSonic’s website to register your
product online.
The ViewSonic CD also provides an opportunity for you to print the product registration
form. Upon completion, please mail or fax to a respective ViewSonic office. To find your
registration form, use the directory “:\CD\Registration”. Registering your product will best
prepare you for future customer service needs.
Please print this user guide and fill the information in the “For Your Records” section. For
additional information, please see the “Customer Support” section in this guide.
For Your Records
Product Name: PJD5151/VS15871/PJD5153/VS15872/PJD5153P/PJD5155/VS15873/
PJD5155N/PJD5250/VS15874/PJD5250P/PJD5253/VS14115/
PJD5253P/PJD5255/VS15875/PJD5255N/PJD5255P/PJD5555w/
VS15876/PJD5154/PJD5254
ViewSonic DLP Projector
Model Number: VS15871/VS15872/VS15873/VS14115/VS15874/VS15875/VS15876
Document Number: PJD5151/VS15871/PJD5153/VS15872/PJD5153P/PJD5155/VS15873/
PJD5155N/PJD5250/VS15874/PJD5250P/PJD5253/VS14115/
PJD5253P/PJD5255/VS15875/PJD5255N/PJD5255P/PJD5555w/
VS15876/PJD5154/PJD5254_UG_ENG Rev. 1A 11-17-16
Serial Number: ________________________________________
Purchase Date: ________________________________________
Product disposal at end of product life
The lamp in this product contains mercury which can be dangerous to you and the environ-
ment. Please use care and dispose of in accordance with local, state or
federal laws.
ViewSonic respects the environment and is committed to working and living green. Thank you
for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

1
Table of contents
Important safety
instructions .......................2
Introduction......................4
Projector features ................................. 4
Shipping contents................................. 5
Projector exterior view......................... 6
Controls and functions ......................... 7
Positioning your
projector..........................12
Choosing a location............................ 12
Projection dimensions ........................ 13
Connection ......................15
Connecting a computer or monitor .... 16
Connecting Video source devices ...... 17
Using the cable management cover
(optional accessory) ........................... 19
Operation ........................20
Starting up the projector..................... 20
Using the menus................................. 21
Utilizing the password function ......... 22
Switching input signal........................ 24
Adjusting the projected image ........... 25
Magnifying and searching for
details ................................................. 26
Selecting the aspect ratio ................... 27
Optimizing the image......................... 28
Setting the presentation timer ............ 31
Hiding the image................................ 33
Locking control keys.......................... 33
Operating in a high altitude
environment ....................................... 33
Using the CEC function..................... 34
Using the 3D functions...................... 34
Using the projector in standby
mode .................................................. 35
Adjusting the sound ........................... 35
Shutting down the projector .............. 36
Menu operation.................................. 37
Maintenance ...................46
Care of the projector .......................... 46
Using the dust filter (optional
accessory) .......................................... 47
Lamp information .............................. 48
Troubleshooting .............51
Specifications ..................52
Projector specifications...................... 52
Dimensions ........................................ 54
Ceiling mount installation ................. 54
Timing chart ...................................... 55
Copyright information...59
Appendix.........................60
IR control table .................................. 60
RS232 command table....................... 61

2
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.
Safety Instructions
1. Please read this manual before you operate your projector. Save it for future
reference.
2. Do not look straight at the projector lens during operation. The intense light beam
may damage your eyes.
3. Refer servicing to qualified service personnel.
4. Always open the lens shutter or remove the lens cap when the projector lamp is
on.
5. In some countries, the line voltage is NOT stable. This projector is designed to operate
safely within a mains voltage between 100 to 240 volts AC, but could fail if power
cuts or surges of ±10 volts occur. In areas where the mains voltage may fluctuate
or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector or uninterruptible power supply (UPS).
6. Do not block the projection lens with any objects when the projector is under
operation as this could cause the objects to become heated and deformed or even
cause a fire. To temporarily turn off the lamp, press BLANK on the projector or
remote control.
7. The lamp becomes extremely hot during operation. Allow the projector to cool for
approximately 45 minutes prior to removing the lamp assembly for replacement.
8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps
beyond the rated life could cause them to break on rare occasions.
9. Never replace the lamp assembly or any electronic components unless the projector is
unplugged.
10. Do not place this product on an unstable cart, stand, or table. The product may fall,
sustaining serious damage.
11. Do not attempt to disassemble this projector. There are dangerous high voltages inside
which may cause death if you should come into contact with live parts. The only user
serviceable part is the lamp which has its own removable cover.
Under no circumstances should you ever undo or remove any other covers. Refer
servicing only to suitably qualified professional service personnel.
12. Do not place this projector in any of the following environments.
- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls
and free flow of air around the projector.
- Locations where temperatures may become excessively high, such as the inside of a
car with all windows rolled up.
- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical
components, shortening the projector's life span and darkening the picture.
- Locations near fire alarms
- Locations with an ambient temperature above 40°C / 104°F
- Locations where the altitudes are higher than 3000 m (10000 feet).

3
13. Do not block the ventilation holes. If the ventilation holes are seriously obstructed,
overheating inside the projector may result in a fire.
- Do not place this projector on a blanket, bedding or any other soft surface.
- Do not cover this projector with a cloth or any other item.
- Do not place inflammables near the projector.
14. Always place the projector on a level, horizontal surface during operation.
- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of
more than 15 degrees front to back. Using the projector when it is not fully horizontal
may cause a malfunction of, or damage to, the lamp.
15. Do not stand the projector on end vertically. Doing so may cause the projector to fall
over, causing injury or resulting in damage to the projector.
16. Do not step on the projector or place any objects upon it. Besides probable physical
damage to the projector, doing so may result in accidents and possible injury.
17. Do not place liquids near or on the projector. Liquids spilled into the projector may
cause it to fail. If the projector does become wet, disconnect it from the power
supply's wall socket and call your local service center to have the projector serviced.
18. This product is capable of displaying inverted pictures for ceiling mount installation.
Use only qualified ceiling mount kit for mounting the projector and ensure it is
securely installed.
19. When the projector is under operation, you may sense some heated air and odor from
its ventilation grill. It is a normal phenomenon and not a product defect.
20. Do not use the Security bar for transporting or installation. It should be used with a
commercially available theft prevention cable.
Safety instructions for ceiling mounting of the
projector
We want you to have a pleasant experience using your projector, so we need to bring this
safety matter to your attention to prevent damage to person and property.
If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and that you ensure it is securely and safely
installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use of the
wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your projector.
We recommend that you also purchase a separate security cable and attach it securely to
both the anti-theft lock slot on the projector and the base of the ceiling mount bracket. This
will perform the secondary role of restraining the projector should its attachment to the
mounting bracket become loose.

4
Introduction
Projector features
The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.
The projector offers the following features.
• Dynamic mode adjusting the power consumption of the lamp according to the
brightness of the image being projected
• Power saving function decreasing the power consumption of the lamp by up to 70%
when no input signal can be detected for a set period of time.
• Presentation timer for better control of time during presentations
• Supports 3D display
• Supports Blu-ray 3D display (for models with HDMI input)
•ColorManagement allowing color adjustments to your liking
• Less than 0.5W power consumption when power saving mode is turned on
• Screen Color correction allowing projection on surfaces of several predefined colors
• Quick auto search speeding up the signal detecting process
• Color modes providing choices for different projection purposes
• Selectable quick power off function
• One-key auto-adjustment to display the best picture quality
• Digital keystone correction to correct distorted images
• Adjustable color management control for data/video display
• Ability to display 1.07 billion colors
• Multi-language On-Screen Display (OSD) menus
• Switchable normal and economic modes to reduce the power consumption
• Component HDTV compatibility (YPbPr)
• HDMI CEC (Consumer Electronics Control) function allows synchronized power ON/
OFF operation between the projector and a CEC-compatible DVD player device
connected to the HDMI input of the projector
The apparent brightness of the projected image will vary depending on the ambient lighting
conditions, selected input signal contrast/brightness settings, and is directly proportional to
projection distance.
The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.

5
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those
illustrated.
Optional accessories
1. Replacement lamp (RLC-092 for PJD5151/PJD5153/PJD5155/PJD5154/PJD5250/
PJD5253/PJD5255/PJD5254. RLC-093 for PJD5555w)
2. Soft carry case
3. VGA-Component adapter
4. Dust filter
5. Cable management cover
Projector Power Cord VGA Cable
Multi-language User
Manual CD Quick Start Guide Remote Control & Batteries

6
Projector exterior view
1. External control panel
(See "Projector" on page 7 for
details.)
2. Lamp cover
3. Vent (heated air exhaust)
4. Front IR remote sensor
5. Adjuster foot
6. Focus and Zoom rings
7. Projection lens
8. Audio signal output socket
9. Audio signal input socket
10. Video input socket
11. S-Video input socket
12. HDMI port
13. RGB (PC)/Component video
(YPbPr/YCbCr) signal input
socket-2
14. RGB (PC)/Component video
(YPbPr/YCbCr) signal input
socket-1
15. RGB signal output socket
16. Mini USB port
17. RS-232 control port
18. AC power cord inlet
19. Security bar for anti-theft lock slot
Warning
• THIS APPARATUS MUST BE EARTHED.
• When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring,
or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should
occur during operation of the unit, operate the disconnect device to switch the power supply
off, or disconnect the power plug.
1
2
3
4
5
6
7
Front/upper side
S-VIDEO
VIDEO
COMPUTER IN 2 COMPUTER IN 1 MONITOR OUT
MINI
USB RS-232
AUDIO
IN
OUT
COMPUTER IN 2 COMPUTER IN 1
MINI
USB RS-232
19
18
PJD5154/
PJD5254
PJD5153/
PJD5253
PJD5155/
PJD5255/
PJD5555w
PJD5151/
PJD5250
14 16 17 128 9
13 14 17 16 15 10 118 9
13 14 16 17 12 15 10 118 9
13 14 17 16
Rear/lower side

7
Controls and functions
Projector
1. Focus ring
Adjusts the focus of the projected image.
2. Zoom ring
Adjusts the size of the projected image.
3. Menu
Turns on the On-Screen Display (OSD)
menu.
Exit
Goes back to previous OSD menu, exits
and saves menu settings.
4. Blank/ Left
Hides the screen picture.
5. Power
Toggles the projector between standby
mode and Power ON.
6. Source
Displays the source selection bar.
(Help)
Displays the HELP menu by a long press
for 3 seconds.
7. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
8. / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
Up/ Down (Arrow keys)
9. (My Button)
Allows user to define a short cut key on
this button, and the function item is
selected in OSD menu.
10. (Power indicator light)
Lights up or flashes when the projector is
under operation.
11. (Temperature indicator light)
Lights up red if the projector's
temperature becomes too high.
12. (Lamp indicator light)
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
13. (Panel Key Lock)
Activates or disables panel key lock by a
long press for 3 seconds.
Right
When the On-Screen Display (OSD)
menu is activated, the #4, #8 and #13
keys are used as directional arrows to
select the desired menu items and to make
adjustments.
14. Color Mode
Selects an available picture setup mode.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8

8
Remote control
To use the remote mouse control keys
(Page Up, Page Down, , and ), see
"Using the remote mouse control" on
page 10 for details.
1. Power
Toggles the projector between standby
mode and Power ON.
2. Source selection keys
•COMP1/COMP2
Selects D-Sub / Comp. 1 or D-Sub /
Comp. 2 source for display.
•HDMI
Selects HDMI source for display.
3. Auto Sync
Automatically determines the best
picture timings for the displayed
image.
4. / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
5. Left/ Right/ Up/ Down
Selects the desired menu items and
makes adjustments.
6. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
7. Menu
Turns on the On-Screen Display
(OSD) menu.
8. (Left mouse button)
Performs the same function as the left
mouse button when the mouse mode is
activated.
Only available when a PC input signal
is selected.
9. (Right mouse button)
Performs the same function as the
right mouse button when the mouse
mode is activated.
Only available when a PC input signal
is selected.
1
2
7
8
3
5
4
16
17
19
22
23
15
18
20
21
26
24
27
25
6
9
13
10
14
11
12
4
COMP1 COMP2 HDMI
Source
Enter
Menu 3D Exit
PgUp
Mouse
Pattern Blank
PgDn
Eco
Mode
Color
Mode
Auto
Sync

9
Remote control code
The projector can be assigned to 8 different remote control codes, 1 to 8. When several
adjacent projectors are in operation at the same time, switching the remote control codes
can prevent interference from other remote controls. Set the remote control code for the
projector first before changing that for the remote control.
To switch the code for the projector, select from among 1 to 8 in the SYSTEM SETTING:
ADVANCED > Remote Control Code menu.
To switch the code for the remote control, press ID set and the
number button corresponding to the remote control code set in
the projector OSD together for 5 seconds or more. The initial
code is set to 1. When the code is switched to 8, the remote
control can control every projector.
If different codes are set on the projector and remote control,
there will be no response from the remote control. When that
happens, switch the code for the remote control again.
10. Mouse
Switches between the normal and mouse
modes.
PgUp, PgDn, , : active after pressing
Mouse. An icon appears on the screen to
indicate the activation of the mouse mode.
Only available when a PC input signal is
selected.
11. (Panel Key Lock)
Activates panel key lock.
12. (Presentation Timer)
Displays the presentation timer settings
menu.
13. (Volume Up)
Increases the volume level.
14. Eco Mode
Selects a lamp mode.
15. LED indicator
16. (My Button)
Allows user to define a short cut key on the
remote control, and the function item is
selected in OSD menu.
17. Source
Displays the source selection bar.
18. 3D
Displays the 3D settings menu.
19. Exit
Goes back to previous OSD menu, exits
and saves menu settings.
20. PgUp (Page Up)/PgDn (Page Down)
Operates your display software program
(on a connected PC) which responds to
page up/down commands (like Microsoft
PowerPoint) when the mouse mode is
activated.
Only available when a PC input signal is
selected.
21. Pattern
Displays embedded test pattern.
22. Blank
Hides the screen picture.
23. (Help)
Displays the HELP menu.
24. (Mute)
Toggles the projector audio between on
and off.
25. (Zoom)
Displays the zoom bar that magnifies or
reduces the projected picture size.
26. Color Mode
Selects an available picture setup mode.
27. (Volume Down)
Decreases the volume level.
COMP1 COMP2 HDMI
Source
Enter
Menu 3D Exit
PgUp
Mouse
Pattern Blank
PgDn
Eco
Mode
Color
Mode
Auto
Sync
E
c
o
M
od
e
C
o
l
o
r
M
od
e

10
Using the remote mouse control
The capability of operating your computer with the remote control gives you more
flexibility when delivering presentations.
1. Connect the projector to your PC or notebook with a USB cable prior to using the
remote control in place of your computer’s mouse. See "Connecting a computer" on
page 16 for details.
2. Set the input signal to D-Sub / Comp. 1 or D-Sub / Comp. 2.
3. Press Mouse on the remote control to switch from the normal mode to the mouse
mode. An icon appears on the screen to indicate the activation of the mouse mode.
4. Perform the desired mouse controls on your remote control.
• To move the cursor on the screen, press / / / .
• To left-click, press .
• To right-click, press .
• To operate your display software program (on a connected PC) which responds to
page up/down commands (like Microsoft PowerPoint), press PgUp/PgDn.
• To return to the normal mode, press Mouse again or other keys except for the
mouse related multi-function keys.
Remote control effective range
The Infra-Red (IR) remote control is located on the front
of the projector. The remote control must be held at an
angle within 30 degrees perpendicular to the projector's
IR remote control sensor to function correctly. The
distance between the remote control and the sensor should
not exceed 8 meters (~ 26 feet).
Make sure that there are no obstacles between the remote
control and the IR sensor on the projector that might
obstruct the infra-red beam.
Approx.30°

11
Replacing the remote control batteries
1. To open the battery cover, turn the remote control over to view its back, press on the
finger grip on the cover and pull it up in the direction of the arrow as illustrated.
2. Remove any existing batteries (if necessary) and install two AAA batteries observing
the battery polarities as indicated in the base of the battery compartment. Positive (+)
goes to positive and negative (-) goes to negative.
3. Refit the cover by aligning it with the base and pushing it back down into position.
Stop when it clicks into place.
WARNING
• Avoid leaving the remote control and batteries in an excessive heat or humid environment
like the kitchen, bathroom, sauna, sunroom or in a closed car.
• Replace only with the same or equivalent type recommended by the battery manufacturer.
• Dispose of the used batteries according to the manufacturer's instructions and local
environment regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are drained or if you will not be using the remote control for an extended
period of time, remove the batteries to avoid damage to the remote control from possible
battery leakage.

12
Positioning your projector
Choosing a location
Your room layout or personal preference will dictate which installation location you select.
Take into consideration the size and position of your screen, the location of a suitable power
outlet, as well as the location and distance between the projector and the rest of your
equipment.
Your projector is designed to be installed in one of the following 4 possible installation
locations:
1. Front Table
Select this location with the projector placed near
the floor in front of the screen. This is the most
common way to position the projector for quick
setup and portability.
2. Front Ceiling
Select this location with the projector suspended
upside-down from the ceiling in front of the
screen.
Purchase the projector ceiling mount kit from your
dealer to mount your projector on the ceiling.
Set Front Ceiling in the SYSTEM SETTING:
BASIC > Projector Position menu after you turn
the projector on.
3. Rear Ceiling
Select this location with the projector suspended
upside-down from the ceiling behind the screen.
Note that a special rear projection screen and the
projector ceiling mounting kit are required for this
installation location.
Set Rear Ceiling in the SYSTEM SETTING:
BASIC > Projector Position menu after you turn
the projector on.
4. Rear Table
Select this location with the projector placed near
the floor behind the screen.
Note that a special rear projection screen is
required.
Set Rear Table in the SYSTEM SETTING:
BASIC > Projector Position menu after you turn
the projector on.

13
Projection dimensions
The "screen" mentioned below refers to the projection screen usually consisting of a screen
surface and a support structure.
PJD5151/PJD5153/PJD5155/PJD5154/PJD5250/
PJD5253/PJD5255/PJD5254
(a) Screen
Size
[inch (cm)]
4:3 image on a 4:3 Screen 4:3 image on a 16:10 Screen
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
50 (127) 2.0 (78) 2.2 (86) 76 (30) 7.6 (3.0) 1.8 (69) 1.9 (76) 67 (26) 6.7 (2.6)
60 (152) 2.4 (94) 2.6 (103) 91 (36) 9.1 (3.6) 2.1 (83) 2.3 (91) 81 (32) 8.1 (3.2)
70 (178) 2.8 (110) 3.1 (120) 107 (42) 10.7 (4.2) 2.5 (97) 2.7 (106) 94 (37) 9.4 (3.7)
80 (203) 3.2 (125) 3.5 (138) 122 (48) 12.2 (4.8) 2.8 (111) 3.1 (122) 108 (42) 10.8 (4.2)
90 (229) 3.6 (141) 3.9 (155) 137 (54) 13.7 (5.4) 3.2 (124) 3.5 (137) 121 (48) 12.1 (4.8)
100 (254) 4.0 (156) 4.4 (172) 152 (60) 15.2 (6.0) 3.5 (138) 3.9 (152) 135 (53) 13.5 (5.3)
120 (305) 4.8 (188) 5.2 (207) 183 (72) 18.3 (7.2) 4.2 (166) 4.6 (182) 162 (64) 16.2 (6.4)
150 (381) 6.0 (235) 6.6 (258) 229 (90) 22.9 (9.0) 5.3 (207) 5.8 (228) 202 (79) 20.2 (7.9)
180 (457) 7.2 (282) 7.9 (310) 274 (108) 27.4 (10.8) 6.3 (249) 7.0 (274) 242 (95) 24.2 (9.5)
(a)
(d)
(b)
(e)
(f)
(c)
(a)
(d)
(c)
(b)
(e)
(f)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 4:3 image on a 4:3 screen
• 4:3 image on a 16:10 screen
(a)
(d)
(c)
(b)
(e)
(f)

14
PJD5555w
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should physically
test the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.
(a) Screen
Size
[inch (cm)]
16:10 image on a 16:10 Screen 16:10 image on a 4:3 Screen
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection
distance [m (inch)]
(c) Image
height
[cm
(inch)]
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
60 (152) 2.0 (79) 2.2 (87) 81 (32) 0.0 (0.0) 1.9 (74) 2.1 (82) 76 (30) 0.0 (0.0)
70 (178) 2.3 (92) 2.6 (101) 94 (37) 0.0 (0.0) 2.2 (87) 2.4 (95) 89 (35) 0.0 (0.0)
80 (203) 2.7 (105) 2.9 (115) 108 (42) 0.0 (0.0) 2.5 (99) 2.8 (109) 102 (40) 0.0 (0.0)
90 (229) 3.0 (118) 3.3 (130) 121 (48) 0.0 (0.0) 2.8 (111) 3.1 (123) 114 (45) 0.0 (0.0)
100 (254) 3.3 (131) 3.7 (144) 135 (53) 0.0 (0.0) 3.1 (124) 3.5 (136) 127 (50) 0.0 (0.0)
120 (305) 4.0 (157) 4.4 (173) 162 (64) 0.0 (0.0) 3.8 (149) 4.2 (163) 152 (60) 0.0 (0.0)
150 (381) 5.0 (197) 5.5 (217) 202 (79) 0.0 (0.0) 4.7 (186) 5.2 (204) 191 (75) 0.0 (0.0)
180 (457) 6.0 (236) 6.6 (260) 242 (95) 0.0 (0.0) 5.7 (223) 6.2 (245) 229 (90) 0.0 (0.0)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 16:10 image on a 16:10 screen
• 16:10 image on a 4:3 screen
(a)
(d)
(c)
(b)
(e)
(f)

15
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 5). They are commercially available from electronics stores.
The connection illustrations below are for reference only. The rear connecting jacks available
on the projector vary with each projector model.
For detailed connection methods, see pages 16-18.
S-VIDEO
VIDEO
COMPUTER IN 2 COMPUTER IN 1 MONITOR OUT
MINI
USB RS-232
AUDIO
IN
OUT
COMPUTER IN 2 COMPUTER IN 1
MINI
USB RS-232
7
PJD5155/
PJD5255/
PJD5555w
PJD5154/
PJD5254
PJD5153/
PJD5253
PJD5151/
PJD5250
577 48 16 3 1 2
Notebook or
desktop computer
Speakers
or
A/V device
Monitor
(DVI)
(VGA)
or
