Vantrue Element 3 User manual

English/Deutsch/Français/Polski Element 3
User Manual
122mmX130mm
70g
Voice-Controlled 3 Channel Dash Cam
更新内容：
英文33页有文字修改

Hey, find us here:
www.vantrue.net/contact facebook.com/vantrue.live

CONTENTS
VERZEICHNIS
CONTENU
SPIS TREŚCI
5
48
Installation
Installations
Installation
Instalacja
3.
93
139
43
88
134
178
Warranty & Support
Kundendienst
Garantie & Support
Gwarancja & wsparcie
6.
41
86
132
176
Specifications
Produktspezifikationen
Spécification
Dane techniczne
5.
Camera Overview
E3-Teile
Vue d'ensemble de la caméra
Budowa kamery
2
45
90
136
2.
17
61
106
152
Basic Operation
Funktion
Opérationdebase
Podstawowe funkcje
4.
1
44
89
135
What's in the box?
Was ist in der box?
Qu'y a-t-il dans la boîte？
Co znajdziemy w pudełku？
1.

- 1 -
1. What’s in the Box?
H.
dust-free
cloth*1
Warning
Stickers *2 L.
CPL Filter
A. VANTRUE® E3
Dash Cam
E.
Type-C Rear
Camera Cable
(20ft)
I.
User Manual
M. N.
B. RC05 Rear
Camera
G.
Crowbar*1 K.
D.
GPS Adhesive
Mount
C.
VANTRUE®Wireless
Remote Controller
F. Type-C USB Data
Cable (3ft, for
data transfer only)
Car Charger with
Built-in Type-C
Cable (11.4 ft)
3M Adhesive
Stickers
J.
Electrostatic
stickers *2
Optional Accessories
Element 2
User Manual
Voice-Controlled Dual Dash Cam
EN EN EN EN

- 2 -
2. Camera Overview
14
15
16
ENEN
34
21
5 6 7
8
131211
10
9
VTJE1210130
NO. DescriptionName
1
Front Facing Camera for video recording road
Events;
2 Front Camera
Delivers sound during video playback;
3
Speaker
Connect to Type C cable or car charger for
external power supply;
Power Port
Type-C USB port for charging or transferring data;
Video stream port for streaming rear camera's
recording;
4 Type-C USB /
Rear Cam Port
2.45 inch LCD Display Screen;5 Screen
Camera for in-car video recording;7 Interior Camera
Steady green light means the camera is connecting;
6 REC

- 3 -
EN EN EN EN
Records clear audio with the video footage;
8
Microphone
Serial Number for warranty registration.
13
Serial Number
9During video recording, long press to turn off the
screen and short press to stop recording; In standby
state, short press to confirm the action; In playback
mode, short press to stop/Start the video Recording;
12
Button
During video recording, short press will lock the
current file and capture a picture, long press for
power off;In standby status, short press will capture
a picture, long press will shut down;In WiFi state,
short press to exit WiFi, long press to power off;
14 Button
During video recording and standby, short press to
switch the video window; In menu setting and file
browsing, short press to display the previous option,
long press to scroll up to display options; in
playback mode, short press to fast forward; In WiFi
mode, press any key to exit WiFi;
10
Button During video recording and standby, long press to
quickly enter parking mode, and short press to turn
on/off the microphone; In menu settings, long press
to scroll through menu options, and short press to
display the next menu option; During file browsing,
long press to scroll to display file, short press to
display the next file; In playback mode, short press
to pop up the delete file menu; In WiFi mode, press
any key to exit WiFi;
11
Button
In the recording mode, long press to turn on/off
WiFi; In the standby state, short press to enter/exit
the setup menu, and long press to turn on/off WiFi;
In the WiFi mode, press any key to exit WiFi;
Button

- 4 -
15 MicroSD Card
Slot
16 Reset Button Press to force reset the device;
ENEN
ENEN
Provides expandable storage (up to 512GB in
FAT32, U3 or higher).
LED Indicator
DescriptionLED
Steady green light Instandbystatus
Camera is recording
LED Status
REC
Blinking green light

14:39:07 02-10-2023
00:00:37 MP/H
35
1440P+1080P+1080P 30FPS
- 5 -
Screen Overview
3. Installation
3.1 Installing a Memory Card (Recommended: Vantrue U3 high-speed
microSD card).
Please insert a memory card (memory card capacity: 32GB-512GB, card
speed: U3/Class10/A2). The dashcam has certain requirements on the
card speed of the memory card. For reliable operation, we recommend
using a VANTRUE SD card(sold separately).
EN EN EN EN
Loop recording OFF
Loop recording for 1 min
Loop recording for 3 min
Loop recording for 5 min
MIC is ON MIC is OFF
NO Memory card
inserted
G-Sensor ON
G-Sensor OF
Recorded driving
speed (KMH or MPH)
Video Resolution
GPS Signal Connecting
GPS Signal Locked
Voice Assistant is ON
Voice Assistant is OFF
MP/H
35
Memory card inserted
Icons for Indicating Buttons
Remote control is connected
Blinking means the remote
control is not connected
IR LED OFF
IR LED ON
IR LED AUTO ON/OFF
Recording Time
(Current Clip
Current Time (24H)
Snapshot
Emergency
File Locked
Current Date (MM/DD/YY)
Collision Detection ON
1080P Low Bitrates
Recording ON
720P Low Bitrates
Recording ON
Motion Detection ON
Low Framerate Parking
Mode
Time Lapse On
Wi-Fi OFF
2.4G Wi-Fi ON
5G Wi-Fi ON
2.4G Wi-Fi Connected
5G Wi-Fi Connected

If the camera is recording, please press the button to pause the
recording, then press the button to enter the menu, then enter
“System Setup,” select the format, and confirm to format the memory
card until it prompts "Formatted successfully''.
After inserting the memory card, if the screen prompts "Card error,
please format" (please note that the recorder does not record at this
time), please directly press the button to enter the menu and start
the formatting process.
- 6 -
Memory Card Installation: There is an icon indicating the insertion direction
of the memory card. Please push the memory card into the card slot
according to the direction indicated by this icon, until a "click" sound is
heard in the card slot, indicating that the memory card is inserted properly.
The microSD card should be formatted once a month to maximize the
lifetime of the memory card.
Pleasedonottakethecardoutwhenthecameraisrecordingincase
theimportantvideofilesmissing.
REMINDER:
1.
2.
ENEN
Before using this card, please follow the steps below to format it properly:

- 7 -
3.
4.
3.2 Installing the camera onto your windshield
Align the mount with the dash cam mount interface then push in until
the mount is installed.
1.
EN EN EN EN
Before installation, please power on the dash cam and check whether
the shooting angle of the front and interior lens are appropriate through
the recording view.
2.
Please do not use bad cards or low-speed cards on the dash cam, as it
is easy to stop or lose the recording due to the failure of a memory card.
Before formatting the memory card, please check the event video
folder in the SD card to see if there are any videos that need to be
saved separately, so as not to delete important videos by mistake.

- 8 -
ENEN
Thoroughly clean the windshield with water or alcohol, then wipe it with
a dry cloth. Stick the electrostatic sticker behind the rear-view mirror,
which is the recommended position to prevent blocking your view while
driving.
Note: The electrostatic stickers with two-sided protective film. Please
remove the protective film from No. 1, paste the electrostatic sticker
on the windshield, and then remove the protective film from No.2.
3.
Remove the 3M tape from the mount, then fix the mount and camera
on the electrostatics stickers.
4.
Electrostatic sticker
Please peel off this mask
AFTER application completed
Please peel off this
mask BEFORE application

- 9 -
EN EN EN EN
Take out the rear camera cable, connect the main camera and the
rear camera, and take out the car charger to connect it. After the
camera is powered on, choose a suitable location and install it.
5.
Rear Camera Installation: Please select the installation position on the
rear windshield. We recommend that you select a position close to the
center of the rear windshield, and avoid the defogging line on the rear
windshield, so as not to affect the video effect. Remove the protection
film of the sticky pad and rear camera lens. Fix the rear camera in the
selected position and adjust the angle, then use the rear camera cable
to connect the rear camera with the main front camera.
6.
(Correct wiring method) (Wrong wiring method)

- 10 -
ENEN
Carefully store the car charger cable in the direction shown in the
picture.
7.
The angle of the window glass of each model is different, please adjust
the recording angle of the main camera and rear camera up and
down according to actual needs.
Note: Only the front camera can be rotated and adjusted, the cabin
camera is fixed.
8.

- 11 -
3.3 APP Download
Please scan the QR code for the relevant version below to download the
app and install it. Search for the "Vantrue" app in App Store or Google
Play Store to find the app and then download and install it on your
phone.
Note: After this camera is successfully connected to your mobile phone
through WiFi, it can perform real-time video preview, change camera
settings, download files without internet connection, and play back
videos on the mobile phone. However, the GPS track playback and video
sharing functions will depend on the internet or telecom value-added
services (requires you to turn off/disconnect the camera WiFi).
EN EN EN EN

- 12 -
3.4 WiFi Connection
ENEN
There are 3 ways to turn on the Wi-Fi of the camera.
VTJE1210130
Long press the menu button
for 2 seconds.
Go to dash cam System Settings
then turn on the Wi-Fi.
3. Use the "Turn on Wi-Fi" voice command to turn it on.
1. 2.
Turn on WiFi
System Setup 2/14
Language
Wi-Fi
Voice Control
Voice Content
OK

- 13 -
EN EN EN EN
After Turning on the WiFi function of the camera, enter the WiFi settings of
the mobile phone, then find the WiFi name, such as E3_VANTRUE_XXXX,
and enter the WiFi default password: 12345678 to connect to WiFi.

- 14 -
After the WiFi connection is successful, click "+" when opening the app
for the first time, add the camera model, and then the app will automati-
cally connect to the camera and display the current real-time recording
situation of the camera.
3.5 APP Connection
Note:
If you do not connect to WiFi before opening the app, the app will
prompt you by saying "Please connect to WiFi first", and will automati-
cally jump to the WiFi settings. Please complete the steps to connect to
WiFi first.
If the WiFi is already connected, but the app jumps to the application
permissions of the APP after selecting the model, please check whether
the wireless network permission of the app is turned on.
1.
2.
ENEN

- 15 -
3.
4.
5.
6.
Camera Setting
Full-Screen icon
Front Rear and
Cabin Display
Switch
Snapshot
Album
Stop Recording icon
Microphone on/
off setting
Mileage Statistics
Lens Correction Line
3.6 App Operation
EN EN EN EN
The initial password for this device is only used for initial login. In order
to prevent potential security risks, please be sure to change the initial
password after the initial login to prevent others from logging into your
device without authorization or other adverse consequences.
If you forget the WiFi password, you can restore the default setting of
the device, and the Wi-Fi password of the device will also be restored
to the default password(12345678).
If the connected WiFi name does not match your dash cam model,
the app will prompt you: "Please select the correct model" and
automatically jump back to the model selection interface.
If there is no connection with the mobile phone after the WiFi is turned
on, the camera will automatically turn off the WiFi and return to the
recording interface after 10 minutes.

- 16 -
After entering the App’s real-time preview, you can perform the following
operations:
Video preview: After the app is successfully connected to the camera,
enter the real-time preview page, click the full-screen icon or place the
phone horizontally, and the real-time screen will automatically switch to
the full-screen preview mode. Click the window switch icon to switch the
front rear and cabin video windows, but only multi-channel dash cams
can use this feature.
Video playback: The video and photo files recorded on the SD card can
be viewed in the app, and the video can be played back after clicking
the file.
Video download: You can select the video or picture you want to
download in the SD card browsing interface or in the video playback
area. After downloading the video, if you play it in the local file of the
app interface, you can view the GPS track of the video.
Video snapshot: You can capture the current screen in the real-time
preview interface of the app.
Mileage Statistics: Users can click to download mileage information as
required, and the mileage information will be saved in the APP as a
picture or PDF file.
Lens correction line: Correct the lens balance via accurate crosshair so
that the video screen will not be skewed.
ENEN
