Vannus FC-AA02/A User manual

INSTRUCTION MANUAL
CEILING FAN
MODEL
FC-AA02/A
FC-AA04/A
FC-AA06/A
FC-AA07/A
ALT. NAME
V3-3B/52 LED
V3-3B/46 LED
V3-3B/40 LED
V3-3B/28 LED
Version: 2023.V1

Safety Precaution
Table of Contents
1. Safety Precaution ................................................................................. 1 - 2
2. Parts & Accessories .............................................................................. 3
3. Installation Instruction ........................................................................... 4 - 7
4. Power Supply Connection .................................................................... 8
5. Circuit Diagram ..................................................................................... 9
6. Transmitter Learning Process ...............................................................10
7. Transmitter Function & Assembly ......................................................... 11
8. Maintenance ........................................................................................ 12
9. Technical Specifications ....................................................................... 12 -13
10. Customer Service Centre ................................................................... 13
Item Page No.
Warning
Installation and maintenance work shall only be performed by qualified persons, familiar
with local code and regulation, and experienced with this type of appliance.
All field wiring must be installed in accordance with the national wiring regulation.
Ensure that the rated voltage of the unit corresponds to that of the name plate before
commencing wiring work according to the wiring diagram.
The appliance must be permanently connected to the electricity supply through a double
pole switch having a contact separation of at least 3mm in all poles.
The unit must be GROUNDED to prevent possible hazard due to insulation failure.
The earth wire is approximately 60mm longer than safety wire. This is to ensure at the
event whereby the suspension system fails, the (L) and (N) wire will break leaving the
fan remain earthed to prevent electrocution.
Tighten the blade firmly using a screw driver.
Blades that are detached from the unit during operation will cause serious injuries and
property damages.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliances.
Confirm that the power supply has been switched OFF before installing or servicing the
unit. Ensure that the blade is fully static before doing any maintenance work.

Safety Precaution
23
3
Parts & Accessories
STOP using the ceiling fan when any abnormality or failure occurs.
If unusual oscillating movement is observed, immediately stop using the ceiling fan and
contact the manufacturer, its service agent or suitably qualified persons.
CAUTION
Please take note of the following important points when installing.
The fixing means for attachment to the ceiling such as hooks or other devices shall be
fixed with a sufficient strength to withstand 4 times the weight of the ceiling fan.
The mounting of the suspension system shall be performed by the manufacturer, its
service agent or suitably qualified persons.
The fan is to be installed so that the blades are more than 2.5m above the floor.
Safety cord should not be longer than the earthing conductor.
Should failure of the suspension system occur, the supporting of the fan must not rely on
the earthing conductor. The earthing terminal in the fan assembly should be such that
should any part of the suspension system fall off, the body of the fan assembly shall
effectively earthed.
Ensure that the unit’s panel is closed after service or installation.
Unsecured panels will cause the unit to operate noisily.
Sharp edges and coil surfaces are potential locations which may cause injury
hazards. Avoid from being in contact with these places.
Before turning off the power supply set the remote controller’s ON/OFF switch to
the “OFF” position.
If this is not done, the unit’s fans will start turning automatically when power resumes,
posing a hazard to service personnel or the user.
Do not operate any heating apparatus too close to the ceiling fan unit or use in room
where mineral oil, oil vapour or oil steam exist, this may cause plastic part to melt or
deform as a result of excessive heat or chemical reaction.
Avoid the ceiling fan unit from exposing to direct sunlight, this may cause degradation of
plastic material as a result of excessive heat and UV radiation.
Ensure the colour of wires of the outdoor unit and the terminal markings are same to the
indoors respectively.
Don’t use joined and twisted wires for incoming power supply.
Do not place any object in the path of the blades. Avoid raising objects or your arms near
the ceiling fan.
The fan suspension system and blade screw tightening shall be examined yearly.
Replacement of parts of the safety suspension system device shall be performed by the
manufacturer, its service agent or suitably qualified persons.
Torque value for screw/bolts for securing primary suspension system for motor is 2Nm.
AAA
AAA
Battery x 2
Wall
Screw x 2
Fan Blade x 3
Rubber Pulley Assembly Lamp Shade
Receiver
LED Light Kit
Blade Screw x 13
Motor Assembly with Downrod,
Canopy and Coupling Cover
LED Light Screw x 3
Transmitter &
Holder x 1

4
Installation Instruction
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
DIMMER SWITCH OR REGULATOR.
5
Installation Instruction
a. Remove safety wire screw and washer from Downrod
b. Detach Canopy vand Coupling Cover from Downrod.
Install the Fan Blade on Motor Assembly with screw.
Downrod
Canopy
Coupling
Cover
Safety Wire
Screw
Upper Blade Bottom Blade
a. Reinstall safety wire screw and washer, Canopy and Coupling Cover back to Downrod
b. Fix the Rubber Pulley Assembly to the Downrod with Bolt, Washer, Nut and tighten them
firmly, then insert the Clevis Pin.
c. Remove the Bolt, Clevis Pin, Nut, Washer and Rubber Pulley from the Downrod.
d. Place the Rubber Pulley onto the ceiling hook.
e. Fix back the Bolt, Clevis Pin, Nut and Washer.
Coupling
Cover
Canopy
Note:
Make sure the coupling
cover is fully insert at
motor bracket
a
Rubber Pulley
Assembly
Bolt Downrod
Washer, Nut &
Celvis Pin
b
c
Rubber
Pulley
Bolt Clevis
Pin
Nut
Safety Wire
Washer
d
e
Safety Wire
Rubber
Pulley
Rubber
Pulley
a b

6
Installation Instruction
7
Installation Instruction
Step 4
White
Yellow
Grey
House Supply Wires
Brown (L)
Blue (N) Green/Yellow (E)
Green/Yellow(E)
Brown (L)
Blue (N)
Green/Yellow(E)
Orange
Blue Orange
Blue
White
Yellow
Grey
a. Remove the Safety Wire screw and washer from the Downrod.
b. Install the Safety Cable.
a. Connect the Connectors from Fan and Receiver.
b. Connect the wires from the receiver to House’s Supply Wire.
c. Connect Earth Wire to House Supply Earth Terminal.
d. Tighten a screw on Canopy and leaving a minimum gap of 5mm between ceiling and
Canopy
a
a. Connect the LED Light Connector.
b. Install LED Light Kit onto Motor Assembly by screw.
Step 5
b
Safety
Wire
Step 7
Lamp
Shade
LED
Light Kit
a
b
Install Lamp Shade by twisting in.
Step 6
LED
Light Kit
LED Light
Screw

8
Power Supply Connection
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
DIMMER SWITCH OR REGULATOR.
Circuit Diagram
9
Installation Instruction
Regulator Dimmer Switch
Double Pole
Switch
Single Pole
Switch
Power
Supply
DC
Motor
ANT
W
N LED+
Blue
Grey
Yellow
White
Neutral (Blue)
Live (Brown)
Earth (Green/Yellow)
Earth (Green/Yellow)
Brown
Green/Yellow
MAIN PCB
LED-
L
E
V
U
LED
22W
Orange
Orange
Blue
Blue
Power Supply
220-240V~ 50Hz
Step 7
Below shows a complete installation diagram.
Light Kit
Screw

10
The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more
Fans using 1 transmitter, the below steps are required.
DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS
Step 1
A) Insert the 2 pcs of batteries (provided) into transmitter.
B) Turn on the power supply (wall switch) to the fan.
C) Within 30 sec., press and hold the “OFF” button for 3 sec. Once the receiver has
Detected the frequency, transmitter will “Beep Beep” twice. Programming process is
completed and fan is ready to use.
If the fan is not responding to the transmitter, repeat Step 1b.
Press and hold
for 3 sec
Transmitter Learning Process
11
Transmitter Function
The transmitter & receiver is incorporated with last memory function. This function
stores your last setting in memory and the next time you turn on the fan, fan will
operate as the last setting.
Function of Forward & Reverse
Fan must be turned on and rotating.
Press Forward/Reverse button and fan will slow down and then change direction
(approx. 15 sec). When the fan is slowing down to change direction, the Fan Speed
function is disabled until direction has been changed.
Forward
Fan rotates anti-clockwise blowing
the air downwards creating the
wind chill effect. Suitable for hot
weather condition
Reverse
Fan rotates clockwise drawing the air
towards the ceiling circulating the warm
air dow.nwards. This function works best
at low speed. Suitable for air-conditioned
condition.
Mount the remote control
holder on the wall with the
screws provided.
1 - 8
- Light on/off & select LED colour
- Turn off fan
- Fan speed lowest to highest
- Natural wind, creating gentle sea-
breeze effect
- Forward/Reverse, turn anti-clockwise
or clockwise rotation.
- Timer on - fan turns on after 1hr
- Timer on - fan turns on after 3hr
- Timer on - fan turns on after 6hr

12 13
More than 1m
More than 2.5m (8’ 2”)
FC-AA02/A (V3-3B/52 LED) : 1320mm (4’ 4”)
FC-AA04/A (V3-3B/46 LED) : 1165mm (3’ 10”)
FC-AA06/A (V3-3B/40 LED) : 1015mm (3’ 4”)
FC-AA07/A (V3-3B/28 LED) : 712mm (2’ 4”)
255mm (10”)
410mm (1’ 4”)
Maintenance
Due to the fan’s natural movement, connections may get loose after period of usage. To
ensure a proper and safety usage, it is highly recommended to inspect and tighten all
connections every 6 months.
Cleaning
Cleaning your fan periodically will prolong its new appearance. Basic cleaning procedures
are as follows :
1. Use only water and mild soap. Do not use solvents, corrosive or acidic solution.
2. Damp the cloth lightly. Use only soft or lint-free cloth to clean the fan. Rough fabric will
scratch the surface.
3. Do not bent the blades while cleaning. At the event where blades are bent or damage,
order new set of blades from service center or dealer shop.
4. There is no need to oil the fan.
Technical Specifications
Technical Specifications
Customer Service Centre
If you need any technical assistance or faulty report, please contact our customer
service centre at :
Alpha Home Appliances Sdn. Bhd. (390258-H)
Head Office : 6, Jalan Sungai Kayu Ara 32/37, Berjaya Park, Section 32, 40460 Shah
Alam, Selangor.
Tel : [phone] Fax : [phone]
Website : www.alphamalaysia.com Email : [email protected]
Johor : 71, Jalan Molek 3/10, Taman Molek, 81100 Johor Bahru.
Tel : [phone] / 4933 Fax : [phone]
Melaka : 19, 19-1 & 19-2, Jalan KSB 11, Taman Kota Syahbandar, 75200 Melaka.
Tel : [phone] / 6293 Fax : [phone]
Perak : 11, Laluan Tasek Timur 5, Pusat Perdagangan Tasek Indra, 31400 Ipoh,
Perak.
Tel : [phone] Fax : [phone]
Penang : 28, Jalan Icon City, Icon City, 14000 Bukit Mentajam, Penang.
Tel : [phone] / 2066 / 2566 Fax : [phone]
Pahang : A131, TK1, Jalan Wang Ah Jang, Taman Liza, 25100 Kuantan, Pahang.
Tel : [phone] Fax : [phone]
Model
Alt. Name
No. of Blades
Fan Width
Motor RPM
Voltage
Motor Wattage
LED Wattage
Nett Weight
FC-AA02/A
V3-3B/52 LED
1320mm (52”)
80 - 233
4W - 45W
5.1kg
FC-AA04/A
V3-3B/46 LED
1165mm (46”)
90- 265
4W - 45W
4.9kg
FC-AA06/A
V3-3B/40 LED
1015mm (40”)
82 - 230
4W - 45W
4.6kg
FC-AA07/A
V3-3B/28 LED
712mm (28”)
100 - 307
4W - 30W
4.4kg
3
22W
220-240V~ 50Hz
