VAPEX TECH Smart Efficharger User manual

4~10 Cells Battery Pack Super-Fast Smart Charger’s Owner’s Manual
Model NO.: VP24W
Smart Efficharger
Smart & Super-Fast Charger for
4~10 Cells Battery Packs
This Charger is designed to charge Nickel-Metal
Hydride or Nickel Cadmium 4~10 Cells battery
packs with Standard Tamiya Male Connector.
This is a Super-Fast & Smart Charger, which can
distinguish 4~10 cells pack by MPU inside
automatically and cut-off the charging accordingly.
It is easy to use. Manual-adjustment is not
needed.
By using different adaptors, this charger can be
used to charge battery packs with Futaba Female
connector, JR Female connector, Tamiya Small
Male connector, Micro Female connector etc.
SAVE THESE INSTRUCTIONS
Input Rated Voltage & Line Frequency:
100~240VAC 50Hz~60Hz
Rated Voltage: DC18.0V+-5%
Rated Current: DC1350mA
Rated Cells Pack: 4~10 Cells
No Load Voltage: DC20V Max
Trickle Current: 60mA Max
Short Circuit & Reverse Polarity
Protection included
Features:
Recharges 4~10 pieces cells battery packs
Ni-MH/Ni-Cd batteries with Standard Tamiya
Male connector.
Microprocessor-control System (For protection
and safety).
Batteries life is well protected by –dV detection
and timer protection.
4LEDs display for Rapid charge/trickle charge
Red LEDs Flash- rapid charge
1 LED Steady: 30%
2 LEDs Steady: 50%
3 LEDs Steady: 70%
4 LEDs Steady: 90%
Green LED- Fully Charged & trickle charge
Flash Red and Green LED- Short or Reverse
polarity or Wrong Battery
Safety features :
-dV cut-off function
OPERATION INSTRUCTIONS : -
1- Connecting 1 pack of 4~10 cells pack with
Tamiya Male connector to the Female
connector of the charger.
2- Make correct contact of the Female and
Male connectors.
3- Plug charger into mains socket.
4- The status 4 LEDs will flash first to check if
the charger good to use, then the 4 LEDs
will be flash red from left to right when the
batteries are receiving charge. The LED
steady Red light shows the charging status
of the battery
5- After charge is completed, the status LED
will change green to indicate that the
charge is completed and batteries are
ready for use. Once the status LED is
Green, the charge switches to trickle mode
to keep the batteries at full.
6- Unplug the charger and remove the batteries
from the charger when not in use.
Mechanical Specification:
1. Plastic Case: 60×42×20mm
2. Output DC Cord: 24AGW×1500mm×2C
Environmental
Operating temperature: 0~35℃
Short Circuit Protection: 20mA
Weight: W.T. 453g for EU adaptor
W.T. 460g for UK adaptor
Package: white box
Dimension: 82mm(L)×60mm(W)×100mm(H)
.
Charging table
Battery Pack
Output
Current
Input
4.8V~6.0V
3A
18V/1.35A
7.2V~9.6V
2A
10.8V~12.0V
1.5A
Charging time for 4.8V~6.0V NiMH Packs
Size
Vapex Battery
Type
Charging Time
950mAh
In950AAA
30mins
1600mAh
VP1600AFP,
VP1600AF
50mins
2000mAh
VP2000AFP,
VP2000AAFP,
VP2000SC
1.1hrs
2200mAh
VP2200SCS
1.3hrs
2500mAh
VP2500SC,
in2500AA
1.5hrs
2600mAh
VP2600AA
1.6hrs
3300mAh
VP3300SC
2hrs
3700mAh
VP3700SC
2.2hrs
4300mAh
VP4300SC
2.4hrs
4600mAh
VP4600SC
2.5hrs
5000mAh
VP5000SC
2.8hrs
5300mAh
VP5300SC
3hrs
Charging time for 7.2V~9.6V NiMH Packs
Size
Vapex Battery
Type
Charging Time
950mAh
In950AAA
35mins
1600mAh
VP1600AFP,
VP1600AF
1hr
2000mAh
VP2000AFP,
VP2000AAFP,
VP2000SC
1.3hrs
2200mAh
VP2200SCS
1.6hrs
2500mAh
VP2500SC,
1.8hrs

4~10 Cells Battery Pack Super-Fast Smart Charger’s Owner’s Manual
in2500AA
2600mAh
VP2600AA
2hrs
3300mAh
VP3300SC
2.4hrs
3700mAh
VP3700SC
2.5hrs
4300mAh
VP4300SC
2.8hrs
4600mAh
VP4600SC
3hrs
5000mAh
VP5000SC
3.3hrs
5300mAh
VP5300SC
3.6hrs
*Charge time will vary depending upon the brand,
capacity and condition of batteries being
charged.
Charging time for 10.8V~12.0V NiMH Packs
Size
Vapex Battery
Type
Charging Time
950mAh
In950AAA
40mins
1600mAh
VP1600AFP,
VP1600AF
1.1hrs
2000mAh
VP2000AFP,
VP2000AAFP,
VP2000SC
1.5hrs
2200mAh
VP2200SCS
1.8hrs
2500mAh
VP2500SC,
in2500AA
2hrs
2600mAh
VP2600AA
2.2hrs
3300mAh
VP3300SC
2.8hrs
3700mAh
VP3700SC
3hrs
4300mAh
VP4300SC
3.2hrs
4600mAh
VP4600SC
3.5hrs
5000mAh
VP5000SC
3.8hrs
5300mAh
VP5300SC
4hrs
*Charge time will vary depending upon the brand,
capacity and condition of batteries being
charged.
Important Safety Instructions
1. Before charging, read instruction.
2. This charger is intended for use with
Nickel-Cadmium and Nickel-metal-hydride
rechargeable batteries only. Attempting to
charge other types of batteries may cause
personal injury and damage to the charger.
3. Recharge only one type of battery (Ni-Cd
or Ni-MH) at each time.
4. Do not expose charger to rain or moisture.
For indoor use only.
5. Remove from mains when not in use.
6. Never use an extension cord or any
attachment not recommended by
manufacturer, otherwise this may result
in a risk of fire, electric shock or injury
to persons.
7. Do not operate the charger if it has been
subjected to shock or damage. Take it to a
qualified serviceman for repair.
8. Do not disassemble the charger. Incorrect
reassembly may result in a risk of electric
shock or fire.
9. Unplug the charger from outlet before
attempting any maintenance of cleaning.
